Tricity Bendix CSB4411 User manual

MODEL NO.
CSB4411
OPERATING AND INSTALLATION INSTRUCTIONS

2
MODEL NO. CSB4411
Voltage: 230/240 Volts AC 50Hz
Wattage: 10.9/11.9kW
Height: 1290mm
Width: 550mm
Depth: 595mm
Weight: 54kg
This appliance complies with: European Council Directive 73/23/EEC.
EMC Directive 89/336/EEC.
CE Marking Directive 93/68/EEC
TECHNICAL DETAILS

3
Technical Details .................................................................................................................................... 2
Contents ................................................................................................................................................. 3
Preface .................................................................................................................................................... 4
Safety ...................................................................................................................................................... 5
Before Installation ........................................................................................................................... 5
During Operation ............................................................................................................................ 5
After Use ........................................................................................................................................ 6
General ........................................................................................................................................... 6
Introduction ............................................................................................................................................ 7
Rating Plate .................................................................................................................................... 7
Installation ...................................................................................................................................... 7
Reversible Oven Door .................................................................................................................... 8
General Notes on Using Your Appliance ....................................................................................... 8
About Condensation and Steam .................................................................................................... 8
Grill and Oven Furniture ................................................................................................................. 8
Getting to Know Your Appliance .......................................................................................................... 9
The Control Panel .......................................................................................................................... 9
The Timer ....................................................................................................................................... 10
The Sealed Hotplates ............................................................................................................................. 13
Recommended Saucepans ............................................................................................................13
Hints and Tips ................................................................................................................................ 13
Deep Fat Frying ...................................................................................................................................... 14
Preserving .............................................................................................................................................. 14
The Grill .................................................................................................................................................. 15
Selecting the Grill ........................................................................................................................... 15
Things to Note ................................................................................................................................ 15
The Grill Pan and Handle ............................................................................................................... 15
Hints and Tips ................................................................................................................................ 16
Grilling Chart .................................................................................................................................. 16
The Oven ................................................................................................................................................. 17
Selecting the Oven ......................................................................................................................... 17
Things to Note ................................................................................................................................ 17
To Fit the Oven Shelves ................................................................................................................. 17
Hints and Tips ................................................................................................................................ 17
Oven Cooking Chart .............................................................................................................................. 18
Oven Roasting Chart ............................................................................................................................. 19
Care and Cleaning ................................................................................................................................. 20
Cleaning Materials ......................................................................................................................... 20
Cleaning the Sealed Hotplates and Hotplate Trims ....................................................................... 20
Things to Note ................................................................................................................................ 20
Cleaning the Outside of the Appliance ........................................................................................... 20
Cleaning the Grill and Oven Furniture ........................................................................................... 21
Cleaning Inside the Oven/Grill Compartments ............................................................................... 21
Care of Stayclean Surfaces ........................................................................................................... 21
Hints and Tips ................................................................................................................................ 21
Something not Working? ...................................................................................................................... 22
Service and Spare Parts ........................................................................................................................ 23
Guarantee Conditions ........................................................................................................................... 24
Notes ....................................................................................................................................................... 25
CONTENTS

4
Dear Customer,
Thank you for buying a Tricity Bendix appliance. With our 80 years experience in
developing and manufacturing the very best in U.K. appliances, you can be
assured that you have purchased a hard working, reliable, quality product.
Tricity Bendix appliances comply with British Standard safety and performance
requirements. They have been approved by BEAB (British Electrotechnical
Approvals Board) and are covered by a 12 month parts and labour guarantee.
To get the best from your new Tricity Bendix appliance, we ask that you PLEASE
READ THESE INSTRUCTIONS CAREFULLY. Particular attention should be made
to cooking times and temperatures, which may differ, from your previous
appliance.
It is most important that this instruction book is retained with the appliance for
future reference. Should the appliance be sold, or if you move house and leave
the appliance, always ensure that the book remains with the appliance. This will
enable the new owner to be acquainted with the functioning of the appliance and
the relevant warnings.
Please read the whole instruction book before attempting to use the appliance
ensuring you follow the recommendations given.
PREFACE

5
THESE WARNINGS ARE PROVIDED IN
THE INTERESTS OF YOUR SAFETY.
ENSURE THAT YOU UNDERSTAND
THEM ALL BEFORE INSTALLING OR
USING THE APPLIANCE.
PLEASE
READ
CAREFULLY
BEFORE INSTALLATION
This appliance is heavy and care
must be taken when moving it.
Ensure that all packaging, both
inside and outside the appliance
has been removed before the
appliance is used.
Do not try to
lift or move the
appliance by pulling the door
handles.
The electrical installation work
must be undertaken by a qualified
electrician/competent person.
It is dangerous to alter or modify
the specifications of the appliance
in any way.
Do not allow young children to
play with any part of the
packaging.
After installation, please dispose of
the packaging with due regard to
safety and the environment, your
local authority can arrange this.
DURING OPERATION
Do not use this appliance if it is in
contact with water. Never operate
it with wet hands.
This appliance is designed to be
operated by adults. Young children
must not be allowed to tamper
with the appliance or play with the
controls.
During use the appliance becomes
Hot. Care should be taken to
avoid touching the heating
elements inside the oven.
CAUTION: Accessible parts may
be hot when the grill is in use.
Young children should be kept
away.
Take great care when heating fats
and oils, as they will ignite if they
become too hot.
This appliance has been designed
for cooking edible foodstuffs only,
and must not be used for any
other purposes.
Never place plastic or any other
material which may melt in the
oven or on the hob.
Ensure cooking utensils are large
enough to contain foods to prevent
spillages and boil overs.
The handles of saucepans which
are smaller than the heated area
on the hob will become hot.
Ensure your hand is protected
before handling the pan.
SAFETY

6
Take care to follow the
recommendations given for
tending the food when grilling.
Always useovenglovesto
remove and replace food in the
oven.
Ensure that you support the grill
pan when it is in the withdrawn or
partially withdrawn position
Ensure that all vents are left
unobstructed to ensure ventilation
of the oven cavity.
Ensure the anti-tilt shelves are put
in place correctly. Refer to
instructions on page 17.
Never line any part of the
appliance with aluminium foil. Do
not allow heatproof cooking
materials e.g. roasting bags, to
come into contact with oven
elements.
Always stand back from the
appliance when opening the oven
door to allow any build up of steam
or heat to release.
Never leave the appliance
unattended when the oven door
is open.
Do not place sealed cans or
aerosols inside the oven. They
may explode if they are heated.
AFTER USE
Ensure that all control knobs are in
the OFF position when not in use.
For hygiene and safety reasons
this appliance should be kept
clean at all times. A build-up of
fats or other foodstuffs could
result in a fire, especially in the
grill pan.
Do not leave utensils containing
foodstuffs, e.g. fat or oil in or on
theapplianceincaseitis
inadvertently switched ON.
Cookers and hobs become very
hot, and retain their heat for a long
periodoftimeafteruse. Children
should be kept well away from the
appliance until it has cooled.
GENERAL Under no circumstances should
any repairs be carried out by an
inexperienced person as this may
cause injury or serious
malfunction.
This appliance should be serviced
by an authorised service Engineer
and only genuine-approved spare
parts should be used. Details of
repair and servicing arrangements
are supplied on page 23 of this
book.
Do not stand on the appliance or
on the open oven door.
Do not hang towels, dishcloths or
clothes from the appliance or its
handle. They are a safety hazard.
Always switch OFF the appliance
at its power point and allow the
appliance to cool before any
maintenance or cleaning work is
carried out.
Only clean this appliance in
accordance with the instructions
given in this book.
Your safety is of paramount importance.
Therefore, if you are unsure about any of
the meanings of these WARNINGS
contact the:
Customer Care Department
Telephone [phone]

7
WARNING: THIS APPLIANCE MUST BE EARTHED
RATING PLATE
This is situated on the front frame of the appliance
and can be seen upon opening the top cavity door.
Alternatively the rating plate may also be found on
the back or top of some models (where applicable).
The appliance must be protected by a suitably
rated fuse or circuit breaker. The rating of the
appliance is given on the rating plate.
Do not remove the rating plate from the
appliance as this may invalidate the guarantee.
INSTALLATION
If your appliance has been damaged in transit,
contact your supplier immediately. DO NOT
attempt to install it.
Your appliance left the factory fully packaged to
protect it from damage. If it is delivered without
packaging and damage has occurred, the
manufacturer cannot accept responsibility. Contact
you supplier for advice.
Once the packaging has been removed the
appliance should only be moved by hand. DO
NOT use a sack barrow or any other aid to lift the
appliance as damage may occur.
Connection to the electricity supply must be carried
out by a qualified electrician/competent person.
The electrical connection should be made using a
double pole isolating switch (cooker socket) with at
least 3mm contact separation in all poles. The
cable must have conductors of sufficiently high
cross-sectional area to prevent overheating and
deterioration.
Six square millimetres (6.00mm2)isthe
recommended cross-section area.
The cable should be routed away from potentially
hot areas marked by X in the diagram below.
To move the appliance, open the main oven door,
and lift the appliance by holding inside the top of
the oven compartment.
This is a type X appliance, which means it is free-
standing and can be fitted with cabinets on one or
both sides. It may also be fitted in a corner setting.
A nominal air gap of 2mm at the sides of the
appliance is required to enable the appliance to be
moved into position.
Side walls which are above hob level should be
protected by heat resistant non-combustible
material and MUST NOT be nearer than 40mm to
the hob side.
Overhanging surfaces or a cooker hood should be
a minimum of 685mm above the hob.
It is important to ensure that the appliance is level
after installation. Levelling feet are fitted to the
appliance to accommodate uneven floors.
INTRODUCTION

8
REVERSIBLE MAIN OVEN DOOR
If you require the oven door to be hinged on the
opposite side, you will need to contact a qualified
Service Engineer. PLEASE NOTE that a charge
will be made.
GENERAL NOTES ON USING YOUR
APPLIANCE
We suggest that you run the oven elements for 10
– 15 minutes at 220oC to burn off any residue from
their surfaces. The procedure should be repeated
with the grill for approximately 5 – 10 minutes.
During this period an odour may be emitted, it is
therefore advisable to open a window for
ventilation.
ABOUT CONDENSATION AND STEAM
When food is heated it produces steam similar to a
boiling kettle. The oven is vented to allow some of
this steam to escape. However, always stand back
from the appliance when opening the oven door to
allow any build up of steam or heat to release.
If the steam comes into contact with a cool surface
on the outside of the appliance, e.g. a trim, it will
condense and produce water droplets. This is
quite normal and is not caused by a fault on the
appliance.
To prevent discolouration, regularly wipe away
condensation and also soilage from surfaces.
For your safety wall coverings at the rear of the
appliance should be securely fixed to the wall.
GRILL AND OVEN FURNITURE
The following items of grill/oven furniture have
been supplied with the appliance. If you require
replacements of any of the items listed below,
please contact your local Service Force Centre
quoting the relevant part number.
1 grill pan
(311409401)
1 grill pan handle
(311468100)
Note
If you require an additional handle for your grill
pan, this can be ordered from your local Service
Force Centre by quoting part number
311479800\6.
1 grill pan grid
(311419801)
1 grill deflector
1 cranked shelf for
grilling
2 straight shelves
for main oven cooking
The grill deflector sits above the grill element and
prevents fat splashing onto the grill roof.
The deflector may be easily removed for cleaning.
Scuffing of the Stayclean oven lining by the oven
furniture pack may occur during transit. These
marks will disappear after the oven elements have
been burnt off for the first time.

9
THE CONTROL PANEL
FEATURES
A-Timer
B - Oven Temperature Control
C - Oven Indicator Neon
D - Grill Control
E - Hotplate Controls
GETTING TO KNOW YOUR APPLIANCE
EDCB
A

10
A CLOCK/COOK TIME SETTING KNOB
B START TIME SETTING KNOB
C MINUTE HAND
D MANUAL SYMBOL ( )
E DISPLAY WINDOW
F START TIME INDICATOR
G HOUR HAND
1. TO SET THE TIME OF DAY
The clock will operate when the appliance is
switched ON at the wall.
To set, push in and turn setting knob (A) anti-
clockwise until the right time of day is displayed,
e.g. 7 a.m. as Fig.1.
2. TO SET TO MANUAL
Ensure the time of day has been set as above.
Push in and turn setting knob (B) in either
direction until the start time indicator (F) lines up
with the hour hand of the clock.
Turn setting knob (A) anti-clockwise, without
pushing it in until the manual symbol ( )can
be seen in the display window as Fig. 2.
The oven temperature controls can now be
operated as required. The oven indicator neon
will glow.
3. TO SET THE MINUTE MINDER
Turn setting knob (A) anti-clockwise, without
pushing it in. The selected minutes can be
seen in the display window, e.g. 60 minutes as
Fig. 3.
A period of up to 3 hours can be timed using the
minute minder. The minute minder cannot be
used when an automatic programme has been
set on the oven timer.
At the end of the set time a continuous bell will
sound for up to 6 minutes. The oven will turn off.
THE TIMER
Fig. 3
A
B
A
Fig. 2
A
Fig. 1
F
G
D
B
C
E
A

11
4. TO CANCEL THE MINUTE MINDER
Turn setting knob (A) anti-clockwise, without
pushing it in until the manual symbol ( )
appears in the display window as Fig.4.
5. HOW TO SET THE OVEN TIMER
When using the oven timer for the very first time,
it is advisable to let it operate while you are at
home. The timer can be checked to show that it
is operating correctly, you will then feel confident
to leave a meal to cook automatically in the
future.
A) TO SWITCH THE OVEN ON AND OFF
AUTOMATICALLY
i) Make sure the electricity supply is switched
ON.
ii) Ensure the clock shows the correct time of
day and the appliance is set in manual (see
point 2).
Adjust as necessary as Fig. 5.
iii) Place food in oven.
iv) To set the length of time you want the food to
cook; turn setting knob (A) anti-clockwise,
without pushing it in, until the required
cooking period can be seen in the display
window e.g. 165 minutes (2 hours 45 mins)
as Fig. 6.
v) Set the start time, by pushing in and turning
setting knob (B) in either direction until
indicator (F) lines up with the time you want
the food to start cooking, e.g. 1.30 p.m. as
Fig.7.
vi) Turn the oven temperature control to the
required setting. The oven indicator light
should be OFF.
vii) When automatic cooking starts the oven
indicator neon will turn ON and OFF showing
that the oven temperature is being
maintained.
viii) The start time indicator ( F) will move with the
hour hand of the clock until the length of
cooking time is complete. A bell will sound
which can be cancelled by turning setting
knob (A) anti-clockwise without pushing it
in, until manual ( ) symbol appears in the
display window as Fig. 8.
ix) The maximum cooking time on automatic is 3
hours.
A
Fig. 4
A
B
Fig. 5
A
Fig. 6
B
Fig. 7
A
Fig. 8

12
B) TO SET THE TIMER TO SWITCH OFF
AUTOMATICALLY
i) Make sure the electricity supply is switched on.
ii) Ensure the clock shows the correct time of day
and the appliance is set to manual. Adjust as
necessary.
iii) Place food in oven.
iv) To set the length of time you want the food to
cook; turn setting knob (A) anti-clockwise,
without pushing it in, until the required cooking
period can be seen in the display window, e.g.
120 minutes (2 hours) and Fig. 9.
v) Turn the oven temperature control to the required
setting. The oven indicator neon should glow.
vi) The oven indicator neon will remain on whilst
reaching temperature and will turn ON and OFF
showing that the oven temperature is being
maintained.
vii) The start time indicator (F) will move with the
hour hand of the clock until the length of cooking
time is complete. A bell will sound which can be
cancelled by turning setting knob (A) anti-
clockwise, without pushing it in,untilthe
manual symbol ( ) appears in the display
window as Fig. 10.
6 RETURNING THE APPLIANCE TO
MANUAL OR TO CANCEL AN
AUTOMATIC PROGRAMME
Turn the oven temperature control OFF. Ensure
the start time indicator (F) lines up with the hour
hand of the clock by pushing in and turning in
either direction, setting knob (B) Fig. 11.
The manual symbol ( ) should be displayed in
the window by turning setting knob (A) anti-
clockwise, without pushing it in.
Turn the oven temperature control ON to check
that the oven operates manually. The oven
indicator neon should glow.
7 THINGS TO NOTE
* If an automatic programme has been set on the
main oven, the grill WILL operate manually.
* The delay time plus the cooking time MUST NOT
exceed 11 hours and 59 minutes.
A
Fig. 9
Fig. 10
A
B
Fig. 11

13
BEFORE USING THE HOTPLATES FOR THE FIRST TIME
Turn the control knob to a medium/high setting and allow the hotplate to heat, uncovered by a saucepan for 3-5
minutes. This hardens the protective coating on the hotplates and makes it more resistant to normal use. A
harmless smoke will be given off from the hotplates.
•To operate the hotplates turn the control knobs in
either direction to vary the heat setting.
•The highest number represents the hottest
setting and the lowest number the coolest
setting. Choose a setting appropriate to the
quantity and type of food to be cooked.
RECOMMENDED SAUCEPANS
For speed and economy only good quality saucepans
with flat bases and close fitting lids are
recommended.
To check the flatness of the saucepan, place a ruler
across the pan base, hold at eye level and look for
light showing. There should be very little or no light
visible between the ruler and the pan base.
The size of the base of the saucepan should be the
same or up to 2.5cm/1 inch larger than the hotplate.
If the base is too small, energy will be wasted,
boilovers will also be more difficult to deal with as
spillage will fall directly onto the hotplate.
Pressure cookers, preserving pans etc., should
comply with the recommendations given above.
Traditional round bottomed Woks must not be used
even with a stand. Woks with flat-bottomed bases
are available and do comply with the above
recommendations.
HINTS AND TIPS
•Lift, rather than slide saucepans on and off the
hob to help reduce scratches and maintain the
efficiency of the hotplates.
•Avoid the use of decorative covers as they can
cause condensation to form on the hotplates
which may lead to deterioration.
•Follow any guidelines provided by the saucepan
manufacturer, particularly those relating to
recommended heat settings.
•Avoid using thin, badly dented or distorted
saucepans as they can lead to sticking and
burning of food.
•To prolong the life of the hotplates:
•Never use utensils with a skirt, e.g. a bucket.
•Never use an asbestos mat.
•Never leave the hotplates ON when not
covered with a saucepan.
THE SEALED HOTPLATES

14
DEEP FAT FRYING
SPECIAL FRYING NOTE:
For safety purposes when deep fat frying, fill the pan
one third full of oil, DO NOT cover the pan with a lid
and DO NOT leave the pan unattended. In the
unfortunate event of a fire, switch the appliance OFF
at the electricity supply and cover the pan with a lid
or damp cloth to assist in smothering the flames.
DO NOT use water on the fire. Leave the pan to cool
for at least 30 minutes before moving it.
DO NOT leave the fat or oil in the frying pan on the
hob to store it in case the hob is inadvertently
switched ON.
1. Preparing the food.
Seal the food by coating with flour, egg and
breadcrumbs or batter. Do not use a basket with
batter coated foods as they will stick.
2. Amount of oil.
For safety purposes fill the pan only one-third full
of oil.
3. Testing the temperature of the oil.
It is advisable to use a thermometer to test the
temperature of the oil. Alternatively, drop a
small cube of bread into the oil which should be
brown in just under a minute if the oil is at the
correct temperature of 190°C/375°F.
4. Cooking the food.
Lower the food gently into the oil. Do Not add
too much food at once or the temperature of the
oil will be reduced and may result in soggy,
greasy food.
Turn the food if necessary; doughnuts float to the
surface so will not brown on the upperside if not
turned. Once cooked, drain the food on
absorbent paper.
5. Double frying chips.
Double frying will ensure good chips. First fry the
chips for a few minutes at 170°C/340°F to seal
the outside. Remove the chips from the oil.
Increase the temperature of the oil to 190°C/375°
to finish cooking and brown the chips.
Chips may be kept for several hours after the first
frying before finishing off with the second frying.
6. Frying temperatures Celsius Fahrenheit
Scale (°C)
150 Scale (°F) 300
First frying of potatoes 170 340
175 350
180 360
Second frying of potatoes 190 375
Frying chicken and fish 195 380
200 390
PRESERVING
1. DO NOT use a pan that overlaps the perimeter of
the hob trim.
2. To allow for a full rolling boil, the pan should be
no more than one third full when all the
ingredients have been added. It is better to use
two pans rather than overfill one, or use half
quantities.
3. Use firm fruit or vegetables and wash well before
using.
4. Preserving sugar gives clear jam, however
granulated sugar is cheaper and gives equally
good flavour.
5. Crystallization may be caused if sugar is not
completely dissolved before bringing jam to the
boil. Over boiling will affect the flavour, setting
properties and colour of the jam.
6. To test jam for setting:
If a jam thermometer is available, boil jam to
104°C. Marmalade should be boiled to 106°C.
If a jam thermometer is not available, remove
pan from heat, place sample of jam on dish and
cool quickly (i.e. in a freezer or frozen food
storage compartment of a refrigerator). When
cold it will crinkle and hold the mark of a finger
run through it, if it is at setting point.
7. The scum should be removed as soon as
possible after setting point has been reached.
Marmalade should be allowed to cool before
potting to prevent the peel rising.

15
USES OF THE GRILL
CAUTION – ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE.
CHLDREN SHOULD BE KEPT AWAY.
SELECTING THE GRILL
•Turn the grill control to the required setting.
•The highest number represents the hottest
setting and the lowest number the coolest
setting.
NOTE
THE GRILL DOOR MUST BE LEFT OPEN DURING
GRILLING.
The cranked shelf MUST only be used in the grilling
compartment, but a straight shelf from the oven may
be used to provide alternative positions.
THE GRILL PAN AND HANDLE
The grill pan is supplied with a removable handle.
To attach the handle, place the wirework under the
cut out in the pan so that the metal plate hooks over
the top of the grill pan.
Slide the handle to the left and over the central bump
on the grill pan.
Ensure the handle is correctly located. It is not
necessary to remove the grill pan handle during
grilling.
Place the grill pan on the shelf so that the pan is
positioned centrally beneath the grill.
To remove the handle, slide the handle to the right
and lift the handle away from the cut out on the grill
pan.
THE GRILL

16
To check the progress of the food being grilled, the
grill pan should be withdrawn on the shelf to tend the
food during cooking, or the carrier shelf can be lifted
away from the appliance and rested on a heat
resistant work surface.
HINTS AND TIPS
•Food should be thoroughly dried before grilling to
minimise splashing. Brush lean meats and fish
lightly with a little oil or melted butter to keep
them moist during cooking.
•Adjust the grid and grill pan runner position to
allow for different foods.
•Accompaniments such as tomatoes and
mushrooms may be placed underneath the grid
when grilling meats.
•When toasting bread use the cranked shelf in
position 2 with the grid in the high position.
•Preheat the grill on a full setting for a few minutes
before sealing steaks or toasting. Adjust the heat
setting and the shelf as necessary during
cooking.
•Thefoodshouldbeturnedoverduringcooking
as required.
NOTE
If you require an additional handle for your grill pan,
this can be ordered from your local Service Force
Centre by quoting part number 311479800\6.
GRILLING CHART
FOOD RUNNER
POSITION GRILL TIME (mins in total)
Bacon Rashers 2 2-3 each side
Beefburgers 2 6-10 each side
Chicken Joints 2 15-20 each side
Chops - Lamb 2 7-10 each side
Pork 2 10-15 each side
Fish – Whole 2
Trout/Mackerel 2 8-12 each side
Fillets – Plaice/Cod 2 4-6 each side
Kebabs 2 10-15 each side
Kidneys – Lamb/Pig 2 4-6 each side
Liver – Lamb/Pig 2 5-10 each side
Sausages 2 10-15 each side
Steaks - Rare 2 3-6 each side
Medium 2 6-8 each side
Well Done 2 7-10 each side
Toasted Sandwiches 2 1¼-1½ each
side
Shelf positions are counted from the bottom upwards.
The times quoted above are given as a guide and
should be adjusted to suit personal taste.

17
SELECTING THE OVEN
•To operate the oven simply set the oven control
dial to the required temperature.
THINGS TO NOTE
1. The oven indicator neon will glow until the oven
has reached the desired temperature and then
go out.
2. It will turn ON and OFF periodically during
cooking showing that the temperature is being
maintained.
TO FIT THE OVEN SHELVES
The shelves should be fitted with the straight rods
uppermost on the frame and the forms towards the
back of the oven. If not fitted correctly the anti-tilt
and safety stop mechanism will be affected.
HINTS AND TIPS
•Arrange the shelves in the required positions
before switching the oven ON. Shelf positions
are numbered from the bottom upwards.
•Theovenisfittedwithsideelements. Thetopof
the oven is the hottest, the bottom the coolest.
•Avoid placing food too close to the side element
covers to prevent scorching.
•Do not line any part of the oven with aluminium
foil as it may cause damage or interfere with the
air circulation.
•Use the recommended temperatures and
cooking times given in the oven cooking chart on
pages 18 and 19.
6
5
4
3
2
1
THE OVEN

18
The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the
temperatures by 10°C to suit individual preferences and requirements.
Shelf positions are counted from the bottom of the oven.
FOOD MAIN OVEN SHELF
POSITIONS
COOKING
TEMP (°C)
APPROXIMATE
COOK
(TIME MINS)
Biscuits 4 and 5 190-200 10-20
Flapjacks 5 180-190 25-30
Shortbread 3 150-160 45-65
Bread 1 and 5 210-220 20-30
Bread rolls/buns
Casseroles- Beef 3 140-150 2-3 hours
Chicken 3 180-190 1½ hours
Cakes: Small & Queen 2 and 5 180-190 20-25
Victoria sandwich 2 and 5 180-190 20-25
Gingerbread 3 150-160 1¼-1½ hours
Madeira 3 170-180 1-1¼ hours
Rich fruit 3 150-160 2¼-2¾ hours
Christmas 2 140-150 Depending on size 3-4½ h
Meringues 2 90-100 2½-3 hours
Convenience foods Follow instructions on the pack
Fish 3 180-190 20-30
Fish pie (potato topped) 3 200-210 20-25
Shepherds pie 4 210-220 40-45
Fruit pies and crumbles 4 210-220 40-45
Milk puddings 2 150-160 1½-2 hours
Pastry: Choux – Chocolate eclairs 2 and 5 190-200 30-35
Profiteroles 2 and 5 180-190 20-30
Shortcrust – Mince pies 2 and 5 200-210 15-20
Flaky/Puff pies 3 220-230 30-40
Quiche Lorraine/tarts/flan 5 200-210 30-45
Meat pie 5 200-210 30-45
Plate tarts/pies 2 and 5 200-210 30-45
Scones 2 and 5 230-240 8-12
Soufflé 3 200 30-40
Roasting Meat and Poultry 1 180-200 See Roasting Chart
Pasta e.g. Lasagne 3 200 30-40
Vegetable dishes
Baked jacket potatoes 2 and 4 200 1-1½ hours
Roast potatoes 5 200-220 1-1½ hours
Yorkshire puddings: Large 5 230 35-40
Individual 2 and 5 230 35-40
OVEN COOKING CHART

19
TEMPERATURES (°C)
MEAT OVEN
COOKING TIME
Beef 180-200 20-35 minutes per ½kg (1lb)
and 20-35 minutes over
Beef, boned 180-200 25-35 minutes per ½kg (1lb)
and 25-35 minutes over
Mutton and Lamb 180-200 25-35 minutes per ½kg (1lb)
and 25-35 minutes over
Pork and Veal 180-200 30-40 minutes per ½kg (1lb)
and 30-40 minutes over
Ham 180-200 30-40 minutes per ½kg (1lb)
and 30-40 minutes over
Chicken 180-200 15-20 minutes per ½kg (1lb)
and 20 minutes over
Turkey and Goose 180-200 15-20 minutes per ½kg (1lb) up
to3½kg(7lb)then15minutes
per ½kg (1lb) over 3½kg (7lb)
Duck 180-200 25-35 minutes per ½kg (1lb)
and 25-35 minutes over
Pheasant 180-200 35-40 minutes per ½kg (1lb)
and 35-40 minutes over
Rabbit 180-200 20 minutes per ½kg (1lb)
and 20 minutes over
Potatoes with meat 180-200 According to size
Potatoes without meat 190-200 According to size
The roasting temperatures and times given in the chart should be adequate for most joints, but slight adjustments may be
required to allow for personal requirements and the shape and texture of the meat. However, lower temperatures and
longer cooking times are recommended for less tender cuts or larger joints.
Wrap joints in foil if preferred, for extra browning uncover for the last 20 – 30 min. cooking time.
ROASTING CHART

20
ALWAYS SWITCH OFF THE
ELECTRICITY SUPPLY AT THE MAIN
WALL SWITCH AND ALLOW THE
APPLIANCE TO COOL BEFORE
CLEANING.
CLEANING MATERIALS
Before using any cleaning materials on your
appliance, check that they are suitable and that their
use is recommended by the manufacturer.
Cleaners that contain bleach should NOT be used as
they may dull the surface finishes. Harsh abrasives
should also be avoided.
CLEANING THE OUTSIDE OF THE
APPLIANCE
DO NOT use abrasive cleaning materials, or
scourers on the outside of the appliance as some of
the finishes are painted and damage may occur.
Cleaners that contain bleach should NOT be used as
they may dull the surface finishes. Regularly wipe
over the control panel, splashback, oven doors and
cooker sides using a soft cloth and liquid detergent.
DO NOT ATTEMPT TO REMOVE ANY OF
THE CONTROL KNOBS FROM THE
PANEL AS THIS MAY CAUSE DAMAGE
AND IS A SAFETY HAZARD.
CLEANING THE SEALED HOTPLATES
AND HOTPLATE TRIMS
In order to maintain the appearance of your
appliance's sealed hotplates and trims, you are
advised to use the recommended cleaning agents
daily. If you do not allow spillages to burn on they
will be much easier to clean off.
THINGS TO NOTE
The red spot in the centre of the hotplates may be
removed with some abrasive cleaning agents. This
is not a fault and does not affect the performance of
the hotplates.
FOR NORMAL SOILAGE
Wipe over the hotplates and trims using a clean
damp cloth then switch to a low or medium setting for
a few minutes to thoroughly dry.
FOR HEAVY SOILAGE
Use a clean damp cloth or scourer with a cream
cleaner e.g. ‘Cif’ or a powder cleaner e.g. ‘Ajax’ on
the hotplate and trims. Follow the circular grooved
pattern on the hotplate when cleaning. Rinse off
cleaning agents thoroughly. Dry as for normal
soilage.
For more stubborn marks warm the hotplate on a low
setting for 30 seconds. Clean the sealed plate with
‘Ajax’ powder cleaner, ‘Cif’ cream cleaner or a ‘Brillo’
pad. You may have to rub hard for several minutes.
Rinse off cleaning agents thoroughly with a damp
cloth. Switch to a low or medium setting for a few
minutes until the hotplate is thoroughly dry.
CLEANING THE HOTPLATE TRIMS
The stainless steel trims may become straw coloured
during use. Using a proprietary stainless steel
cleaner, e.g. ‘Shiny Sinks’ will help maintain a bright
appearance. Alternatively a powder cleaner such as
‘Bar Keepers Friend’ may be used regularly.
CLEANING THE VITREOUS ENAMEL
Use a clean damp cloth or scourer made for non-
stick saucepans with ‘Cif’ or cream cleaner.
AFTER CLEANING
To maintain the appearance of the hotplates
occasionally apply a little salt free vegetable oil or
commercial restorative agent.
To apply vegetable oil, first heat the hotplate on a
medium setting for 30 seconds then turn OFF. Pour
a very small amount of oil onto kitchen paper, apply
the paper to the hotplate and wipe off any excess oil.
Heat the hotplate on a medium setting for 1 minute.
To apply restorative agent, apply a thin coating of ‘4
Hob’ or use a ‘Minky’ Hotplate Cleaning Cloth
following the manufacturers instructions.
CARE AND CLEANING
