Trace Acoustic TA40R User manual

OPERATING
INSTRUCTIONS
ACOUSTIC
INSTRUMENT
AMPLIFIER
TA40R / TA40CR
TA60CR / TA80CR

INTRODUCTION
TA40R / TA40CR / TA60 / TA80
This range of portable amplification has been based on the preamplifier design of the Trace Acoustic
TA35 amplifier. The TA35 has been replaced by the TA40 - the only difference between these units is
a power upgrade from 35 watts to 40 watts rms.
The principle difference between the amplifiers is the power output and loudspeaker configuration.
The TA80 has power output stages delivering 40 watts rms each. These drive into 1 x 10” and 2 x
5” loudspeakers respectively. This configuration was found to be preferable to one 80 watt output
stage as the two power amplifiers each feature their own dynamic correction, enabling more
accurate reproduction of the total range of frequencies produced by an acoustic guitar. The open
back cabinet design produces a loud, more open sound that projects in a manner similar to that of
an electric guitar amplifier.
The TA60 is something of a departure from the standard Trace Acoustic range. It is a 50 watt
combo, delivering its power into 2 x 8” loudspeakers and a high frequency tweeter. This speaker
configuration gives a sound with more emphasised bass and treble frequencies, which is
particularly suited to those players who prefer a more ‘produced’ sound from their acoustic guitar.
By careful control of the equalisation and notch filters, a loud and natural sound can be obtained,
with accurate reproduction of the percussive attack of the strings and pick / fingers.
3

Input/Input switch
There is a single INPUT jack socket that will perfectly match ACTIVE instruments with their own
internal preamp and passive instruments with just a PIEZO pickup or transducer by selecting either
type with the switch adjacent to this socket.
With the input sensitivity set to PIEZO (switch out) the input impedance is extremely high i.e 4
million Ohms. This will perfectly match any PIEZO device giving a clear and accurate response with
no degradation to the signal.
With the input sensitivity set to ACTIVE (switch in) the impedance is much lower 47k Ohms and the
sensitivity much lower. This will match instruments with a built in preamp without fear of clipping
the input. If however your active instrument has an insufficient level of output to light the LEVEL
LED (as some do) then it is perfectly alright to switch back to the PIEZO setting to increase the
sensitivity to a level that works best with your instrument.
Input gain/level indication
The GAIN control should be set in conjunction with the LEVEL LED. When correctly set the amplifier
should perform with very little background noise. It is therefore important to set the GAIN control
correctly using the following method:
1. Plug the instrument into the input jack and select the appropriate INPUT sensitivity.
2. Play the instrument in the style that you would use it e.g. strumming, finger picking etc.
3. Increase the GAIN control until the LEVEL LED is lighting quite often.
4. Decrease the GAIN control so that the LEVEL LED is only lighting on peaks.
5. If the LED cannot be made to light whilst playing then do the following:-
If your instrument is an ACTIVE one then either turn its own level control up further or switch the
INPUT sensitivity to PIEZO and try again.
FRONT PANEL CONTROLS
GAIN LO-TRIM HI-TRIM NOTCHINPUT 1 INPUT PHASE
OFF
PIEZO
ACTIVE
IN PHASE
REVERSE
CHANNEL 1
GAIN LO-TRIM HI-TRIM NOTCHINPUT 2 INPUT PHASE
OFF
PIEZO
ACTIVE
IN PHASE
REVERSE
CHANNEL 2
BALANCE CHORUS
DEPTH LEVEL MASTER
LEVEL
CHAN 1 CHAN 2
SPEED
REVERB
POWER
PULL - SHAPE
TA40CR
LEVEL LEVEL
IN
OUT
IN
OUT
PULL - ONPULL - ON
4

If the instrument uses just a piezo pickup then you will have to leave the GAIN control set on
maximum as this is the best setting you can achieve.
N.B. as the LEVEL indication is driven from after the equalisation circuits, it may be necessary
to re-adjust the GAIN control once the equalisation has been altered.
Phase switch
The ‘PHASE’ switch has two distinct uses, firstly, by reversing the phase of the signal,
feedback from the guitar can very often be considerably reduced, this is dependent upon
the position of the player relative to the amplifier and the switch may need to be either
“in” or “out” depending on player position and the frequency of feedback. This is an ideal
way of reducing feedback as it introduces no change at all to the sound of the
instrument. However this will only work if the amplifier to player distance is fixed as is
often the case with a performer sitting down next to their amplifier.
The second use of the PHASE switch is with the dual pick up system where reversing the
phase of one channel can enhance the effectiveness of the dual pick up depending on the
position of the microphone within the body of the instrument. Again this can also
minimise the chances of feedback.
Description of how the ‘Phase’ switch reduces feedback
If the distance from the instrument to the amplifier is fixed i.e. the player is sitting down
next to or in front of their amplifier then the speakers reproducing the sound of the
instrument set up a series of standing waves, the length of these standing waves is
dependent upon their frequency.
Now as feedback from acoustic guitars is always at fairly low frequencies then the
standing waves associated with it are quite long. If you happen to be sitting at the node
(i.e. the most sensitive spot) of one of these standing waves then feedback is quite likely
to occur as the wave will tend to excite the body of the instrument into resonance.
If however you are sitting at the antinode (least sensitive spot) the feedback will be
unlikely to occur. By simply reversing the phase of the signal through the amplifier you
are in effect reversing the positions of the nodes and antinodes within the standing wave
and consequently changing your relative position in relation to the amplifier i.e. switching
yourself from sitting in a node to sitting in an antinode and thus reducing the likelihood
of feedback occurring.
5

Lo-trim control
The LO- TRIM control is for adjusting the bass end of the instruments sound. This is a BOOST
and CUT type of control i.e. its FLAT (no EQ) position is in its central position with BOOST when
the control is turned to the right and CUT when turned to the left.
The range and effect of this control has been tailored to best suit the requirements of an acoustic
instrument. In use try not to add too much BOOST as this increases the possibility of feedback
from the body of the instrument.
Always start with this control set to its central or FLAT position and get to know the amplified flat
sound of your instrument well before starting to add any equalisation.
Hi-trim control
The HI-TRIM control is for adjusting the treble end of the instrument sound. This is a BOOST and
CUT type of control i.e. its FLAT (no EQ) position is in its central position with BOOST when the
control is turned to the right and CUT when turned to the left.
The range and effect of this control has been tailored to best suit the requirements of an acoustic
instrument.
Always start with this control set to its central or FLAT position and get to know the amplified flat
sound of your instrument well before starting to add any equalisation.
Notch control
The NOTCH is a special type of control that removes a narrow band of frequencies from the audio
spectrum. The band of frequencies removed is kept very narrow so as not to unduly effect the
sound of the instrument. The NOTCH control adjusts where in the audio range this band of
frequencies is placed and within this unit the adjustable range has been optimised for acoustic
guitar.
This is an extremely useful device for an acoustic guitar as it allows the natural body resonance of
the instrument to be ‘Tuned Out’ which in turn enables a far higher level of amplification to be
achieved before feedback. The NOTCH may be switched ‘in’ and ‘out’ with the switch adjacent to
the NOTCH control.
To use the NOTCH facility to its best advantage first of all switch it ‘out’ of circuit, turn up the
MASTER LEVEL control until the instrument starts to feedback (it is very often the ‘A’ string that
goes first), switch the notch ‘in’ and adjust the NOTCH control until feedback either goes away or
is reduced. This is the optimum position for your instrument.
6

Feedback is the amplified sound of the guitar getting back to the instrument from the loud
speakers and exciting it into resonance. Your position relative to the amplification system will effect
the sensitivity of your instrument to feedback. If you have adjusted the NOTCH control to its
optimum position to reduce any initial feedback and you are still having trouble then you will either
have to change your position relative to the speakers use the PHASE switch or turn the unit down
a bit.
Channels
Two channels are available, both of these are identical in facilities. These may either be used for
two separate instruments or for a two pick up system where a piezo transducer is used on the
bridge and a small microphone is used inside the guitar. In this instance each of the two pick ups
would have their own individual channel for adjustment.
Balance slider
The BALANCE slider allows the two channels to be balanced one against the other in level and is
ideal for the two pick up system described above to achieve a good balance between the piezo pick
up and the microphone.
Master level control
This sets the overall volume and should not need to be set beyond 1/4 to 1/2 its full scale for
normal use of the unit. If it needs to be turned beyond these settings then you have not got the
input GAIN correctly adjusted, consequently you will have more background noise than you
should. Reduce the setting of the MASTER LEVEL control and increase the setting of the input
GAIN control to improve this situation.
Pull shape
In addition to the HI and LO TRIM equalisation controls there is a PRESHAPE facility built into the
unit. This may be switched ‘in’ and ‘out’ with the PULL switch on the MASTER LEVEL control.
The PRESHAPE facility is like a preset graphic equaliser built in, that you can switch in and out to
modify the sound of the instrument.
The PRESHAPE is the classic TRACE ACOUSTIC shape as found on the TA50, TA100 and TA200
amplifiers, it adds a boost at both the low end and the high end of the frequency spectrum as well
7

as a cut at mid frequencies. Its sound is ideal for both finger picking and strumming styles of
playing and adds a ‘Sparkle” to the amplified sound.
Chorus
The chorus is switched into circuit with the PULL switch on the chorus DEPTH control. There is
also a foot switch socket on the rear of the unit for switching the chorus in and out, however the
front panel switch must already be ‘on’ for this footswitch facility to function.
The CHORUS section has controls for the DEPTH and the SPEED of the effect and when switched
into the circuit it effects both channels equally.
Reverb
A spring REVERB is provided and is switched into the circuit with the PULL switch on the reverb
LEVEL control. There is also a foot switch socket on the rear of the unit for switching the reverb in
and out, however the front front panel switch must already be ‘on’ for this footswitch facility to
function.
On the TA40R the reverb has controls for level and tone. On the other models only a level control
is available.
Mains inlet socket
The MAINS INLET SOCKET is placed on the rear panel. Above this the required mains voltage will
be clearly marked. Make sure this is correct for your country prior to connecting the supply to the
unit.
BACK PANEL CONTROLS
MANUFACTURED IN ENGLAND BY:- TRACE ELLIOT LIMITED
MAINS INPUT 65VAEARTH LIFT
MODEL:-
OUTPUT POWER
35 WATTS RMS
70 WATTS PEAK
THIS APPARATUS MUST BE EARTHED.
FOR CONTINUED PROTECTION
AGAINST RISK OF FIRE REPLACE
ONLY WITH SAME TYPE AND
RATING OF FUSE
WARNING
TO REDUCE THE RISK OF FIRE OR
ELECTRICAL SHOCK DO NOT
EXPOSE THIS EQUIPMENT TO RAIN
OR MOISTURE. DO NOT OPEN -
NO USER SERVICABLE PARTS INSIDE
- DANGER OF ELECTRICAL SHOCK -
REFER TO QUALIFIED ENGINEER
FOR SERVICE.
WARNING
50/60Hz
V A.C.
MAINS FUSE
230v-
T500mA
115v-T1A
SERIAL No:-
POWER ONOFF LINK/D.I.
FOOTSWITCH
RING = CHORUS
TIP = REVERB
8

Mains fuse
The amplifier should be supplied with the correct fuse fitted for your country. If it is necessary to
change this fuse at any time replace it only with one of the same type and rating as indicated for
your countries voltage adjacent to the fuse holder.
Power On/Off
This is located on the rear panel and is clearly marked as to which position is ON or OFF. Make
sure this switch is in its OFF position prior to connecting the mains supply cable.
Earth lift switch
An EARTH LIFT switch is provided to allow removal of the mains earth from the signal circuits to
eliminate ground loops between connected equipment.
This amp as with all TRACE ELLIOT equipment still maintains an earth connection to the chassis
and all metal parts of the unit for safety reasons even when the EARTH LIFT switch is operated.
NEVER lift the earth or grounding to any equipment by removal of the earth connection in the
mains plug, this can be a potential dangerous practice and in some instances prove fatal to both
the equipment and the user.
Footswitch socket
On the chorus models a stereo jack socket is provided for foot switching both the chorus and
reverb. A two way foot switch unit is available from TRACE ELLIOT for this purpose.
On the TA40R unit any single latching footswitch may be used with a mono jack plug for switching
the reverb.
Link/D.I socket
This jack socket may be used as a LINE OUT to other equipment or as a link to another unit for
further sound reinforcement. Used as a LINK to another unit all that is required is a single jack to
jack cable plugged from the LINK socket on the first amp to the LINK socket on the second.
Each MASTER LEVEL control will set the volume of its own amplifier and sound will come from
units regardless of which preamp is used.
This socket may also be used as a LINE IN if required.
9

TECHNICAL SPECIFICATIONS
input
Impedance PIEZO = 4 Meg Ohms
ACTIVE = 47k Ohms
Sensitivity PIEZO = 150mV to 6V
ACTIVE = 300mV to 12V
Link/D.I.
Impedance 47k Ohms
Signal Level 300mV Nominal
Equalisation
Lo/Trim + & - 15dB @ 150 HZ Acoustically tailored shape
Hi-Trim + & - 15dB @ 5KHZ Acoustically tailored shape
Notch
Range 60 to 300HZ
Attenuation -18dB
Output
Power (TA40) 40 Watts RMS into 2 x 5” speakers
with Dynamic Correction
Power (TA60) 50 Watts RMS into 2 x 8” speakers
with Dynamic Correction
Power (TA80) 80 Watts RMS into 2 x 5” + 1 x 10” speakers
with Dynamic Correction
Enclosure Slit Ported - Tuned Reflex
Reverb
Type 3 spring - medium decay - shock mounted
Chorus
Type Analogue with SPEED and DEPTH control
Enclosure
TA40 Slit ported - tuned reflex
TA60 / TA80 Open back cabinet construction
10

11
SAFETY INSTRUCTIONS
Warning
For continued protection against the risk of fire, replace fuses only with fuses of the same type
and rating.
To reduce the risk of fire or electric shock, do not expose this equipment to rain or moisture.
In the event of a suspected malfunction, always refer this equipment to a qualified service
engineer.
This apparatus must be earthed. The wires in this mains are coloured in accordance with the
following code:-
Green& Yellow - Earth Blue - Neutral Brown - Live
As the colours of the wires in the mains lead of this appliance may not correspond with the
coloured markings identifying the terminals in your plug, proceed as follows:-
The wire which is coloured Green & Yellow must be connected to the terminal in the plug which
is marked with the letter E or by the earth symbol or coloured green or Green and Yellow.
The wire which is coloured Blue must be connected to the terminal which is marked with the
letter N or coloured Black.
The wire which is coloured Brown must be connected to the terminal which is marked with the
letter L or coloured Red.
If A 13 amp (BS1363) plug is used a 13 amp fuse must be fitted, or if any other type of plug is
used a 15 amp fuse must be fitted either in the plug or adaptor or at the distribution board.
EMC Warning
It is inherent in the design of a loudspeaker and in the design of guitar pickups that they should
emit or be affected by electro magnetic fields. Trace Elliot loudspeaker enclosures should not be
used less than 2 metres away from equipment which is likely to be affected by electro magnetic
interference.
Likewise, guitars fitted with electro magnetic pickups should not be used less than 2 metres away
from any source of electro magnetic emissions such as loudspeakers.
Emissions from loudspeakers are dependent on the frequency characteristic of the drive unit.
Levels were measured direct from the drivers of 30 dBuV.
These levels are reduced to a safe level at a distance of 1.27 metres from the drivers.
CONSIGNES DE SECURITE
Attention
Pour une protection continue contre les incendies, ne remplacez les fusibles que par des fusibles
du mÍme type et du mÍme courant nominal.
Pour réduire le risque díincendie ou de décharge électrique, níexposez jamais cet équipement à la
pluie ou à líhumidité.
Si vous soupÁonnez une défaiilance, faites toujours appel à un ingénieur qualifié.
Cet appareil doit Ítre mis à la masse. Les fils de cette conduite díamenée de secteur sont colorés
selon le code suivant:
Vert & Jaune - Masse Bleu - Neutre Marron - Tension
Etant donné que les couleurs des fils de la conduite díamenée de secteur de cet appareil risquent
parfois de ne pas correspondre aux couleurs identifiant les bornes de votre fiche, procédez
comme suit:
Le fil Vert & Jaune doit Ítre relié à la borne de la fiche marquée de la lettre E, du symbole de terre
ou colorée en Vert et Jaune.
Le fil Bleu doit Ítre relié à la borne marquée de la lettre N ou colorée en Noir.
Le fil Marron doit Ítre relié à la borne marquée de la lettre L ou colorée en Rouge.
Si vous utilisez une fiche 13 amp (BS1363) vous devez utiliser un fusible 13 amp. Si vous utilisez
un autre type de prise, installez un fusible 15 amp dans la prise, dans líadaptateur ou dans le
tableau de distribution.
Compatibilité électromagnétique - avertissement
La conception d’un haut-parleur et des pickups de guitare est telle qu’ils sont affectés par des
champs électromagnétiques ou en émettent les enceintes de haut-parleur Trace Elllot ne devraient
pas étre utilisées à moins de 2 mètres de l’équipement susceptible d’être affecté par les parasites
électromagnétiques.
Les émissions en provenance de haut-parleurs dépendent de la caractéristique fréquentielle de
l’émetteur piloté.
De même, les guitares équipées de pickups électromagnétiques ne devraient pas être utilisées à
moins de 2 mètres de toute source d’émissions électromagnétiques telles que des haut-parleurs.
Les niveaux ont été mesurés directement à partir des drivers de 30 dBuV.
Ces niveaux sont réduites à un niveau sûr à une distance de 1,27 mètre des drivers.
SICHERHEITS-ANWEISUNGEN
Warnung
Zum fortdauernden Schutz gegen Feuerrisiken die Sicherungen nur durch Sicherungen desselben
Typs und derselben Nennleistung austauschen.
Um das Risiko von Feuer oder Elektroschock zu reduzieren, dieses Gerät keinem Regen und
keiner Feuchtigkeit aussetzen.
Im Fall eines vermuteten Defekts muß dieses Gerät einem qualifizierten Service-Techniker
übergeben werden.
Dieses Gerät muß geerdet werden. Die Drähte im Stromkabel wurden dem folgende Code nach
koloriert:
Grün & Gelb - Erde Blau - Neutral Braun - Stromführend
Da die Farben der Drähte dieses Geräts nicht notwendigerweise den Farbmarkierungen der Pole
in Ihrem Stecker entsprechen, sollten Sie wie folgt vorgehen:
Der grün/gelbe Draht muß an den Pol im Stecker angeschlossen werden, der mit dem
Buchstaben E oder dem Erde-Symbol oder der Farbe Grün oder Grün/Gelb markiert ist.
Der blaue Draht muß an den Pol angeschlossen werden, der mit dem Buchstaben N oder
schwarz markiert ist.
Der braune Draht muß an den Pol angeschlossen werden, der mit dem Buchstaben L oder rot
markiert ist.
Falls ein 13 amp (BS1363) Stecker benutzt wird, muß eine 13 amp Sicherung eingesetzt werden;
und falls ein Stecker anderer Art benutzt wird, muß eine 15 amp Sicherung entweder im Stecker
selbst oder an der Verteilertafel eingesetzt werden.
EMC Warnung
Es liegt im Design eines Lautsprechers und im Design von Gitarrenaufnehmern, daß sie
elektromagnetische Felder abgeben oder von solchen beeinflußt werden. Trace Elliot
Lautsprechergehäuse sollten daher nicht in unter 2 Metern Entfernung von Geräten benutzt
werden, die durch elektromagnetische Störungen beeinflußt werden könnten.
Auch sollten Gitarren, die mit elektromagnetischen Aufnehmern ausgestattet sind, nicht in unter
2 Metern Entfernung von Quellen elektromagnetischer Emissionen, wie z.B. Lautsprechern,
benutzt werden.
Die Lautsprecheremissionen sind von der Frequenzcharakteristik der Treiber-Einheit abhängig.
Die Werte wurden direkt von den Treibern von 30 dBuV gemessen.
Diese Werte reduzieren sich in einer Entfernung von 1,27 Metern von den Treibern auf ein
sicheres Maß.
INSTRUCCIONES DE SEGURIDAD
Advertencia
Para una protección continua contra el riesgo de incendio, reemplace siempre los fusibles con
otros del mismo tipo y valor.
Para reducir el riesgo de incendio o descarga eléctrica, no exponga este equipo a la lluvia o a la
humedad.
En caso de que sospeche que exista un desperfecto, refiera siempre este equipo a un ingeniero
de servicio calificado.
Este aparato debe tener conexión a tierra. Los cables de esta toma se colorean según el código
siguiente:-
Verde & Amarillo - Tierra Azul - Neutro Marrón - Vivo
Como los colores de los cables de la toma principal de este aparato pueden no corresponder con
los colores marcados que identifican los terminales en su enchufe, proceda como se indica a
continuación:-
El cable verde y amarillo debe conectarse al terminal del enchufe marcado con la letra E, por el
símbolo de tierra, o pintado de verde o verde y amarillo.
El cable azul debe conectarse al terminal marcado con la letra N o pintado de negro.
El cable pintado de marrón debe conectarse al terminal marcado con la letra L o pintado de Rojo.
Si se usa un enchufe de 13 amperios (BS 1363), se deberá poner un fusible de 13 amperios, o un
fusible de 15 amperios si se usa cualquier otro tipo de enchufe, ya sea en el enchufe, en el
adaptador o en la placa de distribución.
Advertencia EMC (de compatibilidad electromagnética)
Es inherente en el diseño de un altavoz y en el de las pastillas de guitarra que emitan o se vean
afectados por campos electro magnéticos. Los recintos de los altavoces Trace Elliot no deberán
usarse a menos de 2 metros de distancia de cualquier equipo que pueda ser afectado por
interferencias electromagnéticas.
Asimismo, las guitarras que tienen pastillas electromagnéticas no deberán usarse a menos de 2
metros de distancia de ninguna fuente de emisiones electromagnéticas tales como los altavoces.
Las emisiones de los altavoces dependen de la característica de frecuencia del equipo de
accionamiento.
Los niveles se midieron directamente desde unidades de accionamiento de 30 dBuV.
Estos niveles se reducen a un nivel seguro a una distancia de 1,27 metros desde las unidades de
accionamiento.

SIKKERHETSANVISNINGER
Advarsel!
For å hindre fare for brann må du alltid skifte en røket sikring ut med en av samme type og
størrelse.
For å redusere faren for brann eller støt må høyttaleren ikke utsettes for regn eller fuktighet.
Hvis du har den minste mistanke om feil må høyttaleren repareres av en kvalifisert tekniker.
Høyttaleren må jordes. Ledningene har følgende fargekode:
Grønn og gul - jord Blå - nøytral Brun - strømførende.
Hvis fargekoden ikke stemmer overens med støpselets fargekoder, går du frem slik:
Den grønne og gule ledningen må kobles til støpselets terminal merket E eller med
jord–symbolet, eller farget grønn og gul.Den blå ledningen må kobles til terminalen merket N eller
farget sort.Den brune ledningen må kobles til terminalen merket L eller farget rød.Høyttaleren må
kobles til en 16 ampere krets.
Advarsel – elektromagnetisk forenlighet
Alle høyttalere og pick–up'er til gitarer gir nødvendigvis fra seg eller påvirkes av
elektromagnetiske felter. Trace Elliot–høyttalerkabinetter må ikke brukes mindre enn 2 m fra utstyr
som trolig kan påvirkes av elektromagnetisk støy.
Gitarer med elektromagnetisk pick–up må likeledes ikke brukes mindre enn 2 m fra en
elektromagnetisk kilde, som f.eks. høyttalere.Utstrålingen fra en høyttaler avhenger av
frekvenskarakteristikken til driver–enheten.Nivåene ble målt direkte fra utganger på 30 dBuV.
Disse nivåene faller til et trygt nivå i en avstand av 1,27 m fra utgangene.
SÄKERHETSFÖRESKRIFTER
Varning
För oavbrutet skydd mot brandrisk, byta ut säkringar endast med samma typ av säkring och
styrka.
För att minska risken för brand eller elektriska stötar, utsätt inte utrustningen för regn eller fukt.
I händelse av en oförutsedd felaktig funktion så vänd er alltid en behörig serviceingenjör.
Denna apparat måste vara jordad. Ledningarna i stickproppen har färger enligt följande kod:
Grön och gul - Jordning Blå - Neutral Brun - Spänningsförande
Eftersom färgerna i apparatens sladd kanske inte överensstämmer med färgmarkeringarna som
identifierar terminalerna i stickproppen, gör enligt följande:
Den ledning som är grön och gul måste anslutas till den terminal i stickproppen som markeras
med bokstaven E eller genom jordsymbolen eller grön och gul färg.
Den ledning som är blå måste anslutas till den terminal som är markerad med bokstaven N eller
svart färg.
Den ledning som är brun måste anslutas till den terminal som är markerad med bokstaven L eller
röd färg.
Om en A 13 amp (BS1363) stickpropp används måste en 13 amp säkring användas eller om
någon annan sorts stickpropp används måste en 15 amp säkring användas i stickproppen eller i
en förgreningspropp eller i fördelningstavla.
Emissionsströmsvarning
Det är ingår i konstruktionen på högtalare och gitarrers pick-uper att de skall påverkas av
elektromagnetiska fält. Trace Elliots högtalarlådor skall inte användas närmare än 2 meter från
utrustning som kan påverkas av elektromagnetiska störningar.
Gitarrer som har elektromagnetiska pick-uper monterade skall heller inte användas mindre än två
meter bort från någon källa med elektromagnetisk emission, som t ex högtalare.
Emissionen från högtalare beror på drivenhetens frekensfunktion.
Nivåer uppmätta direkt från drivenheten var på 30 dBuV.
Dessa nivåer reduceras till en säker nivå på ett avstånd av 1,27 meter från drivenheterna.
TURVAOHJEET
Varoitus
Palovaaran välttämiseksi käytä aina samantyyppisiä ja -tehoisia sulakkeita.
Vähentääkseksi tulipalo- ja sähköiskuvaaraa pidä tämä laite poissa sateesta äläkä altista sitä
kosteudelle.
Jos epäilet laitteen toimivan virheellisesti, ota aina yhteys ammattitaitoiseen huoltohenkilöön.
Tämä laite täytyy maattaa. Tämän laitteen johdot on koodattu seuraavasti:
Vihreä & keltainen - maa Sininen - neutraali Ruskea - jännitteinen
Koska tämän laitteen verkkojohdon värit saattavat erota liittimen värimerkinnöistä, toimi
seuraavasti:
Vihreä & keltainen johto täytyy yhdistää pistokkeen liittimeen, joka on merkattu E:llä tai
maattosymbolilla tai joka on väriltään vihreä tai vihreä ja keltainen.
Sininen johto täytyy yhdistää liittimeen, joka on merkattu N-kirjaimella tai joka on väriltään musta.
Ruskea johto täytyy yhdistää liittimeen, joka on merkattu L-kirjaimella tai joka on punainen.
Käytettäessä 13 ampeerin (BS1363) pistoketta täytyy siihen laittaa 13 ampeerin sulake. Jonkin
muun tyyppistä pistoketta käytettäessä täytyy 15 ampeerin sulake laittaa joko pistokkeeseen,
adapteriin tai jakelutauluun.
Sähkömagneettista virtaa koskeva varoitus
Kaiuttimien ja kitaran mikrofonin suunnitteluun kuuluu lunnostaan se, että
niiden tulee säteillä sähkömagneettista kenttää tai tämän tulee vaikuttaa niihin. Trace
Elliot -kaiuttimia ei saisi käyttää 2 metriä lähempänä sellaisia laitteita joihin sähkömagneettinen
kenttä vaikuttaa häiritsevästi.
Myöskään kitaroita, joissa on sähkömagneettiset mikrofonit ei saisi käyttää 2 metriä lähempänä
mitään sähkömagneettista lähdettä, kuten kaiutinta.
Kaiuttimien päästöjen voimakkuudet ovat riippuvaisia teholähteen taajuudesta.
Voimakkuustasot mitattiin suoraan 30 dBuV:n lähteestä.
Nämä tasot laskevat turvalliselle tasolle oltaessa 1, 27 metrin etäisyydellä teholähteestä.
VEILIGHEIDSVOORSCHRIFTEN
Waarschuwing
Voor bestendige bescherming tegen het gevaar van brand dienen zekeringen alleen vervangen te
worden met zekeringen van hetzelfde type en van dezelfde waarde.
Om het risico van brand of elektrische schok te verminderen, wordt aanbevolen dat de uitrusting
niet wordt blootgesteld aan regen of vocht.
In het geval van een verdacht defect dient altijd de hulp ingeroepen te worden van een bevoegde
onderhoudsmonteur.
Deze apparatuur moet geaard worden. De draden in deze netspanning zijn gekleurd in
overeenstemming met de volgende code:
Groen & Geel - Aardverbinding Blauw - Neutraal Brown - Stroomvoerend
Daar de kleuren van de draden in de netspanning niet overeenkomen met de gekleurde
markeringen van de klemmen in uw stekker, dient u als volgt te werk te gaan:
De Groen & Geel gekleurde draad dient verbonden te worden met de klem in de stekker die
gemarkeerd is met de letter E of met het aardesymbool of groen of Groen en Geel gekleurd is.
De Blauwe draad dient verbonden te worden met de klem die gemarkeerd is met de letter N of
zwart gekleurd is.
De Bruine Draad dient verbonden te worden met de klem die met de letter L gemarkeerd of Rood
gekleurd is.
Wanneer 13 amp. (BS1363) stekker gebruikt wordt dient een 13 amp. zekering aangebracht te
worden, wanneer een ander type stekker wordt gebruikt dient een 15 amp. zekering aangebracht
te worden in de stekker of adapter of in de verdeelkast.
EMC (Electromagnetic compatibility) [bestendigheid tegen elektromagnetische storingen]
Waarschuwing
Het is inherent in het ontwerp van een luidspreker en in het ontwerp van guitaar tastelementen
dat zij elektromagnetische velden emitteren of er door beïnvloed worden. Trace Elliot luidspreker
omkastingen dienen niet gebruikt te worden op een afstand van minder dan 2 meter van de
uitrusting, daar deze beïnvloed zouden kunnen worden door elektromagnetische storing.
Evenzo dienen guitaren uitgerust met elektromagnetische tastelementen niet gebruikt te worden
op een afstand van minder dan 2 meter van een bron van elektromagnetische emissies, zoals
luidsprekers.
Emissies van luidsprekers zijn afhankelijk van de frequentie die kenmerkend is voor de
aandrijfinrichting.
Niveaus van 30 dBuV werden rechtstreeks van de aandrijvers gemeten. Deze niveaus zijn
verminderd tot een veilig niveau op een afstand van 1.27m van de aandrijvers.
12

ÖRYGGISRÁ–DSTAFANIR.
Ao
✗
vörun.
Vio
✗
varandi vernd gegn eldhættu gerir nauo
✗
synlegt ao
✗
endurn´yja öryggi einvöro
✗
ungu meo
✗
nákvæmlega samskonar öryggjum.
Til ao
✗
draga úr eldhættu eo
✗
a pví ao
✗
fá rafstraum ber ao
✗
gæta pess ao
✗
rigning eo
✗
a komist ekki ao
✗
tækinu.
Ef grunur leikur á bilun ber jafnan ao
✗
leita til löggilts vio
✗
gero
✗
armanns.
Tækio
✗
vero
✗
ur ao
✗
vera jaro
✗
tengt. Leio
✗
slurnar í rafmagnio
✗
eru litao
✗
ar samkvæmt eftirfarandi kerfi:
Grænar og gular - jöro
✗
Blaár - núll Brúnar - straumur
Meo
✗
pví litirnir á leio
✗
slum tækisins kunna ao
✗
vera í ósamræmi vio
✗
litamerkingar á innstungu yo
✗
ar
ber ao
✗
fara pannig ao
✗
:
Leio
✗
sluna, sem er græn og gul, ber ao
✗
tengja í innstungu par sem merkt er E eo
✗
a jöro
✗
eo
✗
a er
græn og gul ao
✗
lit.
Leio
✗
sluna, sem er blá, ber ao
✗
tengja í klemmuna par sem merkt er N eo
✗
a sem er svört.
Leio
✗
sluna, sem er brún, ber ao
✗
tengja í klemmuna par sem merkt er L eo
✗
a sem er rauo
✗
.
Ef A 13 amp. (BS1363) innstunga er notuo
✗
ber ao
✗
hafa 13 amp. öryggi eo
✗
a ef önnur
innstungugero
✗
er notuo
✗
ber ao
✗
hafa 15 amp. öryggi annao
✗
hvort á innstungunni eo
✗
a millistykkinu
í töflunni.
EMC ao
✗
vörun.
pao
✗
er föst regla vio
✗
hönnun hátalara og gítargrípa ao
✗
peir gefi frá sér eo
✗
a vero
✗
i fyrir áhrifum af
rafsegulsvio
✗
m. Trace Elliot hátalarakerfi ætti ekki ao
✗
nota í innan vio
✗
2 metra fjarlægo
✗
frá tækjum,
sem kynnu ao
✗
vero
✗
a fyrir áhrifum rafsegultruflana.
Ekki ætti heldur ao
✗
nota gítara meo
✗
rafsegulgrípa í innan vio
✗
2 metra fjarlægo
✗
frá hverskyns
rafsegulútsendingum eins og hátölurum.
Útsendingar frá hátölurum fara eftir tío
✗
nieinkennum driftækisins.
Hávao
✗
amörkin voru mæld beinlínis frá drifum 30 BuV.
Hægt er ao
✗
lækka pau ao
✗
öruggum mörkum í 1.27 metra fjarlægo
✗
frá drifunum.
INSTRUÇÕES DE SEGURANÇA
Aviso
Para protecção contÌnua contra o risco de fogo, substitua os fusíveis só com fusíveis do mesmo
tipo e taxação.
Para reduzir o risco de fogo ou de choque elèctrico, não exponha este equipamaento a chuva ou
humidade.
No caso de suspeita de mau funcionamento, consulte sempre um mecânico de serviço
devidamente qualificado.
Este aparelho deve ser ligado à terra. Os fios neste sector são coloridos em conformidade com
o seguinte código:-
Verde e Amarelo - Terra Azul - Neutro Castanho - Vivo
No caso das cores dos fios no cabo deste aparelho não corresponderem com as marcações em
cor que identificam os terminais na ficha proceda como se segue:-
O fio Verde e Amarelo deve ser ligado ao terminal na ficha marcado com a letra E ou pelo
simbolo à terra ou com a cor verde ou Verde e Amarela.
O fio Azul deve ser ligado ao terminal marcado com a letra N ou com a cor Preta.
O fio castanho deve ser ligado ao terminal marcado com a letra L ou com a cor Vermelha.
Se for usada uma ficha de 13 amp (BS1363) deve ser montado um fusível de 13 amp, se for
usada qualquer outro tipo de ficha tem de ser montado um fusível de 15 amp ou na ficha, ou no
adaptador ou no quadro de distribuição.
Aviso CEM
É inerente ao design de alto-falantes e ao design de reprodutores de guitarras que devem emitir
ou ser afectados por campos electromagnéticos. As coberturas dos alto-falantas Trace Elliot não
devem ser usadas a menos de 2 metros do equipamento que pode ser afectado pela interferíncia
electromagnética.
Igualmente, as guitarras equipadas com reprodutores electromagnéticos não devem ser usadas
a menos de 2 metros da fonte de emissões electromagnéticas tais como alto-falantes.
As emissões dos alto-falantes dependem da característica de frequíncia da unidade accionadora.
Os níveis foram medidos directamente de accionadores de 30 dBuV.
Estes níveis são reduzidos para um nível seguro a uma distância de 1,27m dos accionadores.
ISTRUZIONI PER LA SICUREZZA
Avvertenza
Per assicurarsi di essere sempre protetti contro il rischio di incendi, sostituire i fusibili soltanto
con altri dello stesso tipo e potenza.
Non esporre l'attrezzatura alla pioggia o umidità per ridurre il rischio di incendi o shock elettrici.
Se si sospetta una malfunzione, consultare sempre un tecnico esperto in questo settore.
L'attrezzatura deve essere messa a terra. I fili sono stati colorati secondo il codice seguente:
Giallo e verde - Terra Blu - Neutro Marrone - Sotto tensione
Dato che i colori dei fili nel cavo elettrico del prodotto possono non corrispondere ai segni
colorati che identificano i terminali della spina, procedere come segue:–
Il filo di color giallo e verde deve essere collegato al terminale nella spina marcata con la lettera E
o con il simbolo terra, oppure di colore verde o verde e giallo.
Il filo di colore blu deve essere collegato al terminale che mostra la lettera N oppure di color
nero.
Il filo di color marrone deve essere collegato al terminale che mostra la lettera L oppure di color
rosso.
Con una una spina di 13 amp (BS1363), si deve usare un fusibile di 13 amp. Con qualsiasi altro
tipo di spina inserire un fusibile di 15 amp nella spina, nell'adattatore o nel quadro di
distribuzione.
Avvertenza EMC (per la compatibilità elettromagnetica)
Nel design di altoparlanti o di fonorivelatori di una chitarra, è inerente il fatto che raccoglieranno
o saranno influenzati da campi elettromagnetici. Le custodie per altoparlanti Trace Elliott non
dovrebbero essere poste lontano meno di 2 metri dall'attrezzatura che potrebbe risentire
dell'interferenza elettromagnetica.
Allo stesso modo, non usare le chitarre con fonorivelatori elettromagnetici ad una lontananza
inferiore a 2 metri da qualsiasi sorgente di emissioni elettromagnetiche come altoparlanti.
Le emissioni da altoparlanti dipendono dalla caratteristica di frequenza dell'unità di comando.
I livelli sono stati misurati direttamente da unità di comando di 30 dBuV; il livello sicuro è ad una
distanza di 1,27 metri dalle unità.
SIKKERHEDSINSTRUKTIONER
Advarsel
For vedvarende beskyttelse imod risikoen for brand, må sikringerne kun udskiftes med sikringer
af samme type og størrelse.
For at reducere risikoen for brand og elektrisk chok må dette udstyr ikke udsættes for regn eller
fugt.
Hvis man har mistanke om, at der er en fejl i udstyret, skal man altid henvende sig til en
faguddannet servicetekniker.
Dette apparat skal have jordforbindelse. Lederne i el–ledningen er farvet efter følgende kode:
Grøn og gul - Jord Blå - Nulleder Brun - Spændingsførende
Fordi ledernes farver i dette apparats el–ledning evt. ikke svarer til de farvede afmærkninger, der
identificerer klemmerne i stikket, skal man gå frem på følgende måde:
Den leder, som er farvet grøn/gul, skal forbindes med klemmen i stikket, der er afmærket med
bogstavet E eller med jordsymbolet eller som er grøn eller grøn/gul.
Den blå ledning skal forbindes med den klemme, der er afmærket med bogstavet N eller som er
sort.
Den brune ledning skal forbindes med den klemme, der er afmærket med bogstavet L eller som
er rød.
Hvis der anvendes et 13A (BS1363) stik, skal der monteres en 13A sikring. Hvis der anvendes en
anden type stik, skal der sættes en 15A sikring i stikket eller snydeproppen eller på
strømfordelingstavlen.
EMC advarsel
Højttalere og guitar–pickups er konstrueret således, at de udsender eller påvirkes af
elektromagnetiske felter. Trace Elliot højttalerkabinetter må ikke placeres mindre end 2 meter fra
udstyr, der sandsynligvis vil blive påvirket af elektromagnetiske forstyrrelser.
Ligeledes bør guitarer, som er udstyret med elektromagnetiske pickups, ikke anvendes mindre
end 2 meter væk fra en kilde til elektromagnetiske emissioner som f.eks. højttalere.
Emissioner fra højttalere afhænger af drivaggregatets frekvens. Niveauer måles direkte fra
drivaggregater på 30 dBuV.
Disse niveauer reduceres til et sikkert niveau i en afstand af 1,27 m fra drivaggregaterne.
13

ΟΟ∆∆ΗΗΓΓΙΙΕΕΣΣΑΑΣΣΦΦΑΑΛΛΕΕΙΙΑΑΣΣ
ΠΠρροοεειιδδοοπποοιιηη
Για συνεχη προστασι´α απο´τον κινδυνο ϕωτια´ς, αβτικαταστη´στε τις ασϕα´λειες µο´νο
µε αοϕα´λειες του ι´διου τυ´που και της ι´διας αναλογιας.
Για να µειωσετε τον κι´νδυνο της ϕωτια´ς η´την ηλεκτροπληξι´α, µην εκτι´θετε τον
εξοπλισµο´στη βροχη´η´οτην υγρασι´α.
Σε περι´πτωση που υποψια´ζεστε κα´πιοια δυσλειτουρλι´α, πα´ντοτε να παραπε´µπετε
αυτη´τη συσκευη´σε καταρτισµε´νο µηχανικο´σε´ρβις.
Η συσκευη´αυτη´πρε´πει να διαθε´τει γει´ωση. Τα συ´ρµατα στην κεντρικη´παροχη´
ρευ´µατος ειναι ε´γχρωµα συ´µϕωνα µε τον ακο´λουθο κωδικο´:
ΠΠρραα
´σσιιννοο&&ΚΚιιττρριιννοο−−ΓΓεειι ´ωωααηηΜΜππλλεε ´−−ΟΟυυδδεε ´ττεερροοΚΚααϕϕεε ´−−ΗΗλλεεκκττρροοϕϕοο ´ρροο
Μια και τα χρω´µατα στο συ´ρµα της κεντρικη´ς παροχη´ς αυτη´ς της συσκευη´ς µπορει´
να µην αντιστοιχου´ν µε τα ε´γχρωµα σηµα´δια που ταυτιζουν τους ακροδε´κτες στην
πρι´ζα σας, προχωρη´στε ως εξη´ς:−
Το συ´ρµα που ε´χει χρω´µα Πρα´σινο & Κιτρινο πρε´πει να σονδε´εται µε τον ακροδε´κτη
στην πρι´ζα που ει´ναι σηµειωµε´νος µε το γρα´µµα Ε η´µε το συ´µβολο γει´ωσης η´µε το
πρα´σινο χρω´µα η´µε το Πρα´σινο & Κι´τρινο.
Το αυ´ρµα που ε´χει χρω´µα Μπλε πρε´πει να συνδε´εται στον ακροδε´κτη που ει´ναι
σηµειωµε´νος µε το γρα´µµα Ν η´το Μαυ´ρο χρω´µα.
Το συ´ρµα που ε´χει χρω´µα Καϕε´πρε´πει να συνδε´εται µε τον ακροδε´κτη που ε´ιναι
σηµειωµε´νος µε το γρα´µµα Lη´το Κο´κκινο χπω´µα.
Εα´ν ξρησιµοποιει´ται πρι´ζα Α 13 αµπε´ρ (ΒS1363) θα πρε´πει να εϕαρµο´ζεται ασϕα´λεια
των 13 αµπε´ρ, η´εα´ν χρησιµοποιει´ται οποιοδη´ποτε α´λλο ει´δος πρι´ζας θα πρε´πει να
εϕαρµο´ζεται ασϕα´λεια των 15 αµπε´ρ ει´τε στην πρι´ζα η´στο µετασχηµατιστη´η´στον
πι´νακα διανοµη´ς.
ΠΠρροοεειιδδιιπποοιιηηοοηηττηηςςΕΕΜΜC
Ει´ναι αναγκαι´ο ο´πως στο σχε´διο του µεγαϕω´νου και στο σχε´διο πικα´π κιθα´ρας
πρε´πει να εκπε´µπουν η´να επηρεα´ζονται απο´τα ηλεκτροµαγνητικα´πεδι´α. Τα
εσω´κλειστα µελαϕω´νου της TRACE ELLIOT να µην χρησιµοποιου´νται λιγο´τερο απ´ο 2
µε´τρα µακρια´απο´τη συσκευη´που πιθανο´ν να επηρεα´ζονταιι απο´ηλεκτροµαγνητικη´
παρε´µβαση.
Επι´οης, οι κιθα´ρες που εϕαρµο´ζονται µε ηλεκρροµαγνητικα´πικα´πς δεϖ πρε´πει να
χρησιµοποιου´νται λιγο´τερο απο´2 µε´τρα απο´σταση απο´πηγη´ηλεκτροµαγνητικη´ς
εκποµπη´ς, ο´πως τα µεγα´ϕωνα.
Εκποµπε´ς απο´µεγα´ϕωνα εξαρτω´νται απο´το χαρακτηριστικο´της συχνο´τητας της
συσκευη´ς µετα´δοσης κι´νηοης.
Οι βαθµοι´καταµετρη´θηκαν απευθει´ας απο´το επιπεδο οδηγου´των 30 dBuV.
Αυτα τα´επι´πεδα µειω´νονται για ασϕαλε´ς επι´πεδο σε ασϕαλη´βαθµο´απο´στασης 1,27
µε´τρα απο´τους οδηγου´ς.
14
