Tribesigns HOGA-F1138 User manual

Assembly Difficulty Meter
Easy Tough
HOGA-F1138
Vanity Table w/ lighted mirror
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
If for any reason there is anything missing,
damaged, incorrect or different from what
you expected.
PLEASE contact us for free replacement
instead of hassle of return or other trouble.
Do Not Return This Product!
Contact our customer service team
for help first
[email protected]
WARNING
·For your safety, anchor unit to stud in wall
·Do Not allow children to climb on unit.
·Put heavy items on lower shelves or floor.

ASSEMBLY
REQUIREMENTS
ASSEMBLY PREPARATION
2 HOURS
Assembly Time
(Approximate)
2 Persons Assembly Tools Required (Not Provided):
Phillips Screwdriver
1. Remove all packaging materials, staples and packing straps from the carton.
2. Refer to Parts List and Hardware List and ensure they are complete before you
start assembly.
3. Place all parts on a clean, flat and so surface (e.g. carpet or rug) to prevent parts
from geng scratched.
SAFETY PRECAUTIONS
2. DISPOSE PLASTIC PACKAGING MATERIAL IMMEDIATELY TO AVOID ANY RISK OF
SUFFOCATION TO CHILDREN AND ANIMALS.
TIPS FOR ASSEMBLY:
1. Allow ample room for assembly and in close proximity to where product will be placed.
2. Assemble the product on a surface that does not scratch or damage he exterior
gloss and finish of the furniture.
3. Please check all of the parts and quanes are included before assembly. Contact
customer service for missing parts.
4. Idenfy all of the parts, hardware and quanes required for each step.
5. During assembly, do not over-ghten any fings as this may cause damage.
6. DO NOT USE POWER TOOLS TO ASSEMBLE THIS PRODUCT.
7. Always place the product on a flat surface.
8. Do not sit or stand on the parally assembled product; only use the product for
which it is intended.
1. KEEP ALL HARDWARE PARTS OUT OF REACH OF CHILDREN.
01

Parts & Hardware List
4 pcs
4 pcs
9 pcs
N
O
Push the black lever in and pull the SLIDE from the RAIL.
HG
02

Instrucons For Fastening
CAM-BOLT AND CAM-LOCK
Panel
Panel
Panel
Shoulder
Cam-bolt head needs to be in centre
Wrong
Correct
Correct Wrong
Shoulder is
above panel
Aach the Cam-bolt to the specific pre-drilled holes on the panel. Use a Phillips
Screwdriver to ghten Cam-bolt vercally unl shoulder is flushed (on the same
level) with panel. Do not over-ghten or under-ghten.
Align the arrow of the Cam-lock to
the Cam-bolt head and insert the
Cam-lock.
Use a Flat Screwdriver or Phillips
Screwdriver to turn the Cam-lock
clockwise one half a turn so it locks
onto the head of the Cam-lock. Turn
only unl it is snug. Over-ghtening
could damage Cam-lock or/and
Cam-bolt.
03

04

NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlarged
diagram. Then, slide the inner cartridge of the EXTENSION RAIL out to find the other
hole that lines up with the hole in the END. Turn a SCREW into this hole.
How to Disconnect EXTENSION SLIDES (H) and EXTENSION RAILS (G)
1) Pull toward arrow to open the slide unl its stops and then flip it over.
2) Push plasc lever down and pull apart.
EXTENSION RAILS (G)
EXTENSION SLIDES (H)
05

06

To Insert Drawer into Desk
3) Push the drawer into desk. You may expe-
rience a light resistance when pushing the
drawer into desk, but once both slides are
properly engaged, drawer should slide in and
out smoothly.
2) With help of another person, carefully
align and insert drawer extension slide (H)
between the Extension Rails (G)
1) Bring Extension Rails (G) fully forward
Note: Do not use excessive force to insert
drawer as this may cause the damage to
slides.
PLEASE ensure the #16 drawer
is installed at the LEFT side, and
the #17 drawer is installed at
the RIGHT side.
H
G
07

O
O
O
08

N
09

Give us or shoot us a message,
we will arrange you a free
replacement with zero hassle.
We really don’t want you to go through the hassle of re-packaging your item
and sending it back, because let’s be honest...nobody has me for that.
No heartburn,
when we handle
the return
Our way Their way
Give us a Email
Replacement
Replacement
You
[email protected]
Re-package item
Schedule pick-up
Track package
You
