Trane GEHE 072-180 Installation and operating instructions

SAFETY WARNING
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing
of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and
training. Improperly installed, adjusted or altered equipment by an unqualified person could result in death or
serious injury. When working on the equipment, observe all precautions in the literature and on the tags,
stickers, and labels that are attached to the equipment.
Water Source Heat Pump
Axiom™ Horizontal/Vertical
GEH/V*, EXH/V*
.5 to 25Tons, 50/60 Hz
Installation, Operation,
and Maintenance
Model Numbers GEHE 006-060 - 50/60 Hz GEVE 006-060 - 50/60 Hz
GEHE 072-180 - 50/60 Hz GEVE 072-300 - 50/60 Hz
EXHF 006-070 - 60 Hz EXVF 006-070 - 60 Hz
WSHP-SVX01Q-EN
December 2016

© 2016 Ingersoll Rand All rights reserved WSHP-SVX01Q-EN
Introduction
Read this manual thoroughly before operating or servicing
this unit.
Warnings, Cautions, and Notices
Safety advisories appear throughout this manual as
required.Your personal safety and the proper operation of
this machine depend upon the strict observance of these
precautions.
Important Environmental Concerns
Scientific research has shown that certain man-made
chemicals can affect the earth’s naturally occurring
stratospheric ozone layer when released to the
atmosphere. In particular, several of the identified
chemicals that may affect the ozone layer are refrigerants
that contain Chlorine, Fluorine and Carbon (CFCs) and
those containing Hydrogen, Chlorine, Fluorine and
Carbon (HCFCs). Not all refrigerants containing these
compounds have the same potential impact to the
environment.Trane advocates the responsible handling of
all refrigerants-including industry replacements for CFCs
and HCFCs such as saturated or unsaturated HFCs and
HCFCs.
Important Responsible Refrigerant
Practices
Trane believes that responsible refrigerant practices are
important to the environment, our customers, and the air
conditioning industry. All technicians who handle
refrigerants must be certified.The Federal Clean Air Act
(Section 608) sets forth the requirements for handling,
reclaiming, recovering and recycling of certain
refrigerants and the equipment that is used in these
service procedures. In addition, some states or
municipalities may have additional requirements that
must also be adhered to for responsible management of
refrigerants. Know the applicable laws and follow them.
The three types of advisories are defined as follows:
WARNING Indicates a potentially hazardous
situation which, if not avoided, could
result in death or serious injury.
CAUTIONsIndicates a potentially hazardous
situation which, if not avoided, could
result in minor or moderate injury. It
could also be used to alert against
unsafe practices.
NOTICE Indicates a situation that could result in
equipment or property-damage only
accidents.
WARNING
Proper Field Wiring and Grounding
Required!
Failure to follow code could result in death or serious
injury. All field wiring MUST be performed by qualified
personnel. Improperly installed and grounded field
wiring poses FIRE and ELECTROCUTION hazards.To
avoid these hazards, you MUST follow requirements for
field wiring installation and grounding as described in
NEC and your local/state electrical codes.
WARNING
Personal Protective Equipment (PPE)
Required!
Failure to wear proper PPE for the job being undertaken
could result in death or serious injury. Technicians, in
order to protect themselves from potential electrical,
mechanical, and chemical hazards, MUST follow
precautions in this manual and on the tags, stickers,
and labels, as well as the instructions below:
• Before installing/servicing this unit, technicians
MUST put on all PPE required for the work being
undertaken (Examples; cut resistant gloves/sleeves,
butyl gloves, safety glasses, hard hat/bump cap, fall
protection, electrical PPE and arc flash clothing).
ALWAYS refer to appropriate Material Safety Data
Sheets (MSDS)/Safety Data Sheets (SDS) and OSHA
guidelines for proper PPE.
• When working with or around hazardous chemicals,
ALWAYS refer to the appropriate MSDS/SDS and
OSHA/GHS (Global Harmonized System of
Classification and Labelling of Chemicals) guidelines
for information on allowable personal exposure
levels, proper respiratory protection and handling
instructions.
• If there is a risk of energized electrical contact, arc, or
flash, technicians MUST put on all PPE in accordance
with OSHA, NFPA 70E, or other country-specific
requirements for arc flash protection, PRIOR to
servicing the unit. NEVER PERFORM ANY
SWITCHING, DISCONNECTING, OR VOLTAGE
TESTING WITHOUT PROPER ELECTRICAL PPE AND
ARC FLASH CLOTHING. ENSURE ELECTRICAL
METERS AND EQUIPMENT ARE PROPERLY RATED
FOR INTENDED VOLTAGE.

Introduction
WSHP-SVX01Q-EN 3
Copyright
This document and the information in it are the property of
Trane, and may not be used or reproduced in whole or in
part without written permission.Trane reserves the right
to revise this publication at any time, and to make changes
to its content without obligation to notify any person of
such revision or change.
Trademarks
All trademarks referenced in this document are the
trademarks of their respective owners.
Revision History
• Updated GEH* models in Table 53, p. 88.
• Minor running changes.

4 WSHP-SVX01Q-EN
Table of Contents
Copyright ............................. 3
Model Number Description - .5 to 25 Tons .5
Model Number Description - .5 to 6 Tons .. 6
Overview of Manual ..................... 7
Unit Nameplate ..................... 7
Compressor Nameplate ............... 7
Model Number Description ............ 7
General Information ..................... 8
Pre-Installation ......................... 12
Unit Inspection Checklist ............. 12
Jobsite Inspection Checklist .......... 12
Jobsite Storage .................... 12
Unit Dimensions ........................ 13
Service Clearances .................... 13
Weights ................................ 53
Weight Distribution for Hanging the GEH and
EXH Model ........................ 53
Installation ............................. 54
General Installation Checks ........... 54
Main Electrical ..................... 54
Supply-Air Ductwork ................ 55
Return-Air Ductwork ................. 55
Ducted Panel ....................... 55
Ducted Filter Rack (GEH .5 to 5 ton and EXH .5
to 6 ton only) ....................... 56
Dual Filtration (GEH .5 to 5 ton and EXH .5 to
6 ton) ............................. 56
Sound Attenuation Pad .............. 57
Hanging the Horizontal Unit .......... 57
Condensate Drain Connection ......... 57
Supply/Return Pipe Connections ...... 58
Cleaning and Flushing the Water Loop . 58
Field Installed Power Wiring .......... 58
Main Unit Power Wiring ............. 58
Control Power Transformer ........... 59
Thermostat Location ................ 59
Controls Using 24 VAC .............. 59
Blower Motor Speed-Tap Retrofit ...... 60
Hole Plug Installation ................ 61
Air Flow Adjustment .................61
Waterside Economizer Installation ......62
Waterside Economizer Installation for GEH
and GEV 6 to 25 Ton Models ...........65
Waterside Economizer Start-Up Sequence .67
Electrical Data ...........................69
Pre-Start Checklist .......................86
Start-Up ................................87
Initial Unit Start-up ....................87
Start-Up Checklist and Log ............87
Operating Pressures .................87
Water Pressure Drop ................108
Water Volume ......................110
Maintenance ...........................111
Preventive Maintenance .............111
Condensate Trap ...................112
Troubleshooting ........................113
Wiring Diagrams .......................115
Warranty Information ...................127
Standard Warranty ..................127
Extended Warranty .................127

WSHP-SVX01Q-EN 5
Digits 1-3 - Unit Configuration
GEH = Standard Efficiency Horizontal
.5 to 15Tons
GEV = Standard Efficiency Vertical
.5 to 25Tons
Digit4-Development Sequence
E = R-410A
Digits 5-7 - Nominal Capacity
006 = .5Tons
009 = .75Tons
012 = 1Tons
015 = 1.25Tons
018 = 1.5Tons
024 = 2Tons
030 = 2.5Tons
035 = 3Tons (Horizontal only)
036 = 3Tons (Vertical only)
042 = 3.5Tons
048 = 4Tons
060 = 5Tons
072 = 6Tons
090 = 7.5Tons
120 = 10Tons
150 = 12.5Tons
180 = 15Tons
240 = 20Tons
300 = 25Tons
Digit 8 - Voltage (Volts/Hz/Phase)
0 = 115/60/11
1 = 208/60/1
2 = 230/60/1
3 = 208/60/3
4 = 460/60/3
5 = 575/60/3
7 = 265/60/1
8 = 230/60/3
Digit 9 - Heat Exchanger
1 = Copper-Water Coil
2 = Cupro-Nickel Water Coil
7 = Insulated Copper-Water Coil
8 = Insulated Cupro-Nickel Water Coil
Digit 10 - Current Design
Sequence
Digit 11 - Refrigeration Circuit
0 = Heating and Cooling Circuit
2 = Heating and Cooling Circuit with
Hot Gas Reheat
3 = Heating and Cooling Circuit with
Waterside Economizer
4 = Heating and Cooling Circuit with HGR
and WSE2
1.5 to 1Ton only
26 to 25 Tons only
Digit 12 - Blower Configuration
1 = Standard Blower Motor3
2 = High Static Blower Motor3
A = Drive Package A
B = Drive Package B
C = Drive Package C
D = Drive Package D
E = Drive Package E
F = Drive Package F
G = Drive Package G
H = Drive Package H
J = Drive Package J
1*= 2 Speed Drive Package A
2*= 2 Speed Drive Package B
3 = 2 Speed Drive Package C
4= 2 Speed Drive Package D
5= 2 Speed Drive Package E
6= 2 Speed Drive Package F
7= 2 Speed Drive Package G
8= 2 Speed Drive Package H
9= 2 Speed Drive Package J
Digit 13 - Freeze Protection
A= 20°F Freezestat4
B= 35°F Freezestat
Digit 14 - Open Digit = 0
Digit 15 - Supply-Air
Arrangement
B = Back Supply-Air Arrangement
F = Front Supply-Air Arrangement
L = Left Supply-Air Arrangement
R = Right Supply-Air Arrangement
T = Top Supply-Air Arrangement
Digit 16 - Return-Air
Arrangement
B = Back Return-Air Arrangement2
F = Front Return-Air Arrangement2
L = Left Return-Air Arrangement
R = Right Return-Air Arrangement
Digit 17 - ControlTypes
0 = Basic 24V Controls5
D = Deluxe 24V Controls
B =Tracer® ZN524 Controls
F = UC400
G = UC400 w/Wireless Comm
Digit 18 - Tstat/Sensor Location
0 = Wall Mounted Location
Digit 19 - Fault Sensors
1 = Condensate Overflow Sensor
3 = Condensate Overflow and Filter
MaintenanceTimer
6 = Condensate Overflow and Fan Status
J = Fan Status, Filter MaintenanceTimer
and Condensate Overflow Sensor
3.5 to 5 Tons only
4Extended Range Geothermal
5.5 to 5 Tons only
Digit 20 - Temperature Sensor
0 = NoTemperature Sensor
1 = Entering Water Sensor
Digit 21 - Open
Digit 22 - Electric Heat
0 = No Electric Heat
1 = Internal Boilerless Electric Heat3
4 = External Boilerless Electric Heat
5 = External Supplemental Electric Heat2
Digit 23 - Open
Digit 24 - Filter Type
1 = 1"Throwaway Filter
2 = 2"Throwaway Filter
4=2”MERV8
5=2”MERV13
Digit 25 - Acoustic Arrangement
0 = Enhanced Sound Attenuation
1 = Deluxe Sound Attenuation6
Digits 26-36 - Does Not Apply to
GEH or GEV
00000000000 = Digits 26-36 are not
applicable to the GEH or GEV products
6.5 to 5 Tons (horizontal only)
Model Number Description - .5 to 25 Tons

6 WSHP-SVX01Q-EN
Digits 1-3 — Unit Configuration
EXH =High Efficiency Horizontal
EXV =High Efficiency Vertical
Digit 4 —Development Sequence
F
Digits 5-7 — Nominal Capacity
006 =.5Tons
009 =.75Tons
012 =1Tons
015 =1.25Tons
018 =1.5Tons
024 =2Tons
030 =2.5Tons
036 =3Tons
042 =3.5Tons
048 =4Tons
060 =5Tons
070 =6Tons
Digit 8 — Voltage (Volts/Hz/
Phase)
1 = 208/60/1
2 = 230/60/1
3 = 208/60/3
4 = 460/60/3
7 = 265/60/1
8 = 230/60/3
Digit 9 — Heat Exchanger
1 = Copper-Water Coil
2 = Cupro-Nickel Water Coil
7 = Insulated Copper Water
Coil/Suction Line
8 = Insulated Cupro-Nickel Water
Coil/Suction Line
Digit 10 — Current Design
Sequence
Digit 11 — Refrigeration Circuit
0 = Heating and Cooling Circuit
2 = Heating and Cooling Circuit with
Hot Gas Reheat
3 = Heating and Cooling Circuit with
Waterside Economizer
Digit 12 — Blower Configuration
3 = ECM Motor
Digit 13 - Freeze Protection
A = 20°F Freezestat
B = 35°F Freezestat
Digit 14 — Open Digit = 0
Digit 15 — Supply-Air
Arrangement
B = Back Supply-Air Arrangement
L = Left Supply-Air Arrangement
R = Right Supply-Air Arrangement
T =Top Supply-Air Arrangement
Digit 16 — Return-Air
Arrangement
L = Left Return-Air Arrangement
R = Right Return-Air Arrangement
Digit 17 — Control Types
D = Deluxe 24V Controls
B = Tracer® ZN524 Controls
F = UC400
G = UC400 w/ Wireless Comm
Digit 18 — Tstat/Sensor Location
0 = Wall Mounted Location
Digit 19 — Fault Sensors
1 = Condensate Overflow Sensor
3 = Condensate Overflow and Filter
MaintenanceTimer
6 = Condensate Overflow and Fan Status
J = Fan Status, Filter MaintenanceTimer
and Condensate Overflow Sensor
Digit 20 — Temperature Sensor
0 = No AdditionalTemperature Sensor
1 = Entering Water Sensor
Digit 21 — Open Digit
Digit 22 — Electric Heat
0 = No Electric Heat
1 = Internal Boilerless Electric Heat
4 = External Boilerless Electric Heat
Digit 23 — Open Digit
Digit 24 — Filter Type
1 = 1"Throwaway Filter
2 = 2"Throwaway Filter
4= MERV8
5 = MERV13
Digit 25 — Acoustic
Arrangement
0 = Enhanced Sound Attenuation
1 = Deluxe Sound Attenuation
Digits 26-36 — Does not Apply
to EXH or EXV
00000000000 Digits 26-36 are not
applicable to the EXH or EXV products
Model Number Description - .5 to 6 Tons

WSHP-SVX01Q-EN 7
Overview of Manual
Note: One copy of this document ships with each unit and
is customer property. It must be retained by the
unit’s maintenance personnel.
This booklet describes proper installation, operation, and
maintenance procedures for HVAC systems. By carefully
reviewing the information within this manual and
following the instructions, the risk of improper operation
and/or component damage will be minimized.
Service and maintenance work should be performed by a
qualified technician and all electrical service and
maintenance work should be performed by a qualified
licensed electrician.
Unit Nameplate
The unit nameplate is located on the outside of the control
box access panel at the front of the unit. It includes the unit
model number, serial number, electrical characteristics,
refrigerant charge, and other pertinent unit data.
Compressor Nameplate
The nameplate for the compressors are located on the
compressor shell.
Model Number Description
All products are identified by a multiple-character model
number that precisely identifies a particular type of unit. Its
use will enable the owner/operator, installing contractors,
and service engineers to define the operation, specific
components, and other options for any specific unit.
When ordering replacement parts or requesting service,
be sure to refer to the specific model number and serial
number printed on the unit nameplate.

8 WSHP-SVX01Q-EN
General Information
Unit Description
Before shipment, each unit is leak tested, dehydrated,
charged with refrigerant and run tested for proper control
operation.
Air-to-Refrigerant Coil
The air-to-refrigerant coil is aluminum fin, mechanically
bonded to the copper tubing.
Water-to-Refrigerant Coil
The water-to-refrigerant coil is a copper or cupro-nickel
(option) and steel tube (tube-within-a-tube) design, leak
tested to assure there is no cross leakage between the
water tube (copper/cupro-nickel) and refrigerant gas (steel
tube).
Controls
Basic 24V control is available for the GEH/V .5 -5 ton
models and the Deluxe 24V control option is available for
all unit sizes.Tracer® ZN524, LonTalk® certified control
option is available for all unit sizes. UC400 and UC400 with
wireless comm BACnet® is available in all unit sizes.
All power wiring to the equipment is made at the unit
contactor for .5 to 5 ton, 1-phase units. For 3-phase units all
power wiring to the equipment is made to the contactor or
power block. For EXH/V070 units all power wiring to the
equipment is made to the power block. For the GEH/V 6 to
25 tons units all power wiring is made to the high voltage
terminal block. All low-voltage wiring is made at the unit’s
low voltage terminal board. EXH and EXV 460V units
require a neutral wire.
System Input Devices and Functions
A thermostat, zone sensor, or building automation system
is required to operate the water-source heat pump.The
flexibility of having several mode capabilities depends
upon the type of sensor and/or remote panel selected.
Troubleshooting and connection diagrams for the 24V
control systems may be located in the back of this manual.
All digital control troubleshooting tips and connection
diagrams are located in CNT-SVX11*-EN (ZN524). All
digital control troubleshooting tips and connection
diagrams are located in BAS-SVX065*-EN (UC400).
Basic 24V Controls
Safety devices for equipment containing the basic 24V
control option include a low-pressure switch to prevent
compressor operation during low temperature or low
suction activity.The switch is set to activate at refrigerant
pressure of 40 psig to fit most applications.
A high pressure switch prevents compressor operation
during high or excessive discharge pressures exceeding
650 psig.
The lockout relay will disable the compressor on a high or
low pressure condition. For units that contain a
condensate overflow switch option, a condensate
overflow condition will also disable the compressor
through the lockout relay.The relay may be reset at the
thermostat, or by cycling power to the unit.
General alarm is accomplished through the lockout relay.
This feature will drive dry contacts only, and cannot be
used to drive field installed control inputs.Trane provides
a 3.5-minute time delay for compressor control.
Deluxe 24V Controls (option)
Units containing the Deluxe 24V control design will
incorporate a microprocessor-based control board.The
Trane® microprocessor board is factory wired to a
terminal strip to provide all necessary terminals for field
connection.The deluxe board is equipped with a random
start relay, anti-short cycle timer, brown out protection,
compressor disable, condensate overflow, unit safety
control, diagnostics, and a generic relay (which may be
available for field use). See Table 64, p. 113 for diagnostic
information and Figure 59, p. 62 and Figure 60, p. 63 for
thermostat connections.
Tracer® UC400 (option)
TheTracer® UC400 is a BTL Listed BACnet® controller that
can operate stand- alone or within a Building Automations
system such asTracer® SC. For installation, operation and
Programming, see BAS-SVX065*-EN (UC400).
Tracer® ZN524 Controls (option)
The digital ZN524 controller is designed to support the .5
to 25 ton water-source heat pumps in either a standalone,
or as a full building automation (open protocol) system.
For installation, operation and diagnostics see CNT-
SVX11A-EN (ZN524).
Pump Module (field installed accessory)
The pump module shall consist of either a single or dual 1/
6 HP bronze pump and a brass three-way shut-off valve.
Cast iron pumps are also available.The pump module kits
shall contain the necessary components for the
installation, operation and maintenance of the water
circuit of a closed-loop distributed pumping application.
Table 1. High/Low pressure switch
Trip Recover Unit
LP 40 +/-4 56 +/-4 psig
HP 650 +/-10 550 +/-10 psig

General Information
WSHP-SVX01Q-EN 9
Waterside Economizer (Option)
Instructions for mechanical connection of the waterside
economizer to the water-source heat pump may be found
in the dimensional section of this manual.
The waterside economizer is designed to begin
economizing mode when water temperatures fall below
the field adjustable temperature of 25, 35, 45, 55 or 60°F
(for the Deluxe control option), or below the programmed
set-point (for the ZN524 or UC400 control option).
When the temperature is less than the setpoint, fluid will
flow into the economizing coil, while simultaneously
halting mechanical operation of the compressor.
Mechanical cooling will continue on a call for a second
stage from the thermostat or system control. Entering
water temperature sensor is factory provided for field
installation on the entering water side of the coil.
Boilerless Control/Electric Heat (Option)
Systems that do not contain a boiler may contain a
boilerless control with electric heat.Trane® offers both a
factory mounted electric heat option (.5 to 5 ton only), and
a field mounted duct heater option.
If the .5 to 5 ton GEH, GEV and EXH/V070 unit incorporates
the factory mounted option, the unit will ship from the
factory with an internally mounted nichrome open wire
heating element, designed to start-up electric heat as the
systems primary heat in the event entering water
temperature falls below 55°F. Once the entering water
temperature rises above 60°F, the boilerless controller
returns the unit to normal compressor heating operation,
and locks out the electric heater.
For units comprised of the field installed duct heater
option, the unit will ship from the factory with controls
available to interface with the field provided electric heat
selection.
Note: For geothermal applications, the boilerless
controller has an adjustable setting of 25, 35, 45, 55,
and 60 degrees.
Supplemental or Boilerless Electric Heat
(option)
The GEH/V 6 to 25 ton models which contain boilerless
control electric heat or supplemental electric heat will
contain the controls interface ONLY for field provided
electric heat selection.The heater for this model shall be
external to the equipment by the contractor for ease of
installation. All power connections for the electric heater
will be completely separate from the unit for field supplied
electric heat.
Note: When the unit has boilerless control, the electric
heat is not used as supplemental electric heat, but
as a primary heat.
Hot Gas Reheat (option)
With the reheat option, the return-air from the space is
conditioned by the air-to-refrigerant coil, then reheated by
the reheat coil to control not only the space temperature,
but to also reduce the relative humidity of the space.When
operating in the reheat mode (meaning the sensible
temperature has been met in the space), the humidistat
signals the reheat relay coil to energize, allowing the high
pressure refrigerant gas to flow from the compressor
through the reheat valve, into the reversing valve and
reheat coil.
A switching relay has been provided for the reheat
application to adjust the blower motor from normal
operation to low speed when the hot gas reheat is
energized (for .5 to 5 ton and EXH/V070 equipment only).
Note: A high static blower motor is required to support
the hot gas reheat option for the GEH/V .5 -5 ton.
Note: Units containing the hot gas reheat option should
not be used as a make-up air unit.
2 Speed Blower Motor (option)
The 6 to 25 ton GEH/V models have indoor blowers that are
available with 2 speed motors, selectable in the model
number (Digit 12, drive packages one to nine). High speed
airflow matches the single speed motor airflow,
referenced in the Fan Performance tables. Low fan speed
airflow is approximately 50% of high fan speed airflow.
The 6 to 25 ton GEH/V two-speed blower motors are
available with the following options: Deluxe 24V or UC400
controls, Heat Pump (HP) or HP w/Hot Gas Reheat or HP w/
Waterside Economizer. Not available with Boilerless or
Supplemental Electric Heat.
Table 2. 6 to 25 ton GEH/V fan speed for two-speed
drive packages one to nine
RV State Fan Compressor 1 Compressor 2 Fan Speed
Heat OFF OFF OFF OFF
Heat ON OFF OFF LOW
Heat ON ON OFF HIGH
Heat ON ON ON HIGH
Cool OFF OFF OFF OFF
Cool ON OFF OFF LOW
Cool ON ON OFF LOW
Cool ON ON ON HIGH

General Information
10 WSHP-SVX01Q-EN
Table 3. Refrigerant charge
Model
(60 Hz) Heat Pump (oz)/(Kg) Heat Pump w/HGR (oz)/(Kg)
Circuit 1 Circuit 2 Circuit 1 Circuit 2
GEHE006 25.3 / .717 ----- 26.8 / .760 -----
GEHE009 26.0 /.737 ----- 27.5 / .780 -----
GEHE012 28.5 / .808 ----- 30.5 / .865 -----
GEHE015 29.0 / .822 ----- 30.5 / .865 -----
GEHE018 36.5 / 1.035 ----- 39.5 / 1.120 -----
GEHE024 39.0 / 1.106 ----- 42.0 / 1.191 -----
GEHE030 44.0 / 1.247 ----- 46.5 / 1.318 -----
GEHE035 53.0 / 1.503 ----- 56.0 / 1.588 -----
GEHE042 57.0 / 1.616 ----- 60.5 / 1.715 -----
GEHE048 61.0 / 1.729 ----- 65.5 / 1.857 -----
GEHE060 73.0 / 2.070 ----- 77.5 / 2.197 -----
GEVE006 25.7 / .789 ----- 27.2 / .771 -----
GEVE009 26.5 / .751 ----- 28.0 / .794 -----
GEVE012 29.5 / .836 ----- 31.5 / .893 -----
GEVE015 27.5 / .780 ----- 29.5 / .836 -----
GEVE018 37.0 / 1.049 ----- 40.0 / 1/134 -----
GEVE024 39.0 / 1.106 ----- 41.5 / 1.177 -----
GEVE030 44.5 / 1.262 ----- 47.0 / 1.332 -----
GEVE036 51.0 / 1.446 ----- 54.5 / 1.545 -----
GEVE042 54.0 / 1.531 ----- 57.5 / 1.630 -----
GEVE048 61.0 / 1.729 ----- 66.0 / 1.871 -----
GEVE060 74.0 / 2.098 ----- 79.5 / 2.254 -----
GEHE072 55 / 1.559 55 / 1.559 59 / 1.673 55 / 1.559
GEHE090 64 / 1.814 54 / 1.531 68 / 1.928 54 / 1.531
GEHE120 86 / 2.438 86 / 2.438 90 / 2.551 86 / 2.438
GEHE150 136 / 3.856 136 / 3.856 144 / 4.082 136 / 3.856
GEHE180 126 / 3.572 126 / 3.572 134 / 3.799 126 / 3.572
GEVE072 58 / 1.644 58 / 1.644 62 / 1.758 58 / 1.644
GEVE090 83 / 2.353 75 / 2.126 87 / 2.466 75 / 2.126
GEVE120 88 / 2.495 88 / 2.495 92 / 2.608 88 / 2.495
GEVE150 122 / 3.459 122 / 3.459 130 / 3.685 122 / 3.459
GEVE180 128 / 3.629 128 / 3.629 136 / 3.856 128 / 3.629
GEVE240 284 / 8.051 284 / 8.051 292 / 8.278 284 / 8.051
GEVE300 260 / 7.371 260 / 7.371 267 / 7.569 260 / 7.371
EXHF006 25.3 / 0.717 ----- 26.8 / 0.760 -----
EXHF009 26.0 / 0.737 ----- 27.5 / 0.780 -----
EXHF012 28.5 / 0.808 ----- 30.5 / 0.865 -----
EXHF015 29.0 / 0.822 ----- 30.5 / 0.865 -----
EXHF018 45.0 / 1.276 ----- 48.0 / 1.361 -----
EXHF024 50.5 / 1.432 ----- 53.0 / 1.503 -----
EXHF030 53.0 / 1.503 ----- 56.0 / 1.588 -----
EXHF036 70.0 / 1.984 ----- 73.0 / 2.070 -----
EXHF042 81.0 / 2.296 ----- 85.5 / 2.424 -----
EXHF048 83.0 / 2.353 ----- 87.5 / 2.481 -----
EXHF060 114.0 / 3.232 ----- 118.5 / 3.359 -----
EXHF070 122.0 / 3.459 ----- 127.0 / 3.600 -----
