TPI Robotics unlocked User manual

u s e r m a n u a l
Robotics unlocked

Creativity
gives wings to your
imagination

With QTPI you become part of an eco-system that believes that
‘learning through creating’ is ageless. Today, it’s about learning
to be analytical and logical by creating through coding and
robotics. And we know, creation using robotics, will make an
impact in the real world, now and tomorrow. Fellow earthlings,
let’s hop, skip and jump into the future by unlocking our
imaginations through QTPI Robotics.

COMPONENTS
Welcome to the world of QTPI Robotics.
What you will find in here is everything you need to
expand your imagination and develop special skills in
building unique robotic projects, that’s not just educational
but recreational as well.
5 HOLE PILLAR
The building blocks used to build the
structure for the robot and help to
balance. This is the tallest block
among other Qbits.
MOTHERBOARD
WITH BLUETOOTH
The Qbrick Motherboard is the
processing unit (brain) of the robot
which is powered by a rechargeable
battery and turned ON/OFF using a
switch.
RJ11 CABLE
This cable is used to establish
connection between Qbrick and
Sensor/Actuator.
DC MOTOR
Direct Current (DC) Motors are
electromechanical devices that use
the interaction of magnetic fields and
conductors to convert the electrical
energy into rotary mechanical energy.
CASTER WHEEL
An undriven wheel designed to be
attached to the bottom of a larger
object to enable that object to be
moved.
WHEELS
The Wheels are used to move the
structure of the robot.
T JOINT
This block has hole in the middle, it
resembles the alphabetical letter “T”
when a 5 hole pillar block is connected
to it.
ULTRASONIC SENSOR
An ultrasonic sensor is an electronic
device that measures the distance of
the target object by emitting ultrasonic
sound waves and converts the reflected
sound into an electric signal.
The above components are vital in building your own Merry-Go-Round
QtPi USER MANUAL 04
The above components play a fundamental role in constructing Obstacle Avoider

L BLOCK
The block resembles the
alphabetical letter “L”. It helps in
building structures such as square,
rectangle and cube. It forms 90
degree angle in the structure.
AMBIENT LIGHT AND DIGITAL
PROXIMITY SENSOR
APDS sensor offers light and colour
detection, proximity detection and touch-
free gesture sensing.
Along with other components, use the above two to build your own automatic Basketball Scorekeeper
CONNECTOR
Connector block is the smallest
block in Q bits it is used for
connecting to other blocks for
building structure.
SERVO MOTOR
Servo Motor is a closed-loop system that
uses position feedback to control its
motion and final position.
This components will play a big role in building your Smart Home
QtPi USER MANUAL 05
I BLOCK
This block resembles the
alphabetical letter “i” when a
5 hole pillar block is
connected to it.
ARGB MODULE
ARGB module, addressable RGB header
is a 3-pin connector equipped with an
Integrated Circuit to customize each
individual LED colour when connected.
If Remote Controlled cars are on your mind, this components are vital to build one
CHARGING ADAPTER
Charging Adapter is used to charge
the Qbrick / Motherboard.
SPECIFICATION:
Input Voltage(AC): 100-240v
Output Voltage: 9v
BUZZER
The Buzzer is an audio signaling
device that makes a buzzing sound.
The above components along with others are use to make a Smart Goggle
PLIER
Plier is used to detach the
blocks and dismantle the
structure of your robot.
45 DEGREE BLOCK
The angle of block is 45 degree
and it helps in building
triangular structure and used for
bends in structure.

OBSTACLE AVOIDER
You’ve definitely played with a Remote Controlled (RC) car in
your childhood, but how about an RC car that evades
obstacles? Build your own Obstacle Avoider Car that, on
sensing an obstacle, will change directions using its sensor,
automatically activating the buzzer and indicator!
Zoom away!
QtPi USER MANUAL 06
SMART HOME
You’re smart. Your phone is smart. Now, make your home
smart as well with our ‘Home Automation System’ that can be
controlled using the Mobile App. The kit components make it
easy to notify and control the home devices when connected.
Go, surprise your parents!
BASKETBALL COUNTER
Build a basketball court and compete! What’s amazing is you
can create a counter that keeps the score for you! You can
build it with hoops, sensors and buzzers that count the scores
on your mobile whenever the ball passes through the hoop.
Get scoring!
SMART GOGGLES
Help a visually challenged person by building Smart
Goggles! Build the goggles, connect the components
and through the mobile app, it will alert them of the
obstacles.
PROJECTS

QtPi USER MANUAL 07
MERRY GO ROUND
Just like a merry-go-round in the parks, you can now play in
real-time! Relive your childhood by building a model similar to
the one in the parks which you can operate from your mobile
phone, and even adjust the speed using an application!
Get dizzy!
RC CAR WITH HEADLIGHTS
You can now call your RC car a ‘Night Rider’. Fix two LEDs to
your RC car that will equip you to drive in the dark. Connect
them with the kit components and you can control the car and
headlights using the mobile application. Vroom!
Scan the code and
explore more projects that
can be built using the kit and
unravel your imagination

QtPi USER MANUAL 08
QTPI Pro
You’ve witnessed the amazing
robotic projects you can create with this kit.
Scrubber
Here’s your automatic household Scrubber that
cleans fast and saves your time and energy.
Agronomy
Scrubber | Smart Tap | Green Bot
Smart Tap
You are Captain Planet! Save every drop of water with this automatic
sensor that will only release water when your hands are under the tap.
Green Bot
The agricultural bot that helps discover the moisture level,
and the pump motor will start pumping water automatically.
Want to unlock
the next level?
You should!
Go Explore with
the Add-On themes
below!

QtPi USER MANUAL 09
Uni-light Follower
Want to race your RC car at night? Make your car follow a source of
light automatically. Amazing right!
Robo Wheels
Uni-light Follower | Smart Street Light | Monster Jeep
Smart Street Light
Show the world how we can save electricity by building your
own Smart Street Light that senses movement and turns on.
Monster Jeep
It’s as real as it gets. Build your Monster Jeep to zoom, to avoid obstacles
and automatically open the doors with multiple sensors and motors.
Play Bot
Get friends over, start any game and have this limit Switch, ARGB and
Buzzer to enhance your playing experience.
IOT Power
PlayBot | Count Keeper | Room Temperature Detector
Count Keeper
At the press of a button have this Robot make counting of anything much
easier and automated.
Room Temperature Detector
You can’t control the weather outside, but you can inside. Use this
temperature detector for experiments or even for just checking if the AC is
working.

QtPi USER MANUAL 10
QTPI Pro Max
Want to Explore the Ultimate?
Her’s a few outstanding projects that you can
create by utilising components, motors and
sensors from different themes, and mixing
them up to create unique Robotics.
Become a master, go for MAX!
Wall-E
A Tanker

QtPi USER MANUAL 11
Tipper
Truck
Smart
Car

Warnings
• Follow the instructions in the kit correctly in presence of the trainers.
• Instructions not followed properly can result in injuries.
• Do not put any part of the kit in the mouth.
www.qtpi.in
Imagine | Code | Create
