Vehicle Security System
VSS3 - Vehicle original remote
Setting Guide - English

VSS3 1
Dear Customer,
In this guide you will find the information and operations necessary in order to activate and
deactivate certain features.
If you need any information about the use of the alarm system, please refer to the owner’s manual
for the alarm system.
PIN code
If the alarm system has been installed in you vehicle, you will have received a card (credit card size)
with a PIN code (Personal Identification Number) made up of 4 numbers.
The PIN code is used to deactivate the alarm system in case the remote control does not work
anymore. It will also be used by your authorised dealer to change your system configuration.
You should always keep this card with you, but do not leave it in your car.
If you have lost your PIN code, take contact with your authorized retailer.
To enter the PIN code
1 Press the button on the LED push button the number of times that corresponds to the first
digit of the PIN Code, with a maximum 1.5 second delay between one press and the next.
If the LED is already on when the button is pressed, it will go out.
2 Wait for the LED to flash indicating that the next digit can be entered.
3 Repeat the process for all four digits.
Vehicle security system
Please do not leave this card in your vehicle
EN_VSS3_Setting_Guide.indd 1EN_VSS3_Setting_Guide.indd 1 10/29/2007 10:48:06 AM10/29/2007 10:48:06 AM

2VSS3
Programming mode
This function allows to enable/disable various system options.
In order to do so, you must first enter the programming mode (see procedure below). Then, you
can select the function you want to edit by turning the ignition key from OFF to ON, and/or using
the LED push button. Once you have finished in that mode, you change to another one, or exit by
closing the bonnet.
1 Start of procedure
The alarm system has to be in disarmed state.
2 Enter programming mode
In order to enter the programming mode, you have to follow the procedure below:
– Open the driver’s door, and bonnet.
– Turn the key to IG ON.
– Enter the 4 digit PIN code on the LED push button.
The blinker will flash 1x every 12 sec, and the LED will remain ON as confirmation that
you have entered the programming mode.
Note:
– If the LED does not light ON, withdraw the key from the ignition and repeat the procedure.
EN_VSS3_Setting_Guide.indd 2EN_VSS3_Setting_Guide.indd 2 10/29/2007 10:48:07 AM10/29/2007 10:48:07 AM

VSS3 3
3 Select the programming mode
Navigate through the programming mode by turning the ignition key from OFF to ON, so that
you can check and modify the following settings:
• Buzzer volume: the volume of the buzzer can be increased or decreased.
• Automatic door locking: the doors are locked when the key is turned to IG ON, and unlocked
when the key is turned to IG OFF.
• Passive arming: this arms the alarm system automatically without the car being locked. It
protects your car in case you forget to lock it.
• Door Ajar warning: the buzzer will emit 10 beeps to inform the customer that a door was not
properly closed when the lock button is pressed.
• Arming buzzer: activates the buzzer sound when the alarm system is armed/disarmed.
4 Confirmation of programming mode
The programming mode is confirmed by the number of blinker flashes and the number of LED flashes.
The blinkers are flashing every 10 seconds, a number of times indicating in which programming
mode you are.
Note:
– You select the various programming modes by working through them in a one-way cycle of
steps. If you have moved one step too far, close the bonnet and start complete programming
procedure again.
5 Modify the settings
Refer to the following table for the programming mode selection steps overview.
– Turn the key to IG OFF and IG ON again
Note:
– The Blinkers will flash 1x every 10 sec, and the LED will flash 1x every 3 sec to confirm you
have reached the Mode 1.
EN_VSS3_Setting_Guide.indd 3EN_VSS3_Setting_Guide.indd 3 10/29/2007 10:48:07 AM10/29/2007 10:48:07 AM

4VSS3
5.1 Mode 1: Buzzer volume
Default setting: sound level is set to medium.
• Blinkers flashing 1x every 10 sec, and
• LED flashing 1x every 3 sec.
To increase the buzzer volume by 1 step: short press on the LED push button.
To decrease the buzzer volume by 1 step: press and hold (1 second) the LED press
button.
Repeat this operation until you reach the desired level.
Remark: There are 30 volume steps in total.
Note: Turn key to IG OFF > IG ON; and press 4x the LED push button to go to Mode
2
5.2 Mode 2: Automatic door locking
Default setting: ON
• Blinkers flashing 2x every 10 sec.
• LED if flashing 5x fast every 3 sec: function is disabled.
if flashing 5x slow every 3 sec: function is enabled.
If you want to change the setting, press and hold the LED push button 1x.
Note: Turn key to IG OFF > IG ON to go to Mode 3
5.3 Mode 3: Passive arming
Default setting: ON for PZ464-00134-00 (Belgium) (and cannot be deactivated).
Default setting: OFF for PZ464-00132-00 (Europe except Belgium) (and can be
activated).
• Blinkers flashing 3x every 10 sec.
• LED flashing 1x fast every 3 sec: function is disabled.
flashing 1x slow every 3 sec: function is enabled.
If you want to change the setting, press and hold the LED push button once.
Note: press 6x the LED push button to go to Mode 3.1.
EN_VSS3_Setting_Guide.indd 4EN_VSS3_Setting_Guide.indd 4 10/29/2007 10:48:07 AM10/29/2007 10:48:07 AM

VSS3 5
5.4 Mode 3.1.: Door Ajar warning
Default setting: ON
• Blinkers flashing 3x every 10 sec.
• LED flashing 7x fast every 3 sec: function is disabled.
flashing 7x slow every 3 sec: function is enabled.
If you want to change the setting, press and hold the LED push button 1x.
Note: Turn key to IG OFF > IG ON, to go to Mode 4
5.5 Mode 4: Arming buzzer
Default setting: OFF
• Blinkers flashing 4x every 10 sec.
• LED flashing 1x fast every 3 sec: function is disabled.
flashing 1x slow every 3 sec: function is enabled.
If you want to change the setting, press and hold the LED push button 1x.
6 Exit from programming mode
Close the bonnet.
The blinker will flash 5x to confirm.
Note:
– You can exit the programming mode at any time by closing the bonnet.
EN_VSS3_Setting_Guide.indd 5EN_VSS3_Setting_Guide.indd 5 10/29/2007 10:48:07 AM10/29/2007 10:48:07 AM

6VSS3
7 Programming setting guide diagram
Blinker
LED*
Setting
1 flash every 10 sec
1 flash every 3 sec
• Buzzer volume
Mode 1
2 flashes every 10 sec
5 flashes every 3 sec
• Automatic door
locking ON/OFF
Mode 2
3 flashes every 10 sec
1 flash every 3 sec
• Passive arming
ON/OFF
Mode 3
3 flashes every 10 sec
7 flashes every 3 sec
• Door ajar
warning ON/OFF
Mode 3.1.
4 flashes every 10 sec
1 flash every 3 sec
• Arming buzzer
ON/OFF
Mode 4
5 quick blinker
flashes
OFF
• Exit program
mode
Exit
Turn Key
to IG
OFF/ON
Step 3 Turn key to IG
OFF/ON
and
Press LED push
button
4 times
Turn key to IG
OFF/ON
Press LED push
button
6 times
Turn key to IG
OFF//ON
Close
bonnet
Turn key to IG
OFF//ON
• LED ON • Blinker flash every 12 sec • Enter PIN CODE with
LED push buttonStep 2
• Open bonnet • Open driver door • Turn key to IG ON
Step 1
Program mode is activated
Notes: - * The LED flashing speed will inform you about the function status:
- fast blink: the function is disabled. - slow blink : the function is enabled. => If you want to change the function status, press and hold (1 sec.) the LED
push button 1x.
- You can exit the programming mode at any time by closing the bonnet. - If you pressed the LED too many times, or turned the key IG too many times,
close the bonnet and start again.
EN_VSS3_Setting_Guide.indd 6EN_VSS3_Setting_Guide.indd 6 10/29/2007 10:48:07 AM10/29/2007 10:48:07 AM

VSS3 7
8 Arm without intrusion sensor
If you have to lock the car with somebody inside (passenger, children, dog, …), or if you want to
leave the window open, you must deactivate the intrusion sensor.
Activation steps Hazard light
indication
Alarm status light
(LED)
Buzzer
1 Lock the car by
remote control.
Flashes once. On for 30 sec. 1 beep sound if
buzzer enabled
2 During the first 30
seconds, press the
lock button once
again.
Flashes once. On for 30 sec. 1 beep sound if
buzzer enabled
Summary:
Press the remote
twice within
30 seconds.
Note:
– The interior sensor is deactivated once only. Next time the interior sensor will be activated
again.
EN_VSS3_Setting_Guide.indd 7EN_VSS3_Setting_Guide.indd 7 10/29/2007 10:48:07 AM10/29/2007 10:48:07 AM

8VSS3
9 Arm without additional sensors
For example, if you have an inclination sensor, you need to deactivate it when you are travelling by
boat or train, or if you are parking in a car park served by lifts.
If your alarm system has additional sensors, you can deactivate them as follows:
Activation steps Hazard light
indication
Alarm status light
(LED)
Buzzer
1 Lock the car by the
remote control.
Flashes once. On for 30 sec. 1 beep sound if
buzzer enabled.
2 During the first
30 sec., press the
lock button again
twice.
Flashes once. On for 30 sec. 1 beep sound if
buzzer enabled.
Summary:
press the remote
3 times within
30 sec.
Note:
– The sensor is deactivated for 1 use only. Next time you arm the alarm, the sensor will be
activated again.
EN_VSS3_Setting_Guide.indd 8EN_VSS3_Setting_Guide.indd 8 10/29/2007 10:48:08 AM10/29/2007 10:48:08 AM

VSS3 9
10 Garage mode
If you have to bring your car to your authorised retailer and do not want to provide the remote
controlled key, you can deactivate the alarm system for a limited period of time.
During garage mode, all the alarm system functions are inhibited.
This mode has to be manually activated by following this procedure:
1. Disarm by the remote control.
2. Insert the key into the ignition and turn to IG ON.
3. Open the driver door.
4. Enter PIN CODE with LED push button.
The hazards and LED will give 1 long flash and a long beep beep will sound for confirmation.
To exit:
1. Turn IG ON.
2. Long push on the remote unlock button, or on the LED push button.
Note:
During garage mode, the LED will flash at each ignition ON.
EN_VSS3_Setting_Guide.indd 9EN_VSS3_Setting_Guide.indd 9 10/29/2007 10:48:08 AM10/29/2007 10:48:08 AM
