Toyota 2005 Yaris User manual

Yaris
AUDIO
RHD installation instructions
Model year: 2005
Vehicle code: **P90R-****KW
Part number: • CD-Changer: 08601-00911
• Subwoofer: 08691-00834
Manual ref. no: AIM 000 481-01
All manuals and user guides at all-guides.com
all-guides.com

Yaris (RHD) - 2
02-07
Yaris AUDIO
Rev. Nr.
Rev. No
No. version
Datum
Date
Date
Seite
Page
Page
Abbildung
Aktualisierung
Update
Mise à jour
Neu
New
Nouveau
Gelöschte Schritte
Deleted steps
Etapes supprimées
102-07 5Application
Chart
Application
Chart Europe
102-07 6Application
Chart
Application
Chart Japan X
102-07 9Step 7 - 8 X
102-07 12 Step 8 - 9 X
102-07 13 Step 10 - 11 X
102-07 14 Step 12 - 13 X
Revision Record
All manuals and user guides at all-guides.com

Yaris (RHD) - 302-07
Yaris AUDIO
PRECAUTIONS
PLEASE READ THOROUGHLY THESE PRECAUTIONS BEFORE THE INSTALLATION .
• Do not pinch the rear wiring or
harness in the tightened part.
• Be sure to disconnect the nega-
tive (-) lead from the battery ter-
minals.
• When passing the wires through
the dashboard or other panels,
use a grommet to ensure water-
proofing.
• Protect the wiring with tape
when it is passed through a hole.
• When disconnecting the con-
nectors, be sure to grip the con-
nector body. Do not tug on the
wiring.
• Do not forcibly pull any car
wiring harness. Rough tugging
may result in opened connec-
tions, or a broken wire or har-
ness.
• Confirm that lamps, horn, wiper
and other car accessories operate
normally.
• Protect your car with fender
covers, seat and so on.
• Use the correct tool when
tightening bolts or nuts.
• Before drilling a hole, check
that the rear of the mount-
ing wall is clear.
• Be sure to firmly tight-
en connectors and ter-
minals.
• Before connecting the
power wiring to the battery,
check the wiring con-
nections, harness, etc. to see
that they are properly
secured.
• Check body and trim near area of installation to be
certain no dirt or scratches resulted from the installa-
tion.
waterproof - O.K. !!
Taping
Grommet
Insert completely
Stop it !
All manuals and user guides at all-guides.com

Yaris (RHD) - 4
02-07
Yaris AUDIO
Revision Record ................................................................................................................................2
Precautions ........................................................................................................................................ 3
Application Chart Europe production ............................................................................................ 5
Application Chart Japan production ................................................................................................ 6
AUDIO Installation Instructions
• Vehicle Disassembly .................................................................................................................. 7
• CD-Changer Installation ..........................................................................................................10
• Subwoofer Installation ..............................................................................................................15
TABLE OF CONTENTS
All manuals and user guides at all-guides.com

Yaris (RHD) - 502-07
Yaris AUDIO
APPLICATION CHART EUROPE PRODUCTION
All manuals and user guides at all-guides.com

Yaris (RHD) - 6
02-07
Yaris AUDIO
APPLICATION CHART JAPAN PRODUCTION
All manuals and user guides at all-guides.com
all-guides.com

Yaris (RHD) - 702-07
Yaris AUDIO
VEHICLE DISASSEMBLY
2. Remove the center cluster panel (L)
and (R) .
: Clip (6x)
: Hook (8x)
5
5
Fig. 1
1. Put protective tape on the shaded areas.
Be sure to remove the parts carefully
so you do not damage the panels.
CAUTION
3.
a) Put protective tape on the shaded areas.
b) Remove the meter cluster panel .
: Clip (5x)
: Hook (4x)
8
Fig. 3
8
Be sure to remove the parts carefully
so you do not damage the panels.
CAUTION
Fig. 2
5
All manuals and user guides at all-guides.com

Yaris (RHD) - 8
02-07
Yaris AUDIO
5. Remove the scuff plate and the cowl
side trim on the driver’s side.
: Clip (1x) (Cowl side trim)
: Hook (1x) (Cowl side trim)
: Clip (2x) (Scuff plate)
: Hook (2x) (Scuff plate)
13
10
6. Remove the driver’s seat .
: Bolt (4x)
108
15
Fig. 6
15 108
Fasten the bolts with specified torque
(37 Nm) when reassembling.
CAUTION
4. Remove the audio unit .
: Clip (4x)
: Screw (4x)
100
9
Fig. 4
100
9
FOR EUROPE PRODUCTION
Fig. 5
10
13
All manuals and user guides at all-guides.com

Yaris (RHD) - 902-07
Yaris AUDIO
7. Remove the scuff plate and the cowl
side trim on the passenger’s side.
: Clip (1x) (Cowl side trim)
: Hook (1x) (Cowl side trim)
: Clip (2x) (Scuff plate)
: Hook (2x) (Scuff plate)
13
10
8. Remove the passenger’s seat .
: Bolt (4x)
108
15
Fig. 8
15 108
Fasten the bolts with specified torque
(37 Nm) when reassembling.
CAUTION
FOR JAPAN PRODUCTION
Fig. 7
10
13
All manuals and user guides at all-guides.com

Yaris (RHD) - 10
02-07
Yaris AUDIO
1. Cut one tape into ten pieces and
another tape into six as shown in the
picture.
•: Component part of CD changer kit
15
15
Fig. 1
2.
a) Route the changer wire by using the
tape pieces.
b) Connect the changer wire harness to
the audio unit by using the AVC-LAN
conversion wire 08695-000370.
9
28
15
28
Fig. 2
15
28
CD-CHANGER INSTALLATION
9
6x
10x
08695-00370 FOR EUROPE PRODUCTION
3. Unscrew and pull forward to remove the
fuel lid opener .
: Screw (1x)
102
14
Fig. 8
14
102
All manuals and user guides at all-guides.com

Yaris (RHD) - 11 02-07
Yaris AUDIO
09-05
4. Cut the floor carpet.
50mm
20mm
50mm
170mm
20mm
Fig. 4
5. Route the changer wire . Bundle
excess wire and tape with the large
tape as shown by going through the
hole of the cross member near the door.
15
28
6. Replace the carpet and pull through the
changer wire . Install the bracket
to the floor.
: Bolt (2x)
•: Component part of audio
mounting kit PZ425-B0220-60
103
103
12
28
Fig. 5
28
Excess wire
15
Hole
Fig. 6
103
12
28
All manuals and user guides at all-guides.com
all-guides.com

Yaris (RHD) - 12
02-07
Yaris AUDIO
7.
a) Install the changer unit to the brack-
et .
b) Connect the changer wire to the
changer unit .
: Screw (4x)
•: Component part of CD changer kit
104
104
18
28
12
18
FOR JAPAN PRODUCTION
8.
a) Turn the floor carpet with felt.
b) Route and tape the subwoofer wire
with tapes .
15
28
9. Cut the carpet with felt as shown in the
illustration.
270mm
160mm
60mm
80mm
80
Fig. 9
Fig. 7
104
12
18
28
Fig. 8
15
28
Excess wire
Floor carpet
All manuals and user guides at all-guides.com

Yaris (RHD) - 13 02-07
Yaris AUDIO
Fig. 10
17
13
1
17
13
15
1
17
10. Attach the spacers and the tapes
to the base bracket .
: Screw (M5x10) (4x)
: Spacer with nut (4x)
: Tape (2x)
1
17
15
13
1
17
11. Attach the base bracket to the floor
and fold back the cut parts of the carpet
.
14
3
Fig. 11
14
3
All manuals and user guides at all-guides.com

Yaris (RHD) - 14
02-07
Yaris AUDIO
Re-assembly.
Replace all removed parts and panels. Be sure all panel clips and connectors are proper-
ly engaged.
12. Install the side brackets to the chang-
er unit .
: Side bracket (2x)
: Flat head screw (M5x8) (4x)
103
6
7
6
Fig. 12
7
Hole position on the
left side (●)
Hole position on the
right side (●)
6
6
103
Screw
13. Install the changer unit .
a) Connect the changer wire to the
changer unit .
b) Then install the changer unit to the
base bracket .
: Screw (M5x10) (2x)
104
3
7
7
2
7
Fig. 13
3
2
104
7
14
3
All manuals and user guides at all-guides.com

Yaris (RHD) - 15 02-07
Yaris AUDIO
3.
a) Put protective tape on the shaded areas.
b) Remove the meter cluster panel .
: Clip (5x)
: Hook (4x)
8
Fig. 3
8
Be sure to remove the parts carefully
so you do not damage the panels.
CAUTION
SUBWOOFER INSTALLATION
2. Remove the center cluster panel (L)
and (R)
: Clip (6x)
: Hook (8x)
5
5
1. Put protective tape on the shaded areas.
Be sure to remove the parts carefully
so you do not damage the panels.
CAUTION
Fig. 1
Fig. 2
5
All manuals and user guides at all-guides.com

Yaris (RHD) - 16
02-07
Yaris AUDIO
4. Remove the audio unit .
: Clip (4x)
: Screw (4x)
100
9
Fig. 4
100
9
5. Remove the scuff plate and the cowl
side trim on the passenger’s side.
: Clip (1x) (Cowl side trim)
: Hook (1x) (Cowl side trim)
: Clip (2x) (Scuff plate)
: Hook (2x) (Scuff plate)
13
10
6. Remove the passenger’s seat .
: Bolt (4x)
108
15
Fig. 6
15 108
Fasten the bolts with specified torque
(37 Nm) when reassembling.
CAUTION
Fig. 5
10
13
All manuals and user guides at all-guides.com
all-guides.com

Yaris (RHD) - 17 02-07
Yaris AUDIO
7. Fit brackets to the subwoofer .
: Screw with washer (4x)
•: Component part of audio mounting
kit PZ425-B0221-60
•: Component part of subwoofer kit
27
26
105
242726
Fig. 7
8. Cut the carpet with felt as shown in the
illustration.
130mm
130mm
100mm
100
60mm
60mm
20mm
60mm
Fig. 8
105 26
24
27
9. Cut one tape in ten pieces.
•: Component part of subwoofer kit
15
15
Fig. 9
15
10x
All manuals and user guides at all-guides.com

Yaris (RHD) - 18
02-07
Yaris AUDIO
10.
a) Turn the floor carpet with felt.
b) Route and tape the subwoofer wire
with tapes .
15
28
11. Connect the subwoofer wire harness
to the 10P audio connector of the vehi-
cle wire harness and to the audio unit
.
9
28
12. Before installing the subwoofer
adjust the HIGH CUT and GAIN to the
correct position.
24
HIGH CUT
HIGH CUT GAIN
GAIN
Fig. 12
24
Fig. 10
15
28
Excess wire
Floor carpet
Fig. 11
10P Audio connector
9
28
All manuals and user guides at all-guides.com

Yaris (RHD) - 19 02-07
Yaris AUDIO
13.
a) Replace the floor carpet with felt.
b) Fit the base bracket to the floor using
adhesive tape .
•: Component part of audio mounting
kit PZ425-B0221-60
25
25
26
Fig. 13
25
28 24
26
14. Mount the subwoofer as shown in
the illustration and connect the sub-
woofer wire to the subwoofer .
2428
24
32mm
36mm
100mm
55mm
Fig. 14
24
28
Re-assembly.
Replace all removed parts and panels. Be sure all panel clips and connectors are proper-
ly engaged.
Rattling noises might be heard when
there’s something in the tray under the
seat.
NOTE
