TrainModules TM-73736 User manual

TM-73736
Servo Decoder, Mini
User's Manual

1

© 2011 BioDigit Ltd.
All rights reserved. It is forbidden to reproduce and/or publish the contents of
the present document in any form including electronic and mechanical design
without the written permission of BioDigit Ltd.
Safety Warnings
During the operation of the device, the specified technical parameters shall
always be met. At the installation, the environment shall be fully taken into
consideration. The device must not be exposed to moisture and direct
sunshine.
A soldering tool may be necessary for the installation and/or mounting of the
devices, which requires special care. During the installation it shall be
ensured that the bottom of the device should not contact with a conductive
(e.g. metal) surface!
Contents
Safety Warnings........................................................................................ 1
Contents.................................................................................................... 1
Features and Properties ........................................................................... 2
Technical Parameters ............................................................................... 2
Short Description ...................................................................................... 2
Programming ............................................................................................ 2
Guarantee and Legal Statement .............................................................. 4

2

Features and Properties
Developed for DCC systems
Control for two independent servos
No external power supply needed
Extremely small size
Simple and quick address entry method
Low stand-by current consumption
Technical Parameters
Input supply voltage: 7-24 V DCC
Stand-by current consumption: 20 mA
Maximum current consumption: 1000 mA
Size: 62x58 mm
Short description
A small size control circuit ideal for controlling the servo motor of switches.
Thismoduleisaservocontrolleranddecoderinone.
Connection
Both the input voltage and the digital signal connect to the points labeled
"DCC IN" .
Connection of servo motor
Servo motors may be connected at the points indicated on the drawing. Make
sure to observe polarity! (Figure 1)
Setting of end-positions and the speed of movement
1. Power on the module, and make sure that the servo(s) is/are
connected
2. Hold "PROG" for max. 1 second
3. "LED1" lights up to indicate that "Servo 1" is being programmed
4. Use UP/DOWN to set the first end-position
5. Briefly press "PROG"
6. Use UP/DOWN to set up the second end-positions

3

7. Briefly press "PROG"
8. Use UP/DOWN to set the speed of switching between the previous
two end-positions
9. Briefly press "PROG"
10. "LED2" lights up to indicate that "Servo 2" is being programmed
11. Repeat steps 4 to 8 for the second servo as well
12. Briefly press "PROG" to exit from programming mode
Quick programming of digital addresses
Digital addresses can be set up easily without CV programming by using
quick programming.
1. Power on the module
2. Hold "PROG" for at least 3 seconds
3. "LED1" flashes briefly to indicate that the address connected to the
output "Servo 1" is being programmed
4. Set the desired switch address on the digital center
5. Issue the switch command (in any direction)
6. "LED1" lights up for longer, indicating that the address has been
registered
7. Briefly press "PROG"
8. "LED2" flashes briefly to indicate that the address connected to the
output "Servo 2" is being programmed
9. Repeatedly issue the address (steps 4 to 5)
10. Briefly press "PROG" to exit from programming mode.
After exiting from programming mode, the decoder can be controlled
from the digital center.

4

Guarantee and Legal Statement
Each parameter of the device has been submitted to extensive testing prior to
marketing. The manufacturer undertakes one year guarantee for the product.
Defects occurred during this period will be repaired by the manufacturer free
of charge against the presentation of the invoice.
The validity of the guarantee will cease in case of improper usage and/or
treatment.
Attention! By virtue of the European EMC directives the product can be used
solely with devices provided with CE marking.
The mentioned standards and brand names are the trademarks of the firms
concerned.
TrainModules – BioDigit Ltd
Kerepesi street 92. H-
1144, Budapest
Made in Hungary. Tel.:
[phone]
http://www.trainmodules.hu/


Figure 1
PROG
PLUS(+)
MINUS(-)
