The 200Mbps Powerline AV Adapter uses any electrical outlet to create a
secure high speed building-wide network. Connect one adapter to your
network and plug another adapter in to any outlet on your electrical
system for instant high speed network access.
Connect adapters quickly using the convenient one-touch connect button.
Use up to 8 adapters to network devices in different rooms without
running new cabling.
Power Save mode reduces power consumption by up to 70%. LED
displays convey device status for easy power management and
troubleshooting. Quality of Service technology prioritizes video, audio, and
online gaming. Advanced AES encryption secures your network. This
adapter is ideal for use in buildings that interfere with wireless networking
signals.
TPL-303E (V1.0R)
200Mbps Powerline AV Adapter
PoEpowerline
• Enjoy high speed building-wide networking over an existing connected electrical system
• One-touch connect button networks adapters quickly
• Plug & Play support
• Windows based configuration utility for a quick and simple installation
• Share data intensive files, play games, download music and more at very fast data transfer rates
• Advanced encryption (AES) ensure total network security
• Power Saving mode supports low power consumption
• IPv4 and IPv6 network protocol support
• Supports Wake-On-Link when in Standby mode
• Neighbor network support for up to 4 overlapping networks
• Connect one 200Mbps* Powerline AV Adapter to the Internet and then plug in up to 7 additional adapters for instant building connectivity
• Network signal transmitted up to 300 meters (984ft.)
• Auto QoS support through traffic classification and multiple priority queuing
• Configuration utility compatible with Windows 7, Vista, and XP operating systems
• 3-year limited warranty
FEATURES
* 200Mbps is the maximum theoretical data rate. Actual throughput will vary depending on environment.
** Networked Powerline devices need to be plugged into power outlets that are on the same electrical system.

Interface
Frequency Band
Modulation
Speed
Utility Comptibility
Encryption
LED
Temperature
Humidity
• IEEE 802.3, IEEE 802.3u, IEEE 802.3x, • HomePlug AV
• Power, Powerline, Ethernet
• 63 x 38 x 102 mm (2.5 x 1.5 x 4 inches)
• 2~30MHz
• Powerline: Up to 200Mbps
• 128-bit AES
• Operating: 0°~ 40°C (32°~ 104°F)
• Storage: -10° ~ 55°C (14° ~ 131°F)
• 5%~95% (Non-Condensing)
• LAN: 10/100Mbps
• Up to 8 nodes
• A: 100~230V AC, 50~60Hz • EU: 220~240V/5A AC, 50Hz
Dimension (L x W X H)
Consumption
Standards
Hardware
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
SPECIFICATIONS
Nodes
• Windows 7 (32/64-bit), Vista (32/64-bit), XP(32/64-bit)
• 10/100Mbps Auto-MDIX RJ45 Port
Power Source
• Active mode: 3.5 Watts (max.) • Standby mode: 0.93 Watts (max.)
Weight • 110 g. (3.8 oz.)
Certification • CE, FCC
• Power Prongs
• OFDM, QAM, QPSK, BPSK, ROBO
PACKAGE CONTENTS
RELATED PRODUCTS
• CD-ROM (Utility & User’s Guide)
• Multi-Language Quick Installation Guide
TPL-302E
• TPL-303E
TPL-303E2K 200Mbps Powerline AV Adapter Kit
4-Port Gigabit Firewall Router
200Mbps Powerline AV Ethernet Adapter
TWG-BRF114
• Cat.5 Ethernet Cable (1.8m / 6ft )
TPL-303E (V1.0R)
200Mbps Powerline AV Adapter
NETWORKING SOLUTIONS
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
10/100Mbps Powerline
200Mbps Powerline AV Adapter
(TPL-303E)
Internet
