Tricity Bendix TM 560 Product guide

TUMBLE DRYER
TM 560
OPERATING & INSTALLATION
INSTRUCTIONS
125996112
125996112.qxd 08/03/01 15.38 Pagina 1 (Nero/Process Black pellicola)

CONTENTS
2
TECHNICAL SPECIFICATIONS
Warnings ..........................Page 3
Intallation .........................Page 4
Positioning..........................Page 4
Levelling ..........................Page 5
Door reversal .........................Page 5
Electrical connections ......................Page 6
Use ...........................Page 7
Control panel .........................Page 7
Use of controls ........................Page 7
Drying Times .........................Page 8
Drying ..........................Page 9
Useful hints .........................Page 9
Maintenance .........................Page 10
External cleaning .......................Page 10
Cleaning the door .......................Page 10
Cleaning the filter .......................Page 10
Servicing ..........................Page 10
Tricity Bendix Guarantee Conditions .................Page 11
Tricity Bendix Service Centres ...................Page 12
DIMENSIONS Height 85 cm (33.5”)
Width 60 cm (23.6”)
Depth 57 cm (22.4”)
ELECTRICAL CONNECTION Voltage 230-240 V/50 Hz
Max. power absorbed 2650 W (13A)
DRYING CAPACITY Cotton, linen 5 kg (11 lb)
Synthetics 2.5 kg (5 lb)
This appliance complies with the following
E.E.C. Directives:
- 73/23 EEC of 19.2.73 (Low Voltage Directive)
and subsequent modifications;
- 89/336 EEC of 3.5.89 (Electromagnetic
Compatibility Directive) and subsequent modifi-
cations.
Stacking kit
A special stacking kit is available through your dealer,
to enable the mounting of the dryer on top of your
washing machine.
Child safety device
This tumble dryer incor-
porates a special child
safety feature.
At the top, on the inside
of the porthole door, you
will notice a catch, if this
is removed it will prevent
the machine from work-
ing. To remove, press the
catch downwards (see
picture). You MUST replace the catch to enable the
appliance to work.
3
26
125996112.qxd 08/03/01 15.38 Pagina 2 (Nero/Process Black pellicola)

WARNINGS
3
It is most important that this instruction book
should be retained with the appliance for future
reference. Should the appliance be sold or trans-
ferred to another owner, or should you move
house and leave the appliance, always ensure that
the book is supplied with the appliance in order
that the new owner can get to know the function-
ing of the appliance and the relevant warnings.
These warnings have been provided in the interest
of safety. You MUST read them carefully before
installing or using the appliance.
INSTALLATION
■Any electrical work required to install this appliance
should be carried out by a qualified electrician or
competent person.
■Make sure that the appliance does not stand on its
electrical supply cable.
■If the machine is situated on a carpeted floor,
please adjust the feet in order to allow air to circu-
late freely.
■This tumble dryer is designed to be vented through
to the open air. It should have its own ventilation
system which should not be joined with any other
ventilation system connected to any other appli-
ance.
USE
■Always unplug the appliance after use.
■Clothes which are dripping wet should not be
placed in the dryer.
Always load well spun laundry. The higher the
spin speed, the lower the electricity consumption
and the shorter the drying times.
■Never tumble dry items that have been in contact
with chemicals such as dry cleaning fluid. These
are of a volatile nature and could cause an explo-
sion.
■As some bulky items such as duvets and eider-
downs should be dried in large commercial
machines because of their bulk, check with the
manufacturer of the item if it is suitable for drying in
a domestic machine, even if the dry weight of the
item is within the limit advised.
■Always check that no cigarette lighters have been
left in pockets.
■Leave the porthole door slightly ajar when not in
use to preserve the door seal.
■The fluff filter must be cleaned after every use.
■Do not operate the appliance with a damaged filter
as this may cause a fire.
■Do not overload the appliance.
■ Do not allow fluff to accumulate around the dryer.
SERVICE/REPAIR
■Under no circumstances should you attempt to
repair the machine yourself. Repairs carried out by
inexperienced persons may cause injury or serious
malfunctioning. Refer to your local Tricity Bendix
Service Centre. Always insist on genuine Tricity
Bendix spare parts.
GENERAL SAFETY
■It is dangerous to modify or try to modify the speci-
fications of this appliance in any way.
■This appliance is designed to be used by adults.
Children should not be allowed to touch the con-
trols or play with the product.
■Pets and small children may climb into tumble dry-
ers. Check your appliance each time before use.
ENVIRONMENT PROTECTION
■The materials used on this appliance marked with
the symbol are recyclable.
This means that they can be recycled by disposing
of them properly in appropriate collection contain-
ers.
■If you take your appliance to a refuse disposal
site, cut off the power cable flush with the appli-
ance to avoid the danger of the appliance being re-
used, and disable the door catch to prevent chil-
dren becoming trapped inside.
125996112.qxd 08/03/01 15.38 Pagina 3 (Nero/Process Black pellicola)

INSTALLATION
4
Positioning
The appliance may be placed in any room, provided
the following precautions are taken.
The appliance expels hot, very moist air. The rest of
the house must be able to easily absorb this moisture.
Normally, absorption is only possible in houses where
there is very little humidity. Otherwise, the room must
have ventilation towards the outside; generally, an
open door or window is enough.
The capacity of the venting circuit must be at least
150 m3/hour. Check that the air inlet and outlet vents
are unobstructed.
The best way of evacuating the moisture is through a
vent hose to the outside of the building. Use the spe-
cial 100 mm diameter flexible hose supplied with the
appliance connected to one of the air outlet vents with
the collar supplied.
The unused outlets must be covered.
Never connect the air vent hose into an existing dis-
charge pipe or duct, as this could be dangerous, might
disturb neighbours and could cause the dryer to mal-
function.
This product is supplied with a 2.50 metre vent
hose, although the maximum length of the vent
hose may be:
4 metres with no bends, or
2 metres with 2 bends.
Advice: If the hose is long and the room temperature
low, the moisture might condense to water inside the
hose. This is an unavoidable natural phenomenon.
To prevent this water from Iying in the hose or flowing
back into the tumble dryer, it is advisable to drill a
small hole (dia. 3 mm) in the lowest point of the hose
and to place a small container below it.(See picture,
point A).
Connect the other end of the hose to an opening in a
door or window. Fit a suitable shield or point the hose
downwards to prevent any rain water and wind from
getting in.
Rain and wind shields for placing over openings usu-
ally consist of valves or movable flaps. Periodically
check the shield since strong winds and other factors
(rust, dirt) can sometimes prevent it from opening, so
causing problems with air venting.
If you use a rain shield, check that the openings in it
are large enough to allow air to escape. Openings
which are too small restrict the flow of air.
Problems can be encountered in rooms fitted with a
very powerful central extractor fan. If you find that dry-
ing times are too long, switch off the extractor or close
its grille whilst the tumble dryer is in use.
A highly effective solution is to simply poke the vent
hose through a window or skylight. This might how-
ever cause problems in winter because the dryer will
draw in very cold (and often also very damp) air
through the open window, so increasing drying times
and leading to very high energy consumption.
If the dryer is fitted next to kitchen units, make
sure that the vent hose is not squashed. If the
hose is partially squashed, drying efficiency wlll
be reduced, resulting in longer drying times and
higher energy consumption.
If the hose is completely squashed, the safety cut-
outs with which the machine is fitted may operate.
Condensation discharge through the vent
hose
Condensation may be discharged either through a
vent outlet provided at the back or through the left or
right side outlet.
The vent hose collar is placed in the rear vent outlet.
Remove the collar by
pulling it out of the vent
outlet. Screw the collar to
the vent hose.
Fit the hose into the
required vent outlet, and
place vent covers provid-
ed over the unused out-
lets.
The vent hose must not
contain more than two
bends when it is placed in
position for operation.
You should NOT con-
nect the flexible vent
hose to, for example, a
chimney or flue pipe
designed to carry the
exhaust from a fuel burn-
ing heating appliance.
A
P0751
P0330
P0279
A
P0055
125996112.qxd 08/03/01 15.38 Pagina 4 (Nero/Process Black pellicola)

5
The tumble dryer must be installed in a clean place,
where dirt does not build up.
Make sure there are no
obstructing items or
material near the air-in-
take louvres provided at
the back (e.g. paper,
rags
etc.).
Important
When operating the tumble dryer, the room tempera-
ture must not exceed 35°C, as it may affect the perfor-
mance of the appliance.
To save energy, the room temperature should not be
lower than +15°C.
Levelling
Level the tumble dryer
into place by screwing or
unscrewing the front feet
as required.
Accurate levelling will
keep vibration and
noise to a minimum
when the dryer is in
use.
Door reversal
To make it easier to load or unload the laundry the
door can be reversed.
This operation must be carried out by qualified
personnel.
Operate as follows:
- Remove the door by unscrewing the two screws (1)
fastening the hinge to the cabinet (Fig. A).
- Remove the safety catch (2) by pressing it down-
wards (Fig. A) and refit it on the opposite side of the
door.
- Using a screwdriver, remove screws (3), plastic
plate (4) and plug (5), see picture A. Take care not
the damage the cabinet.
Refit them on the opposite side (Fig. B)
- Refit the door by screwing in the two screws (1)
which fasten the door to the cabinet (Fig. B).
P0281
P0046
1
2
34
P0883
5
A
1
2
3
4
P0884
5
B
125996112.qxd 08/03/01 15.38 Pagina 5 (Nero/Process Black pellicola)

6
Electrical Connections
WARNING:THIS APPLIANCE MUST BE EARTHED.
The manufacturer declines any liability should this
safety measure not be observed.
If the plug that is fitted to your appliance is not suitable
for your socket outlet, it must be cut off, and the
appropriate plug fitted.
Remove the fuse from the cut off plug. The cut off
plug should then be disposed of to prevent the hazard
of electric shocks, in case it should be plugged into a
13 Amp socket in another part of your home.
IMPORTANT
The wires in the mains
lead are coloured in
accordance with the fol-
lowing code:
Green and Yellow - Earth
Blue - Neutral
Brown - Live
If you fit your own plug,
the colours of the wires in the mains lead of your
appliance may not correspond with the markings iden-
tifying the terminals in your plug.
To fit the plug, proceed as follows:
Connect the green and yellow (earth) wire to the ter-
minal in the plug which is marked with the letter «E»
or the earth symbol , or coloured green and yellow.
Connect the blue (neutral) wire to the terminal in the
plug which is marked with the letter «N» or coloured
black.
Connect the brown (live) wire to the terminal in the
plug which is marked with the letter «L» or coloured
red.
The plug moulded on to the lead incorporates a fuse.
For replacement, use a 13 Amp BS1362 fuse. Only
ASTA or BSI approved fuses should be used.
The plug must not be used if the fuse cover/carrier is
lost. The cover/carrier is indicated by the coloured
insert at the base of the plug.
A replacement cover/carrier must be obtained from
your local Tricity Bendix Service Centre.
There is a list of these at the end of this instruction
book.
Avoid connecting the tumble dryer to the same socket
as your washing machine (or any other appliance) by
means of an adaptor. Have an extra socket installed if
necessary, by a qualified electrician.
Note
Installation, and, in particular, connection to the elec-
tric mains and to the discharge vent must be carried
out by a competent person or qualified electricians.
Please ensure that when the appliance is installed it is
easily accessible for the engineer, in the event of a
breakdown.
GREEN & YELLOW 13 AMP FUSE
BROWN
CORD CLAMP
BLUE
13 AMP
P0329
125996112.qxd 08/03/01 15.38 Pagina 6 (Nero/Process Black pellicola)

USE
7
USE OF CONTROLS
1 Programme Chart
This will help you to select the correct time for drying.
2 Half Heat Button
Press this button to reduce the temperature when dry-
ing particularly delicate cotton or linen items.
In this case you should select a longer drying time.
On the programmes for synthetics the temperature is
automatically reduced.
Therefore it is not necessary to depress this button.
3 Fresh & Cool Button
By depressing this button the heat is cut off. This is
particularly useful to freshen the laundry (e.g. to
remove a persistent odour of moth-balls).
4 Mains-On Light
This lights up when the machine starts operating and
goes out at the end of the programme.
5 Drying Time Selector Dial
The selector dial incorporates two drying cycles, one
of up to 120 minutes at a high temperature (dark
green section) for cotton and linen, and one of up to
80 minutes at a low temperature (light green section)
for synthetic fabrics.
To set the machine to the selected time, turn the dial
clockwise until the time you want coincides exactly
with the pointer.
NEVER attempt to turn the dial in an anticlockwise
direction.
When selecting the drying time, you should remember
that it includes a 8 minute cooling phase (position
on the dial).
This phase should not be shortened, stopped or
avoided, as this could cause skin burns or damages
to the laundry.
Additional drying
If at the end of the programme the laundry is still too
damp, set the dial for a further period of drying
(remembering to take into account the cooling period).
Control panel
1 5432
MAINS ON
DRYING TIME
HALF
HEA
FRESH
& COOL
TM 560
IMPORTANT: PLEASE READ THE INSTRUCTION BOOK BEFORE USE.
2.5 kg Cupboa d D y 55 - 70 min
5 kg Cupboa d D y 80 - 100 min
2.5 kg I on D y 35 - 50 min
5 kg I on D y 70 - 90 min
Ref eshe 8min
SYNTHETICS MIXED FABRICSCOTTONS LINENS
1.0 kg Cupboa d D y 30 - 35
min
2.5 kg Cupboa d D y 50 - 60
min 1.0 kg I on D y 25 - 30
min
TUMBLE DRYER
125996112.qxd 08/03/01 15.38 Pagina 7 (Nero/Process Black pellicola)

8
Cotton and Linen
Selector dial: up to 120 minutes (dark green section)
Synthetics
Selector dial: up to 80 minutes (light green section)
Degree of drying required
and labels on articles
Degree of spin given
rpm
Quantity
kg
Drying times
mins
800-1000
1200
800-1000
1200
5 80-100
2.5 55-70
5 75-90
2.5 50-60
5 70-90
2.5 35-50
5 65-80
2.5 30-40
Cupboard dry
Iron dry
Degree of drying required
and labels on articles
Degree of spin given
rpm
Quantity
kg
Drying times
mins
650
2.5 50-60
1 30-35
0.5 25-30
Cupboard dry
650
2.5 40-50
1 25-30
0.5 20-25
Iron dry
high temperature
reduced temperature
1) Never overfill the drum (do not load large quilts, for example).
The laundry must be suitably spin dried in your washing machine before being placed in the tumble dryer (500rpm
minimum).
Drying times vary according to:
- The type of laundry
- The size of the load
- The degree of spinning prior to drying
Drying times are given as a guide only. Experience will soon enable you to estimate the drying time needed for
your usual laundry loads.
Do not start by selecting a long drying time. It is better to determine the required degree of dryness by gradually
increasing the drying time.
For a mixed load (cotton and resistant synthetics, for example) select the time for the most delicate fibres and
increase it by 10 mins.
DRYING TIMES
(•)
(•) This programme is the reference programme for the Energy label according to the article 2, paragraph 1 of the
EEC Directive 92/75.
125996112.qxd 08/03/01 15.38 Pagina 8 (Nero/Process Black pellicola)

9
Drying
1. Load the laundry
Open the door by pulling
it outward.
Load the items one at a
time, shaking them out
loosely and close the
door.
Please check the laundry
does not get caught
between the door and
filter.
2. Select the required option
Depress Half Heat or Fresh & Cool, if desired.
3. Select time
Turn the selector dial
clockwise to the required
minute setting (in the
high or low temperature
range, according to the
fabric): the mains-on
light illuminates and the
ma- chine starts operat-
ing.
4. When drying is completed
The machine stops automatically, the mains-on light
goes out.
If the laundry is still too damp, select a further brief
drying time, bearing in mind that during the last 8 min-
utes the dryer carries out the cooling and anti-crease
treatment phase.
When the programme has finished you are advised to
unplug the appliance.
Clean the filter after every drying programme. A
clean filter ensures correct functioning of the
appliance.
P0305
M0016
100
Useful hints
■Try to load to the maximum capacity of the
machine as small loads are uneconomical.
For information, here is a list of the average
weights of some common laundry items.
Sheet 700 - 1000 g
Tablecloth 400 - 500 g
Kitchen towel 70 - 120 g
Table napkin 50 - 100 g
Towelling hand towel 150 - 250 g
Bathrobe 1000 - 1500 g
Man’s shirt 200 - 300 g
Pillowcase 100 - 200 g
Man’s pyjamas 400 - 500 g
Ladies’ nightdress 200 - 250 g
■Never tumble dry the following:
Particularly delicate items such as net curtains,
woollen, silk, fabrics with metal trim, nylon tights,
bulky materials such as anoraks, blankets, eider-
downs, sleeping bags, feather quilts and any items
containing rubber foam or materials similar to rub-
ber foam.
■Always follow the instructions on garment labels.
tumble dry normal (high temperature)
tumble dry delicate (low temperature)
do not tumble dry
■Close pillowcases and covers with fasteners to
prevent small laundry items getting tangled inside
them. Close press studs, zips and hooks and tie
belts and apron strings.
■Sort laundry according to type and degree of dry-
ing required.
■Do not over-dry laundry, this avoids creasing and
saves energy.
■Avoid drying dark clothes with light coloured fluffy
items such as towels as they could attract the fluff.
■ Remove the laundry when the dryer has finished
drying.
■ To avoid a static charge when drying is completed,
use either a fabric softener when you are washing
the laundry or a fabric conditioner specifically for
tumble dryers.
Laundry Shrinkage
Certain fabrics such as woollens and silks are gener-
ally not suitable for tumble drying. Due to the structure
of some woollen garments which are recommended
for tumble drying, shrinking could still occur, but once
the garment is worn again, it should regain its shape.
Starched Laundry
Starched laundry can also be dried in the tumble
dryer. Make sure that the time selected is for iron dry.
After completion of the programme wipe out the drum
with a damp cloth and dry to remove any traces of
starch.
125996112.qxd 08/03/01 15.38 Pagina 9 (Nero/Process Black pellicola)

MAINTENANCE
10
Important
You must disconnect the appliance from the electrici-
ty supply, before you can carry out any cleaning or
maintenance work.
External cleaning
Use only soap and water and then dry thoroughly.
From time to time, apply a little wax furniture cream
with a soft cloth.
Important: do not use methylated spirit, diluents or
similar products.
Cleaning the door
Clean periodically the
interior part of the door to
remove any fluff.
Accurate cleaning en-
sures correct drying.
Cleaning the filter
Your dryer will only func-
tion well if the filter is
clean.
The filter collects all the
«fluff» which accumu-
lates during drying and it
must therefore be
cleaned at the end of
each programme with a
damp cloth.
The filter cannot be removed.
It is perfectly normal for fluff to accumulate in the filter
during drying. In fact, even fabrics dried in the open
air lose their fibres, but we do not notice it.
P0328
P0767
SERVICING
Before contacting your local Tricity
Bendix Service Centre, please make the
following checks:
The dryer does not start up
■The door is open
■The plug is not fitted into the wall socket
■There is no electricity supply from the wall socket
■The time selector dial is not set correctly
■The child safety catch is not in position
The dryer does not dry properly
■The filter is clogged
■Insufficient drying time
■Excessive laundry load
■The dryer is not correctly installed
If, after the above checks, there is still a fault, call your
local Tricity Bendix Service Centre. Addresses and
tele- phone numbers are detailed at the back of the
instruction book headed Tricity Bendix Service Force.
Please make sure you give the model and serial num-
ber of the appliance.
This information can be
found on the rating
plate (see picture) or on
the guarantee card.
Original spare parts can be purchased from Tricity
Bendix Service Centres.
In-guarantee customers should ensure that the
above checks have been made as the engineer
will make a charge if the fault is not a mechanical
or electrical breakdown.
Please note that proof of purchase is required for
any in-guarantee service calls.
P0307
Mod. ...
Prod. No. ........
Ser. No. ............
125996112.qxd 08/03/01 15.38 Pagina 10 (Nero/Process Black pellicola)

TRICITY BENDIX GUARANTEE CONDITIONS
11
Standard guarantee conditions
We, Tricity Bendix, undertake that if, within 12 months
of the date of the purchase, this TRICITY BENDIX
appliance or any part thereof is proved to be defective
by reason only of faulty workmanship or materials, we
will, at our option, repair or replace the same FREE
OF ANY CHARGE for labour, materials or carriage on
condition that:
■The appliance has been correctly installed and
used only on the electricity supply stated on the
rating plate.
■The appliance has been used for normal domestic
purposes only, and in accordance with the manu-
facturer’s instructions.
■The appliance has not been serviced, maintained,
repaired, taken apart or tampered with, by any
person not authorised by us.
All service work under this guarantee must be under-
taken by a Tricity Bendix Service Force Centre.
Any appliance or defective part replaced shall
become the Company’s property.
This guarantee is in addition to your statutory and
other legal rights.
Home visits are made between 8.30am and 5.30pm
Monday to Friday. Visits may be available outside
these hours in which case a premium will be
charged.
Exclusions
This guarantee does not cover:
■Damage or calls resulting from transportation,
improper use or neglect, the replacement of any
light bulbs or removable parts of glass or plastic.
■Costs incurred for calls to put right an appliance
which is improperly installed or calls to appliances
outside the United Kingdom.
■Appliances found to be in use within a commercial
environment, plus those which are subject to
rental agreements.
■Products of Tricity Bendix manufacture which are
NOT marketed by Tricity Bendix.
European guarantee
If you should move to another country within Europe
then your guarantee moves with you to your new
home subject to the following qualifications:
■The guarantee starts from the date you first pur-
chased your product.
■The guarantee is for the same period and to the
same extent for labour and parts as exists in the
new country of use for this brand or range of prod-
ucts.
■The guarantee relates to you and cannot be trans-
ferred to another user.
■Your new home is within the European Community
(EC) or European Free Trade Area.
■The product is installed and used in accordance
with our instructions and is only used domestically,
i.e. a normal household.
■The product is installed taking into account regula-
tions in your new country.
Before you move please contact your nearest
Customer Care Centre, listed below, to give them
details of your new home. They will then ensure that
the local Service Organisation is aware of your move
and able to look after you and your appliances.
France Senlis [phone]
Germany Nurnberg [phone]
Italy Pordenone [phone]
Sweden Stockholm [phone]
UK Newbury [phone]
125996112.qxd 08/03/01 15.38 Pagina 11 (Nero/Process Black pellicola)

12
To contact your local Service Force Centre telephone [phone]
CHANNEL ISLANDS
GUERNSEY Guernsey Electricity
PO Box 4
Vale, Guernsey
Channel Islands GY1 3AD
JERSEY Jersey Electricity Company
Haut De Lorme
Rue De Haut De Lorme
Trinity
Jersey
Channel Islands JE3 5FG
SCOTLAND
ABERDEEN 54 Claremont Street
Aberdeen AB10 6RA
AUCHTERMUCHTY 33a Burnside
Auchtermuchty
Fife KY14 7AJ
BLANTYRE Unit 5
Block 2
Auchenraith Ind. Estate
Rosendale Way
Blantyre G72 0NJ
DUMFRIES 93 Irish Street
Dumfries
DG1 2 PQ
DUNOON 7 Hill Street
Dunoon
Argyll
PA23 7AL
EDINBURGH Unit 12
Dumbryden Ind. Estate
2 Dumbryden Road
Edinburgh
EH14 2AB
GLASGOW Unit 4
Wellington Road
Bishopriggs
Glasgow G64 2SA
INVERNESS Unit 3BI
Smithton Ind. Estate
Smithton
Inverness IV2 7WL
ISLE OF ARRAN Arran Domestics
The Douglas Centre
Brodick
Isle of Arran KA27 8AJ
ISLE OF BARRA J Zerfah
244 Bruernish
Isle of Barra
Western Islands HS9 5QY
ISLES OF BUTE Walker Engineering
Glenmhor
Upper Serpentine Road
Rothesay
Isle of Bute PA20 9EH
ISLE OF LEWIS ND Macleod
16 James Street
Stornoway
Isle of Lewis PA87 2QW
KELSO 2, 6 & 8 Woodmarket
Kelso
Borders
TD5 7AX
ORKNEY 7 King Street
Kirkwall
Orkney
KW15 1JF
PERTH Scottish Hydro Electric
Central Warehouse
Inveralmond
(OWN SALES) Perth PH1 3AF
SHETLAND 3-4 Carlton Place
Lerwick
Shetland
(OWN SALES) ZE1 0PW
SHETLAND Bolts Shetland
26 North Road
Lerwick
(OWN SALES) Shetland ZE1 0PE
WHALSAY Leask Electrical
Harisdale
Symbister, Whalsay
(OWN SALES) Shetland ZE2 9AA
NORTHERN IRELAND
BELFAST Owenmore House
Kilwee Business Park
Dunmurry
Belfast
BT17 0HD
WALES
CARDIFF Unit 4
Guardian Industrial Estate
Clydesmuir Road
Cardiff
CF2 2QS
CLYWD Unit 6-7 Coed Parc
Abergele Road
Rhuddlan
Clwyd
LL18 5UG
DYFED Unit 9
St. Clears Business Park
Tenby Road
St. Clears
Carmarthen
SA33 4JW
OSWESTRY Plas Ffynnon Warehouse
Middleton Road
Oswestry
SY11 2PP
NORTH EAST
GATESHEAD Unit 356a
Dukesway Court
Dukesway
Gateshead NE11 0BH
GRIMSBY 15 Hainton Avenue
Grimsby
N. E. Lincs
DN32 9AS
HULL Unit 1
Boulevard Industrial Estate
Hull
HU3 4AY
LEEDS 64-66 Cross Gates Road
Cross Gates
Leeds
LS15 7YS
NEWTON AYCLIFFE Unit 23
Northfield Way
Aycliffe Industrial Park
Newton Aycliffe
DL5 6EJ
SHEFFIELD Pennine House
Roman Ridge Road
Sheffield
S9 1GB
NORTH WEST
BIRKENHEAD 1KelvinPark
Dock Road
Birkenhead
CH41 1LT
CARLISLE Unit 7
James Street Workshops
James Street
Carlisle
Cumbria CA2 5AH
ISLE OF MAN South Quay Ind. Estate
Douglas
Isle of Man
IM1 5AT
BOLTON Unit B
Central Industrial Estate
St Marks Street
Bolton
BL3 6NR
PRESTON Unit 250
Dawson Place
Bamber Bridge
Preston
Lancashire PR5 8AL
STOCKPORT Unit 20 Haigh Park
Haigh Avenue
Stockport
SK4 1QR
125996112.qxd 08/03/01 15.38 Pagina 12 (Nero/Process Black pellicola)

13
To contact your local Service Centre telephone [phone]
MIDLANDS
BIRMINGHAM 66 Birch Road East
Wyrley Trading Estate
Witton
Birmingham
B6 7DB
BOURNE Pinfold Road
Bourne
PE10 9HT
BRIDGNORTH 68 St. Marys Street
Bridgnorth
Shropshire
WV16 4DR
GLOUCESTER 101 Rycroft Street
Gloucester
GL1 4NB
HEREFORD Units3&4
Bank Buildings
Cattle market
Hareford
HE4 9HX
HIGHAM FERRERS 30 High Street
Higham Ferrers
Northants
NN10 8PL
ILKESTON Unit 2
Furnace Road
Ilkeston DE7 5EP
LEICESTER Unit 7
Oaks Industrial Estate
Coventry Road
Narborough
Leicestershire
LE9 5GF
LINCOLN Unit 8
Clifton Street
Stone Field Park
Lincoln
LN5 8LQ
NEWCASTLE 18-21 Croft Road
UNDER LYME Brampton Ind. Estate
Newcastle under Lyme
Staffordshire
ST5 0TW
REDDITCH 13 Thornhill Road
North Moons Moat
Redditch
Worcestershire
B98 9ND
TAMWORTH Unit 3
Sterling Park
Claymore
Tamworth
B77 5DQ
WORCESTER Units1&2
Northbrooks Close
Gregorys Mill Ind. Estate
Worcester
WR3 8BP
LONDON & EAST ANGLIA
BECKENHAM 11a Gardner Ind. Estate
Kent House Lane
Beckenham
Kent BR3 1QZ
CHELMSFORD Hanbury Road
Widford Ind. Estate
Chelmsford
Essex
CM12 3AE
COLINDALE Unit 14
Capitol Park
Capitol Way
Colindale
London NW9 0EQ
ELTHAM 194 Court Road
Mottingham
Eltham
London SE9 4EW
ENFIELD 284 Alma Road
Enfield
London
EN3 7BB
GRAVESEND Unit B4
Imperial Business Estate
West Mill
Gravesend
Kent
DA11 0DL
IPSWICH Unit 6C
Elton Park Business Centre
Hadleigh Road
Ipswich
IP2 0DD
LETCHWORTH 16-17 Woodside Ind. Park
Works Road
Letchworth
Herts
SG6 1LA
LONDON 2 - 4 Royal Lane
Yiewsley
West Drayton
Middlesex
UB7 8DL
MAIDENHEAD Reform Road
Maidenhead
Berkshire
SL6 8BY
MOLESEY 10 Island Farm Avenue
West Molesey
Surrey
KT8 2UZ
NEWBURY 9 Pipers Court
Berkshire Drive
Thatcham
Berkshire
RG19 4ER
NORWICH 2b Trafalgar Street
Norwich
NR1 3HN
SUNBURY Unit 1a
The Summit
Hanworth Road
Sunbury on Thames
TW16 5DB
SOUTH EAST
ASHFORD Unit 2
Bridge Road Business Centre
Bridge Road
Ashford
Kent TN23 1BB
FLEET Unit 1
Redfields Ind. Estate
Church Crookham
Fleet
Hampshire GU13 0RD
HAYWARDS 21-25 Bridge Road
HEATH Haywards Heath
Sussex RH16 1UA
TONBRIDGE Unit 30
Deacon Trading Estate
Morley Road
Tonbridge
TN9 1RA
SOUTH WEST
BARNSTAPLE Main Road
Fremington
Barnstaple
North Devon EX31 2NT
BOURNEMOUTH 63-65 Curzon Road
Bournemouth
Dorset
BH1 4PW
BRIDGEWATER 6 Herswell Business Park
Salmon Parade
Bridgwater
Somerset TA6 5PY
BRISTOL 11 Eldon Way
Eldonwall Trading Estate
Bristol
BS4 3QQ
EMSWORTH 266 Main Road
Southbourne
Emsworth
PO10 8JL
ISLE OF WIGHT Unit 8
Enterprise Court
Ryde Business Park
Ryde
Isle of Wight PO33 1DB
NEWTON ABBOT Unit 2
Zealley Ind. Estate
Kingsteignton
Newton Abbot
TQ12 3TD
REDRUTH Unit 7D
Pool Ind. Estate
Druids Road
Redruth
Cornwall TR15 3RH
125996112.qxd 08/03/01 15.38 Pagina 13 (Nero/Process Black pellicola)

Tricity Bendix, 55-77 High Street - Slough - Berkshire - SL1 1DZ
Consumer care telephone number 08 05 950950
© Electrolux Household Appliances Limited 2000
125996112.qxd 08/03/01 15.38 Pagina 14 (Nero/Process Black pellicola)
