Toyota FJ CRUISER BROCHURE 2011 User manual

FJ Cruiser shown in Silver Fresco Metallic with available Upgrade Package and accessory roof rack.
The off-road driving shown in this brochure was done in areas open to 4WD vehicles. Always be responsible when operating a vehicle
in the wilderness. Remember to cross streams only at designated road crossings and comply with all signs and barriers.
Level ground never made a skillful climber. Sometimes it takes a tremendous challenge to
discover how good you can be. For FJ Cruiser, that challenge came one summer day back in
1951 when the first Toyota Land Cruiser, then called the BJ, started up the side of Mt. Fuji.
Scrambling ultimately to a spot designated Checkpoint No.6, it accomplished a feat no
other vehicle in history had managed to achieve. The triumph not only demonstrated the
extraordinary capabilities of Toyota’s new SUV, but also marked the birth of a legend.
Today, more than 50 years and four million Land Cruisers later, the FJ Cruiser proudly
carries the torch of Toyota’s storied o-road legacy.

Our engineering standards were written in stone. After five decades of o-road experience,
we know a few things about making vehicles that are capable and durable. And FJ Cruiser
is the latest beneficiary of this proud heritage. Its V6 engine features Dual Independent
Variable Valve Timing with intelligence (VVT-i). Cranking out 260 hp and 271 lb.-ft. of
torque, it has the muscle to take on mountains. Add to that an available 6-speed manual
transmission with 2-speed transfer case and an electronically controlled locking rear
dierential, and FJ Cruiser possesses impressive o-road capability. Solid body-on-frame
construction keeps the FJ rigid, which helps the suspension do its work. The independent
front suspension system delivers nearly eight inches of wheel travel, while the 4-link
rear suspension with lateral rod oers more than nine inches. In short: On rocks, it rocks.
Back on pavement, its Vehicle Stability Control (VSC)1adjusts engine power and braking to
help the vehicle maintain the direction in which it has been steered, while Traction Control
(TRAC)helps reduce slipping when accelerating.
In the end, while the terrain may be
uncertain, you can always count on the quality and reliability of FJ Cruiser.
Before taking on steep slopes or crossing over a ridge, be aware
of your clearance angles. The greater the approach and departure
angles, the steeper the slope you can drive onto or off without
scraping your bumpers, while a greater breakover angle helps
avoid scrapes on the undercarriage.
When faced with a large obstacle, like a rock, fallen tree or
gully, the best way to take advantage of your vehicle’s ground
clearance and avoid damaging your undercarriage is to attack
it diagonally. If you should happen to make contact, the FJ is
armed with standard skid plates.
1See footnote 16 in Disclaimers section.
ApproachDeparture
31o34o
27o
Breakover
4x4 measurements
Off-roading is inherently risky. Please use caution.

Off-roading is inherently risky. Please use caution.

The key to driving in sand is to stay on top of it. Reducing tire
pressure, or airing down, improves “flotation” by creating
a wider footprint and distributing weight across a larger area.
A good rule of thumb is to reduce the tire profile by about
25%. And always remember to reinflate the tires to proper air
pressure once you’re off the sand.
Before tackling a steep hill, inspect it first on foot. With the
transfer case in Low, attack the slope at a 90° angle to help
avoid rolling over. Ascend in a gear high enough to prevent
wheelspin, but low enough to provide power. Descend slowly
in 1st gear, using engine braking, not the brakes, to maintain
traction. Also, watch your clearance angles at the top and bottom.
FJ Cruiser shown with available Convenience Package,
accessory TRD 16-in. alloy wheels, rock rails, tow hitch,
off-road lights with air dam and roof rack.
Correct
angle
Regular
pressure
Reduced pressure
increases footprint Incorrect
angle
Off-roading is inherently risky. Please use caution.

2.3 ft.
Fig. 1: When making a water crossing, walk the route first to
determine depth, bottom firmness and obstacle location. Know
the vehicle’s water-fording1limit so the engine intake doesn’t
suck in water. Fig. 2: With your available transfer case in Low,
cross slowly, but with enough speed to create a small bow wave,
which can help protect engine components.
Fig. 1: Before jacking, make sure you have a proper jack point
and solid footing. Once the vehicle has been elevated clear of the
obstruction, place rocks or fallen branches under the tires for
traction or for needed height, then lower the vehicle and drive
off. Fig. 2: Another option is to “pole-vault” the elevated vehicle
by pushing it off the jack onto solid ground.
1Do not attempt at high speeds.
FJ's water-
fording limit:
(fig. 1)
(fig. 1)
(fig. 2)
(fig. 2)
4x4 model shown
Off-roading is inherently risky. Please use caution.

Out in nature, the ability to adapt is key. To help you survive the wilderness in maximum
comfort, the driver’s seat of the FJ Cruiser is adjustable eight ways. And when it comes to
loading or unloading passengers and cargo, the front passenger seat’s new design allows it
to fold farther forward, while the two full-size passenger doors and two rear access doors
oer added flexibility. Once you get back from the trail, the doors’ wide-open functionality
also makes removal of dust and debris from the easy-clean interior a breeze. With so much
adaptability, you could say the FJ Cruiser is highly evolved.

MULTI-INFORMATION DISPLAY
The available floating-ball Multi-Information Display includes
such helpful tools as an inclinometer, compass and outside
temperature gauge.
ADVANCED AUDIO
The audio system oers hands-free phone and music streaming
via
Bluetooth
®1 wireless technology and a 90-day trial subscription
to XM®Radio.
2Included are an auxiliary audio jack and a standard
USB3port that lets you play music from a compatible MP3 player
or flash drive. Steering wheel-mounted controls help you operate
the system while keeping your eyes on the trail ahead.
FJ Cruiser interior shown with available Upgrade Package.
1See footnote 14 in Disclaimers section. 2See footnote 11 in Disclaimers section.
3See footnote 12 in Disclaimers section.

REAR CARGO TIE-DOWN HOOKS
A must-have for any serious o-roading. These handy tie-downs
help keep your gear in place when your rig is rocking and rolling.
VERSATILE CARGO CAPACITY
Get your gear on. The vast cargo area found in FJ Cruiser, with its
60/40 split rear seat and fold-down seatbacks, can handle all manner
of weekend warrior ordnance. Just drop the seatbacks to open up
66.8 cu. ft.
1of cargo space. Plus, water-resistant seats and durable
rubber-type flooring and rear deck make cleaning easy.
115V AC POWER OUTLET
Power up. With the available 115V/400W AC power outlet, you’ve
got the juice to recharge electronic devices or run small equipment,
like an air compressor for refilling the tires.
1See footnote 6 in Disclaimers section.

72.0"
105.9"
*4x4 measurements
183.9"
34o
*31o *
FEATURES9 SPECIFICATIONS
EXTERIOR
Multi-reflector halogen headlamps with auto-off feature Standard
Two-tone exterior color (body color with white roof top)10 Standard
Black front and rear bumpers with metallic silver trim Standard
Metallic silver door handles and outside mirrors Standard
Two full doors and two access doors Standard
17-in. black steel wheels with P265/70R17 tires Standard
17-in. alloy wheels with P265/70R17 tires Available
Lift-up glass hatch Standard
Rear door window defogger with timer Standard
Exterior spare tire cover Available
Black overfenders and black front and rear mudguards Standard
INTERIOR
Air conditioning with filter and rear vents Standard
AM/FM CD player with MP3/WMA playback capability, six speakers (two in
headliner), XM®Radio11 (includes 90-day trial subscription), auxiliary audio
jack, USB12 port with iPod®13 connectivity and hands-free phone capability
and music streaming via Bluetooth®14 wireless technology Standard
JBL®AM/FM 6-disc CD changer with MP3/WMA playback capability,
11 speakers including subwoofer, XM®Radio11 (includes 90-day trial subscription),
auxiliary audio jack, USB12 port with iPod®13 connectivity and hands-free
phone capability and music streaming via Bluetooth®14 wireless technology Available
Water-resistant fabric-trimmed seating surfaces Standard
8-way adjustable driver’s seat with armrest; 4-way adjustable front passenger
seat with seatback pocket Standard
60/40 split fold-down tumble rear seat with removable bottom cushion
and folding headrests on outboard seats Standard
Rubber-type flooring and rear deck Standard
Tilt 3-spoke steering wheel with audio and Bluetooth®14 hands-free phone controls Standard
Analog instrumentation with white backlit speedometer, tachometer, fuel,
temp and voltmeters Standard
Flat dash panels with pipe-like structure and metallic silver trim Standard
Exterior color-keyed center instrument panel Standard
Power windows and door locks Standard
Auto-dimming rearview mirror with integrated backup camera monitor15 Available
Cargo area tie-down hooks Standard
Digital clock Standard
Dual sun visors with vanity mirrors Standard
Four assist grips (two A-pillars, two above driver and front passenger doors) Standard
Four cup holders and two bottle holders Standard
Maplamps and map pockets Standard
SAFETY AND CONVENIENCE FEATURES
STAR SAFETY SYSTEM™
The 2011 FJ Cruiser comes standard with the Toyota Star Safety System.
™This integration
of safety features serves the fundamental aim of helping to assist drivers to avoid accidents
in the first place. It includes Vehicle Stability Control (VSC),
16 Traction Control (TRAC), Anti-
lock Brake System (ABS), Electronic Brake-force
Distribution (EBD) and Brake Assist (BA).
5
SMART STOP TECHNOLOGY17
When both brake and accelerator pedals are pressed at the same time under certain
conditions, this safety feature is designed to automatically reduce engine power to
help bring the vehicle to a stop.
Star Safety System™ – includes Vehicle Stability Control (VSC),
16 Traction
Control (TRAC), Anti-lock Brake System (ABS), Electronic Brake-force
Distribution (EBD) and Brake Assist (BA)5Standard
Smart Stop Technology17 Standard
Driver and front passenger Advanced Airbag System18 Standard
Driver and front passenger front seat-mounted side airbags and front
and rear Roll-Sensing side Curtain Airbags (RSCA)18 with cutoff switch Standard
Driver and front passenger active headrests19 Standard
Driver and front passenger seatbelt pretensioners with force limiters Standard
3-point seatbelts for all seating positions, driver-side Emergency Locking
Retractor (ELR) and Automatic/Emergency Locking Retractors (ALR/ELR)
on all passenger belts Standard
LATCH (Lower Anchors and Tethers for CHildren) includes lower anchors
on outboard rear seats and tether anchors on all rear seats Standard
Side-impact door beams Standard
Tire Pressure Monitor System (TPMS)20 Standard
Daytime Running Lights (DRL) Available
Rear parking assist sonar Available
Engine immobilizer21 Standard
Available1
Available2
Available4
Available1
Available3
See numbered footnotes in Disclaimers section.
MECHANICAL AND PERFORMANCE
Engine: 4.0-Liter DOHC 24-Valve V6 with Dual Independent Variable Valve
Timing with intelligence (VVT-i); 260 hp @ 5600 rpm; 271 lb.-ft. @ 4400 rpm Standard
Ignition: Electronic, with Toyota Direct Ignition (TDI) Standard
Emission rating: Low Emission Vehicle II (LEV-II) Standard
5-speed Electronically Controlled automatic Transmission with intelligence (ECT-i) Standard
6-speed manual
Rear-Wheel Drive with Automatic Limited-Slip Differential (Auto LSD) Standard
Part-time 4WD
Full-time 4WD
Electronically controlled locking rear differential
Active Traction Control (A-TRAC)
Suspension: Independent high-mounted coil-spring double-wishbone front
suspension with stabilizer bar; 4-link rear suspension with lateral
rod, coil springs and stabilizer bar Standard
Steering: Engine speed-sensing power-assisted rack-and-pinion Standard
Turning circle diameter, curb to curb (ft.) 40.7
Brakes: Power-assisted 4-piston front/2-piston rear ventilated disc brakes
with Anti-lock Brake System (ABS), Electronic Brake-force Distribution
(EBD) and Brake Assist (BA)5Standard
EXTERIOR DIMENSIONS (in.)
Overall height (4x2/4x4) 71.3/72.0
Overall width 75.0
Overall length 183.9
Wheelbase 105.9
Track (front/rear) 63.2/63.6
INTERIOR DIMENSIONS front/rear seat (in.)
Head room 41.3/40.3
Shoulder room 58.4/53.9
Hip room 55.4/51.0
Leg room 41.9/31.3
Seating capacity 5
OFF-HIGHWAY
Skid plates: On engine/front suspension, fuel tank and transfer case
(transfer case on 4x4 models only) Standard
Approach/departure/breakover angle (degrees) (4x2/4x4) 32/30/26 34/31/27
Ground clearance (in.) (4x2/4x4) 8.7/9.6
Ratios:
Front axle (4x2/4x4 AT/4x4 MT) NA / 3:72:1 / 3:91:1
Rear axle (4x2/4x4 AT/4x4 MT) 3:72:1 / 3:72:1 / 3:91:1
Transfer case – 2-speed (high/low) (4x4 models only) 1.000/2.566
WEIGHTS AND CAPACITIES
Curb weight (lb.) (4x2/4x4 AT/4x4 MT) 4079/4343/4332
Gross Vehicle Weight Rating (GVWR) (lb.) (4x2/4x4 AT/4x4 MT) 5330/5570/5570
Cargo volume6(cu. ft.) (behind front/rear seats) 66.8/27.9
Towing capacity7(lb.) 5000
Fuel tank (gal.) 19
TIRES
Size P265/70R17
Type: Mud-and-Snow-rated steel-belted radials Standard
Spare: Full-size, mounted on rear door Standard
Full-size, on alloy wheel, mounted on rear door Available
MILEAGE ESTIMATES (mpg city/highway)8
4x2 AT 17/22
4x4 AT 17/21
4x4 MT 15/20

PACKAGES OPTIONS/WHEELS
TRAIL TEAMS SPECIAL EDITION PACKAGE1
Army Green exterior color including roof top, black bumpers, grille, door handles, power outside mirrors with
illuminated markers, and rock rails; trail-tuned Bilstein®shock absorbers, electronically controlled locking rear
differential,
4Active Traction Control (A-TRAC), remote keyless entry system, Army Green door trim and fabric seat
inserts, floating-ball Multi-Information Display with inclinometer, compass and outside temperature, cruise control,
roof rack, auto-dimming rearview mirror with integrated backup camera monitor,
15 JBL®audio system, leather-
trimmed steering wheel, 115V/400W AC power outlet, TRD 16-in. 6-spoke Special Edition alloy wheels with
BFGoodrich®All-Terrain P265/75R16 tires, wheel locks, Daytime Running Lights (DRL), Trail Teams badge,
rear window wiper, and rear privacy glass on rear side, quarter and rear door windows
THE MAKING OF A LEGEND
Separated by over two decades, FJ40 and
its o-road heir, FJ Cruiser, share common
DNA. With its box shape and lozenge grille,
FJ40 is instantly recognizable, but it was
its capability and durability that made
it an icon. With 1,100,000 built between
1960 and 1984, it’s one of the most
popular o-road vehicles in history.
OPTIONS
17-in. alloy wheels with P265/70R17 tires Available
Electronically controlled locking rear differential
Daytime Running Lights (DRL)
Running boards
WHEELS
1. 17-in. black steel wheel Standard
2. 17-in. alloy wheel Available
3. TRD 16-in. 6-spoke alloy wheel
4. TRD 16-in. 6-spoke Special Edition alloy wheel Available1
Available1
Available4
Available24
Available25
1. 2. 3. 4.
OFFROAD PACKAGE1, 22, 23
Trail-tuned Bilstein®shock absorbers, electronically controlled
locking rear dierential,
4Active Traction Control (A-TRAC),
floating-ball Multi-Information Display with inclinometer,
compass and outside temperature
TRD PACKAGE23
TRD 16-in. 6-spoke alloy wheels with BFGoodrich®All-Terrain
P265/75R16 tires, high-speed-tuned TRD Bilstein®shock
absorbers and TRD decals
CONVENIENCE PACKAGE
Remote keyless entry system, cruise control, power outside
mirrors with illuminated markers, rear wiper, exterior spare
tire cover, auto-dimming rearview mirror with integrated
backup camera monitor15 and privacy glass on rear side,
quarter and rear door windows
UPGRADE PACKAGE
17-in. alloy wheels with P265/70R17 tires, Active Traction
Control (A-TRAC),
1electronically controlled locking rear
dierential,
4115V/400W AC power outlet, JBL®audio system,
leather-trimmed steering wheel, exterior color-keyed door trim
inserts, floating-ball Multi-Information Display with inclinometer,
compass and outside temperature, shift2and transfer1levers
with silver accents and rear parking assist sonar
See numbered footnotes in Disclaimers section.

See numbered footnotes in Disclaimers section.
See
n
u
m
be
r
ed
f
oot
n
otes
in Di
sc
l
a
im
e
r
s
sect
i
o
n
.
COLORS
TRD 16-in. off-road beadlock wheels
(black or bronze)
TRD performance brake kit
Center armrest Tonneau cover
Ashtray kit
Cargo net
Cargo tote
Carpet cargo mat
Carpet floor mats26
Emergency assistance kit
First aid kit
Hood protector
Off-road lights with air dam
attachment
Paint protection film
Spare tire cover
Tow hitch and ball mount
TRD air filter
TRD oil filter
TRD performance
brake pads
TRD quick shifter
TRD radiator caps
TRD shift knobs
TRD shocks
Vehicle Intrusion Protection
(VIP) — Glass Breakage
Sensor (GBS)27
Wheel locks
All-weather cargo mat Doorsill enhancements
Auxiliary driving lights Exhaust tip
Rock rails Roof rack
GENUINE TOYOTA ACCESSORIES
EXTERIOR
INTERIOR
TRD PERFORMANCE
ADDITIONAL ACCESSORIES
BLACK
CAVALRY BLUE
ARMY GREEN
BRICK
QUICKSAND
SILVER FRESCO METALLIC
ICEBERG For a complete list of accessories, go to toyota.com/fjcruiser
See numbered footnotes in Disclaimers section.

For Toyota Mobility program details, go to www.toyota.com/mobility
or call the Toyota Customer Assistance Center at 1-800-331-4331.
Toyota Care features a complimentary 2-year or 25K-mile maintenance plan with 24/7 roadside assistance. Covers normal factory scheduled service for 2 years or 25K miles,
whichever occurs first. See participating dealer for coverage details.
WARRANTIES
Every Toyota Car, Truck and SUV is built to exceptional standards. And that’s not idle boasting. We back it up with these Limited Warranty Coverages:
Basic: 36 months/36,000 miles (all components other than normal wear and maintenance items).
Powertrain: 60 months/60,000 miles (engine, transmission/transaxle, front-wheel drive, rear-wheel drive, seatbelts and airbags).
Rust-Through: 60 months/unlimited miles (corrosion perforation of sheet metal).
Emissions: Coverages vary under Federal and California regulations. Refer to applicable Warranty and Maintenance Guide for details.
Accessories: For Genuine Toyota accessories purchased at the time of the new vehicle purchase the Toyota Accessory Warranty coverage is in effect for 36 months/36,000 miles from
the vehicle’s in-service date, which is the same coverage as the Toyota New Vehicle Limited Warranty.
For Genuine Toyota accessories purchased after the new vehicle purchase the coverage is 12 months, regardless of mileage, from the date the accessory was installed on the vehicle,
or the remainder of any applicable new vehicle warranty, whichever provides greater coverage, with the exception of car covers. Car covers are warranted for 12 months from the date
of purchase and do not assume any coverage under the Toyota New Vehicle Limited Warranty.
You may be eligible for transportation assistance if it’s necessary that your vehicle be kept overnight for repairs covered under warranty. Please see your authorized Toyota dealership
for further details.
For complete details about Toyota’s warranties, please visit www.toyota.com, refer to the applicable Warranty and Maintenance Guide or see your Toyota dealer.
Toyota FJ Cruiser is designed to meet most off-road driving requirements. Abusive use may result in bodily harm or damage. Toyota encourages responsible operation to protect
you, your vehicle and the environment. Seatbelts should be worn at all times. Please do not allow passengers to ride in the cargo area. Towing hitch receivers/ball mount kits are not
intended to provide crash protection.
For details on vehicle specifications, standard features and available equipment in your area, contact your Toyota dealer. A vehicle with particular equipment may not be available at
the dealership. Ask your Toyota dealer to help locate a specifically equipped vehicle. All information presented herein is based on data available at the time of printing, is subject to
change without notice and pertains specifically to mainland U.S.A. vehicles only. Prototypes shown. Actual production vehicles may vary.
DISCLAIMERS
1. 4x4 models only. 2. Automatic transmission only. 3. Manual transmission only. 4. Standard on manual transmission model. 5. Brake Assist is designed to help the driver take full advantage of the benefits
of ABS. It is not a substitute for safe driving practices. Braking effectiveness also depends on proper brake-system maintenance and tire and road conditions. 6. Cargo and load capacity limited by weight and
distribution. 7. Before towing, confirm your vehicle and trailer are compatible, hooked up and loaded properly and that you have any necessary additional equipment. Do not exceed any Weight Ratings and follow
all instructions in your Owner’s Manual. The maximum you can tow depends on the total weight of any cargo, occupants and available equipment. Calculated with new SAE J2807 method. 8. 2011 EPA-estimated
mileage. Actual mileage will vary. 9. Toyota strives to build vehicles to match customer interest and thus they typically are built with popular options and option packages. Not all options/packages are available
separately and some may not be available in all regions of the country. See toyota.com for information about options/packages commonly available in your area. If you would prefer a vehicle without any or with
different options, contact your dealer to check for current availability or the possibility of placing a special order. 10. Monotone exterior on vehicles equipped with Iceberg paint color. 11. XM services require a
subscription after 90-day trial period. Subscriptions governed by XM Customer Agreement available at xmradio.com. If you decide to continue your XM service at the end of your complimentary trial, the
plan you choose will automatically renew and bill at then-current rates unless you call 1-800-967-2346 to cancel. Fees and programming subject to change. Available only to those at least 18 years of
age in the 48 contiguous United States and D.C. 12. May not be compatible with all MP3/WMA players and like models. 13. iPod®is a registered trademark of Apple, Inc. All rights reserved. 14. The Bluetooth®
word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Toyota is under license. Other trademarks and trade names are those of their respective owners.
The Bluetooth®wireless technology phones listed on toyota.com have been tested for compatibility with Toyota vehicles. Performance will vary based on phone software version, coverage and your wireless
carrier. Phones are warranted by their manufacturer, not Toyota. 15. The backup camera does not provide a comprehensive view of the rear area of the vehicle. You should also look around outside your vehicle
and use your mirrors to confirm rearward clearance. Cold weather will limit effectiveness and view may become cloudy. 16. Vehicle Stability Control (VSC) is an electronic system designed to help the driver
maintain vehicle control under adverse conditions. It is not a substitute for safe driving practices. Factors including speed, road conditions and driver steering input can all affect whether VSC will be effective in
preventing a loss of control. Please see your Owner’s Manual for further details. 17. Smart Stop Technology operates only in the event of certain simultaneous brake and gas pedal applications. When engaged,
the system will reduce engine power to help the brakes bring the vehicle to a stop. Factors including speed, road conditions and driver input can all impact stopping distance. Smart Stop Technology is not a
substitute for safe and attentive driving and does not guarantee instant stopping. Please see your Owner's Manual for further details. 18. All the airbag (AB) systems are Supplemental Restraint Systems. All ABs
(if installed) are designed to inflate only under certain conditions and in certain types of severe collisions: frontal and knee ABs typically inflate in frontal collisions; side and side curtain ABs in side collisions;
Roll-Sensing Curtain ABs at a severe tilt degree, roll or lateral G-force. In all other accidents, the ABs will not inflate. To decrease the risk of injury from an inflating AB, always wear seatbelts, sit upright in the
middle of the seat as far back as possible and do not lean against the door. Do not put objects in front of an AB or around the seatback. Do not use a rearward-facing child seat in any front passenger seat.
The force of an inflating AB may cause serious injury or death. See your Owner’s Manual for further information/warnings. 19. Active front headrests can help reduce the extent of whiplash in certain types of
rear-end collisions. 20. The Toyota Tire Pressure Monitor alerts the driver when tire pressure is critically low. For optimal tire wear and performance, tire pressure should be checked regularly with a gauge; do
not rely solely on the monitor system. See your Owner’s Manual for details. 21. The engine immobilizer is a state-of-the-art anti-theft system. When you insert your key into the ignition switch, the key transmits
an electronic code to the vehicle. The engine will only start if the code in the transponder chip inside the key matches the code in the vehicle’s immobilizer. Because the transponder chip is embedded in the
key, it can be costly to replace. If you lose a key, your Toyota dealer can help, or you can find a qualified independent locksmith to replace your key or perform high-security key services at www.aloa.org
22. Manual transmission model includes 17-in. alloy wheels with P265/70R17 tires. 23. Requires Convenience Package. 24. Not available with Trail Teams Special Edition Package. 25. Also available through
Genuine Toyota accessories. 26. This floor mat was designed specifically for use in your model and model year vehicle and SHOULD NOT be used in any other vehicle. To avoid potential interference with pedal
operation, each mat must be secured with retention hooks/clips. Do not install a floor mat on top of an existing floor mat. 27. Available for vehicles with factory security.
