Trail Embers SMK8028AS User manual

OWNER’S MANUAL/ MANUAL DEL PROPIETARIO
PELLET SMOKER & GRILL
Pellet fumador y parrilla
ADVERTENCIA/WARNING
PLEASE READTHIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF
THIS PELLET FUEL-BURNING APPLIANCE. FAILURE TO FOLLOW THESE
INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY
OR EVEN DEATH. CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT
RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS INYOUR
AREA. SAVE THESE INSTRUCTIONS.
LEA ESTE MANUAL COMPLETO ANTES DE LA INSTALACIÓN Y EL USO DE
ESTE ARTEFACTO CALENTADOR A COMBUSTIBLE GRANULAR SI NO SIGUE
ESTAS INSTRUCCIONES, PUEDE PROVOCAR DAÑOS A LA PROPIEDAD,
LESIONES CORPORALES E INCLUSO LA MUERTE. COMUNÍQUESE CON LOS
OFICIALES LOCALES DE CONSTRUCCIÓN O DE INCENDIOS PARA SABER LAS
RESTRICCIONESY LOS REQUISITOS DE INSPECCIÓN DE INSTALACIÓN EN SU
ÁREA. CONSERVE ESTAS INSTRUCCIONES.
NOTICE TO INSTALLER:
LEAVE THESE
INSTRUCTIONS WITH THE
GRILL OWNER FOR
FUTURE REFERENCE.
AVISO PARA EL
INSTALADOR:
ENTREGUE ESTAS
INSTRUCCIONES AL
PROPIETARIO DE LA
AHUMADOR PARA
REFERENCIA FUTURA.
Model / Modelo SMK8028AS
®
ASSEMBLY AND OPERATING INSTRUCTIONS
INSTRUCCIONES DE ARMADO Y OPERACIÓN
SAVE THIS MANUAL FOR FUTURE REFERENCE
GUARDE ESTE MANUAL PARA REFERENCIA FUTURA

Do NOT use in humid or wet conditions
WARNING
IMPORTANT SAFETY WARNINGS
WE WANT YOU TO ASSEMBLE AND USE YOUR SMOKER AS SAFELY AS POSSIBLE.
THE PURPOSE OF THIS SAFETY ALERT SYMBOL
IS TO ATTRACT YOUR ATTENTION TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR SMOKER/GRILL.
WHEN YOU SEE THE SAFETY ALERT SYMBOL, PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS!
READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING AND OPERATING YOUR SMOKER/GRILL.
1. Improper installation, adjustment, service or maintenance can cause injury or property damage.
2. Read all instructions and guidelines carefully and thoroughly before installation, use or service.
3. Failure to follow these instructions could result in re or electrical shock.
WARNING
NOT for use in or on boats or recreation vehicles.
DANGER
1. Do not store or use gasoline, liquid propane or any other ammable vapors or
liquids in the vicinity of this appliance.
DANGER
1

2
General Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Operating the Grill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Proper Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Transporting and Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Grill Cooking Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-22
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING: Be alert to the possibility of serious bodily injury if the instructions are not followed. Be sure to read and
carefully follow all of the messages.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
TABLE OF CONTENTS:
CALIFORNIA PROPOSITION 65 WARNING
This product contains chemicals, and when used, produces
chemicals, including carbon monoxide, known to the State of California
to cause cancer and birth defects or other reproductive harm.
https://www.p65warnings.ca.gov
WARNING! CONTAINS LEAD. MAY BE HARMFUL IF
EATEN OF CHEWED. MAY GENERATE DUST
CONTAINING LEAD. COMPLIES WITH FEDERAL STANDARDS.
KEEP OUT OF THE REACH OF CHILDREN.
For accessories and other products, please visit us at:
www.embersgrills.com

WARNING
When using electric appliances, basic safety precautions should always be followed including the following:
• Operate only per manufacturers instructions.
• Keep all combustible materials at least 36 inches (66 cm) away from the grill at all times. Do not use this grill under
any overhang or near any combustible structures.
• Minimum clearance from side and back of unit to combustible materials, 36 inches (66 cm) from side and 36
inches (66 cm) from back.
• DO NOT use on wood decks. Set up this grill on a hard, non-combustible smooth level surface.
• In case of re, turn the control “OFF”. Unplug the grill from the power source and allow the re to burn out on its
own. Do not use water to try to extinguish a re.
• Keep a re extinguisher on hand acceptable for use with electric products. Refer to your local authority to determine
proper size and type.
• Creosote – Formation and need for removal. When wood pellets are burned slowly, they produce tar and other
organic vapors that combine with expelled moisture to form creosote. The creosote vapors condense in a relatively
cool oven u and exhaust hood of a slow burning re. As a result, creosote residue accumulates on the ue lining
and exhaust hood. When ignited, this creosote makes an extremely hot re.
• The grease duct should be inspected at least twice a year to determine when grease and/or creosote buildup has
occurred.
• When grease or creosote has accumulated, it should be removed to reduce risk of re.
• Do not attempt to touch cooking surfaces or other hot surfaces. Use handles or knobs.
• To protect against electric shock, do not immerse cord, plugs, or heating element in water or any other liquids.
• Never leave appliance unattended. Hot while in operation. Keep children, clothing and furniture away. Contact may
cause burns.
• Unplug this grill from the power source when not in use and before cleaning. Allow appliance to cool down before
attempting to clean or service.
• Do not operate any appliance with a damaged power cord or plug, or after the appliance has malfunctioned or
been damaged in any manner.
• Do not use accessories or attachments not recommended by the manufacturer, as they may not be compatible
with this appliance, and may cause damage or injury.
• Do not place power cord where it may come in contact with hot surfaces, or pose a tripping hazard.
• Do not use this appliance for anything other than its intended use.
• NEVER add cooking pellets to a hot re pot by hand.You could be seriously burned. If the hopper runs out of
pellets or your re goes out while cooking, let the grill completely cool and follow the Initial Lighting Instructions.
• Use only cooking grade wood pellets. Never use heating grade wood pellets as they are not safe for cooking.
• Always store wood pellets away from heat.
• NEVER use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter uid, or similar liquids to start or
“freshen up” a re in this appliance. Keep all such liquids well away from the appliance when in use.
• This grill is not for use indoors. Do not use inside a building, garage or any other enclosed area.
• This product is not designed for commercial use.
GENERAL WARNINGS:
3

4
• This product is not designed for tabletop use. Do not set this product on a tabletop.
• Outdoor extension cords must be used with outdoor use products and are marked with suffix “W” and with
the statement “Suitable for Use with Outdoor Appliances.”
• Only use a properly-grounded power source.
• Use only with a properly-grounded GFCI (Ground Fault Circuit Interrupter) household circuit.
• Do not operate this product in rain or wet conditions. Do not allow this product to come in contact with water.
Set this product up more than 10’ from any large body of water (swimming pool, lake, pond, etc).
• CAUTION - To reduce the risk of electric shock, keep extension cord connection dry and off the ground.
• Never alter or remove the grounding plugs on the power cord or household outlet.
• Disconnect electric cord from outlet before cleaning.
• Keep appliance clean. See Proper Care and Maintenance section for cleaning.
• Do not operate this grill while under the inuence of drugs, alcohol, or while fatigued.
• Do not use in the presence of explosive or ammable gases, vapor or other substances.
• Do not use this grill unless it is completely assembled and all parts are securely fastened and tightened.
• Use only identical replacement parts.
• Do not use this product in high winds.
• Do not attempt to move this appliance while it is in use.
• Always open the grill lid carefully - heat and steam trapped inside the lid can burn.
• Do not use this product for indoor heating, as toxic fumes will accumulate.
• After a period of storage, inspect the grill for abrasion, wear, cuts, or damage to the temperature controller
and power cord.
• Always use a meat thermometer to ensure food is cooked to a safe temperature.
• Keep grill covered when not in use - out of the reach of children. Do not clean this product with a water spray
or the like.
• Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts.
• Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions
or is dropped or damaged in any manner.
Follow these guidelines to prevent this colorless,odorless gas from poisoning you, your family
or others.
• Know the symptoms of carbon monoxide poisoning; headache, dizziness, weakness, nausea,
vomiting, sleepiness and confusion. Carbon monoxide reduces the blood’s ability to carry
oxygen. Low blood oxygen levels can result in loss of consciousness and death.
• See a doctor if you or others develop cold or u-like symptoms while cooking or in the vicinity
of this appliance. Carbon monoxide poisoning, which can easily be mistaken for a cold or u, is
often detected too late.
• Alcohol consumption and drug use increase the effects of carbon monoxide poisoning.
• Carbon monoxide is especially toxic to mother and child during pregnancy, infants, the elderly,
smokers and people with blood or circulatory system problems, such as anemia or heart
disease.

TURNING ON THE GRILL:
Initial Lighting Instructions (To be used on initial ring or anytime the grill runs out of pellets)
Always allow the auger tube to fully load with pellets to ensure proper lighting of the grill.
Step 1 Open lid to cooking chamber and remove cooking grills, grease tray and heat baffle from inside
the grill. Leave door open.
Read and follow all warnings and instructions contained in the preceding sections of this manual.
WARNING
OPERATING THE GRILL:
BREAKING IN YOUR GRILL:
• In manufacturing and preserving the components of your grill, oil residue may be present on the
cooking surfaces of your grill.
• Before cooking on your grill for the rst time you should follow “Initial Lighting Instructions” to ensure
the auger is fully charged with pellets.
PREHEATING GRILL:
• Prior to use, it is recommended that you preheat your grill. This ensures that the grilling surfaces are at
the desired temperatures to sear the food sugars when cooking. Preheat the grill for 10 to 15 minutes
or until it reaches the desired temperature before adding food. Close the lid during the preheat period.
5
• DO NOT leave your grill unattended while in use.
• DO NOT move grill when in use. Block wheels in place to stabilize grill.
• DO NOT use water to extinguish are-ups.
WARNING
IF AN EXTENSION CORD IS NECESSARY:
• Use a CSA or UL approved 3-prong grounded extension cord that is rated for at least 7-10 Amp
and is marked as suitable for outdoor use.
• Keep the power cord connection dry and off of the ground.
• Avoid running the power or extension cord across walkways, driveways, or anywhere where it could
pose a tripping hazard.
USE CAUTION AND COMMON SENSE WHEN OPERATING YOUR PELLET SMOKER &
GRILL. FAILURE TO ADHERE TO THE SAFETY WARNINGS AND GUIDELINES IN THIS
MANUAL COULD RESULT IN SEVERE BODILY INJURY OR PROPERTY DAMAGE. SAVE
THIS MANUAL FOR FUTURE REFERENCE.

6
Step 2 Make sure temperature control knob is “OFF”. Plug power
cord into a GFCI (grounded) outdoor electrical outlet.
Step 3 Open the pellet hopper lid. Make sure the auger is free from
debris and other objects. Turn the temperature control knob
to “SMOKE”.
Step 4 In the cooking chamber, place your hand about 3” above the
re pot and make sure you can feel air blowing out from the
re pot.
Step 5 Look inside the re pot and make sure the heating element
is getting hot. It will take a couple of minutes for the element
to glow red. DO NOT TOUCH THE HEATING ELEMENT!
Turn temperature control knob to “OFF”.
Step 6 Fill the pellet hopper with cooking pellets. NEVER USE
HEATING FUEL PELLETS AS THEY ARE NOT SAFE
FOR COOKING.
Step 7 Turn the temperature control knob to “SMOKE
NOTE: During the initial loading of the auger tube, it will
take approximately 5 minutes for the pellets to move
from the pellet hopper to the re pot.
Step 8 When the pellets start falling into the re pot, turn the
temperature control knob to “OFF”.
Step 9 Replace heat baffle, grease tray and cooking
grills into the cooking chamber.
Step 10 Keep the cooking chamber lid open. Turn temperature
control knob to “SMOKE”. You should see smoke coming out
of the cooking chamber as the pellets ignite in about 2
minutes.
Step 11 Close cooking chamber lid and set the temperature control knob to the desired setting. See
note below for curing process.
NOTE: Curing the grill is highly recommended before rst use. Close cooking chamber lid
and set temperature control knob to “HIGH” and allow grill to cure for 45 minutes. This will
burn off any oil or paint residue inside the cooking chamber before cooking for the rst
time.
SUBSEQUENT LIGHTING INSTRUCTIONS:
Step 1 Open pellet hopper lid and check the pellet level. Add more pellets if necessary.
WARNING: NEVER add cooking pellets to a hot re pot by hand. You could be seriously
burned.
Control Panel
Temperature
Control Dial
Auger
Inside Pellet
Hopper
Fire Pot

7
Step 2 Open cooking chamber lid and turn temperature control knob to “SMOKE”. You should see
smoke coming out of the cooking chamber as the pellets ignite in about 2 minutes.
NOTE: Always start the grill on “SMOKE” setting with the cooking chamber lid open.
Step 3 Close cooking chamber lid and set the temperature control knob to the desired setting. For
best results, preheat the grill for 10 to 15 minutes with the lid closed before placing food in the
grill.
Follow these steps If the grill does not ignite or if the re in the re pot goes out while cooking:
Step 1 Turn the temperature control knob to “OFF” and unplug. Open cooking chamber lid and
remove all food, cooking grills, grease tray and heat distribution plate.
CAUTION: Some parts may contain sharp edges. Wear protective gloves if necessary.
WARNING: Always use oven mitts/gloves to protect your hands. Metal parts become hot
during use. Use extreme caution when handling cooking grills, grease tray and baffle.
Step 2 Remove all unburned pellets and ash from inside and around the re pot.
Step 3 Restart the grill and check that the ignition cycle is working. The heating element
should turn red after 1-2 minutes and pellets should be falling into the re pot from the auger tube.
Step 4 Wearing oven mitts/gloves, replace the baffle, grease tray and cooking grills.
Step 5 Preheat the grill for 10 to 15 minutes with the lid closed before placing food back in the grill. If this
procedure is not successful, see Trouble Shooting section in your owner’s manual.
TURNING OFF THE GRILL:
• Turn the temperature control knob to “OFF”. An auto cool down feature will keep the fan running for
several minutes.
• Unplug the power cord from the wall outlet.
WARNING: NEVER add cooking pellets to a hot re pot by hand. You could be seriously burned.
If the hopper runs out of pellets or your re goes out while cooking, let the grill completely cool
and follow the Initial Lighting Instructions.
COOKING:
• Set temperature controller to desired level and allow temperature to be reached.
• Place food on cooking grill.
• With lid open or closed, cook until desired internal temperature is reached.
• Use caution when removing food from Pellet Fuel Grill. All surfaces are HOT and may cause burns.
Use protective gloves or long, sturdy cooking tools to remove food.
• Pellet Fuel Grill is HOT while in use and will remain HOT for a period of time afterwards. Use caution.
OPERATING TIPS:
• Your Trail Embers Pellet Smoker & Grill® should never be moved while it is hot. If you are transporting
your grill in a vehicle after cooking on it, make sure the re is completely out and the grill is cold before
placing it in any vehicle. NEVER put water into the re pot. It will jam the auger.
• The Trail Embers Pellet Smoker & Grill® is designed to operate with the lid closed. Cooking with the lid
open greatly lengthens your cooking time.
• Make sure the heat baffle is properly seated on its locating brackets. The long legs of the heat baffle
should be pointing down over the re pot. If not seated properly, direct heat and ame could come up
out of the re pot and cause a grease re in the grill.
• Smoke stack cap can be adjusted up or down to provide additional temperature and smoke control.

8
SMOKE MODE:
• The “SMOKE” settings is for smoking and adding smoke avor to foods being cooked.
• Smoke Mode can be adjusted from P0 to P4. P0 provides less smoke into the cooking chamber
and can be adjusted up to P4 for maximum smoke. P2 is the normal factory setting.
• Adjusting the smoke mode to a higher setting will cause more uctuation in the temperature of
the cooking chamber.
• Turn the temperature control knob to smoke. Use a small head tool to push in
on the switch located behind the “P” Set opening to change the P Setting.
8.8.8.
P3
COOK
˚F
225
1.0.5.
P3
COOK
˚F
225
1.0.5.
COOK MODE:
• The temperature dial can be changed at any time to increase or decrease the
cooking temperature of the grill.
• The 325˚F to “HIGH” temperature settings are for grilling.
• The 180˚F to 300˚F temperature settings are for slow cooking.
• Adjust the control knob to a desired temperature. The selected temperature will
be in the bottom left hand corner of the digital display.
• Adjusting the smoke mode to a higher setting will cause more uctuation in the
temperature of the cooking chamber.
• Smoke Mode can be adjusted from P0 to P4. P0 provides less smoke into the
cooking chamber and can be adjusted up to P4 for maximum smoke.
ERROR CODES:
• “8.8.8.” – Display will ash for 1-2 seconds when rst plugged into power outlet.
This is normal, not an indication of a problem.
• “ErP” – Error Power will occur when grill is plugged into power outlet and the
temperature control knob is not in “OFF” position.
• “. . .” – Flashing Dots indicate that the igniter is “ON”. The igniter will stay on for
5 minutes and then go off.
• “ErH” – High Temp Limit indicates that the temperature in the cooking chamber
has exceeded 565˚F.
• “1.0.5.” – Flashing Temperature indicates temperature is below 110˚F on
“SMOKE” setting or temperature is below 150˚F on all cooking temperatures.
• “Err” – Thermocouple may be unhooked or damaged.
P3
SMOKE ˚F
1.2.0.
˚F
250 375
225 300
Smoke
Off
High
180 325
350
375
Temperature
“P” SET
˚F
250 275
225 350
Smoke
Off
High
180 325
350
375
Temperature
“P” SET
P3
COOK
˚F
225 2.1.5.

9
PROPER CARE & MAINTENANCE:
• Remove wood pellets from hopper if grill will not be used for a long period of time. Wood pellets
can become soggy due to moisture/humidity and can cause the auger to bind up or not push
pellets to burn chamber.
• Disposal of ashes – Ashes should be placed in a metal container with a tight-tting lid. The
closed container of ashes should be placed on a non-combustible oor or on the ground, well
away from all combustible materials, pending nal disposal. When the ashes are disposed by
burial in soil or otherwise locally dispersed, they should be retained in the closed container
until all cinders have thoroughly cooled.
• To protect your grill from excessive rust, the unit must be kept clean and covered at all times when
not in use.
• Wash cooking grills and heat distribution plate with hot, soapy water, rinse well and dry. Lightly
coat cooking grill with vegetable oil or vegetable oil spray.
• Clean inside and outside of grill by wiping off with a damp cloth. Apply a light coat of vegetable oil
or vegetable oil spray to the interior surface to prevent rusting.
• Never apply paint to the interior surface. Rust spots on the interior surface can be buffed, cleaned,
the lightly coated with vegetable oil or vegetable oil spray to minimize rusting.
• Depending on use, periodically remove the cooking grills, grease tray and heat distribution plate to
clean the ash from in and around the re pot. A shop-vac is handy for this chore. Make sure the
grill is cold before starting this procedure.
HELPFUL HINTS:
• If you pre-cook meat or poultry, do so immediately before grilling.
• Never defrost meat at room temperature or on a counter top.
• Refrigerate leftovers within 2 hours of taking food off the grill.
• For additional information, please phone the USDA’s toll free Meat & Poultry Hotline at 800-535-
4555.
CLEANING AND MAINTENANCE:
• Keep the appliance free and clear of combustible materials, gasoline and other ammable vapors
and liquids.
• For safe grilling and peak performance of your grill, perform these checks at least twice per year
or after extended periods of storage.
• Be sure to tighten up all hardware (nuts, bolts, screws, etc.) at least twice per year.
CAUTION: Some parts may contain sharp edges. Wear protective gloves if necessary.
• Remove the cooking grills, from inside your grill. Use a brush with hot water and detergent to
remove excess residue. NEVER use a commercial oven cleaner. Rinse completely with water.
Towel dry and replace all components as described in the assembly instructions.
COOKING GRILLS:
• Clean with mild soap detergent and water. Use a grill cooking grate brush to remove residue from
the porcelain coated surfaces. The steel wire can cause the nish to chip or crack. DO NOT use a
commercial oven cleaner.

BEFORE STORING YOUR GRILL:
• Clean all surfaces.
• If storing the grill outdoors, close the wood pellet lid and cover the grill with a grill cover for
protection from the weather.
• If the grill is stored outside during the rainy season, care should be taken to ensure that water does
not get into the pellet hopper. Wood pellets, when wet, expand greatly and will jam your auger.
10
• Never move a grill when it is hot or when objects are on the cooking surfaces.
• Never store ammable liquids or spray canisters under or near the grill.
• DO NOT extinguish grease res using water.
WARNING
TRANSPORTING AND STORAGE:
GRILL COOKING TIPS:
CLEANLINESS:
• Always wash hands thoroughly with soap and hot water prior to handling food and after handling raw
meat, uncooked poultry or seafood.
• When using a platter to carry raw meat, uncooked poultry or seafood to the grill, make sure to wash
the platter thoroughly with soap and hot water before placing cooked foods back on the platter or use
different platters for raw and cooked foods.
• Never use the same utensils when handling raw meat, uncooked poultry or seafood unless you wash
the utensils thoroughly with soap and hot water.
• Never re-use marinade from raw meat or uncooked poultry on foods that have been cooked and are
ready to be served.
GRILLING TO PROPER TEMPERATURE:
• Use a meat thermometer to be sure food has reached a safe internal temperature.
• The US Department of Agriculture recommends the minimum temperature be reached for the
following food items:
Chops . . . . . . . . . . . . . . . . . . . . . 145 degrees F (62.8° C)
Ground Meat . . . . . . . . . . . . . . . 160 degrees F (71° C)
Pork . . . . . . . . . . . . . . . . . . . . . . 145 degrees F (62.8° C)
Poultry . . . . . . . . . . . . . . . . . . . . 165 degrees F (73.9° C)
Roasts . . . . . . . . . . . . . . . . . . . . 145 degrees F (62.8° C)
Seafood . . . . . . . . . . . . . . . . . . . 145 degrees F (62.8° C)
Vegetables . . . . . . . . . . . . . . . . . 145 degrees F (62.8° C)

11
TROUBLE SHOOTING:
PROBLEM CAUSE CORRECTION
Electric
element
will not
heat up
Grill is
not getting
hot enough
Grill is
getting
too hot
Smoke
comes out of
smoker box
Temperature
or digital display
does not
match “set”
temperature
1. Check that the 3-wire plug is fully seated
into a 3-wire grounded GFCI outlet wired
for 120 volts.
2. Check the breakers or fuses for the outlet
being used are not open or blown.
3. Check that the GFCI outlet has not been
tripped.
4. Electric element only heats up (becomes
red) during the rst 5 minutes after power
switch is turned on.
5. Fuse-Blown.
1. Reseat plug in a 3-wire grounded GFCI
outlet wired for 120 volts.
2. Reset breakers or replace fuse.
3. Reset GFCI outlet.
4. Turn Power switch “Off” then “Smoke”
again.
5. Replace max fuse size: 5mm x 20 mm,
5 amps.
1. Adjust temperature control on temperature
controller.
2. Avoid the temptation to check food too
often.
3. Verify that there are pellets in pellet hop-
per.
4. Fire goes out on “SMOKE” setting.
1. Turn up heat on control dial.
2. Opening the door allows heat to escape
and slows the cooking process; open door
only when necessary.
3. Add pellets and allow sufficient time for the
pellets to travel from the pellet hopper to
the re pot (can take up to 7 minutes).
4. Excess ash. IMPORTANT: Remove all
unburned pellets and ash from inside and
around the re pot. A shop-vac is ideal for
the task CAUTION! ASSURE THAT THE
GRILL IS COLD TO AVOID A FIRE FROM
HOT ASH.
1. Adjust temperature control.
1. This is normal due to the air pressure
inside the smoker. The amount of smoke
can vary depending on cooking conditions.
1. When rst lighting smoker, it takes 15
minutes or so for temperature to stabilize.
2. When adjusting temperature, it takes 15
minutes or so for temperature to stabilize.
1. Turn down heat on temperature control
dial.
1. This condition will not affect cooking.
1. Wait 15 minutes or so for temperature to
stabilize.

12
WIRING DIAGRAM:
WHITE
POWER CORD
BLACK WHITE
NOTE: FUSE IS LOCATED ON BACK OF CONTROL.
Maximum Fuse Size: 5mm x 20 mm, 5 amps
RED
WHITE
WHITEPURPLE
MOLEX TYPE CONNECTOR
4-TYPICAL
FIRE POT
AUGER MOTOR
HOT ROD
BLOWER FAN
ORANGE
Off High
180
225
250 275 300
325
350
375
Smoke
S
M
O
K
E
˚F

13
ASSEMBLY INSTRUCTIONS:
Make sure you have all items listed under PARTS LIST and PARTS CARD CONTENTS before
you begin the installation process.
PARTS CARD CONTAINS:
(1) M4 Bolt & Nut
(2) M12 Wheel Washers
(2) M12 Nuts
(32) M6 Nuts
(44) M6 Bolts

14
READ ALL SAFETY WARNINGS & INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING AND OPERATING YOUR TRAIL EMBERS® PELLET SMOKER & GRILL.
FOR MISSING PARTS, PLEASE CALL CUSTOMER SERVICE AT 855-735-9922.
(Proof of purchase will be required.)
The following tools are required to assemble your Trail Embers ® Pellet Smoker & Grill:
• Phillips Screwdriver
• Wrench
1 Grease Bucket
1 Left Rear Leg
1 Left Front Leg
1 Right Rear Leg
1 Right Front Leg
2 Front Shelf Mounting Bracket
1 Front Shelf
1 Bottom Shelf
1 Leg Bracket
2 Wheels
1 Wheel Axle
1 Chimney Gasket
1 Pellet Hopper Gasket
PARTS LIST:
1 Warming Rack
2 Cooking Grates
1 Grease Tray
1 Right Side Mounting Bracket
1 Grease Drainage Tray
2 Warming Rack Brackets
1 Heat Baffle
1 Chimney Cap
1 Chimney
1 Temperature Gauge
1 Grill Body Assembly
1 Side Handle
1 Pellet Hopper Assembly
1
2
3
4
5
6
7
8
9
10
12
13
14
15
16
17
11
18
19
20
21
22
23
24
FOR COVERS, ACCESSORIES AND OTHER PRODUCTS, PLEASE VISIT US ONLINE AT:
www.embersgrills.com
Inspect contents of the box to ensure all parts are included and undamaged.
25
26

15
1
2
3
4
5
6
7
8
9
10
12
11
13
14
15
16
17
18
19
20
21
22
23
24
26
25

16
Grease Hole
Smoke Stack
opening Grill Body Assembly
TOP VIEW
1
2
Place grill body on its
end with the lid open as
illustrated.
(8) M6 Bolts
(8) M6 Nuts
Note: Do not fully tighten

17
BOTTOM VIEW
3
4
(4) M6 Bolts
Note: Fully tighten
(8) M6 Bolts
(8) M6 Nuts
Note: Do not fully tighten

18
5
6
(2) M12 Wheel Washers
(2) M12 Nuts
(2) M6 Bolts
Note: Do not fully tighten
7Once you have followed steps 1-6, turn the smoker
upright and make sure it’s on level ground. Tighten
all bolts.

19
9
Felt Gasket
(8) M6 Bolts
(8) M6 Nuts
(1) Felt Gasket
(2) M6 Bolts
Chimney
Cap
Grease
Drainage
Tray
8
Note: Remove pre-attached
shoulder bolt before installing
grease drainage tray.
