TPL VISION HIGH POWER HPBACK User manual

Preamble
User gUide
UnPacking
risk class
Products are packed in our factory, using suitable materials for a safe transport through the usual means of trans-
portation, in France and internationally. However, a damaged package must be reported to the carrier on delivery.
Hand-written reservations must be indicated on the delivery order. Moreover, please send a letter or an email to
TPL Vision as soon as possible (up to 24 hours after the delivery). If the transportation damage has not been stipu-
lated on the delivery order and reported to TPL Vision in time, the package will not be taken back nor exchanged.
To open the package, do not use any cutting blade to avoid damaging the product(s). Please use the delivered
accessories, if needed (do not use any other products or equivalents to replace the delivered accessories).
This Technical User Guide contains warnings and guidance for correct and safe operation of the product.
These instructions must be followed at all times. TPL Vision will not be held responsible for problems
caused by using the product contrary to these instructions and the Warranty will be deemed invalid.
The EN-62471 norm about lighting uxes enables the classication of led lightings in 4 distinct groups, according
to their hazardousness degree. Please nd below an indicative table, recapitulating the classes of risk for our
standard products.
TPL Vision can provide guidance notes about the nominal distance to minimize eye risks.
BEWARE to the infrared light, invisible to the eyes.
To know if the light is on, please refer to the LED indicators.
In all cases, TPL Vision recommends
the use of the protection glasses
that are listed in its catalog.
For more information about photo-
biological risks, do not hesitate to
contact us.
Colour Class Risk
White WHI, Green 525 nm, Red 630 nm 0none
UV 405 nm, Blue 470 nm, IR 850 nm 1low
UV 365 nm 2moderate
UV 385 nm 3high

User gUide P2/8
FIXING ON THE LENGTH (groove) FIXING ON THE CORNER
(4 M4 nuts – supplied) (CHC screw M4x20 – not supplied)
max. depth:
5mm
M4 nut
fixing
dimensions
Length x Width
(mm)
Height
(mm)
A x B C
Min: 200x200 ; Max: 900x900 or 1900x400 45
•Useful surface: A x B
•Max. useful surface: 0.88 m2
•Max.useful perimeter: 4.6 m
•Total surface: (A + (4mm x 2)) x (B + (4mm x 2))
(connector excluded)
During the set up, the light has to be switched off and unplugged. Please use the xing groove or holes designed
for that purpose. We recommend the using of nuts (supplied) in the groove or M4 screws (not supplied) with
atightening torque from 0.5 to 1.5 Nm. We also recommend the use of a threadlocker (not supplied) to avoid any
risk of loosening.

P3/8
BE CAREFUL WHEN USING ANGLE BRACKETS.
(TPL Vision reference: TPL-MOUNT-HPB-SQUARE1)
Do not hang up.
Do not deform the structure.
led indicaTors Wiring
righT angle cable direcTion
Power
LED indicator
Strobe
LED indicator
SURFACE ≤0.25 m2
SURFACE >0.25 m2
+
1M12 connector +1additional power cable
1M12 connector

User gUide P4/8
connecTion
M12 Connector 5 male points
+ 24 V
1
2
3
4
Ground
PNP
5Dim 0-10V
STROBE PNP :
+ 24 V
NPN
1
2
3
4
Ground
STROBE NPN :
+ 24 V
1
2
3
4
Ground
PNP
+ 24 V
NPN
1
2
3
4
Ground
CONTINUOUS MODE :
or
2
4
1
+ 24 V
3GND
5DIM 0-10V
STROBE
NPN
STROBE
PNP 5Dim 0-10V
5Dim 0-10V 5Dim 0-10V
black
brown
blue
grey
white
Double Wiring Version recommendation (for >0.25m² products only)
2 4
13
24 V GND
In the DOUBLE WIRING version,
both wirings can be powered by
THE SAME POWER SUPPLY 24V.
WIRING 1
WIRING 2
(control and power)
(power)
1 2
4
5
3
Voltage drop for connector M12 +10 meter wire:
(minimum voltage at product input: 20VDC) 2.2V @ 4A 1.6V @ 3A 1.1V @ 2A 0.55V @ 1A
NOTE: Wiring 2 is only for power.
M12 5P connector (wiring1) oper-
ates as shown above for NPN, PNP
and Dim 0-10V.

P5/8
Double Wiring Version using 2 supplies recommendation (for >0.25m² products only)
24 V GND
WIRING 1
WIRING 2
(control and power)
(power)
1 2
4
5
3
1 1
POWER SUPPLY 1
Power 1 (min) = 96W
POWER SUPPLY 2
Power 2 (min) = total power –96W
2 4
13
24 V GND
2 2
eqUiPmenT mainTenance
oPeraTing condiTions
CLEANING (when the product is switched off)
Please use a soft and dry cloth. Do not use any abrasive material.
Do not use any cleaning solvent or aggressive chemical product.
TPL Vision recommends to use isopropyl alcohol.
Not for outdoor use.

User gUide P6/8
conTrol
dimming 0-10V
20%
30%
40%
60%
80%
100%
0 2 4 6 8 10
VOLTS
LIGHT POWER
Potential dimming between 0 & 10 V.
At 0 Volts, the productreaches100%
of itslighting power.
sTrobe mode
Entrée Déclenchement
Sortie Éclairage
Triggering input
Light status
OFF
ON
15 µs 10 µs
dimming seTTing
The product is optimised for a lifespan >50kh in a 40°C atmosphere.
In strobe mode, the strobing time is directly equivalent to the time during which the strobe entry is activated.
• Lowest level: 30% of the power.
• Highest level: 100% of the power.

P7/8
Technical informaTion
Electronics
Power supply 24 VDC ±10%
Functioning mode Continuous or strobed
Strobe input PNP : From 5 to 24V for 100% ON. From 0 to 1V for 100% OFF.
NPN : less than 1V for 100% ON. Above 2V for 100% OFF. Max 20V.
Overdrive No
Strobe conditions
(On time, duty cycle) No restriction
Dimming Pin 5 (M12 5Pole Connector): 0-10V = 100-30% Respectively
Maximum rising time 15 µs
Maximum falling time 10 µs
Control Connector M12 5 Poles
Connector pin conguration 1: 24VDC / 2: NPN / 3: GND / 4: PNP / 5: DIM 0-10V
Consumption
• 1.72W per 25cm² (IR)
• 1.41W per 25cm² (red )
• 1.35W per 25cm² (white)
Min. functioning Voltage 20V in the light input
Normal functioning Voltage 24V in the light input (±10%)
Max. functioning Voltage 30V in the light input
Max. consumption Strobe signal 5mA
Optics
Colour White (5700k), Red (630nm) and Infrared (850nm)
Mechanics
Thickness 45mm
Lighting surface Minimum: 0.2 x 0.2 m / Maximum Surface: 0.88m²
Maximum Length: 1.9m / Maximum Perimeter: 4.6m
Weight 23.2 Kg/m² ±15%
Materials Aluminum and loaded ABS
Diffuser White PMMA
Fixing 4 M4 nuts (supplied) to insert in the groove
or 4 M4x20 screws (not supplied) applied to the corner slots
Environment
Operating temperature -10° C to +40° C / 80% of humidity without condensation
No thermal shock (maximum temperature variation: 10 DegC in 24h)
Storage temperature -20° C to +60° C / 80% of humidity without condensation
No thermal shock (maximum temperature variation: 10 DegC in 24h)
IP protection IP 40
Labels RoHS-CE-DEEE

www.tpl-vision.com
TPL VISION
IS AN ISO9001
CERTIFIED MANUFACTURER
[phone] [e-mail]
Brenchley House, School Road
Charing, Kent TN27 0JW
United Kingdom
Features and presentations liable to changes without notice. Ref.UG-020301-C7, 2022/12 edition.
User gUide
User secUriTy
Please respect the power supply voltages and the connection terminals.
Do not modify or dismantle all or part of the product.
Do not connect or clean when power is on.
Do not watch the lighting source directly, and follow the advice below :
• If the workstation enables it, interpose a lter that will stop the lighting radiation under xed or adjustable
frame between the source and the operator.
• When these measures cannot be implemented, supply the operators with glasses (class 4) available for sale
at TPL Vision.
• Forbid or limit the direct access to the lighting source (exposure into the radiation axis).
• Establish a security perimeter so as to prevent the operators from approaching the lighting source beyond
the recommendations of the manufacturer, where eye irritation is concerned.
• Ensure that the chosen means properly reduce the exposure level (e.g. features of screens or glasses to be
chosen, according to the wavelengths that the operators are exposed to).
