TP-Link Archer T4UH User manual

AC1300 High Gain
Wireless Dual Band USB Adapter
7106506324 REV3.0.0
Quick
Installation
Guide
WPS
MODEL NO. Archer T4UH
Connect to a Computer
1 2 Install Driver and Utility
Insert the CD.
Browse the CD, go to Archer T4UH > Mac OS
X Driver, unzip the Mac OS X version.zip file
and run the Installer.
3Join a Wireless Network
For Mac OS X
Option 1: Directly Option 2: Via the USB Cradle
WPS
uninstall.commandInstaller.pkg
SHELL
Follow the wizard to complete the installation.
b.
a.
c.
Note: You can also download the driver and
utility at www.tp-link.com.
Option 1: Via TP-LINK Utility Option 2: Via Wi-Fi Protected Setup (WPS)
a. Click (TP-LINK Wireless Configuration
Utility) on the menu bar.
b. Select your Wi-Fi network and enter the Wi-Fi
password when prompted.
a. Press the WPS button on your router.
b. Within 2 minutes, press and hold the WPS button
on the adapter until the following screen appears.
c. When you are prompted “WPS Protocol Finished”,
click OK.
WPS
Please key the PIN code intoyour AP ’sconfig page
PIN: 66853657
WPS Progress: Scan ActiveWPS AP
8 sec
PIN
PBC
Cancel
SETUP
Fri 5:14 PM
34567_TEST
abcdef_0903
AAAAAA
TP-LINK_A
Join Other Network
WPS
Open Wireless Utility
USB-WiFi: On
Turn USB-WiFi Off

Connect to a Computer
1
For Windows
Option 1: Directly Option 2: Via the USB Cradle
Note:
In Windows XP, a Found New Hardware Wizard window will appear when the adapter is detected. Please click Cancel.
WPS
This USB Adapter can only be powered by computers that comply with
Limited Power Source (LPS).
2Install Driver and Utility
Insert the CD and run the Autorun.exe
from the pop-up Autoplay window.
Setup Wizard
Browse CD EXIT
Archer T4UH
Install Driver and Utility
User Guide
Select Archer T4UH and click Install Driver
and Utility, then follow the InstallShield
Wizard to complete the installation.
Notes:
1. You can also download the driver and utility at
www.tp-link.com.
2. In some operating systems, the CD screen will pop
up automatically. Otherwise, run the CD manually.
a.
b.
For more information, please visit our website
http://www.tp-link.com
3Join a Wireless Network
Option 1: Via TP-LINK Utility Option 2: Via Wi-Fi Protected Setup (WPS)
Network Name(SSID)
Channel
Signal
Security
2 (2.4G)
5 (2.4G)
149 (5G)
None
WPA/WPA2-Personal
None
34567_TEST
abcdef_0903
AAAAAA
6 (2.4G) TP-LINK_A
Connect automatically
WPA/WPA2-Personal
Connect
Status WPS Profile AdvancedNetwork
Select your Wi-Fi network from the pop-up
utility window and click Connect. The symbol
indicates a successful connection.
Note: In Windows XP, you need to close the TP-LINK Utility
before using the WindowsWireless Utility.
Click or (Network icon) on the taskbar,
select your Wi-Fi network, and click Connect.
Option 3: Via Windows Wireless Utility
a. Press the WPS button on your router.
c. When you are prompted“Successfully connected
to the network by WPS!”, click OK.
34567_TEST
Network Na
TP-LINK_A
b. Within 2 minutes, press and hold the WPS button
on the adapter until the following screen appears.
Configuring the wireless network.
Connecting to the network…
