Travla C147 Setup guide

Travla C147
1U 15 INCH DUAL-MOTHERBOARD
mini-ITX RACKMOUNT CHASSIS
QUICK START
USER GUIDE
WARNING: Install and service to
this product is performed only by
qualified personnel to avoid risk of
injuries.
A B C
5
B. Flat head screw M3-5mm
A. Flat head screw #6-5mm
Screw Idenfication Guide
Index
1) Remove Top Cover
2) Install 3.5" HDD to drive bay holder
3) Install compact flash to drive bay holder
4) Install 2.5" HDDs to drive bay holder
5) Install drive bay holder with 2.5" HDDs to
1U chassis
6) Install drive bay holder with 3.5" HDDs to
1U chassis
7) Install motherboards to 1U chassis
5
C. Hex head screw #6-5mm
Front Connectors
Rear Connectors
Copyright © 2003-2005 Casetronic Engineering Group
5
USB 2.0
IOIO
Compact Flash
Power Switch
Combo Inlet
Rear Mainboard
Connectors
1
2
1. Lift cover upward
2. Slide top cover to rear
Remove screw "A" (x3)
Remove top cover
1.
1. Attach 3.5" HDD on top of the drive bay holder
2
Install 3.5" HDD to drive bay holder
2.
3.5" HDD
Drive bay holder
2. Install screw "A" (x4)
1
1. Attach compact flash to drive bay holder
2. Install screw "B" (x4)
Install compact flash to drive bay holder
3.
Drive bay holder
Compact flash
2
1
Install 2.5" HDDs to drive bay holder
4.
1. Attach 2.5" HDDs on top of the drive bay holder
2. Install screw "B" (x8)
2.5" HDD (x2)
Drive bay holder
2
1 2.5" HDD
Install drive bay holder with 2.5" HDDs to 1U chassis
5.
1. Slide each drive bay holder into lances as shown above
2. Install screw "C" (x2)
Note: view without front panel
Lances
1
2
Note: view without front panel
1. Place motherboards onto 1U chassis with the right I/O gasket
2. Install screw "C" (x8)
2
Lances
HDD
HDD
Install drive bay holder with 3.5" HDDs to 1U chassis
6.
Install motherboards to 1U chassis
7.
Case designs are subjected to change without prior notice.
Please visit www.Travla.com for more information to this product.
Copyright © 2003-2005 Casetronic Engineering Group.
1. Slide each drive bay holder into lances as shown above
2. Install screw "C" (x2)
2
Motherboards
1
1
