TP-Link TL-ANT5830B User manual

5GHz 30dBi Outdoor Grid Parabolic Antenna
Quick Installation Guide
TL-ANT5830B
7106503929
Rev. 1.0.0

1
I. Introduction
TL-ANT5830B, the TP-Link 5GHz 30dBi Outdoor Grid Parabolic
Antenna, is applicable for outdoor point-to-point or point-to-multi-point
directional signal transmission.
It is usually mounted on such high-level outdoor locations as towers,
roofs, etc.
The easy way to mount TL-ANT5830Bis to bind it to a mast, as
illustrated above.
*TL-ANT5830B is only compatible with 5GHz Access Points.
Please do not connect it with 2.4GHz AP.

2
II. Specifications
Electrical Specifications
Model TL-ANT5830B
Frequency Rang-MHz 5150-5850
Gain-dBi 30
VSWR ≤1.8
Horizontal Beamwidth-° 6
Vertical Beamwidth-° 4
Polarization Vertical or Horizontal
F/B Ratio-dB ＞30
Impedance-Ω50
Maximum Input Power-W 100
Connector N Female
Mechanical Specifications
Antenna Dimension-mm 600×900
Weight-Kg 3, 5
Mounting Mast Diameter-mm Ø30～Ø50
Radome Material Aluminium Die Cast
Rated Wind Velocity-Km/h 241

3
III. Radiation Patterns
Vertical Pattern
Horizontal Pattern

4
IV. Installation
Please find the necessary accessories in the attachment, and take
the following steps to install your antenna TL-ANT5830B.
1. Mount the antenna on the “L” type brackets according to the
mounting diagram.
Make sure the antenna polarization is parallel to the direction
you need. When the antenna polarization is vertical to the

5
ground, the antenna is vertically polarized. When the antenna
polarization is horizontal to the ground, the antenna is
horizontally polarized.
2. Mount the antenna on the pipe mast according to the mounting
diagram.
3. Test the antenna with equipment to make sure the antenna
receive the best signal by turning the azimuth and pitching angle,
then lock all the screws and seal the connector between
antenna and cable.

6
4. Connect TL-ANT5830B to 5GHz AP (Access Point) interface
with cables. It’s recommended to use radio frequency cables
with high quality and low loss. Besides, the shorter the cable is,
the better it will be to avoid unnecessary loss.
Warning:
Mount the antenna at a safe location, far away from power lines,
lamps, and other cables.
Do not mount the antenna in the rain or thunder storm.
Do not mount the antenna alone.
