Treekeeper TK-10169 User manual

MODEL #TK-10169
For assistance with assembly including instructional videos, parts and customer service visit
www.TreeKeeperBags.com
PARTS LIST
Please lay out all parts prior to assembly or installation. Read instructions prior to assembly.
A.
B.
C.
Side Frame
Pre-assembled
Trays
Frame Bar
2
3
3
QUANTITYPART PICTUREPART
F.
G.
H.
Nuts
6
6
1
QUANTITYPART PICTUREPART
D.
Storage Bag 1
I.
Bolt
Wrench 1
Allen
Screws
Alan Wrench
E.
Castors 4
J.
Castor
Wrench 1
*See other side for step-by-step assembly explanations.
Ornament Chest Assembly Instructions

Step 1 & 2. While holding one side of the ornament chest side frame (Part B), attach the cross-frame bar (Part C) by
lining up the holes and inserting the Allen bolt (Part G) as shown. After the bolt is inserted through the frame and
cross bar, attach a nut (Part F) and tighten with provided bolt wrench (Part I). Repeat this on the other side of the
cross-frame bar using the opposite ornament chest side frame (Part B).
Step 3. Attach second frame bar (Part C) to the top of the side frames in the same fashion as step one.
Step 4 & 5. Turn partially assembled frame upside down and attach remaining frame bar (Part C) as shown on the
bottom of the assembled frame using the same process.
Step 6. Place the assembled chest frame into the storage bag (Part D)
Step 7. Locate the velcro straps on the back and bottom of the storage bag and secure around the chest frame.
Step 8. Turn partially assembled bag on its back revealing the bottom. Situate the four holes in the bag to reveal
screw holes in the frame. Screw on four provided castors (Part E). You may use the included castor wrench (Part J)
to tighten the castors.
Step 9. Slide the three pre-assembed trays (Part A) onto the drawer rods through the fabric tray sleeves located on
each short side of the tray.
C
G
G
TOP
STEP 4
STEP 7 STEP 8
STEP 9
ASSEMBLY
STEP 2
A
D
E
F
STEP 6STEP 5
STEP 1
B
B
B
C
C
C
G
G
GTOP
TOP
x 4
x 3
STEP 3
