KidzTech Roller Maz RC Dinoz User manual

87411
3
age
PRO . S Y S TE M
Contents
Dinoz x 1
Transmitter x 1
Water Pump x 1
Instruction Manual x 1
Battery Precaution
1. Alkaline batteries are recommend
Battery Requirement
1. Dinoz: 4 x 1.5V AAbatteries
2. Transmitter: 2 x 1.5VAAbatteries
4 x AA
For Dinoz
( Included )
2 x AA
For Transmitter
(Not Included )
2. Only batteries of the same or equivalent type as recommended are to beused
3. Do not mix alkaline, standard, or rechargeable batteries
4. Do not mix old and new batteries or different types ofbatteries
5. Non-rechargeable batteries are not to be charged
6. If rechargeable batteries are to be used, they are only to be charged under adultsupervision
7. Rechargeable batteries are to be removed from the product before they are charged
8. Be sure to insert batteries with correct polarities and always follow the battery manufacturer’sinstructions
9. Remove all batteries from the Dinoz and Transmitter when not inuse
10. Exhausted batteries are to be removed from the product
11.The supply terminals are not to be short-circuited
12. Dispose of batteries properly / do not dispose the batteries in fire - it may cause them to explode or leak causing injury or damage
13. Battery installation and removal must only be done by an adult
Battery Installation
For Dinoz (Fig. 1 and Fig. 2)
1. Switch the power button to OFF position
2. Unscrew the battery cover
3. Open the battery cover
4. Install 4 new 1.5V”AA” batteries with correct polarities (+/-)
5. Close the battery cover
6. Tighten the screw on the battery cover
For Transmitter (Fig. 3 and Fig. 4)
1. Unscrew the battery cover
2. Open the battery cover
3. Install 2 new 1.5V “AA” batteries with correct polarities (+/-)
as shown inside the battery compartment
4. Close the battery cover
5. Tighten the screw on the battery cover
Fig. 1
Dinoz
Fig. 2
Dinoz
Fig. 3
Transmitter
Fig. 4
ON/OFF
& Try Me
1.5V
AA
_
+
+ + _
_ +
Move Forward/
Backward
2.4 GHz
Signal Light
Light, Sound
& Smoking
Effect
Transmitter - Battery Installation
How to fill with water for smo ing effect
1. Please prepare a cup of clear tap water.Keep
squeezing and releasing the provided water
pump to fill with the water. (Fig.5)
3. Squeeze the provided water pump to fill the
water tank into the Dinoz. (Fig.7)
2. Open the water tank cap on the Dinoz. (Fig.6)
4. Close the water tank cap firmly. (Fig.8)

Trouble shooting for 2.4GHz pairing in case of no signal
1. Switch OFF the Dinoz and Switch ON to re-start the Dinoz.
2. Re-install batteries to the transmitter.
3. The transmitter signal light will flash for 7-8 seconds.
4. After the LED light of the transmitter stops flashing, the pairing process is complete forplaying.
5. If pairing cannot be completed within 8 seconds, please turn off the Dinoz and re-start the pairingprocess.
6. When the pairing process is done, whenever switching the Dinoz on and off, it searches for the code that is memorized and will only lock on to the
transmitter signal contained that code.
7. If the pairing signal disconnected, please turn off the Dinoz and re-install the batteries in the transmitter. The pairing process will be completed after
turning on the Dinoz again.
How to play
87411
2. Press the right button of the transmitter for light, sound and smoking effect
1. Press the left button of the transmitter to control
the Dinoz random walking
3. Play on a smooth surface for optimal performance
4. Remember to switch OFF the power of the Dinoz afterplaying
5. The optimal control range is up to 15M (49 ft) indoors
Performance Tips
1. Do not operate Dinoz on grass, dirt, sand, dusts, carpet or go through water.
2. Do not operate Dinoz in windy or rainy weather.
3. Avoid direct impact with obstacles.
4. Switch OFF the power when not in use to prevent damage of Dinoz due to leakage of
electrolyte from batteries.
5. Remove all batteries from the Dinoz and Transmitter when not in use for long period.
6. Keep fingers, hair and loose clothing away from wheels.
7. The operating range can be affected by a variety of factors
a) Low Voltage of batteries in Transmitter or Dinoz
b) Interference from other items that emit radio frequency signals.
8. Outdoor usage is recommended in order to get optimal control range.
9. Play with the Dinoz on a clean and smooth surface.
10. Clean the battery compartment to make sure it is free from dust to prevent poor
contact of batteries
FCC Label Compliance Statement:
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna
- Increase the separation between the equipment and receiver
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
- Consult the dealer or an experienced radio/TV technician for help
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
RSS-210 Compliance Statement:
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
(1) L’appareil ne doit pas produire de brouillage;
(2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
Declaration of Conformity
The product is in conformity with the requirement of EU Directive 2014/53/EU.
Environmental Notes:
The whole product also does not belong to household waste at the end of the product life.
Youcan return it at collection points for the recycling of electronic and electronical instruments
The symbol on the item, instruction manual, hangtag or packing is showing this clearly.
Materials should be recycled according to their respective markings.
Recycling of old devices or other re-use of materials contained therein represents an important
contribution to environmental protection.
Please ask at your local community for the correct collection point.
Disposal of Batteries
Batteries should not be disposed of in the household waste. As the consumer you are legally obliged to
return batteries containing harmful substances and all other used batteries. You can hand in your old
batteries at public collection points in your area or wherever batteries are sold.
You will find these chemical abbreviations along with a crossed-out refuse bin on batteries containing
harmful substances:
Pb=Battery contains lead
Conforms to the safety requirements of ASTM F963
Cd=Battery contains cadmium
Hg=Battery contains mercury
Frequency band: 2408-2475 MHz
Maximum radio frequency
power transmitted: <0dBm
KIDZTECH TOYS MANUFACTURING LTD.
Room 802, 8/F, Inte -Continental Plaza,
94 G anville Road, TST East, Hong Kong.
Tel: [phone] [e-mail]
Made in China http://www.kidztech.net
KT20/05/19-01
