Trane Axiom EXH Series Installation and operating instructions

SAFETY WARNING
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning equipment
can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person could result in death or
serious injury. When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are attached to the equipment.
May 2023 WSHP-SVX014J-EN
Installation, Operation, and Maintenance
Water Source Heat Pump
Axiom™ Horizontal/Vertical —
EXH/EXV, DXH/DXV
0.75 to 6 Tons – 60 Hz, High Efficiency and Two-
Stage High Efficiency
Model Numbers:
DXHG 024-070 - 60 Hz
DXVG 024-070 - 60 Hz
EXHG 009-070 - 60 Hz
EXVG 009-070 - 60 Hz

©2023 Trane WSHP-SVX014J-EN
Introduction
Read this manual thoroughly before operating or servicing
this unit.
Warnings, Cautions, and Notices
Safety advisories appear throughout this manual as
required. Your personal safety and the proper operation of
this machine depend upon the strict observance of these
precautions.
The three types of advisories are defined as follows:
WARNING
Indicates a potentially hazardous situation which, if
not avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if
not avoided, could result in minor or moderate
injury. It could also be used to alert against unsafe
practices.
NOTICE
Indicates a situation that could result in equipment
or property-damage only accidents.
Important Environmental Concerns
Scientific research has shown that certain man-made
chemicals can affect the earth’s naturally occurring
stratospheric ozone layer when released to the
atmosphere. In particular, several of the identified
chemicals that may affect the ozone layer are refrigerants
that contain Chlorine, Fluorine and Carbon (CFCs) and
those containing Hydrogen, Chlorine, Fluorine and Carbon
(HCFCs). Not all refrigerants containing these compounds
have the same potential impact to the environment. Trane
advocates the responsible handling of all refrigerants.
Important Responsible Refrigerant
Practices
Trane believes that responsible refrigerant practices are
important to the environment, our customers, and the air
conditioning industry. All technicians who handle
refrigerants must be certified according to local rules. For
the USA, the Federal Clean Air Act (Section 608) sets forth
the requirements for handling, reclaiming, recovering and
recycling of certain refrigerants and the equipment that is
used in these service procedures. In addition, some states
or municipalities may have additional requirements that
must also be adhered to for responsible management of
refrigerants. Know the applicable laws and follow them.
WARNING
Proper Field Wiring and Grounding
Required!
Failure to follow code could result in death or serious
injury.
All field wiring MUST be performed by qualified
personnel. Improperly installed and grounded field
wiring poses FIRE and ELECTROCUTION hazards. To
avoid these hazards, you MUST follow requirements
for field wiring installation and grounding as
described in NEC and your local/state/national
electrical codes.
WARNING
Personal Protective Equipment (PPE)
Required!
Failure to wear proper PPE for the job being
undertaken could result in death or serious injury.
Technicians, in order to protect themselves from
potential electrical, mechanical, and chemical
hazards, MUST follow precautions in this manual and
on the tags, stickers, and labels, as well as the
instructions below:
• Before installing/servicing this unit, technicians
MUST put on all PPE required for the work being
undertaken (Examples; cut resistant gloves/
sleeves, butyl gloves, safety glasses, hard hat/
bump cap, fall protection, electrical PPE and arc
flash clothing). ALWAYS refer to appropriate
Safety Data Sheets (SDS) and OSHA guidelines
for proper PPE.
• When working with or around hazardous
chemicals, ALWAYS refer to the appropriate
SDS and OSHA/GHS (Global Harmonized
System of Classification and Labelling of
Chemicals) guidelines for information on
allowable personal exposure levels, proper
respiratory protection and handling
instructions.
• If there is a risk of energized electrical contact,
arc, or flash, technicians MUST put on all PPE in
accordance with OSHA, NFPA 70E, or other
country-specific requirements for arc flash
protection, PRIOR to servicing the unit. NEVER
PERFORM ANY SWITCHING, DISCONNECTING,
OR VOLTAGE TESTING WITHOUT PROPER
ELECTRICAL PPE AND ARC FLASH CLOTHING.
ENSURE ELECTRICAL METERS AND
EQUIPMENT ARE PROPERLY RATED FOR
INTENDED VOLTAGE.

WSHP-SVX014J-EN 3
WARNING
Follow EHS Policies!
Failure to follow instructions below could result in
death or serious injury.
• All Trane personnel must follow the company’s
Environmental, Health and Safety (EHS) policies
when performing work such as hot work,
electrical, fall protection, lockout/tagout,
refrigerant handling, etc. Where local
regulations are more stringent than these
policies, those regulations supersede these
policies.
• Non-Trane personnel should always follow local
regulations.
Copyright
This document and the information in it are the property of
Trane, and may not be used or reproduced in whole or in
part without written permission. Trane reserves the right to
revise this publication at any time, and to make changes to
its content without obligation to notify any person of such
revision or change.
Trademarks
All trademarks referenced in this document are the
trademarks of their respective owners.
Revision History
• Removed EXHF/DXHF data and ZN524 data
throughout the document.
• Added Symbio™ 400-B information throughout the
document.
• Updated the dimensional data diagrams and tables for
EXH/DXH in the Unit Dimensions chapter.
• Updated the Electrical data tables and Wiring Diagram
chapter.
Introduction

4WSHP-SVX014J-EN
Model Number Description . . . . . . . . . . . . . . . . . . . 6
EXVH/DXVH Models . . . . . . . . . . . . . . . . . . . . . . . 6
Overview of Manual. . . . . . . . . . . . . . . . . . . . . . . . . . 7
Unit Nameplate. . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Compressor Nameplate . . . . . . . . . . . . . . . . . . . . 7
Model Number Description . . . . . . . . . . . . . . . . . . 7
General Information . . . . . . . . . . . . . . . . . . . . . . . . . 8
Unit Description . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Air-to-Refrigerant Coil . . . . . . . . . . . . . . . . . . . . . . 8
Water-to-Refrigerant Coil . . . . . . . . . . . . . . . . . . . 8
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
System Input Devices and Functions . . . . . . . . . 8
Deluxe 24V Controls (option) . . . . . . . . . . . . . . . 8
Symbio™ 400-B/Tracer® UC400-B
(option). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Pump Module (Field Installed
Accessory) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Waterside Economizer (Option) . . . . . . . . . . . . . 8
Boilerless Control/Electric Heat
(Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Pre-Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Unit Inspection Checklist. . . . . . . . . . . . . . . . . . . 10
Jobsite Inspection Checklist . . . . . . . . . . . . . . . . 10
Jobsite Storage . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Unit Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Service Clearances . . . . . . . . . . . . . . . . . . . . . . . 12
Unit Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Weight Distribution for Hanging the DXH
and EXH Model . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
General Installation Checks . . . . . . . . . . . . . . . . 27
Main Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Electric Heat Requirements . . . . . . . . . . . . . . . . 27
Low Voltage Wiring (AC)
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Filter Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Supply-Air Ductwork . . . . . . . . . . . . . . . . . . . . . . 28
Return-Air Ductwork . . . . . . . . . . . . . . . . . . . . . . 28
Ducted Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Ducted Filter Rack . . . . . . . . . . . . . . . . . . . . . . . 30
Sound Attenuation Pad . . . . . . . . . . . . . . . . . . . . 30
Hanging the Horizontal Unit . . . . . . . . . . . . . . . . 30
Condensate Drain Connection. . . . . . . . . . . . . . 31
Supply Pipe Connections . . . . . . . . . . . . . . . . . . 31
Cleaning and Flushing the Water Loop. . . . . . . 31
Field Installed Power Wiring. . . . . . . . . . . . . . . . 32
Main Unit Power Wiring. . . . . . . . . . . . . . . . . . . . 32
Control Power Transformer . . . . . . . . . . . . . . . . 32
Thermostat Location . . . . . . . . . . . . . . . . . . . . . . 33
Thermostats and Zone Sensors . . . . . . . . . 33
Controls Using 24 Vac . . . . . . . . . . . . . . . . . . . . . 36
External Smoke Detection Wiring to
Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Deluxe Controller . . . . . . . . . . . . . . . . . . . . . 39
Symbio™ 400-B/UC400-B
Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Airflow Adjustment . . . . . . . . . . . . . . . . . . . . . . . . 39
Units with Deluxe 24V controls . . . . . . . . . . 39
Waterside Economizer Installation . . . . . . . . . . 40
Waterside Economizer Installation for
Horizontal 0.75 to 6 Ton Units . . . . . . . . . . . 40
Waterside Economizer Installation for
Vertical Units . . . . . . . . . . . . . . . . . . . . . . . . . 41
Waterside Economizer Start-Up
Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Pre-Start Checklist. . . . . . . . . . . . . . . . . . . . . . . . . . 51
Start-Up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Initial Unit Start-Up. . . . . . . . . . . . . . . . . . . . . . . . 52
Start-Up Checklist and Log. . . . . . . . . . . . . . . . . 52
Operating Pressures . . . . . . . . . . . . . . . . . . . . . . 52
Table of Contents

WSHP-SVX014J-EN 5
Water Pressure Drop. . . . . . . . . . . . . . . . . . . . . . 59
Water Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Preventative Maintenance . . . . . . . . . . . . . . . . . 61
Condensate Trap . . . . . . . . . . . . . . . . . . . . . . . . . 62
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Deluxe Controls . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Wiring Diagrams. . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . 67
Standard Warranty. . . . . . . . . . . . . . . . . . . . . . . . 67
Extended Warranty . . . . . . . . . . . . . . . . . . . . . . . 67
Table of Contents

6WSHP-SVX014J-EN
Model Number Description
EXVH/DXVH Models
Digits 1–3 — Unit Configuration
EXV = High Efficiency Vertical
DXV = Two-stage High Efficiency Vertical
EXH = High Efficiency Horizontal
DXH = Two-stage High Efficiency Horizontal
Digit 4 — Development Sequence
G
Digits 5–7 — Nominal Size (MBH)
009 = 9.0 MBH (EX only)
012 = 12.0 MBH (EX only)
015 = 15.0 MBH (EX only)
018 = 18.0 MBH (EX only)
024 = 24.0 MBH
030 = 30.0 MBH (EX only)
036 = 36.0 MBH
042 = 42.0 MBH (EX only)
048 = 48.0 MBH
060 = 60.0 MBH
070 = 70.0 MBH
Digit 8 — Voltage (Volts/Hz/Phase)
4= 460/60/3
7= 265/60/1
A= 208-230/60/1
B= 208-230/60/3
Digit 9 — Heat Exchanger
1= Copper-Water Coil
2= Cupro-Nickel Water Coil
7= Insulated Copper-Water Coil/Suction Line
8= Insulated Cupro-Nickel Water Coil/Suction Line
Digit 10 — Design Sequence
A= First Design Sequence
Digit 11 — Refrigeration Circuit
0= Heating and Cooling Circuit
2= Heating and Cooling Circuit with Hot Gas
Reheat
3= Heating and Cooling Circuit with Waterside
Economizer
4= Heating and Cooling Circuit with Waterside
Economizer, Hot Gas Reheat
Digit 12 — Blower Configuration
K= Variable ECM Motor, Constant Torque
Digit 13 — Freeze Protection2
A= 20°F Freezestat (For Glycol Loop)
B= 35°F Freezestat (For Water Loop)
Digit 14 — Open Digit = 0
Digit 15 — Supply-Air Arrangement
T= Top Supply-Air Arrangement
B= Back Supply-Air Arrangement
L= Left Supply-Air Arrangement
R= Right Supply-Air Arrangement
Digit 16 — Return-Air Arrangement
L= Left Return-Air Arrangement
R= Right Return-Air Arrangement
Digit 17 — Control Types
D= Deluxe 24V Controls
H= Symbio™ 400-B/UC400-B
J= Symbio 400-B/UC400-B w/Air-Fi® Wireless
Communications
Digit 18 — Tstat/Sensor Location
0= Wall Mounted Location
Digit 19 — Fault Sensors
1= Condensate Overflow Sensor
3= Condensate Overflow and Filter Maintenance
Timer
6= Condensate Overflow and Fan Status
J= Fan Status, Filter Maintenance Timer and
Condensate Overflow Sensor
Digit 20 — Temperature Sensor
0= No Additional Temperature Sensor
1= Entering Water Sensor
Digit 21 — Insulation
1= Matte Faced Insulation
2= Foil Faced Insulation
Digit 22 — Electric Heat
0= No Electric Heat
6= Field Mounted External Boilerless LOW Electric
Heat
7= Field Mounted External Boilerless MED Electric
Heat
8= Field Mounted External Boilerless HIGH
Electric Heat
9= Boilerless Electric Heat Ready
Digit 23 — Unit Mounted Disconnect
0= No Unit Mounted Disconnect
2= Unit Mounted Disconnect
Digit 24 — Filter Type
1= 1-inch Throwaway Filter
2= 2-inch Throwaway Filter
4= 2-inch MERV 8
5= 2-inch MERV 13
Digit 25 — Acoustic Arrangement
1= Standard Sound Attenuation
2= Deluxe Sound Attenuation
Digits 26–36 — Does Not Apply
00000000000 = Digits 26-36 are not applicable to
the EXV or DXV products
Digit 37 — Ducted Filter Rack
0= Non-ducted filter rack
A= Ducted Filter Rack Side Access/LH-RH
C= Ducted Filter Rack (Bottom Access)
Digit 38 — Isolation Valve
0= No Isolation Valve
1= Factory Mounted Isolation Valve
Digit 39 — Power Connection
1= Single Point
2= Electric Heat Power Separate from Unit
Digit 40 — Drain Pan
A= Polymer Drain Pan
B= Stainless Steel Drain Pan
Model Number Note:
Notes:
1. Deluxe Sound option to be made available in
later product release.
2. 20°F Freezestat is typically used in a
geothermal application. 35°F Freezestat is
typically used in a boiler/tower application

WSHP-SVX014J-EN 7
Overview of Manual
Note: One copy of this document ships inside the control
panel of each unit and is customer property. It must
be retained by the unit’s maintenance personnel.
This booklet describes proper installation, operation, and
maintenance procedures for air cooled systems.
By carefully reviewing the information within this manual
and following the instructions, the risk of improper
operation and/or component damage will be minimized.
It is important that periodic maintenance be performed to
help assure trouble free operation. A maintenance
schedule is provided at the end of this manual.
Should equipment failure occur, contact a qualified service
organization with qualified, experienced HVAC technicians
to properly diagnose and repair this equipment.
Unit Nameplate
The unit nameplate is located on the outside of the control
box access panel at the front of the unit. It includes the unit
model number, serial number, electrical characteristics,
refrigerant charge, and other pertinent unit data.
Compressor Nameplate
The nameplate for the compressors are located on the
compressor shell.
Model Number Description
All products are identified by a multiple-character model
number that precisely identifies a particular type of unit. Its
use will enable the owner/operator, installing contractors,
and service engineers to define the operation, specific
components, and other options for any specific unit.
When ordering replacement parts or requesting service, be
sure to refer to the specific model number and serial
number printed on the unit nameplate.

8WSHP-SVX014J-EN
General Information
Unit Description
Before shipment, each unit is leak tested, dehydrated,
charged with refrigerant and run tested for proper control
operation.
Air-to-Refrigerant Coil
The air-to-refrigerant coil is aluminum fin, mechanically
bonded to the copper tubing.
Water-to-Refrigerant Coil
The water-to-refrigerant coil is a copper or cupro-nickel
(option) and steel tube (tube-within-a-tube) design, leak
tested to assure there is no cross leakage between the
water tube (copper/cupro-nickel) and refrigerant gas (steel
tube).
Table 1. High/low pressure switch
Trip Recover Unit
LP 40 +/-4 56 +/-4 psig
HP 650 +/-10 550 +/-10 psig
Controls
The available control type is a Deluxe 24V control option, a
Symbio™ 400-B/Tracer® UC400-B BACnet® control
option for all unit sizes.
All power wiring to the equipment is made at the unit’s
compressor contactor or optional disconnect switch for the
EXH/V 0.75 to 6 ton units and the DXH/V 2 to 6 ton units.
For units without the disconnect switch, the power wiring
needs to be connected to the screw terminals of the
compressor contactor. All low-voltage wiring is made at the
unit’s low voltage terminal plug.
System Input Devices and
Functions
A thermostat, zone sensor, or building automation system
is required to operate the water-source heat pump. The
flexibility of having several mode capabilities depends upon
the type of sensor and/or remote panel selected.
Troubleshooting and connection diagrams for the 24V
control systems may be located in the back of this manual.
All digital control troubleshooting tips and connection
diagrams are located in BAS-SVX065*-EN (UC400-B).
Deluxe 24V Controls (option)
Units containing the Deluxe 24V control design will
incorporate a microprocessor-based control board. The
Trane microprocessor board is factory wired to a terminal
plug to provide all necessary terminals for field connection.
The deluxe board is equipped with a random start relay,
anti-short cycle timer, brown out protection, compressor
disable, condensate overflow, unit safety control,
diagnostics, and a generic relay (which may be available
for field use).
Symbio™ 400-B/Tracer® UC400-
B (option)
The Symbio 400-B/UC400-B is a BTL Listed BACnet®
controller that can operate stand- alone or within a Building
Automation System (BAS) such as Tracer® SC+. For
installation, operation, and maintenance, see BAS-
SVX065*-EN (UC400-B).
Pump Module (Field Installed
Accessory)
The pump module shall consist of either a single or dual 1/6
HP cast iron pump and a brass three-way shut-off valve.
The pump module kits shall contain the necessary
components for the installation, operation and maintenance
of the water circuit of a closed-loop distributed pumping
application.
Waterside Economizer (Option)
Instructions for mechanical connection of the waterside
economizer to the water-source heat pump may be found
in the dimensional section of this manual.
The waterside economizer is designed to begin
economizing mode when water temperatures fall below the
field adjustable temperature of 25, 35, 45, 55 or 60°F (for
the Deluxe control option), or below the programmed set-
point (for the Symbio™ 400-B/UC400-B control option).
When the temperature is less than the setpoint, fluid will
flow into the economizing coil, while simultaneously halting
mechanical operation of the compressor. Mechanical
cooling will continue on a call for a second stage from the
thermostat or system control. Entering water temperature
sensor is factory provided for field installation on the
entering water side of the coil.
Boilerless Control/Electric Heat
(Option)
This option targets building designs that do not incorporate
a boiler to heat the loop system. During a heavy heating
load, the loop temperature may begin to fall. As the loop
temperature decreases, the heating capacity of the heat
pump will also decrease. In the heating mode, when the
loop temperature falls below 55°F (factory setting), the
electric heater is energized, and the compressor is locked
out. The system’s electric heat source will continue to be
utilized for primary heating until the loop temperature rises

WSHP-SVX014J-EN 9
above 60°F. Once the loop temperature rises above 60°F,
the boilerless controller returns the unit to normal
compressor heating operation and locks out the electric
heater.
For the EXV/H and DXV/H models, the electric heat will be
field installed by the contractor.
Note: The boilerless controller has a field adjustable
entering water temperature setting of 25, 35, 45, 55,
and 60 degrees. The compressor operation will
return to normal operation when the loop
temperature rises 5 degrees above the setpoint.
This electric heat option is designed for primary heat
only, not to run as supplemental heat to the heating
function of the heat pump.
Table 2. Refrigerant charge (EXH/EXV)
Model (60 Hz) Heat Pump (oz)/Kg)
Heat Pump w/ HGR
(oz)/Kg)
EXH/V009 35 / 0.992 37 / 1.049
EXH/V012 35 / 0.992 37 / 1.049
EXH/V015 39.5 / 1.12 42.5 / 1.205
EXH/V018 56 / 1.588 59.5 / 1.687
EXH/V024 60 / 1.701 64 / 1.814
Table 2. Refrigerant charge (EXH/EXV) (continued)
Model (60 Hz) Heat Pump (oz)/Kg)
Heat Pump w/ HGR
(oz)/Kg)
EXH/V030 67 / 1.899 72.5 / 2.055
EXH/V036 68 / 1.928 74 / 2.098
EXH/V042 83 / 2.353 90.5 / 2.566
EXH/V048 87 / 2.466 95 / 2.693
EXH/V060 101 / 2.863 111 / 3.147
EXH/V070 122 / 3.459 132 / 3.742
Table 3. Refrigerant charge (DXH/DXV)
Model (60 Hz) Heat Pump (oz)/Kg)
Heat Pump w/ HGR
(oz)/Kg)
DXH/V024 59 / 1.673 63 / 1.786
DXH/V036 64 / 1.814 70 / 1.984
DXH/V048 86 / 2.438 94 / 2.665
DXH/V060 101 / 2.863 111 / 3.147
DXH/V070 123 / 3.487 133 / 3.77
General Information

10 WSHP-SVX014J-EN
Pre-Installation
WARNING
Fiberglass Wool!
Exposure to glass wool fibers without all necessary
PPE equipment could result in cancer, respiratory,
skin or eye irritation, which could result in death or
serious injury. Disturbing the insulation in this
product during installation, maintenance or repair will
expose you to airborne particles of glass wool fibers
and ceramic fibers known to the state of California to
cause cancer through inhalation.
You MUST wear all necessary Personal Protective
Equipment (PPE) including gloves, eye protection, a
NIOSH approved dust/mist respirator, long sleeves
and pants when working with products containing
fiberglass wool.
Precautionary Measures:
• Avoid breathing fiberglass dust.
• Use a NIOSH approved dust/mist respirator.
• Avoid contact with the skin or eyes. Wear long-
sleeved, loose-fitting clothing, gloves, and eye
protection.
• Wash clothes separately from other clothing;
rinse washer thoroughly.
• Operations such as sawing, blowing, tear-out,
and spraying may generate fiber concentrations
requiring additional respiratory protection. Use
the appropriate NIOSH approved respirator.
First Aid Measures:
• Eye Contact - Flush eyes with water to remove
dust. If symptoms persist, seek medical
attention.
• Skin Contact - Wash affected areas gently with
soap and warm water after handling.
Unit Inspection Checklist
• Unpack all components of the kit.
• Check carefully for any shipping damage. If any
damage is found it must be reported immediately and a
claim made against the transportation company.
Important: Equipment is shipped FOB (Free on Board)
at the manufacturer. Therefore, freight
claims for damages against the carrier
must be initiated by the receiver.
• Visually inspect the components for shipping damage
as soon as possible after delivery, before it is stored.
Concealed damage must be reported within 15 days.
• If concealed damage is discovered, stop unpacking the
shipment.
• Do not remove damaged material from the receiving
location. Take photos of the damage, if possible. The
owner must provide reasonable evidence that the
damage did not occur after delivery.
• Notify the carrier’s terminal of damage immediately by
phone and by mail. Request an immediate joint
inspection of the damage by the carrier and the
consignee.
• Do not attempt to repair any damaged parts until the
parts are inspected by the carrier’s representative.
Jobsite Inspection Checklist
Always perform the following checks before accepting a
unit:
• Verify that the nameplate data matches the data on the
sales order and bill of lading (including electrical data).
• Verify that the power supply complies with the unit
nameplate specifications.
• Visually inspect the exterior of the unit, for signs of
shipping damage. Do not sign the bill of lading
accepting the unit(s) until inspection has been
completed. Check for damage promptly after the unit(s)
are unloaded. Once the bill of lading is signed at the
jobsite, the unit(s) are now the property of the SOLD
TO party and future freight claims MAY NOT be
accepted by the freight company.
Jobsite Storage
NOTICE
Microbial Growth!
Failure to follow instructions below could result in
odors and damage to the equipment and building
materials.
The floor or foundation must be level and the
condensate drain at the proper height for proper
drainage and condensate flow. Standing water and
wet surfaces inside the equipment can become an
amplification site for microbial growth (mold). If there
is evidence of microbial growth on the interior
insulation, it should be removed and replaced prior to
operating the system.
This unit is intended for indoor use only. To protect the unit
from damage due to the elements, and to prevent possible
IAQ contaminant sources from growing, the unit should be
stored indoors. If indoor storage is not possible, the
following provisions for outdoor storage must be met:
• Place the unit(s) on a dry surface or raise above the
ground to assure adequate air circulation beneath the
unit.
• Cover the unit(s) with a water proof tarp to protect them
from the elements.
