Trebor MAXIM 50R-X12 Manual

SERIAL NUMBER (located on top of product):
PATENTS: U.S. 09642426, U.S. 06106246, U.S. 05971402, U.S. 05370507 07/27/12 –MM50R-X12-F
Phone: [phone] or 801-561-0303
Fax: [phone]
e-mail: [email protected]
MAXIM 50R-X12 PUMP
Operation / Maintenance
Manual

MAXIM 50R PUMP OPERATION / MAINTENANCE MANUAL CONTENTS
CONTENTS
1INSTALLATION............................................................................................................3
1.1 UNPACKING ......................................................................................................3
1.2 UTILITIES / HOOK-UP.......................................................................................3
1.3 REMOTE EXHAUST HOOK-UP ........................................................................5
2OPTIONS......................................................................................................................6
2.1 FLUID PORT CONNECTION OPTIONS............................................................6
2.2 FLUID FITTINGS / SURGE SUPPRESSOR HOOK-UP....................................6
2.3 OPTIONAL LEAK SENSING..............................................................................7
2.3.a Installation..............................................................................................7
2.3.b Sensor Signal Specifications.................................................................7
3START-UP....................................................................................................................8
3.1 PERFORMANCE CHARTS................................................................................8
4MAINTENANCE .........................................................................................................10
4.1 PREVENTIVE MAINTENANCE SCHEDULE...................................................10
4.1.a Preventive Maintenance Record.........................................................12
4.2 RECOMMENDED SPARE PARTS..................................................................13
4.3 TOOLS..............................................................................................................13
4.4 PARTS ILLUSTRATION...................................................................................14
4.5 PARTS LIST.....................................................................................................15
4.6 CLEAN-UP........................................................................................................15
4.7 DISASSEMBLY ................................................................................................16
4.7.a Body Disassembly...............................................................................17
4.7.b Head Disassembly...............................................................................17
4.7.c Control Base Disassembly ..................................................................17
4.7.d Cleaning...............................................................................................18
4.8 ASSEMBLY ......................................................................................................18
4.8.a Control Base Assembly.......................................................................18
4.8.b Body Assembly....................................................................................19
4.8.c Final Assembly....................................................................................20
5TROUBLESHOOTING ...............................................................................................22
6WARRANTY...............................................................................................................23
7CONTACT INFORMATION........................................................................................24
7.1 GENERAL CONTACT INFORMATION............................................................24
7.2 TECHNICAL SUPPORT...................................................................................24
7.3 REGIONAL REPRESENTATIVES...................................................................24

MAXIM 50R PUMP OPERATION / MAINTENANCE MANUAL PAGE 3
1 INSTALLATION
1.1 UNPACKING
After unpacking, the pump should be checked for any damage that may have
occurred during shipment. Damage should be reported to the carrier
immediately.
The following items should be included within the shipping container:
Qty
Item
Description
1
M50R-X12
Maxim 50R-X12 Pump
1
MM50R-X12
Operation/Maintenance Manual
1.2 UTILITIES / HOOK-UP
It is recommended that the pump be positioned within 15from level to maintain
self-priming ability and pumping efficiency. Allow sufficient room for tubing
connectors. The pump mounts on a quick-change base for easy installation.
The pump has an exhaust location on the backside of the base. The exhaust
location requires 1/2” (12mm) minimum clearance behind the control base. Care
should be taken to elevate the pump whenever possible to help prevent flooding
these ports when the pump is located in a wet bench plenum. For remote
exhaust connection see Section 1.3.
Air Inlet: 1/4” FNPT (3/8” Dia. [8mm] supply tube minimum).
Fluid Ports: Integrated male ¾” Super 300 Type Pillar®fluid ports Surge
Suppressor requires torqueing during pump installation. See
Section 2 for hook- up diagram and torque values..
Air Supply: 20-60 psig (.14 –.41 MPa) clean dry air or nitrogen (See
Performance Charts, Section 3.1.)

PAGE 4 MAXIM 50R-X12 PUMP OPERATION / MAINTENANCE MANUAL
Figure 1-1
ATTENTION: The pump should be operated with clean, dry air or nitrogen.
Particulate, water and oils in the air supply can damage the pump.
NOTE:
1. It is recommended that a filter be placed on the discharge side of the pump.
2. Although extensive efforts are made to deliver pumps to our customers
completely dry, new pumps may contain residual moisture from their final DI
water test.
Recommended Maximum Operating Levels: See Figure 3-2: Pressure vs.
Fluid Temperature Chart

MAXIM 50R PUMP OPERATION / MAINTENANCE MANUAL PAGE 5
1.3 REMOTE EXHAUST HOOK-UP
Remove existing Muffler Assembly from pump base.
Install Exhaust Plug in Exhaust Port.
Remove Pipe Plug (1/4” NPT) from the pump base. Install the appropriately
sized fitting and tubing (not provided) to remote exhaust.
NOTE: To maintain optimum pump performance use 3/8” tubing minimum at a
length of 10 ft. maximum.
Figure 1-2

PAGE 6 MAXIM 50R-X12 PUMP OPERATION / MAINTENANCE MANUAL
2 OPTIONS
2.1 FLUID PORT CONNECTION OPTIONS
All M50R pumps with –X12 option have integrated ¾” Super 300 Type Pillar® fluid
ports.
2.2 FLUID FITTINGS / SURGE SUPPRESSOR HOOK-UP
Surge Suppressor
Assembled Height: IN (CM)
SS85
17.12 (43.49)
SS95
13.97 (35.48
Figure 2-1
NOTE: See Surge Suppressor Operation Manual for detailed installation
instructions.

MAXIM 50R PUMP OPERATION / MAINTENANCE MANUAL PAGE 7
2.3 OPTIONAL LEAK SENSING
2.3.a Installation
Remove plug seal from port. Probe is self-sealing.
Install probe assembly into leak sensor port.
Thread probe cap into port. (NOTE: Do not over tighten; damage to threads
will occur.)
Push protective tubing into probe cap.
Connect fiber optic cable to sensor (NOTE: Minimize bends in fiber optic
cable to 2” radius minimum to help ensure optimum signal strength.) Fiber
optic cable can be cut to desired length using the cable cutter provided.
2.3.b Sensor Signal Specifications
The sensor signal is normally closed. In the event of a leak, no light signal is
returned to the sensor.
NOTE: See your fiber optic sensor installation instructions for proper hook-up
and adjustment.
Figure 2-2

PAGE 8 MAXIM 50R-X12 PUMP OPERATION / MAINTENANCE MANUAL
3 START-UP
Pump air supply pressure must be regulated. (See Figure 3-2: Pressure vs.
Fluid Temperature Chart)
Open the fluid suction (IN) line valve, if necessary.
Open the fluid discharge (OUT) line valve, if necessary.
Start with air regulator at low (> 20 psi) pressure setting. Increase pressure
to attain desired flow, up to the maximum rating (See Section 3.1).
Table 1: Consumption / Efficiency can be used to determine approximate air
consumption.
Refer to Troubleshooting, Section 5, if pump fails to start.
ATTENTION: Prolonged periods (>10 minutes) of dry running can damage
critical internal pump parts.
CAUTION: When handling potentially dangerous fluids under pressure,
the pump and its fittings should be placed in an enclosure.
3.1 PERFORMANCE CHARTS
Pumping capacity is a function of air supply pressure and volume, suction head,
suction line restrictions, discharge head, discharge line restriction, and fluid
specific gravity and viscosity.
Air Supply
Pressure
(PSIG)
Discharge
Fluid Pressure
(PSIG)
Air
Used
(SCFM)
20
0
4.3
20
10
3.2
30
0
6.6
30
15
5.1
40
0
9.3
40
20
6.8
50
0
12.0
50
30
8.2
60
0
15.3
60
40
9.7
Table 1: Consumption / Efficiency
NOTE: Specification to be used to size regulators and control valves.

MAXIM 50R PUMP OPERATION / MAINTENANCE MANUAL PAGE 9
Figure 3-1: Pressure & Capacity Chart
NOTE: Test information is based on specific conditions and limited sampling.
Use for general reference only.
Figure 3-2: Pressure vs. Fluid Temperature Chart
Recommended Maximum Pump Operating Levels
NOTE:
1. This graph is not representative of all operating conditions - customer’s
specific application results may vary.
2. Be sure that fittings and tubing used are capable of these operating
conditions.

PAGE 10 MAXIM 50R-X12 PUMP OPERATION / MAINTENANCE MANUAL
4 MAINTENANCE
Trebor pump maintenance can be divided into two categories: air system
maintenance and fluid system maintenance. The purpose of air system
maintenance is to prevent air system failures such as stalling or erratic cycling.
The purpose of fluid system maintenance is to maintain suction and lift
capabilities.
Pump Rebuild Service
Trebor International provides a factory rebuild service for customers using Trebor
products. Trebor will rebuild any standard pump (exclusive of options). Please
contact Trebor International Sales Department for current rebuild pricing. The
fixed rebuild price includes a factory rebuild and parts equivalent to the standard
rebuild kit. Each factory rebuild comes with a new one-year warranty. Repairs
requiring more extensive part replacements will be quoted prior to proceeding
with the pump rebuild. If the pump has exceeded its useful life and cannot be
rebuilt, the customer may elect to purchase a new Trebor pump. If the customer
chooses not to rebuild or replace the pump, a $150.00 evaluation charge will be
required.
All returned pumps are to be shipped freight prepaid with a valid Purchase Order
for the cost of rebuild service. Please contact Trebor International prior to
returning your pump to obtain an RMA Number and Pump Return Data Sheet to
ensure proper safety precautions. Each pump will be evaluated and repaired
within 5 working days of the receipt of pump at Trebor facility.
4.1 PREVENTIVE MAINTENANCE SCHEDULE
The following maintenance schedule is recommended to optimize pump
performance and minimize failures. Certain operating conditions that require
more frequent maintenance intervals have been noted. In positive pressure inlet
conditions where suction or lift is not required, fluid system maintenance may be
extended.
Adhering to the recommended preventative maintenance schedule along with
periodic inspection of the pump will ensure continued efficient operation and
overall reliable pump performance.
It is recommended that the Preventive Maintenance Record (Section 4.1.a) be
copied, maintained and kept with this unit for future reference.

MAXIM 50R PUMP OPERATION / MAINTENANCE MANUAL PAGE 11
MAXIM 50R Maintenance Schedule
Install
30 Days
3 Months
6 Months
9 Months
12 Months
15 Months
18 Months
21 Months
24 Months
Poppet Pilot Valves and Seals
C-Ring and Detent Legs
R
Muffler Media
R
Shaft Seal and Shaft
R
Check Balls and O-Rings
R
Diaphragms
R
Check Plug Seal
R
Suction and Discharge Check Cage
I
I=Inspect, R=Replace

PAGE 12 MAXIM 50R-X12 PUMP OPERATION / MAINTENANCE MANUAL
4.1.a Preventive Maintenance Record
Company Name:
_____________________________________________________
Company Address:
_____________________________________________________
_____________________________________________________
Product:
_________________
Serial Number:
________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________
Date:
________
Tech:
_____
Notes:
________________________________________
________________________________________

MAXIM 50R PUMP OPERATION / MAINTENANCE MANUAL PAGE 13
4.2 RECOMMENDED SPARE PARTS
KR50R-00-A Spares Rebuild Kit, which includes:
Part No
Qty
Description
KM50R-00-A
1
Maintenance Kit
Includes:
(2)
(2)
(1)
(2)
(1)
AK018
AK020
AK205
L0197
L0145
Pilot Seat
Pilot Poppet
Muffler Assembly
Detent Leg
Detent Ring
KD50-00-A
1
Diaphragm Kit
Includes:
(4)
(2)
1700C0047
W0151
Diaphragm, Maxim 50
Fiber Optic Target
98001415
4
Check Ball, PTFE
98002334
4
O-ring, -312 PTFE
98003079
2
Shaft Seal
AK004
1
Shaft, Maxim 50
AK153
2
Check Plug Seal
AM082
2
Adapter Port Seal (not used with X-12 model)
In critical applications, a spare pump is recommended to minimize possible down
time during service intervals.
4.3 TOOLS
The following tool kit is recommended as standard service equipment.
KT50X-00-A Tool Kit, which includes:
Part No
Qty
Description
98003108
1
Torque Wrench, 30-150 ft/lb., 1/2” Drive
98003150
1
Tool Case, w/Foam, M50
98003305
1
Handle, Soc, 1/4" Drive
98003306
1
Wrench, Adj, 15/16"
T0126
1
Tool, Shaft Insert
T0129
1
Tool, Strap Wrench
T0168
1
Rebuild Fixture, M50R-X12
T0144
1
Tool, Wedge, Head Removal
T0146
1
Tool, Pin, 3/4x1/4 Drive
T0147
1
Tool, Pin, 1x1/4 Drive
T0148
1
Tool, Pin, 1/2x1/4 Drive
T0149
1
Tool, Pin, Optic Cap, 3/4

PAGE 14 MAXIM 50R-X12 PUMP OPERATION / MAINTENANCE MANUAL
4.4 PARTS ILLUSTRATION

MAXIM 50R PUMP OPERATION / MAINTENANCE MANUAL PAGE 15
4.5 PARTS LIST
ILL
NO
PART NO
QTY
DESCRIPTION
PM
YEAR #
MATERIAL
1
AM075
1
Damper Plug
PTFE
2
AM084
1
Surge Port Seal
PTFE
3
AK192
1
Body
PTFE
4
98003079
2
Shaft Seal
2
PTFE
5
AK004
1
Shaft
2
PFA
6
1700B0041
2
Push Plate
PTFE
7
1700C0047
4
Diaphragm
2
PTFE
8
W0151
2
Fiber Optic Target
2
PTFE
9
AK124
2
Head
PTFE
10
AK018
2
Pilot Seat
1 & 2
PFA, PTFE
11
AK030
2
Pilot Cap Seal
PTFE
12
AK008
2
Pilot Cap
PTFE
13
AK003-01
2
Union Nut
PVDF
(PP optional)
14
AM035
2
Leak Port Plug
PTFE
15
AM037
2
Leak Port Seal
PTFE
16
AK182
4
Transfer Tube
PFA
17
98003277
4
Transfer Tube Nut
PP
18
AK076
1
Control Base
PP
19
AK088
1
Mounting Base
PP
20
AK108
1
Locking Lever
PP
21
98003071
3
Screw, PP
PP
22
98003080
2
1/4 NPT Fitting
PP
23
L0104
1
Detent Cap
PP
24
L0113
1
Detent Cap Seal
PTFE
25
L0131
1
Spool Assembly, High Load
Ceramic,
PEEK, Delrin
25a
L0197
2
Detent Leg
1 & 2
Torlon
25b
L0145
1
Detent Ring
1 & 2
PEEK
26
L0105
1
Detent Adapter
PP
27
AK058
1
Shuttle Sleeve Assembly
Ceramic,
PTFE
28
AK205
1
Muffler Assembly
1 & 2
PP
29
AK149
2
Suction Plug
PTFE
30
AK153
2
Check Port Seal
2
PTFE
31
AK066
2
Suction Seat
PTFE
32
98002334
4
O-Ring
2
PTFE
33
98001415
4
Check Ball
2
PTFE
34
AK068
2
Suction Check
PTFE
35
AK026
2
Discharge Check Cage
PTFE
4.6 CLEAN-UP
To help remove potentially dangerous chemicals prior to service or shipment, the
pump should be flushed with DI water or disassembled and thoroughly cleaned.
Allow DI water to flush through the inlet and out the outlet to prevent pressure
build up.
CAUTION: When handling pump wear appropriate personal protection
gear, including safety glasses.

PAGE 16 MAXIM 50R-X12 PUMP OPERATION / MAINTENANCE MANUAL
4.7 DISASSEMBLY
During the life of the pump it will be necessary to perform certain preventative
maintenance procedures to ensure its continued high performance. This section
and the next (4.8 Assembly) are provided for the user’s convenience in
disassembly and re-assembly procedures.
Loosen quick grip nuts on the transfer tubes from the pump base using
13/16” open-end wrench.
Remove pump assembly from the pump control base.
Immerse or flush the pump assembly using DI water and a neutralizing agent.
Install pump into tie down fixture with the fluid ports away from the mounting
fittings and tighten the clamp nuts. Lock the body into bench mounting
fixture. NOTE: Securely attach mounting fixture to work surface using
hardware provided.
Figure 4-1
Remove the transfer tubes from pump heads (using latex gloves).
Using strap wrench, turn union nuts counter-clockwise to remove.
Figure 4-2

MAXIM 50R PUMP OPERATION / MAINTENANCE MANUAL PAGE 17
Remove head and check diaphragms for cracks or cuts.
To remove diaphragms, slit diaphragm with a sharp knife and pull the
diaphragms from the grooves. (Do not pry on diaphragm seal groove, as
this will damage the sealing surface.)
Unscrew push plate from the shaft in a counter-clockwise direction. Pull
other push plate and shaft from pump body.
CAUTION: Following disassembly, parts should be thoroughly washed
and be free from chemical residue for handling purposes.
4.7.a Body Disassembly
Remove suction plugs and seal on bottom of pump body using 1” pin tool.
Remove suction seat using 1” pin tool.
Remove ball and O-ring.
Unscrew suction check using 1” pin tool turning it counter-clockwise.
Remove second set of O-rings and balls and pull out discharge check cage.
Remove shaft seals from pump shaft seal groove in the center of the shaft
bore using the tip of a razor knife. Take care not to damage the shaft bore.
NOTE: Do not reuse seals.
Remove damper plug and seal using 3/4” pin tool.
4.7.b Head Disassembly
Unscrew and remove pilot cap using the 3/4” pin tool
Remove seal and pilot poppet.
Unscrew and remove pilot seat using 3/4” pilot pin tool.
4.7.c Control Base Disassembly
Unlock control base from quick-change mount by pulling out lever on front of
base to unlock mount. Then slide base back until it stops. Lift base off
mount.
Using pH test strips evaluate whether base has any contamination in air
passages especially the muffler area. If present, neutralize using best
methods prior to disassembly.
Unscrew and remove muffler assembly from base using the 3/4” pin tool.
Unscrew and remove the shuttle cap and seal.
Remove spool assembly from detent adapter.
Remove detent legs and detent ring from spool.
Unscrew detent adapter from base using 3/4” pin tool.
Do not remove the shuttle sleeve from the shuttle bore.

PAGE 18 MAXIM 50R-X12 PUMP OPERATION / MAINTENANCE MANUAL
4.7.d Cleaning
Gently spray clean or dunk rinse all components with DI water to remove any
trace materials remaining after disassembly.
4.8 ASSEMBLY
Prior to beginning assembly, inspect all parts to ensure they are clean and dry.
Wear clean protective gloves. Precautions should be exercised to prevent
contaminating any of the air chamber surfaced with chemicals during handling.
4.8.a Control Base Assembly
Thread detent adapter into shuttle bore using 3/4” pin tool. (Detent adapter
must be flush against base as shown.)
Shuttle spool assembly instructions:
Hold shuttle spool (item 1) upright and align slot and in detent legs (item 2)
with notch on shuttle spool, see Fig. 1.
Apply pressure upward onto base of detent legs with thumb and index finger,
as shown in Fig. 2.
Tilt the detent ring (item 3) over one of the legs, and align the groove on the
inside of the detent ring with the end of the detent leg. Tilt the other side of
the ring down, expanding it slightly, so that the other detent leg snaps into the
detent ring groove. See Fig. 3. The completed assembly should look like
Fig. 4 (see Figure 4-3).
Figure 4-3
Insert spool assembly into detent adapter and shuttle sleeve (Do not lubricate
spool or sleeve).
Install seal onto seal groove shoulder of shuttle cap.

MAXIM 50R PUMP OPERATION / MAINTENANCE MANUAL PAGE 19
Thread shuttle cap onto detent adapter hand tight.
Figure 4-4
ATTENTION: Threads should be snug. Do not over tighten.
Thread muffler assembly into base using 3/4” pin tool.
4.8.b Body Assembly
Install seal and damper plug into body using 3/4” pin tool.
Remove pump from assembly fixture.
Turn pump upside down to access check bores.
Install discharge check cage into bore making sure small end fits into relief in
bottom of bore.
Drop ball into check cage, then O-ring.
Install suction sleeve into the bore; tighten using 1” pin tool. Tighten snug;
do not over tighten as damage may occur.
Install second ball into check cage, then O-ring.
Install suction seat using the 1” pin tool.
Install check seal onto suction plug and thread into bores using 1” pin tool.
Repeat for the second bore.
Install two shaft seals in shaft bore groove with slits 180apart.
Thread push plate onto main shaft.
Thread shaft onto shaft insert tool and insert shaft into bore.

PAGE 20 MAXIM 50R-X12 PUMP OPERATION / MAINTENANCE MANUAL
Figure 4-5
Remove shaft insert tool and thread second push plate onto main shaft.
Tighten snug; do not over tighten as damage may occur.
4.8.c Final Assembly
Reattach pump to assembly fixture.
Attach union nut to one side of pump body (hand tight). Do not install
diaphragm on this step. This will protect body during initial pump assembly.
Remove pump from the assembly fixture.
Place pump body with union nut down and place two diaphragms, removing
all air from between diaphragms, with “V” groove point toward the body.
Install head on body. Note tab alignment and orientation of transfer tube
ports in head.
Install union nut on pump while gently pressing down on the head to engage
tabs in head and body, spin union nut down hand tight.
Turn pump over and remove union nut to install diaphragms.
Repeat diaphragm, head and union installation.
Lock body into mounting fixture.
Using strap wrench, torque union nuts slowly to 75 ft-lbs. with the wrench at
90° +/- 15° to the nut’s surface as shown.
Figure 4-6
