TP Spiro Hop Bouncer TP749 Quick guide
Important! These instructions must be followed for safe assembly and use. Please retain for future reference.
Important! Vous devez suivre ces instructions pour que le montage et l’utilisation se fassent en toute sécurité.
Veuillez conserver pour référence ultérieure.
Importante! Per garantire sicurezza di montaggio ed uso, seguire queste istruzioni e conservarle per futuro riferimento.
Importante! Debe seguirse estas instrucciones para un armado y uso seguros. Sírvase conservarlas para consultarlas en el futuro.
Wichtig! Diese Anweisung ist für sicheren Aufbau und Gebrauch zu befolgen. Für künftigen Gebrauch aufbewahren.
Importante! Para assegurar uma montagem e uma utilização seguras, têm de ser seguidas estas instruções. Guardar para referência futura.
TOY MUST BE ASSEMBLED BY AN ADULT BEFORE USE.
THIS PRODUCT CONTAINS SMALL PARTS AND IS NOT SUITABLE FOR CHILDREN UNDER 36
MONTHS.
REMOVE ALL PACKAGING BEFORE GIVING TO YOUR CHILDREN.
ONLY FOR DOMESTIC USE. FOR INDOOR AND OUTDOOR USE. ADULT SUPERVISION IS REQUIRED.
THIS PRODUCT IS INTENDED FOR USE BY CHILDREN FROM AGES 3 TO 8 YEARS.
TWO USERS MAXIMUM. ONE USER PER SEAT ONLY.
MAXIMUM USER WEIGHT 35KGS PER SEAT
ANCHORS THAT ARE SUPPLIED WITH THIS PRODUCT MUST BE FITTED BEFORE USE.
MADE IN CHINA
WARNING!
INSTRUCTIONS FOR ASSEMBLY MAINTENANCE AND USE
PLEASE RETAIN FOR FUTURE REFERENCE.
TP749
Spiro Hop Bouncer™
The TP logo and Spiro Hop are UK Registered trademarks of Robovision Limited.
Robovision Ltd t/a TP Toys protects their unique designs worldwide with patents and design registrations.
For full information on the intellectual property relating to TP products please visit www.tptoys.com/intellectualproperty
Wichtig!
3 - 8 Jahre
Max.
Benutzer-Gewicht
pro Sitz: 35kg.
Please ensure the exposed holes are blanked with bolts supplied.
Required for indoor use only.
After inflation check ball at regular intervals and re-inflate when necessary before play.
Recommended Free Space:
This product requires a level ground surface of 91cm x 91cm for a Safe Play Area.
The Safe Play Area refers to the zone extending 200cm beyond the toy on all sides, including the space above the toy. The Safe
Play Area must be free from all structures, landscaping, trees and branches, rocks, wires, sprinkler heads and other similar ob-
stacles to safe play. Children can be seriously injured running or colliding into such obstacles.
Important! These instructions must be followed for safe assembly and use. Please retain for future reference.
Ball replacement
9191
200
3
8 3
35
WARNING
TOY MUST BE ASSEMBLED BY AN ADULT BEFORE USE.
THIS PRODUCT CONTAINS SMALL PARTS AND IS NOT SUITABLE
FOR CHILDREN UNDER 36 MONTHS.
REMOVE ALL PACKAGING BEFORE GIVING TO YOUR CHILDREN.
ONLY FOR DOMESTIC USE. FOR INDOOR AND OUTDOOR USE.
ADULT SUPERVISION IS REQUIRED.
THIS PRODUCT IS INTENDED FOR USE BY CHILDREN FROM AGES
36 MONTHS TO 8 YEARS.
MAXIMUM USER WEIGHT 35KGS PER SEAT
ANCHORS THAT ARE SUPPLIED WITH THIS PRODUCT MUST BE
FITTED BEFORE USE.
MADE IN CHINA
3
836
35
TP749 Spiro Hop IN9434 - I 05.19.indd 1 22/05/2019 08:56
INSTRUCTIONS FOR ASSEMBLY, MAINTENANCE AND USE OF TP
TOYS
Please read carefully and keep all enclosed information for future
reference.
1. ASSEMBLY AND SAFETY INFORMATION
TP toys must be assembled by an adult. They must be erected exactly in accordance
with the assembly instructions. Enlisting the aid of a helper will make assembly
easier. This pack may contain small parts and is not suitable for children under
36 months. We recommend that you place small parts on a tray, or something
similar, to prevent the frustration and disappointment of mislaying them. Please take
care during assembly as the manufacturing process can sometimes result in the
occasional sharp edge and small pieces of waste metalwork. General instruction to
kit/accessory about installation of rope/nets (in relation with the diameter fixed at
both ends, length of pending, interaction with other structure. Should there be any
missing parts, the toy must not be used until replacement parts have been fitted -
2. SITING
Under no circumstances should any of our toys be positioned on a hard surface,
unless the ground under the toy plus the recommended freespace area is covered
with a safety surface (please refer to diagram on page 14). The toy should ideally be
sited with grass, sand or a recommended play surface covering the freespace area.
A fall onto a hard surface can result in serious injury. TP toys should be sited on level
ground away from the house, overhanging branches, laundry lines, electrical wires
or any other similar obstruction. Installing your playset on sloping ground can cause
it to lean or ‘rack.’ This puts additional stress on all the connections and joints and in
time will cause them to fail. This is not covered by any guarantee.
3. USAGE
TP toys are designed and made to be used by children aged between 36 months
and 8 years, unless otherwise stated, and must not be used by anybody else.
Warning only for Domestic use. For indoor/outdoor use only.
4. SUPERVISION
Children should always be supervised while they are playing on TP toys and should
be instructed not to use the toy in an inappropriate or hazardous manner. Make
sure they do not wear loose-fitting clothing or jewellery that can catch or snag.
Children should not wear cycle helmets while playing on TP toys. Please note the
orientation of the activity toy in relation to the exposure to the sun.
5. WEATHER CONDITIONS
Many surfaces can become slippery in wet or icy conditions. Lips, tongues and
wet skin can stick to metalwork in very cold weather. Therefore, in these conditions
children must not be allowed to use the toy. Extra caution and supervision is
required when combining water (eg. paddling pools, aqua slides, etc.) with outdoor
play.
In warmer and sunnier weather, parts can become hot, and the temperature should
be regularly checked during play, especially metal parts and slides.
6. MAINTENANCE
With all toys it is vital that the equipment is checked regularly and often by an
adult. The complete toy should be checked at least once a month, and particular
attention should be paid to the suspension system, ropes, and all fittings, bolts,
nuts, and shackles, etc. If any parts exhibit signs of wear and tear, they may need
to be replaced. To replace defective parts in accordance with the manufacturer’s
instructions. Checks must be carried out at the beginning of the usage season as
well as at regular intervals throughout the usage season. Failure to do this may
result in the product malfunctioning and causing injury. If a sharp edge or protruding
bolt is found, saw and file it down until flush and smooth. Children must not be
allowed to use the toy until properly installed and checked.
Galvanised tubular products - This range of TP toys is made from either zinc-coated
or hot-dipped galvanised tubing. If surface rust appears it should be removed
with either a wire brush or coarse sandpaper, and the area treated with a cold
galvanising paint such as Galvafroid or Polygalv. These are two well-known names,
although other makes of paint are available from most hardware or DIY stores.
7. FIRE RISKS AND DISPOSAL
Never allow TP toys to be placed or used near a fire. When it becomes necessary to
dispose of your equipment, remove all bolts and disassemble. Store out of the reach
of children until it can be properly disposed of.
These instructions are issued in the interest of child safety, and we do ask you to
follow our advice.
