iO-LORA Wireless Expander
Installation manual
December, 2022

www.trikdis.com 2December, 2022
iO-LORA Wireless Expander
Contents
SAFETY PRECAUTIONS ...................................................................................................................................................3
1DESCRIPTION .........................................................................................................................................................4
1.1 Specifications ........................................................................................................................................................4
1.2 Expander elements................................................................................................................................................5
1.3 Purpose of terminals .............................................................................................................................................5
1.4 LED indication of operation...................................................................................................................................5
2WIRING SCHEMATICS .............................................................................................................................................6
2.1 Fastening ..............................................................................................................................................................6
2.2 Schematic for connecting the power supply .........................................................................................................6
2.3 Schematics for connecting input...........................................................................................................................6
2.4 Schematic for connecting a temperature sensor ..................................................................................................6
2.5 Schematics for connecting CZ-Dallas reader.........................................................................................................7
2.6 Schematics for connecting iO-LORA modules .......................................................................................................7
3REGISTERING THE IO-LORA WIRELESS EXPANDER TO THE CONTROL PANEL “FLEXI” SP3........................................8

www.trikdis.com 3December, 2022
iO-LORA Wireless Expander
Safety precautions
The iO-LORA wireless expander should only be installed and maintained by qualified personnel.
Please read this manual carefully prior to installation in order to avoid mistakes that can lead to malfunction or even damage
to the equipment.
Always disconnect the power supply before making any electrical connections.
Any changes, modifications or repairs not authorized by the manufacturer shall render the warranty void.
Please adhere to your local waste sorting regulations and do not dispose of this equipment or its components with
other household waste.

www.trikdis.com 4December, 2022
iO-LORA Wireless Expander
1Description
iO-LORA wireless expanders with RF-LORA transceiver increase the number of inputs and outputs of the "FLEXi" SP3 security
panel using two-way RF communication.
Temperature sensors (up to 4 pcs.) and readers of contact ("iButton") keys can be connected to the iO-LORA expander. The
PGM output (relay) of the expander can be remotely controlled (on/off) by various electrical devices. iO-LORA has one digital
input.
Features
Communication:
Line-of-sight wireless range up to 1000 m.
Up to 8 iO-LORA wireless expanders can be connected to the "FLEXi" SP3
control panel.
Inputs and outputs:
Bus "1-Wire" is intended for connection of temperature sensors (up to 4
pcs.) and readers of contact ("iButton") keys.
1 input, of selectable type: NC, NO.
1 output (relay).
Connection:
The iO-LORA wireless expander is connected to the "FLEXi" SP3 control
panel via the RF-LORA transceiver.
1.1 Specifications
Parameter
Description
Transmission frequency
867-869 MHz
Modulation type
LORA
Power supply voltage
9-26 V DC
Current consumption
Up to 50 mA (stand-by)
Up to 100 mA (short-term, while sending)
Report encryption
Yes
Range in open space
Up to 1000 m
Input
1, selectable type: NC, NO
Output
1, relay, 250 V AC, 4 A
Temperature sensor
4, Maxim®/Dallas® DS18S20, DS18B20
Operating environment
Temperature from –20 °C to +50 °C, relative humidity –up to 80% at +20 °C
Dimensions
62 x 77 x 25 mm
Weight
80 g

www.trikdis.com 5December, 2022
iO-LORA Wireless Expander
1.2 Expander elements
1. Light indicators.
2. Frontal case opening slot.
3. Terminal for external
connections.
1.3 Purpose of terminals
Terminal
Description
+DC
Power terminal (9-26 V DC positive)
-DC
Power terminal (9-26 V DC negative)
A 485
Not used
B 485
Not used
+5V
Positive 5 V power terminal for "1-Wire" devices
1Wire
"1-Wire" data bus terminal
COM
Common negative terminal
IN1
1 input, of selectable type NO, NC (factory setting: NO)
NC
Relay terminal NC
C
Relay terminal C
NO
Relay terminal NO
1.4 LED indication of operation
Indicator
Light status
Description
NETWORK
Off
No RF signal
Green blinking
RF signal level from 0 to 10. Sufficient strength is 3
OUTPUT/KEY
Green solid
Relay output activated
Yellow solid
Dallas contact key activated
POWER
Off
No supply voltage
Green blinking
Normal supply voltage level
Yellow blinking
Low supply voltage level (≤11.5 V)

www.trikdis.com 6December, 2022
iO-LORA Wireless Expander
2Wiring schematics
2.1 Fastening
1. Remove the top lid.
2. Remove the PCB board.
3. Fasten the base of the case in the desired place
using screws.
4. Reinsert the board.
5. Close the top lid.
2.2 Schematic for connecting the power supply
2.3 Schematics for connecting input
iO-LORA has one input. Input type can be set: NC, NO.
2.4 Schematic for connecting a temperature sensor
Temperature sensors should be connected according to the
given schematic. Maxim®/Dallas® DS18S20, DS18B20
temperature sensors (up to 4) can be connected to the iO-LORA
wireless expander.
If a wire longer than 0,5 meters is used to connect a temperature
sensor, we recommend using twisted pair cable (UTP4x2x0,5 or
STP4x2x0,5).

www.trikdis.com 7December, 2022
iO-LORA Wireless Expander
The +5V terminal on the board is for supplying devices connected to the "1-Wire" data bus with 5 V DC voltage. The maximum
output current is 0,2 A. The output is protected from overload. If the maximum allowed current is exceeded, the power will
automatically be switched off. The "FLEXi" SP3 control panel automatically recognizes and links connected temperature
sensors.
2.5 Schematics for connecting CZ-Dallas reader
The CZ-Dallas iButton key reader connects to the iO-LORA using the "1 Wire" data bus. The length of the wires connecting to
the data bus can be up to 30 m.
2.6 Schematics for connecting iO-LORA modules

www.trikdis.com 8December, 2022
iO-LORA Wireless Expander
Note:
An RF-LORA transceiver must be connected to the "FLEXi"SP3 security panel and then up to 8 pcs. can be connected
iO-LORA wireless expanders.
It is recommended to use a twisted pair cable (UTP4x2x0.5 or STP4x2x0.5) to connect the temperature sensor.
CZ-Dallas iButton key readers and temperature sensors must be connected to "1-Wire" bus.
3Registering the iO-LORA wireless expander to the control panel “FLEXi” SP3
1. An RF-LORA transceiver must be connected to the "FLEXi" SP3 control panel.
2. Turn on the power supply of the "FLEXi" SP3 control panel.
3. Turn on the power supply to the iO-LORA wireless expander.
4. Launch TrikdisConfig.
5. Connect the "FLEXi" SP3 to a computer using a USB Mini-B cable or connect to the "FLEXi" SP3 remotely.
6. Click the button Read [F4] for the program to read the parameters currently set for the "FLEXi" SP3 control panel. If a
window for entering the Administrator code opens, enter the six-symbol administrator.
7. In the "Modules" list, select "iO-LORA expander".
8. In the "Serial No." field, enter the serial number of the module.
9. In the "Zones" tab, make settings for the expander's input.
10. In the "PGM" tab, configure the expander's PGM output.
11. Temperature sensors will be included in the "Sensors" list if a temperature sensor is connected to the iO-LORA
expander.

www.trikdis.com 9December, 2022
iO-LORA Wireless Expander
12. Once configuration is complete, click the Write [F5] button.
13. Wait for the updates to finish.
14. Click the "Disconnect" button and disconnect the USB cable.
