Installation Guide:
Traffic Logix®SafePace™100 Radar Sign
Universal Mounting Bracket System
With the Universal Mounting Bracket System, the SafePace™100 Radar Speed Sign can easily
be mounted and dismounted from the installation pole with just the turn of a key. This quick mount
and dismount feature readily allows the sign to be moved from one location to another with relative
ease and convenience. Additional pole brackets can be purchased separately.
Components:
SafePace™100 radar sign –available at SafestParkingProducts.com
Universal Mounting Bracket System (includes 1 sign bracket & 1 pole bracket)
Installation Hardware (included)
** Please refer to our “General Installation Guide: SafePace™100 Radar Sign”document for
choosing the proper installation location and further details.
Installing the Mounting Brackets
Sign Bracket
Attach the Sign Bracket to the backside of the SafePace™100 radar sign using the included hardware.
Use supplied hardware to mount the Sign Bracket to the rear of the SafePace™100 radar sign
Pole Bracket
The Pole Bracket can be secured to any type of standard pole or Telespar type pole by a choice of
banding straps, lag screws, or bolts and nuts.
Pole bracket mounted to circular pole
Pole bracket mounted to 2” Telespar pole

2
Installation of the Pole Bracket using supplied banding straps
Figure 3.1
Pole bracket banded to utility pole.
Figure 3.2
Additional lag bolts should be used for
added security.
Figure 3.3
Profile view of pole bracket banded.
NOTE: It is highly recommended that if banding is used to secure the Pole Bracket additional
screws and/or bolts should also be used (see Figure 3.2 above) to further prevent theft and
vandalism.
Installation of Pole Bracket on Telespar Pole (Note: a 2 inch Telespar pole should be used)
Use the supplied 2.5” stainless steel security bolts and nuts to secure the Pole Bracket to the 2”
Telespar pole. Note: It is very important that the head of the bolt be placed on the Telespar pole (See
Figures 4.1 and 4.2) and that the nuts be placed on the inside part of the bracket (see Figures 4.3
and 4.4).
Figure 4.1
Figure 4.2
Figure 4.3
Figure 4.4

3
Mounting and Dismounting the SafePace™100 Radar Sign
The SafePace™100 radar sign easily mounts by sliding the sign down onto the Pole Bracket and
dismounts by sliding the sign up off of the Pole Bracket. Once mounted, the sign should be locked
into place as shown in Figure 5.3.
Figure 5.1
Step 1: Position the sign above the
bracket.
Figure 5.2
Step 2: Slide the sign down the bracket.
Figure 5.3
Step 3: Lock the sign in place.
WARNING: To prevent damage to the locking mechanism
of the Universal Mounting Bracket System, the key must
be removed from the lock and the locking mechanism
must be set in the “unlocked” position (see picture on
right) BEFORE sliding the sign ON or OFF of the Pole
Bracket. Locking Mechanism
in “unlocked” position
Pole Bracket
** Detailed installation instructions (i.e. how to connect the proper power source and optional Solar Panel) are shipped with
every SafePace™100 radar sign.
**Technical Support: for any questions or comments regarding the SafePace™100 radar sign, please contact: [phone]
or [e-mail].
