Kramer VP-420 User manual

KRAMER ELECTRONICS LTD.
USER MANUAL
MODEL:
VP-420, VP-421
PC/HD Scaler
P/N: 2900-000506 Rev 5

VP-420, VP-421 – Contents
i
Contents
1Introduction 1
2Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 3
2.3 Recycling Kramer Products 3
3Overview 4
3.1 Defining the VP-420 PC/HD Scaler 5
3.2 Defining the VP-421 PC/HD Scaler 6
4Connecting the VP-420, VP-421 7
5Operating the VP-420, VP-421 9
5.1 Using the Front Panel Buttons 9
5.2 Using the OSD 9
6Technical Specifications 12
Figures
Figure 1: VP-420 PC/HD Scaler 5
Figure 2: VP-421 PC/HD Scaler 6
Figure 3: Connecting the VP-420 PC/HD Scaler 8

VP-420, VP-421 - Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.
Congratulations on purchasing your Kramer VP-420, VP-421 PC/HD Scaler, which
is ideal for the following typical applications:
Projection systems in conference rooms, boardrooms, auditoriums, hotels
and churches, production studios, rental and staging
Home theater up-scaling

2
VP-420, VP-421 - Getting Started
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Go to http://www.kramerelectronics.com to check for up-to-date
user manuals, application programs, and to check if firmware
upgrades are available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight coils
Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
Position your Kramer VP-420, VP-421 away from moisture, excessive
sunlight and dust
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
i
!

VP-420, VP-421 - Getting Started
3
2.2 Safety Instructions
Caution:
There are no operator serviceable parts inside the unit
Warning:
Use only the Kramer Electronics input power wall
adapter that is provided with the unit
Warning:
Disconnect the power and unplug the unit from the wall
before installing
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country
go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
!

4
VP-420, VP-421 - Overview
3 Overview
The Kramer VP-420, VP-421 are high-performance digital scalers for computer
graphics and HDTV signals. They up- or down-scale computer graphics and HDTV
signals to resolutions up to WUXGA and 1080p. The following output resolutions
are supported:
PC: VGA, SVGA, XGA, 1280x800, SXGA, UXGA, WXGA, SXGA+, WXGA+,
WSXGA, WUXGA,
COMPONENT: 480p, 576p, 720p @50/60Hz, 1080i @50/60Hz, 1080p @50/60Hz.
The VP-420, VP-421 also feature:
An On-Screen Display (OSD) for easy setup and adjustment, accessible via
the front-panel buttons
A built-in ProcAmp for convenient signal adjustment
A non-volatile memory that retains the last settings used
Quick auto-adjust
A freeze button
RGBHV or component video input and/or output
The VP-421 is identical to the VP-420 with the addition of a DVI output port.
The machines are fed from an external 5V DC source, making them suitable for
field operation.
Operate your VP-420, VP-421/VP-421 directly via the front panel push buttons and
the on-screen display (OSD).

VP-420, VP-421 - Overview
5
3.1 Defining the VP-420 PC/HD Scaler
This section defines the VP-420.
Figure 1: VP-420 PC/HD Scaler
#
Feature
Function
1
ON LED
Lights when the unit is powered on
2
COMPONENT OUT LED
Lights when component video is output
3
MENU button
Press to enter/escape the on-screen display (OSD)
menu.
Press together with the –button to reset to 720p
4
ENTER button
In OSD, press to choose the highlighted menu item.
Press together with the + button to reset to XGA
5
–/AUTO ADJUST button
In OSD, press to move backward through the list or to
decrement the parameter value. When not in OSD,
press to automatically adjust the picture to fit the
display
6
+/FREEZE button
In OSD, press to move forward through the list or to
increment the parameter value. When not in OSD,
press to freeze the display
7
PC/HD OUTPUT 15-pin HD
connector
Connects to computer graphics or HDTV acceptor
8
PC/HD INPUT 15-pin HD
connector
Connects to computer graphics or HDTV source
9
5V DC
+5V DC connector for powering the unit

6
VP-420, VP-421 - Overview
3.2 Defining the VP-421 PC/HD Scaler
This section defines the VP-421.
Figure 2: VP-421 PC/HD Scaler
#
Feature
Function
1
ON LED
Lights when the unit is powered on
2
COMPONENT OUT LED
Lights when component video is output
3
MENU button
Press to view the on-screen display (OSD) menu.
Press together with the –button to reset the display to
720p resolution
4
ENTER button
In OSD, press to choose the highlighted menu item.
Press together with the + button to reset to XGA
5
–/AUTO ADJUST button
In OSD, press to move backward through the list or to
decrement the parameter value. When not in OSD,
press to automatically adjust the picture to fit the
display
6
+/FREEZE button
In OSD, press to move forward through the list or to
increment the parameter value. When not in OSD,
press to freeze the display
7
PC/HD OUTPUT 15-pin HD
connector
Connects to computer graphics or HDTV acceptor
8
DVI OUTPUT DVI connector
Connects to DVI acceptor
9
PC/HD INPUT 15-pin HD
connector
Connects to computer graphics or HDTV source
10
5V DC
+5V DC connector for powering the unit

VP-420, VP-421 - Connecting the VP-420, VP-421
7
4 Connecting the VP-420, VP-421
Always switch off the power to each device before connecting it to your
VP-420, VP-421. After connecting your VP-420, VP-421, connect its
power and then switch on the power to each device.
To connect the VP-420, VP-421 as illustrated in the example in Figure 3:
1. Connect a computer graphics or HDTV source to the PC/HD INPUT 15-pin
HD connector.
2. Connect to the PC/HD OUTPUT 15-pin HD connector to a computer
graphics or HDTV acceptor as follows:
When connecting to an XGA acceptor (RGBHV), connect to the
acceptor’s XGA connector
When connecting to a component acceptor (YPbPr), connect as shown
here:
PIN #
Signal
1
Pr
2
Y
3
Pb
6, 7, 8
Ground
3. If connecting a VP-421, connect the DVI OUTPUT to a DVI acceptor.
The VP-421 outputs on both the 15-pin HD connector and the DVI connector. You can
connect to either output or to both of them simultaneously.
4. Connect the 5V DC power adapter to the power socket and connect the
adapter to the mains electricity (not shown in Figure 3).
i

8
VP-420, VP-421 - Connecting the VP-420, VP-421
Figure 3: Connecting the VP-420 PC/HD Scaler

VP-420, VP-421 - Operating the VP-420, VP-421
9
5 Operating the VP-420, VP-421
The VP-420, VP-421 is operated directly via the front panel buttons, and via the
OSD menu (see Section 5.2).
5.1 Using the Front Panel Buttons
During normal operation (without the OSD), the front panel buttons perform the
following functions:
Pressing MENU opens the on-screen display (OSD) main menu (see
Section 5.2), the next press closes the OSD
Pressing +/FREEZE freezes the display, the next press unfreezes the
display
Pressing –/AUTO ADJUST automatically centers the display
Pressing MENU and –/AUTO ADJUST together resets the display to 720p
and the COMPONENT OUT LED lights
Pressing +/FREEZE and ENTER together resets the display to XGA and the
COMPONENT OUT LED turns off
5.2 Using the OSD
You can use the OSD to set a wide variety of parameters. When the MENU button
is pressed, the main menu opens allowing access to all the device settings (see
Section 5.2.2).
When setting FINETUNE, COLOR, SIZE, OUTPUT (see Section 5.2.3), and OSD
(see Section 5.2.4) a submenu opens with the applicable parameters.
5.2.1 Using the Front Panel Buttons
While the OSD is open, the front panel buttons perform the following functions:
Pressing + and –move forward and backward through the menu items and
increment or decrement the parameter values
Pressing ENTER selects and activates a menu item or accepts the
parameter value set

10
VP-420, VP-421 - Operating the VP-420, VP-421
Pressing MENU closes the OSD menu
The menu times out by default after 10 seconds. To change the OSD display time,
adjust the OSD/TIMER parameter.
As an example of setting parameters, to increase the contrast on the display:
1. From normal operation, press MENU.
The OSD main menu appears on the screen.
2. Press the + or –button to highlight CONTRAST.
CONTRAST changes to green when highlighted.
3. Press ENTER.
The contrast value parameter changes to red.
4. Press the + button to increase the value (increase the contrast) or
the –button to decrease the value (decrease the contrast).
The value ranges from 0 to 100.
5. Press ENTER to set the value.
The contrast value parameter changes back to white.
6. To return to normal operation, highlight EXIT and press ENTER, press
MENU, or wait until the menu times out.
5.2.2 The MAIN MENU
The following table defines the MAIN MENU parameters and functions.
Parameter
Function
CONTRAST
Adjusts the contrast
BRIGHTNESS
Adjusts the brightness
FINETUNE
Adjusts the other ProcAmp parameters, for example, hue, sharpness,
noise reduction, and so on
COLOR
Adjusts the color of the display –RED, GREEN, BLUE
SIZE
Select the size of the display: LETTER BOX, PANSCAN, FULL,
OVERSCAN, and two underscan settings: UNDER 1 and UNDER 2
OUTPUT
Sets the output resolution (see Section 5.2.3)
OSD
Adjusts parameters of the on-screen display (see Section 5.2.4)
FACTORY
RESET
Resets the device to its factory default parameters and automatically
senses the input and output devices
INFORMATION
Displays the source, input and output resolutions and the software version
EXIT
Select to exit the OSD

VP-420, VP-421 - Operating the VP-420, VP-421
11
5.2.3 The “OUTPUT” Submenu
The “OUTPUT” submenu allows you to choose the output resolution sent to the
display. Each press of the + or –button cycles through the list of resolutions.
The following table defines the resolutions available on the “OUTPUT” submenu
and how they appear on the display.
Parameter
Appears As
Parameter
Appears As
VGA
640x480
WUXGA
1920x1200
SVGA
800x600
480P
480p
XGA
1024x768
576P
576p
1280x800
1280x800
720P50
720p @50Hz
SXGA
1280x1024
720P60
720p @60Hz
UXGA
1600x1200
1080P50
1080p @50Hz
WXGA
1366x768
1080P60
1080p @60Hz
SXGA+
1400x1050
1080p (RGBHV) (appears
in the Menu as 1080PRGB)
1920x1080
WXGA+
1440x900
1080I50
1080i @50Hz
WSXGA
1680x1050
1080I60
1080i @60Hz
5.2.4 The “OSD” Submenu
The “OSD” submenu allows you to adjust the location of the OSD, the length of
time it is displayed, and the darkness of its background.
Parameter
Function
Range
Default
H-POSITION
Adjusts the horizontal position of the OSD on
the screen
0–100
50
V-POSITION
Adjusts the vertical position of the OSD on the
screen
0–100
50
TIMER
Adjusts the length of time in seconds the OSD
appears on the screen
0–100
10
BACKGROUND
Adjusts the shade of the OSD background from
black to transparent
0–8
4
EXIT
Select to exit to the Main Menu

12
VP-420, VP-421 - Technical Specifications
6 Technical Specifications
INPUTS:
1 PC/HD on a 15-pin HD connector, RGBHV/YPbPr
OUTPUT:
1 PC/HD on a 15-pin HD connector, RGBHV/YPbPr;
1 DVI on a DVI connector (VP-421 only)
OUTPUT RESOLUTIONS:
PC: VGA, SVGA, XGA, 1280x800, SXGA, UXGA, WXGA,
SXGA+, WXGA+, WSXGA, WUXGA, COMPONENT: 480p,
576p, 720p @50/60Hz, 1080i @50/60Hz, 1080p
@50/60Hz
All resolutions are outputted @ 60Hz, except where noted
OUTPUT REFRESH RATE:
60Hz for computer graphics resolutions, 50/60Hz for HDTV
resolutions
PROCESSING DELAY:
3 frames
CONTROLS:
Front panel buttons, ON and COMPONENT OUTPUT
LEDs
POWER CONSUMPTION:
5V DC, 800mA (VP-420), 1A (VP-421)
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
19cm x 13.5cm x 2.5cm (7.5” x 5.3” x 0.98”) W, D, H
WEIGHT:
0.66kg (1.45lbs) approx.
ACCESSORIES:
Power supply
OPTIONS:
19" rack adapter
Specifications are subject to change without notice at http://www.kramerelectronics.com

For the latest information on our products and a list of Kramer distributors,
visit our Web site where updates to this user manual may be found.
We welcome your questions, comments, and feedback.
Web site: www.kramerelectronics.com
E-mail: [e-mail]
P/N:
2900-000506
Rev:
5
!
SAFETY WARNING
Disconnect the unit from the power
supply before opening and servicing
