TradeQuip 1003 User manual

Product Code: 1003
OWNER’S MANUAL
PRODUCT CODE: 1003
90 LITRE PARTS WASHER
Tank Dimensions
Max. Fluid
Capacity
Min. Fluid
Capacity
Pump Type
Pump Flow
Rate
Overall Dimensions
758x527x275mm
45 Litres
18 Litres
240V 50Hz
3.15L per min
780x540x908mm

Product Code: 1003
Page 2
WARNING
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE
WARNING
The instructions and warnings contained in this manual should be read and understood before
using or operating this equipment. Do not allow anyone to use or operate this equipment until
they have read this manual and have developed a thorough understanding of how this
equipment works. Failure to observe any of the instructions contained in the manual could
result in severe personal injury to the user or bystanders, or cause damage to the equipment
and property. Keep this manual in a convenient and safe place for future reference.
Whilst every effort has been made to ensure accuracy of information contained in this manual,
the TQB Brands Pty Ltd policy of continuous improvement determines the right to make
modifications without prior warning.
CONTENT
WARNING .....................................................................................................................................2
CONTENT ......................................................................................................................................2
SAFETY INSTRUCTIONS .................................................................................................................3
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE..............................................................4
PARTS LIST ....................................................................................................................................6
WARRANTY...................................................................................................................................7

Product Code: 1003
Page 3
SAFETY INSTRUCTIONS
SAFETY OPERATING INSTRUCTIONS
Always wear suitable protective clothing, gloves and goggles.
Clean off any accidental splashes of parts cleaning fluid on the skin.
Follow cleaning fluid manufacturer's instructions carefully.
Always check for damage. Before using the washer, any damaged part, should be
checked to ensure that it will operate properly, and perform its intended function. Any
damage should be repaired or the part replaced.
Always disconnect the parts washer from the power supply before carrying out any
maintenance or cleaning of the parts washer unit.
Always keep work area clean. Cluttered areas and benches invite accidents.
Always keep children away. All visitors should be kept a safe distance from the work area,
especially whilst operating the machine.
Always ensure the switch is off before plugging in to mains. Avoid accidental starting.
When servicing, use only TradeQuip identical replacement parts. Use of any other parts
will void the warranty. Ensure the parts washer is disconnected from power before
servicing.
Use the right product for the job. There are certain applications for which the Parts
Washer was designed. Do not modify the Parts Washer and do not use the Parts Washer
for a purpose for which it was not intended.

Product Code: 1003
Page 4
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE
1. FEATURES
The TradeQuip Parts Washer has a large tank with component shelf, plus small parts tray.
Suitable for use with aqueous (water) based solutions only. Petroleum based cleaning
fluids are harmful and will damage the pump and void the warranty. Incorporated is a
"Quick Close" fusible link that automatically closes the lid in case of fire. The unit has a
built in replacement cleaning fluid filter and easy maintenance 240V cleaning fluid pump.
2. ASSEMBLY
Unpacking: after removing the packing material, make sure the product is in perfect
condition and that there are no visible damaged parts. The packaging materials
(Polyethylene bags, polystyrene etc.), must be disposed of in an appropriate refuse
collection container. Recycle cardboard.
1. Choose a firm, flat and level surface to site the machine on, in a well ventilated are
and away from any naked flames.
2. Assemble the legs and shelf to the parts washer as shown in the diagram on page (7),
using the screws and nuts supplied.
3. Remove the pump housing cover plate (2 self tapping screws) and dispose of any
packaging around the pump.
4. Replace the cover plate and mount the pump housing through the slot in the side of
the tank. The switch housing protrudes through the slot with its underside hooking
over the edge of the tank.
5. Ensure all packaging is removed before filling with parts washer fluid.
3. BEFORE USE
Prior to each use conduct a visual inspection by checking for abnormal conditions, such as
cracked joins and damaged, loose, or missing parts.
Cleaning Solutions:
The pump of your parts washer will be damaged if you use any solvents other than water
based solvents. Never use any flammable liquids.
Use of non-water based solutions will void the warranty for improper use.
Recommended Parts Washer Solution TradeQuip 5082. 20 Litres makes up to 100 Litres.
*Warning: For use with aqueous (water) based solutions only. Petroleum based cleaning fluids are harmful
and will damage the pump and void the warranty.

Product Code: 1003
Page 5
Visit us at www.tqbbrands.com.au
4. OPERATION
1. Fill the parts washer only with a non-flammable parts cleaning fluid, to just below
the level of the parts shelf. DO NOT fill with flammable petroleum solvents such as
paraffin, thinners, etc.
2. Open the lid, switch the pump on and hold the part to be cleaned under the nozzle,
slowly rotate the component until clean. Use a brush to loosen stubborn grime.
3. When clean, leave to drain on the tray or in a small component container until dry.
4. Switch off the pump and close the lid and disconnect the power supply.
5. Remove gloves and goggles, store safely.
Note: Any spillages should be mopped up immediately, so as not to cause a safety
hazard.
Important:
1. The lid stay incorporates a "Quick Close" fire safety device in the form of a fusible
link, which closes the lid in the event of fire. The link is non-resetting and must be
replaced should it be activated.
2. Clean the pump filter regularly, by sliding it away from the pump housing and rinsing
it in clean parts cleaning fluid.
3. Do not allow the level of fluid in the parts washer to fall below the pump inlet, as
damage to the pump can result. (Minimum fluid capacity is 33 Litres)
5. STORAGE
This Parts Washer should always be stored in a dry location on a level surface. Disconnect
240V power supply and air supply and empty the parts cleaning fluid into a container.
6. MAINTENANCE
Disconnect power prior to any maintenance. Inspect the general condition of the Parts
Washer checking:
For loose hardware
Misalignment of binding or parts, cracked, bent, or broken parts, and
Any other condition that may affect the Parts Washers safe operation
Disconnect 240V power plug, remove flex hose from pump flow-out line
Remove cover of pump housing. Clean any foreign matter lodged around impeller
Re-assemble in reverse order
For heavy build-up of dirt and grime, our enamel paint finish can be cleaned with
spray wax. Lightly spray the wax on the surface, and gently wipe with a soft, dry
microfiber cloth.
Window cleaner and a soft cloth dampened with water can be used to clean the
finish on a regular basis.
7. SERVICE & REPAIR
Any Parts Washer found damaged in any way, or found to be worn or operates
abnormally should be removed from service until repaired by an authorised service agent.
Owners and/or operators should be aware that repair of this product may require
specialised equipment and knowledge. Only authorised parts, labels and decals shall be
used on this equipment. Annual inspection of the Parts Washer is recommended and can
be made by an authorised repair facility to ensure that your equipment is in optimum
condition and that the equipment has the correct decals and safety labels specified by the
manufacturer.

Product Code: 1003
Page 6
PARTS LIST
Part #
Description
QTY
Part #
Description
QTY
1
Lid
1
18
M5 Nut
1
2
Fusible Link
1
19
Pump Housing
1
3
Shaft
1
20
Flexible Pipe
1
4
Work Basket
1
21
Elbow Seat
1
5
Work Shelf
1
22
Strain Relief
1
6
Body
1
23
M4x8 Screw (with Nut, Spring
Washer and Flat Washer)
5
7
O-ring
1
24
Switch
1
8
Plug
1
25
Switch Box
1
9
M6 Nut
24
26
Elbow-1
1
10
Spring Washer
24
27
Elbow-2
1
11
M6x12 Screw
24
28
O-ring
1
12
Leg
4
29
Connector
1
13
Shelf
1
30
O-ring
1
14
Filter Cover
1
31
Pump
1
15
Filter
1
32
Strain Relief
1
16
Pump Housing Cover
1
33
Cable & Plug
1
17
M5x20 Screw
1
34
Pump Assembly
1

Product Code: 1003
Page 7
WARRANTY
TradeQuip products have been carefully tested and inspected before shipment and are
guaranteed to be free from defective materials and workmanship for a period of 12 months
from the date of purchase except where tools are hired out when the guarantee period is
ninety days from the date of purchase.
Should this piece of equipment develop any fault, please return the complete tool to your
nearest authorised warranty repair agent or contact TQB Brands Pty Ltd Warranty team –
[email protected].
If upon inspection it is found that the fault occurring is due to defective materials or
workmanship, repairs will be carried out free of charge. This guarantee does not apply to
normal wear and tear, nor does it cover any damage caused by misuse, careless or unsafe
handling, alterations, accident, or repairs attempted or made by any personnel other than the
authorised TQB Brands Pty Ltd repair agent.
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its
terms are not authorised.
Your TQB Brands Pty Ltd guarantee is not effective unless you can produce upon request a
dated receipt or invoice to verify your proof of purchase within the 12 month period.
Consumer Guarantee
Our goods come with a guarantee that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for any
other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure does not amount to a
major failure.
