TOV Porter Sectional User manual

Porter Sectional
ASSEMBLY INSTRUCTIONS
Page 1 of 5

BEFORE BEGINNING ASSEMBLY: CARE & MAINTENANCE
Read instructions cover to cover
Have two adults on hand for
assembly
DO NOT assemble on flooring or
carpet. Assemble on a clean
non-marring surface (ex: packing
foam)
Save all packaging until assembly is
completed
Do not put hot items directly on
furniture surface.
Do not clean furniture with harsh
cleansers or polish.
Dust and pick up spills using a clean,
non-colored, lint-free cloth.
Stains may be removed with mild
soap solution and a damp cloth.
Do not place furniture under direct
sunlight.
Do not place furniture near heating or
cooling vents.
Do not write on furniture without a
padded barrier to protect the surface.
Do not place furniture outside, for
indoor use only.
Page 2 of 5
PORTER SECTIONAL CONTENT
LEFT / RIGHT ARM SOFA
LEFT / RIGHT CHAISE
RIGHT
ARM
CHAISE
LEFT
ARM
CHAISE
COMPONENTS & HARDWARE
A. Left or Right Sofa 1
B. Leg 4
C. Allen Head Bolt 16
D. Lock Washer 16
E. Flat Washer 16
F. Allen Wrench 16
COMPONENTS & HARDWARE
A. Left or Right Chaise 1
B. Leg 4
C. Allen Head Bolt 16
D. Lock Washer 16
E. Flat Washer 16
F. Allen Wrench 16

STEP 1:
On a plain and non-abrasive surface, gently lay the sofa or the chaise (either Left
or Right) on its back. Unzip the pocket underneath the sofa and remove the leg
and hardware inside.
“Need a part? Call TOV at 516-888-3355 or email [email protected]” Page 3 of 5
RIGHT
ARM
CHAISE
LEFT ARM SOFA
66"
37"
86.5"
LEFT ARM
CHAISE
RIGHT ARM SOFA
66"
37"
86.5"
LEFT AND RIGHT-ARM CONFIGURATION
LEFT ARM SOFA AND RIGHT ARM CHAISE
SECTIONAL
RIGHT ARM SOFA AND LEFT ARM CHAISE
SECTIONAL
ASSEMBLY STEPS

STEP 2:
On all corners underneath the sofa(A) or chaise(A) are holes with pre-installed
threaded nuts which correspond to the holes on the mounting plate of the legs
(B). Align and set each leg (B) in the cavity and engage Allen Head bolt (C)
together with Lock Washer (D), Flat Washer (F). Tighten them with Allen Wrench
(F) Provided.
ASSEMBLY STEPS
DE
F
B
C
Page 4 of 5
STEP 3:
The Porter chaise has a pre-installed Connector post which corresponds to the
pre-installed fork on the sofa. To connect both chaise and sofa, turned the
pre-installed fork outward or pointing to the chaise.

“Need a part? Call TOV at 516-888-3355 or email [email protected]” Page 5 of 5
STEP 4:
The easiest way to install the sofa and chaise is to align the backs as the locking
mechanism is installed properly. With the help of another person push both ends
while constantly aligning the back.
STEP 5:
Push both ends until the last ratcheting sounds.
ASSEMBLY STEPS
