TRENDnet TFC-1600 User manual

TRENDnet's TFC-1600 16-slot EIA-19" Rack-Mount Chassis
System provides housing for up to 16 TFC series media converters.
Designed for continuous operation, the chassis is equipped with
dual cooling fans and redundant power supplies (optional). Its Plug-
and-Play and Hot-Swap features allow installing/removing the
converter unit without powering off the chassis. TFC-1600 rack-
mount chassis eliminates the external power adapters for TFC
series media converters and organizes multiple converters in a
single unit, which makes it the perfect solution for managing multiple
TFC series converters.
TFC-1600
16-Slot Chassis System for TFC series
Fiber Converter
TFC-1600
rev:07.31.2006
• Provides housing for up to 16 TFC series media converters
• Front panel LEDs indication tiation Mode for Fiber Port
• Standard 19" rack-mount size, 2U height
• Hot-Swappable; easy & quick replacement of converter and power supply
• Single cooling fan (internal) mounted at the rear panel
• Optional redundant power supply to ensure non-stop reliable operation
• Optional Management Module
• Load Sharing mechanism to minimize downtime (available only with redundant power supplies)
• Power isolation designed with converter bays: ensures each bay is electrically isolated from others
• 5 Year Warranty
FEATURES
BENEFITS
• 1 x 10/100Mbps Fast Ethernet RJ45 port and 1 x RS-232 Console ports for management
• Web Browser Based Management via Ethernet port or Command Line Interface Management via RS-232 port
• SNMP Agent
• Provides media Link/Connection Speed/Duplex status for each module
• Provides Cooling Fans and Power Supplies status

Management Protocol
Temperature
Power
Input
Cooling
Humidity
Certifications
• 16 slots for housing up to 16 TFC series media converters
• 415 x 390 x 89 mm (16.3 x 15.4 x 3.5 inches)
• 1 x 10/100Mbps Fast Ethernet RJ45 and 1 x RS-232
• appr. 7Kg (15.4 lbs) (with one power supply)
• Operating: 10% ~ 90%
• FCC, CE, VCCI
• SNMP(RFC1157), ARP(RFC826), IP(RFC791), ICMP(RFC792), UDP(RFC768), TCP(RFC793), TFTP(RFC783), Telnet(RFC854),
• Power x 2, In Use x 2, Fan Fault x 2
• One power supply; optional second power supply
• AC 100 ~ 240 VAC. Power Consumption: 150 watts max
• Operating: 0°~ 40°C (32°~ 104°F)
• All outputs protected from short circuit condition with automatic recovery
• Single cooling fan (internal) mounted at the rear panel
• Steel sheet metal
• Storage: 5% ~ 90% (no-condensing)
• Storage: -10°~ 50°C (14°~ 122°F)
Housing
Weight
Capacity
Hardware
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
16-Slot Chassis System for TFC series Fiber Converter
TFC-1600
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
3135 Kashiwa Street,Torrance, CA 90505 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
SPECIFICATIONS
Management Ports
Diagnostic LEDs
Power Overload Protection
Dimensions
BOOT(RFC951), MIB II (RFC1213)
RELATED PRODUCTS
TFC-1600
TFC-1600MM
TFC-1600RP
TFC-1600R48
16-Slot Chassis System for TFC series Fiber Converter
Management Module for the TFC-1600
Redundant Power Supply for the TFC-1600
48V Redundant Power Supply for TFC-1600
