Towelrads HANWORTH PLUS User manual

TOWELRADS
HANWORTH PLUS
DURING INSTALLATION
• Place the radiators on the consoles by means of the suspension
elements behind them.
• After placing the radiator on the console, pay attention to
whether it is level or not. If there is a slope in the radiator, some
slices will not heat up, preventing the radiator from working at
full efficiency.
• Special valve connection possibility with bottom inlet and outlet
in aluminum radiators is possible if the directions are notified
with the order. In this connection, the direction plug is mounted
during manufacture. In this connection, it should be noted that
the hot water inlet is made from the outside and the cold water
outlet is from the inside. Otherwise, the radiator will not work
efficiently.
• Another type of connection where the direction plug will be
used is the bottom opposite end connection. Radiator slice
intervals where the direction plug will be placed specified on the
connection forms page.
AFTER INSTALLATION
• Do not use dirty water in your system (even if it is for testing the
heating system). The use of dirty water, water with a hardness
higher than 25 Fr, waters outside the range of PH value (7-8)
(acidic or basic character) will exclude the product from the
warranty.
• After the installation is completed, make sure that all construction
and installation residues in the installation are removed by filling
the installation with water for the first time and emptying all the
water after 5 minutes of water cycle.
• Heat the radiators by filling the installation with water, and bleed
the radiators by means of the air vent on the radiator corner.
Repeat the deaeration process for the next few heatings. If it
sounds like water is flowing from the radiator, there is air in it. In
this case, repeat the bleeding process.
• Do not empty the system water unless necessary.
• Do not add any chemical substances (inhibitors, antifreeze,
pH regulators, lime and bacteria inhibitors, chemicals that are
claimed to increase radiator efficiency, etc.) that the company
has not approved in writing, to the installation system. Otherwise,
the radiator will be out of warranty.
• Take the necessary measures to prevent the installation water
from freezing. Freezing of water damages the radiator and
the damage caused by freezing of water is not covered by the
warranty.
• Never clean your radiator with hard and streaky cleaning agents.
Do not use any bleach or chemicals, clean using a damp and soft
cloth. Chemical and abrasive substances damage the paint and
anodized layer on the radiator. Such damages are not covered by
the warranty.
MOUNTING ACCESSORIES
Up to 1200 mm height, 3 consoles, 9 screws, 9 dowels, 3 adjustment screws
Up to 1500 mm height, 4 consoles, 9 screws, 9 dowels, 4 adjustment screws
Up to 1800 mm height, 5 consoles, 9 screws, 9 dowels, 5 adjustment screws
INSTRUCTION MANUAL

CONSIDERATIONS BEFORE INSTALLING ALUMINUM RADIATOR
• In aluminum radiator heating systems, it should be installed and
used by experts in aluminum radiators, in accordance with the
standards in which the installation principles are determined and
the principles specified in the installation manual.
• Before installing the radiators , make the necessary checks and
cleanings to ensure that there are no construction residues or
chemicals in the entire heating system.Residues or chemicals
in the heating device or installation may clog and damage the
water channels. Damages caused by these materials are not
covered by the warranty.
• If a thermostatic valve is used in the radiator, and if your
circulation pump is not by-passed in itself, it is necessary to use
the radiator with a standart valve.
• It is necessary to use a pressure reducer where the water inlet
pressure is higher than 10 bar. If not used, the radiator is out of
warranty.
• The system must be grounded against electrical leakages.
• Check that the hot water inlet and outlet connections to the
radiator are correct. Connection types that do not comply with
the installation rules prevent your radiator from working.
• Radiators are easily mounted on the wall with the help of console.
Radiator valve connections are G1/2’’. Radiator valves to be used
must be chrome or nickel plated. All parts required for assembly
are included in the package.
• Drill the necessary holes according to the axis dimensions to
mount the consoles to the wall.
• After mounting the plastic dowels on the wall, fix the consoles to
the wall with screws.
INSTRUCTION MANUAL
1) Console
2) Bracket
3) Plastic Cover
4) Screw
5) Dowel
