TP-Link TL-ANT2424B User manual

User Guide
TL-ANT2424B
24dBi 2.4GHz Grid Parabolic Antenna
3
Electrical Specifications
Frequency Range 2.4GHz ~ 2.5GHz
Impedance 50Ω
iBd42niaG
VSWR ≤1.5
Horizontal Beamwidth 14°
Vertical Beamwidth 10°
F/B Ratio ＞30dB
Polarization Vertical or Horizontal
Maximum Input Power 100W
Connector N Female
Application Outdoor
Mount Style Pole Mount / Wall Mount
Mechanical Specifications
Antenna Dimension 600×1000 mm
Weight 3.5 +/-0.15 KG
Mounting Mast Diameter Ø30~Ø50 mm
Rated Wind Velocity 216 Km/h
Rev:1.0.0
7106500760

1
COPYRIGHT & TRADEMARKS
Specifications are subject to change without notice. is a
registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other
brands and product names are trademarks or registered trademarks of
their respective holders.
No part of the specifications may be reproduced in any form or by any
means or used to make any derivative such as translation, transformation,
or adaptation without permission from TP-LINK TECHNOLOGIES CO.,
LTD. Copyright © 2009 TP-LINK TECHNOLOGIES CO., LTD. All rights
reserved.
http://www.tp-link.com
2
Installation:
1. Assembly the two pieces of reflector symmetrically.
2. Mount the feed horn on the reflector according to the Mounting
diagram. Make sure the feed dipoles parallel with most bars of the grid
reflector. When the feed dipoles and most grid bars are vertical to the
ground, the antenna is vertical polarized. When the feed dipole and
most grid bars are horizontal to the ground, the antenna is horizontal
polarized.
3. Mount the “L” type bracket at the back of the reflector, then mount the
antenna on the mast supplied by customer according to the Mounting
diagram.
4. Test the antenna with equipment to make sure the antenna receive
the best signal by turning the azimuth and pitching angle, then lock all
the screws and seal the connector between antenna and cable.
