TrickleStar PowerStation1500 User manual

Quick Start Guide
TS6015 PowerStation1500
What’s in the box?
Accessories (sold separately)
1500 Wh PowerStation 200 W AC Charger with
5 ft. (1.5 m) Cable
Y Anderson to DC 7909
Adapter Cable
1 ft. (0.3 m)
Dust Cover
TS3015 Solar Panel Cable
(to connect a 3rd party solar panel)
5 ft. (1.5 m)
TS3016 12 V DC Cable
2.4 ft. (0.7 m)
Two units 100 W Solar Panel
with Anderson connector
(Only available with TS6015SC)
TS601P one unit 100 W Solar Panel
with Anderson connector
Charging the PowerStation1500
200 W
AC charger 0.31 in. (8 mm)
charging input port
Page 1
Two units 100 W Solar Panel with Anderson connector
(Only available with TS6015SC)
Solar panel
charging cable
Solar panel
charging cable
Y Anderson to DC 7909 Adapter cable
0.31 in. (8 mm)
charging input port
If you have purchased a package with TrickleStar solar panels, you may use the solar panels to charge the PowerStation1500.
When you first receive the PowerStation1500, please charge the unit fully (battery status indicator showing 5 segments) before
using or storing it. Fully charge the unit with the supplied 200 W AC Charger.

PowerStation1500 Features
Page 2R8/8 Nov 2022
Main Power
Button
DC Power
Button Charging Input
(0.31 in. (8 mm))
LCD Display
12 V DC Output
Front View Rear View
120 V AC
Outlets (4)
AC Power
Button
USB Type-C
Output
USB Type-A
Outputs (4)
Understanding the LCD Display
Press and hold the power button for 2-3 seconds for power on/off.
Note:
• During charging, the display turns on to show the charging status, but the system remains turned off. Turn on the main power,
then turn on the AC/DC powers before use.
• For long term storage, charge and discharge (connect loads for 2 to 3 mins) every 3 to 6 months for good battery health.
1. Charging power
2. DC ON/OFF status
3. DC output power
4. AC ON/OFF status
5. AC output power
6. Battery status indicator
INPUT
DC ON/OFF
W
W
W
AC ON/OFF
1
2
3
4
5
6
