Trane Axiom GECE 006 Installation and operating instructions

Water Source Heat Pump
Axiom™ High Efficiency Console
0.5 to 1.5 Tons — 50/60 Hz
Installation, Operation, and Maintenance
March 2021 WSHP-SVX11E-EN
Model Numbers: GECE 006, 009, 012, 015, 018 (60 Hz)
GECE 006, 009, 012, 015 (50 Hz)
SAFETY WARNING
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of
heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are
attached to the equipment.

©2021 Trane WSHP-SVX11E-EN
Introduction
Read this manual thoroughly before operating or servicing
this unit.
Warnings, Cautions, and Notices
Safety advisories appear throughout this manual as
required. Your personal safety and the proper operation of
this machine depend upon the strict observance of these
precautions.
The three types of advisories are defined as follows:
WARNING Indicates a potentially hazardous
situation which, if not avoided, could
result in death or serious injury.
CAUTIONsIndicates a potentially hazardous
situation which, if not avoided, could
result in minor or moderate injury. It
could also be used to alert against
unsafe practices.
NOTICE Indicates a situation that could result in
equipment or property-damage only
accidents.
Important Environmental Concerns
Scientific research has shown that certain man-made
chemicals can affect the earth’s naturally occurring
stratospheric ozone layer when released to the
atmosphere. In particular, several of the identified
chemicals that may affect the ozone layer are refrigerants
that contain Chlorine, Fluorine and Carbon (CFCs) and
those containing Hydrogen, Chlorine, Fluorine and
Carbon (HCFCs). Not all refrigerants containing these
compounds have the same potential impact to the
environment. Trane advocates the responsible handling of
all refrigerants-including industry replacements for CFCs
and HCFCs such as saturated or unsaturated HFCs and
HCFCs.
Important Responsible Refrigerant
Practices
Trane believes that responsible refrigerant practices are
important to the environment, our customers, and the air
conditioning industry. All technicians who handle
refrigerants must be certified according to local rules. For
the USA, the Federal Clean Air Act (Section 608) sets forth
the requirements for handling, reclaiming, recovering and
recycling of certain refrigerants and the equipment that is
used in these service procedures. In addition, some states
or municipalities may have additional requirements that
must also be adhered to for responsible management of
refrigerants. Know the applicable laws and follow them.
WARNING
Proper Field Wiring and Grounding
Required!
Failure to follow code could result in death or serious
injury. All field wiring MUST be performed by qualified
personnel. Improperly installed and grounded field
wiring poses FIRE and ELECTROCUTION hazards. To
avoid these hazards, you MUST follow requirements for
field wiring installation and grounding as described in
NEC and your local/state electrical codes.
WARNING
Personal Protective Equipment (PPE)
Required!
Failure to wear proper PPE for the job being undertaken
could result in death or serious injury. Technicians, in
order to protect themselves from potential electrical,
mechanical, and chemical hazards, MUST follow
precautions in this manual and on the tags, stickers,
and labels, as well as the instructions below:
• Before installing/servicing this unit, technicians
MUST put on all PPE required for the work being
undertaken (Examples; cut resistant gloves/sleeves,
butyl gloves, safety glasses, hard hat/bump cap, fall
protection, electrical PPE and arc flash clothing).
ALWAYS refer to appropriate Safety Data Sheets
(SDS) and OSHA guidelines for proper PPE.
• When working with or around hazardous chemicals,
ALWAYSrefer tothe appropriateSDSandOSHA/GHS
(Global Harmonized System of Classification and
Labeling of Chemicals) guidelines for information on
allowable personal exposure levels, proper
respiratory protection and handling instructions.
• If there is a risk of energized electrical contact, arc, or
flash, technicians MUST put on all PPE in accordance
with OSHA, NFPA 70E, or other country-specific
requirements for arc flash protection, PRIOR to
servicing the unit. NEVER PERFORM ANY
SWITCHING, DISCONNECTING, OR VOLTAGE
TESTING WITHOUT PROPER ELECTRICAL PPE AND
ARC FLASH CLOTHING. ENSURE ELECTRICAL
METERS AND EQUIPMENT ARE PROPERLY RATED
FOR INTENDED VOLTAGE.

WARNING
Follow EHS Policies!
Failure to follow instructions below could result in
death or serious injury.
• All Trane personnel must follow the company’s
Environmental, Health and Safety (EHS) policies
when performing work such as hot work, electrical,
fall protection, lockout/tagout, refrigerant handling,
etc. Where local regulations are more stringent than
these policies, those regulations supersede these
policies.
• Non-Trane personnel should always follow local
regulations.
Introduction
WSHP-SVX11E-EN 3
Copyright
This document and the information in it are the property of
Trane, and may not be used or reproduced in whole or in
part without written permission. Trane reserves the right
to revise this publication at any time, and to make changes
to its content without obligation to notify any person of
such revision or change.
Trademarks
All trademarks referenced in this document are the
trademarks of their respective owners.
Revision History
Electrical Data updates - Blower motor hp

4WSHP-SVX11E-EN
Table of Contents
Model Number Description . . . . . . . . . . . . . . . 5
General Information . . . . . . . . . . . . . . . . . . . . . 6
Jobsite Inspection . . . . . . . . . . . . . . . . . . . . . 6
Jobsite Storage . . . . . . . . . . . . . . . . . . . . . 6
Unit Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . 7
Service Clearances . . . . . . . . . . . . . . . . . . . . . 7
Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Pre-Start Checklist . . . . . . . . . . . . . . . . . . . . . . 25
Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Initial Unit Start-up . . . . . . . . . . . . . . . . . . . 26
Start-Up Checklist and Log . . . . . . . . . . . 26
Operating Pressures . . . . . . . . . . . . . . . . . 26
Water Pressure Drop . . . . . . . . . . . . . . . . 29
Water Volume . . . . . . . . . . . . . . . . . . . . . . 30
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Preventive Maintenance . . . . . . . . . . . . . 31
Filter Replacement (standard height configu-
ration) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Filter Replacement (low height configuration)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 32
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . 34
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Standard Warranty . . . . . . . . . . . . . . . . . . 38
Extended Warranty . . . . . . . . . . . . . . . . . 38

WSHP-SVX11E-EN 5
Digits 1-3 — Unit Configuration
GEC = High Efficiency Console
Digit 4 — Unit Configuration
E
Digits 5-7 — Nominal Capacity
006 = 0.5 Tons
009 = 0.75 Tons
012 = 1 Tons
015 = 1.25 Tons
018 = 1.5 Tons
Digit 8 — Voltage Volts/Hz/
Phase)
0 = 115/60/1
1 = 208/60/1
2 = 230/60/1
6 = 220-240/50/1
7 = 265/60/1
Digit 9 — Heat Exchanger
1 = Copper-Water Coil
2 = Cupro-Nickel Water Coil
Digit 10 — Design Sequence
B
Digit 11 — Refrigeration Circuit
0 = Heating and Cooling Circuit
2 = Heating and Cooling Circuit with Hot
Gas Reheat
Digit 12 — Blower Configuration
1= Standard Blower Motor
Digit 13 — Freeze Protection
A = 20° F Freezestat (Extended Range
Geothermal)
B = 35° F Freezestat
Digit 14 — Open Digit
0 = Open Digit
S = Design Special
Digit 15 — Supply-Air
Arrangement
0 = Standard Supply-Air Arrangement
Digit 16 — Return-Air
Arrangement
0 = Standard Return-Air Arrangement
Digit 17 — Control Types
D = Deluxe 24V Controls
B = Tracer® ZN524 Controls
E = Deluxe 24V Control with
Programmable Thermostat
H = UC400-B
J = UC400-B with Air-Fi® Wireless
Communications
Digit 18 — Tstat/Sensor Location
0 = Wall Mounted Location
1 = Unit Mounted Location with Standard
Entry
2 = Unit Mounted Location with Keylock
Entry
Digit 19 — Fault Sensors
1 = Condensate Overflow Sensor
3 = Condensate Overflow and Filter
Maintenance Timer
6 = Condensate Overflow and Fan Status
J = Condensate Overflow Sensor, Fan
Status and Filter Maintenance Timer
Digit 20 — Temperature Sensor
0 = No Additional Temperature Sensor
1 = Entering Water Sensor
Digit 21 — Open Digit
0 = Open Digit
Digit 22 — Electric Heat
0 = No Electric Heat
2 = Boilerless Control Electric Heat
(minimum)
3 = Boilerless Control Electric Heat
(maximum)
Digit 23 — Unit Mounted
Disconnect
0 = No Unit Mounted Disconnect
A = Power Cord/Receptacle Box
B = Power Cord/Receptacle Box with
Circuit Breaker
C = On/Off Toggle Switch
Digit 24 — Filter Type
0 = No Filter; Chassis Only
1 = 1-inch Throwaway Filter
A = 1-inch MERV 8 Filter
Digit 25 — Acoustic
Arrangement
0 = Enhanced Sound Attenuation
Digit 26 — Factory Configuration
0 = Standard Factory Configuration
(Chassis, Cabinet and Subbase)
1 = Chassis ONLY
2 = Low Height Factory Configuration
(Chassis, Cabinet and Subbase)
3 = Extended Length Factory
Configuration (Chassis, Cabinet and
Subbase)
Digit 27 — Paint Color
0 = No Paint Selection Available 
1 = Deluxe Beige
2 = Cameo White
3 = Soft Dove
Digit 28 — Outside Air
0 = No Outside Air Option
1 = Outside Air Opening
2 = Motorized Outside Air (2-position)
Digit 29 — Piping Arrangement
L = Left Hand Piping Arrangement
R = Right Hand Piping Arrangement
Digit 30-36 — Does Not Apply to
GEC
0000000 = Digits 30-36 are not applicable
to the GEC product
Model Number Description

6WSHP-SVX11E-EN
General Information
Jobsite Inspection
Each unit has been inspected, tested and operated at the
factory by production and quality associates prior to being
crated for safe transit. However, rough handling or
accidents can occur resulting in damaged equipment
being delivered. Always perform the following checks
before accepting a unit:
• Do not sign the bill of lading accepting the unit(s) until
inspection has been completed. Check for damage
promptly after the unit(s) are unloaded. Once the bill of
lading is signed at the jobsite, the unit(s) are now the
property of the SOLD TO party and future freight claims
MAY NOT be accepted by the freight company.
• Check the unit model numbers on the bill of lading
against those ordered and received to assure
equipment is AS ORDERED.
• Check that the refrigerant charge has been retained
during shipment by use of gauges. Schrader taps are
located and labeled internal to the cabinet.
Figure 1. Schrader location
Important: Verify the charge has been retained. Then,
re-install schrader caps to ensure that
refrigerant leakage does not occur.
Re-install the unit panel using all factory
provided screws.
Jobsite Storage
NOTICE:
Microbial Growth!
Wet interior unit insulation can become an
amplification site for microbial growth (mold), which
could result in odors and damage to the equipment and
building materials. If there is evidence of microbial
growth on the interior insulation, it should be removed
and replaced prior to operating the system.
NOTICE:
Microbial Growth!
Failure to follow instructions below could result in
odors and damage to the equipment and building
materials.The floor or foundation must be level and the
condensate drain at the proper height for proper coil
drainage and condensate flow. Standing water and wet
surfaces inside the equipment can become an
amplification site for microbial growth (mold).
This unit is intended for indoor use only. To protect the unit
from damage due to the elements, and to prevent possible
IAQ contaminant sources from growing, the unit should be
stored indoors. If indoor storage is not possible, the
following provisions for outdoor storage must be met.
• Place the unit(s) on a dry surface or raise above the
ground to assure adequate air circulation beneath the
unit. This is to assure that no portion of the unit
contacts standing water at any time.
• Cover the unit(s) with a water proof tarp to protect
them from the elements.
•Make provisions for continuous venting of the covered
units to prevent moisture from standing on the unit(s)
surfaces. Wet interior unit insulation can become an
amplification site for microbial growth which has been
determined to be a cause of odors and serious health
related indoor air quality problems.
• Store units in the normal UP orientation. Storing units
in this manner maintains oil in the compressor.
• Units may be stacked two high.
Important: Equipment is shipped FOB (Free on Board)
at the manufacturer. Therefore, freight
claims for damages against the carrier must
be initiated by the receiver.

WSHP-SVX11E-EN 7
Unit Dimensions
Service Clearances
Access to the unit for servicing purposes should be
provided at installation. All configurations require
clearance from other mechanical and electrical equipment
on three service sides (shown below). This enables panel
removal from the unit for service/maintenance ability.
Figure 2. Clearances - GEC 0.5 to 1.5 tons
Figure 3. GEC 0.5 to 1.5 tons (60 Hz), 0.5 to 1.25 tons (50 Hz) - cabinet (RH) piping connection
48"
12"
CONTROL
ACCESS
PANEL
2 1/2"
6" LONG, 5/8" I.D.
PLASTIC HOSE
PROVIDED FOR
CONDENSATE
CONNECTION
3 3/8"
2 3/4"
5 5/8"
33" 6"
3 3/4"
4"
7/8"
1 3/4"
3/4"
1 3/4"
4 3/8"
7/8"
25"
23 3/4"
22 3/8"
6 1/4"
21 7/8"
10"
11 1/4"
ELECT. FIELD
HOOK-UP
(4) 1/4" WALL SLEEVE
MOUNTING HOLES
RETURN-AIR OPENING
O/A OPENING
TOP VIEW
FRONT VIEW RIGHT SIDE VIEW
BACK VIEW
WATER-OUT
5/8" ODS
WATER-IN
5/8" ODS
PLASTIC DRAIN
5/8" I.D.
FIELD ADJUSTABLE
BI-DIRECTIONAL GRILLES
9 3/4"
3/4"
4 3/4"
3/4"
7 1/2"
15 3/4"
47 1/4"
PIPE & ELEC.
FIELD HOOK-UP
15" 9 1/4"
4 1/2"
3 5/8" 5/8"
12”
1"
1"

Figure 4. GEC 0.5 to 1.5 tons (60 Hz), 0.5 to 1.25 tons (50 Hz) - cabinet (LH) piping connection
4"
3/4" 9 5/8"
3/4"
47 1/4"
15"
7/8"
4"
1 3/4"
3/4"
13 1/4"
PIPE & ELEC.
FIELD HOOK-UP
7 1/2"
15 3/4"
(4) .250 WALL
SLEEVE MOUNTING HOLES
FILTER ACCESS
33"
3 3/4"
FOR CONDENSATE
2 1/2"
CONNECTION
2 3/4"
3 3/8"
PLASTIC HOSE
6" LONG
6"
1 3/4"
UNIT CONTROLLER
4 3/8"
21 7/8"
11 1/4"
DRAIN CONN.
.625 I.D.
10"
7 3/8"
23 3/4"
22 3/8"
25"
.625 ODS
WATER IN CONN.
.625 ODS
WATER OUT
7/8"
11 3/4"
4 7/8"
RECEPTACLE BOX
48"
12"
SUPPLY AIR GRILLE
SIDE VIEW
BACK VIEW
FRONT VIEW
BACK UNIT PIPE & ELEC.
FIELD HOOK-UP
TOP VIEW
5 1/4"
20 1/2"
7/8"
Unit Dimensions
8WSHP-SVX11E-EN

Figure 5. GEC 0.5 to 1.5 tons (60 Hz), 0.5 to 1.25 tons (50 Hz) - subbase (RH)
4 3/4"
48"
9 1/4"
33"
6"
15"
9 5/8"
3/4"
11 1/4"
3 3/4"
3/4"
TOP VIEW
ISO VIEW
Unit Dimensions
WSHP-SVX11E-EN 9

Figure 6. GEC 0.5 to 1.5 tons (60 Hz), 0.5 to 1.25 tons (50 Hz) - subbase (LH)
4 3/4"
48"
13 1/4"
33"
6"
15"
9 5/8"
3/4"
11 1/4"
3 3/4"
3/4"
TOP VIEW
ISO VIEW
Unit Dimensions
10 WSHP-SVX11E-EN

Figure 7. GEC 0.5 to 1.5 tons (60 Hz), 0.5 to 1.25 tons (50 Hz) - cabinet (RH) piping extended length
18 7/8"
9 1/4"
1"
1"
O/A OPENING 15" 3/4"
1 3/4"
9 1/4"
(4).25 WALL SLEEVE
MOUNTING HOLES
19"
3/8"
20 1/2"
10 1/2"
7/8"
4 3/8"
6 1/4"
21 7/8" 23 3/4"
22 3/8"
11 1/4"
25"
PLASTIC DRAIN CONN.
.625 I.D.
WATER IN CONN.
.625 O.D.S.
WATER OUT CONN
.625 O.D.S.
16 3/8"
6 3/8"
RECEPTACLE BOX
UNIT CONTROLLER
33"
3 3/4"
FILTER ACCESS
2 1/2"
6" LONG PLASTIC HOSE
FOR CONDENSATE CONN.
6"
1 3/4"
18 1/4"
17 3/4"
63"
12"
SUPPLY AIR GRILLE
PIPE & ELEC.
FIELD HOOK-UP.
SIDE VIEW
FRONT VIEW
BACK VIEW
TOP VIEW
BACK OF UNIT
20 5/8"
ELECTRIC
FIELD
HOOKUP
62 1/4"
3/4"
7 1/2"
15 3/4"
Unit Dimensions
WSHP-SVX11E-EN 11

Figure 8. GEC 0.5 to 1.5 tons (60 Hz), 0.5 to 1.25 tons (50 Hz) - cabinet (LH) piping extended length
ELECTRIC & PIPE
FIELD HOOK UP
62 1/4"
15"
1 3/4"
3/4"
7/8"
19"
20 1/2"
28"
O/A OPENING
7 1/2"
15 3/4"
(4) .25 WALL SLEEVE
MOUNTING HOLES
4 3/8"
21 7/8"
11 1/4"
PLASTIC DRAIN CONN.
.625 I.D.
7 3/8"
23 3/4"
22 3/8"
25"
WATER OUT
.625 ODS
WATER IN CONN
.625 ODS
7/8"
6" LONG
PLASTIC HOSE FOR
CONDENSATE CONN.
33"
3 3/4"
2 1/2"
18 1/2"
17 3/4"
FILTER ACCESS
6"
1 3/4"
UNIT CONTROLLE
R
63"
SUPPLY AIR GRILLE
12"
8 3/4"
3/4"
9 1/4"
3/4"
SIDE VIEW
BACK VIEW
FRONT VIEW
BACK OF UNIT
PIPE & ELEC.
FIELD HOOK-UP
TOP VIEW
11 3/4"
10"
4 7/8"
RECEPTACLE BOX
3/8"
3/4"
Unit Dimensions
12 WSHP-SVX11E-EN

Figure 9. GEC 0.5 to 1.5 tons (60 Hz), 0.5 to 1.25 tons (50 Hz) - subbase (RH) extended length
19 3/4"
63"
9 1/4"
33"
6"
15"
9 5/8"
3/4"
11 1/4"
3 3/4"
3/4"
TOP VIEW
ISO VIEW
Unit Dimensions
WSHP-SVX11E-EN 13

Figure 10. GEC 0.5 to 1.5 tons (60 Hz), 0.5 to 1.25 tons (50 Hz) - subbase (LH) extended length
19 3/4"
63"
28"
33"
6"
15"
9 5/8"
3/4"
11 1/4"
3 3/4"
3/4"
TOP VIEW
ISO VIEW
Unit Dimensions
14 WSHP-SVX11E-EN

Figure 11. GEC 0.5 to 1.5 tons (60 Hz), 0.5 to 1.25 tons (50 Hz) - cabinet (RH) low height unit
3/4"
3/4"
4"
9 5/8"
10 1/2"
7/8"
4 3/8"
3 3/4"
19 3/8" 21 1/4"
19 7/8"
11 1/4"
22 1/2"
.625 I.D.
DRAIN CONN. WATER IN
.625 ODS
WATER OUT
.625 ODS
13 7/8"
6 1/4"
RECEPTACLE BOX
PIPE & ELECTRICAL
FIELD HOOK-UP
47 1/4"
5"
15 3/4"
(4) .25 WALL SLEEVE
MOUNTING HOLES
4"
7/8"
34 3/4"
1 3/4"
RETURN AIR OPENING
1 1/4"
6" LONG,
PLASTIC HOSE
PROVIDED FOR
CONDENSATE
CONNECTION
7 3/4"
3 3/8"
2 3/4"
UNIT CONTROLLER
48"
12"
FIELD ADJUSTABLE
BI-DIRECTIONAL GRILLES
SIDE VIEW
BACK VIEW
FRONT VIEW
TOP VIEW
PIPE & ELECTRICAL
FIELD HOOK-UP
BACK OF UNIT
1 1/2"
3/4"
20 1/2"
Unit Dimensions
WSHP-SVX11E-EN 15

Figure 12. GEC 0.5 to 1.5 tons (60 Hz), 0.5 to 1.25 tons (50 Hz) - cabinet (LH) low height unit
4"
3/4" 3/4"
9 5/8"
47 1/4"
7/8"
4" 3/4"
PIPE & ELECTRIC
FIELD HOOK-UP
5"
15 3/4"
(4) .250 WALL SLEEVE
MOUNTING HOLES
48"
FIELD ADJUSTABLE
BI-DIRECTIONAL GRILLES
12"
34 3/4"
1 3/4" 1 1/4"
6" LONG
PLASTIC HOSE
PROVIDED FOR
CONDENSATE
CONNECTION.
1 1/2"
4 7/8"
2 3/4"
3 3/8" CONTROL
ACCESS
PANEL
4 3/8"
19 3/8"
11 1/4"
10 3/8"
4 7/8"
21 1/4"
19 7/8"
22 1/2"
.625 ODS
WATER OUT
.625 ODS
WATER IN
7/8"
SIDE VIEW
BACK VIEW
FRONT VIEW
TOP VIEW
PIPE & ELEC.
FIELD HOOK-UP
BACK OF UNIT
4 7/8"
RECEPTACLE BOX
9 1/4"
PLASTIC DRAIN CONN.
.625 I.D.
20 1/2"
Unit Dimensions
16 WSHP-SVX11E-EN

Figure 13. GEC 0.5 to 1.5 tons (60 Hz), 0.5 to 1.25 tons (50 Hz) - chassis (RH)
3"
1 7/8"
3/4"
2 1/4"
12 1/4"
4"
14 1/2"
3 3/4"
2"
5/8"
17 1/4"
CUT OUT FOR
LOW VOLTAGE
TERMINAL STRIP
6 1/4"
10 1/2"
AIR SIDE
SERVICE PANEL
20 1/4"
REFRIGERATION
SERVICE PANEL
.625ODS
WATER IN
2 1/8"
1 1/2"
6" LONG, 625 I.D.
PLASTIC HOSE PROVIDE
FOR CONDENSATE CONNECTION.
WATER OUT
.625 ODS
42 1/4"
CONTROL BOX
SERVICE PANEL
2 3/8"
11 1/2"
6 3/8"
4 1/4"
2x4 HIGH VOLTAGE BOX
RIGHT SIDE VIEW
FRONT VIEW
TOP VIEW
Unit Dimensions
WSHP-SVX11E-EN 17

Figure 14. GEC 0.5 to 1.5 tons (60 Hz), 0.5 to 1.25 tons (50 Hz) - chassis (LH)
3"
1 7/8"
17 1/4"
14 1/2"
3 3/4"
CUT OUT FOR
LOW VOLTAGE
TERMINAL STRIP.
3 1/4"
4 3/4"
4"
3/4"
5/8"
2"
10 3/8"
7 5/8"
WATER OUT
.625 ODS.
2 3/8"
1 3/8"
2 1/8"
CONDENSATE CONNECTION
PLASTIC HOSE PROVIDE FOR
6.0" LONG. .625 I.D.
.625 ODS.
WATER IN
AIR SIDE
SERVICE PANEL REFRIGERATION
SERVICE PANEL
HIGH VOLTAGE BOX
42 1/4"
11 1/2" 4 1/4"
6 3/8"
CONTROL BOX
SERVICE PANEL
RECEPTACLE BOX
FRONT VIEW
TOP VIEW
SIDE VIEW
SIDE VIEW
20 1/4"
Unit Dimensions
18 WSHP-SVX11E-EN

WSHP-SVX11E-EN 19
Weights
Table 1. Unit weights GEC (0.5 to 1.5 tons)
Unit Size Shipping Weight with Pallet Shipping Weight without Pallet
GEC Unit Weight (lbs) Chassis Weight (lbs) Unit Weight (lbs) Chassis Weight (lbs)
006 218 170 188 140
009 219 171 189 141
012 234 186 204 156
015 240 192 210 162
018 242 194 212 164

20 WSHP-SVX11E-EN
Installation
WARNING
Hazardous Voltage!
Failure to disconnect power before servicing could
result in death or serious injury. Disconnect all electric
power, including remote disconnects before servicing.
Follow proper lockout/tagout procedures to ensure the
power can not be inadvertently energized.
WARNING
Proper Field Wiring and Grounding
Required!
Failure to follow code could result in death or serious
injury. All field wiring MUST be performed by qualified
personnel. Improperly installed and grounded field
wiring poses FIRE and ELECTROCUTION hazards. To
avoid these hazards, you MUST follow requirements for
field wiring installation and grounding as described in
NEC and your local/state electrical codes.
1. Remove the unit and packaging from the crate. Inspect
the unit. Carefully remove the stretch wrap and
cardboard pieces. The installation literature and may
be found on the back of the unit in a clear, plastic bag.
Unit has been tied to skid by (2) shipping brackets.
2. Remove refrigeration panel and inspect the unit. Be
certain the refrigerant tubing has clearance from
adjacent parts. Verify that the electrical connections
are tight and in-place.
Chassis Refrigeration
Front Panel
Shipping Brackets
Mounting Locations
3. With the chassis still on the subbase, align the unit to
the wall. If unit contains an outside air option, align the
wall cut-out to the subbase outside-air cut-out. Level
the unit per plan requirements. Mark the four
mounting locations for wall sleeve mounting to the
wall. The dimensions should fall in line with Step 5.
4. Remove the chassis from thesubbase via 6 screws. The
chassis is attached to both the subbase and the wall
sleeve (see diagram above). To assure proper
alignment, re-install screws 2 and 3 in the final
installation of the unit (Step 11).
1
2
5
34
6
5. After removing chassis from the subbase, install the
wall flange assembly to the desired wall with the use of
four #10-field provided screws. The wall flange
assembly includes four,¼ in. diameter clearance holes.
6. Mounting of the receptacle box (option) should be
made prior to piping and electrical hook-up. This
factory disconnect option is designed to fit inside the
end pocket. Mount the receptacle box 2 in. above the
top of the subbase with four, #8-field supplied screws.
2"
(4)--#8 FIELD
PROVIDED
MOUNTING
DEVICE
RECEPTACLE BOX
(FACTORY OPTION)
SEE UNIT WIRE
DIAGRAM FOR
ELECTRICAL HOOK-UP
7 1/4"
15 3/4"
47 1/4"
or
62 1/4"
#10 FIELD
PROVIDE
MOUNTING
DEVICE
7. Mounting of the circuit breaker/receptacle box (option)
should be made prior to piping and electrical hook-up.
This factory disconnect option is designed to fit inside
the end pocket. Mount the electrical box flush with the
subbase with four, #8-field supplied screws.
8. Wiring of receptacle box (option). Power wiring to the
equipment should be installed per national and local
electric codes by a professional electrician. Power
wiring to the receptacle box may be done at this time.
See the unit’s wiring schematic for field wiring.
