INTRODUCTION
Congratulations on your selection of the Triminator Hybrid™ commercial wet/dry trimmer! We want to
help you to get the best results from your new trimmer and to operate it safely. This User Guide
contains information on how to do that; please read it carefully before you set up and use your
trimmer.
We suggest you read the warranty to fully understand coverage and your responsibilities of
ownership. Keep this User Guide handy, so you can refer to it at any time. This User Guide is
considered a permanent part of the trimmer and should remain with the trimmer if resold. The
information and specifications included in this publication are those that were in effect at the time of
approval for printing. Eteros Technologies, (Eteros) reserves the right, however, to discontinue or
change specifications or design at any time without notice and without incurring any obligation. No
part of this publication may be reproduced without written permission.
SAFETY MESSAGE
To ensure operator safety while in use, this device includes decals, guarding, and other safety
features. Operators are encouraged to use caution and best judgment when using the equipment.
Equipment should be serviced when required.
To avoid possible damage to the machine and risk of injury to the operator, consult with an Eteros
Technologies representative to answer any questions.
This document refers to the Eteros Technologies product trimming machine as the Hybrid™ Trimmer.
Since this machine has a rotary cutting unit, special safety precautions must be observed to reduce
the risk of personal injury. Careless or improper use may cause serious or even fatal injury. Please
read and understand these precautions thoroughly before using the machine.
All operators must read and understand this User Guide and be trained in the safe operation and use
of the Hybrid™ Trimmer. We recommend the owner of this equipment develop a standard operating
procedure specific to each worksite to address any local hazards or other conditions not outlined in
this User Guide. The Hybrid™ Trimmer must be inspected regularly for damage, component failure,
and wear. The results of the inspection activity should be documented.
3

Eteros Technologies makes every effort to ensure the Hybrid™ Trimmer is compliant with all current
safety standards. It is the responsibility of the owner to ensure all municipal, provincial, state, county,
territorial, and federal codes, regulations, and standards have been met in each working location.
Do not lend or rent your machine without providing the User Guide. A first-time operator should
receive practical instruction before using the machine.
This machine is not to be used for any purpose other than those expressly stated in the User Guide,
advertising literature, or other Eteros Technologies written material pertaining to the Hybrid™
Trimmer.
Operators must be in good physical condition and mental health to operate this device. Under no
circumstances should the device be operated by any person under the influence of any substance,
including drugs or alcohol, which might impair vision, dexterity, or judgment. Do not operate the
Hybrid™ Trimmer when fatigued. Be alert. If tired while operating the device, take a break. Fatigue
may result in loss of control. Working with any equipment can be strenuous. If you have any condition
that might be aggravated by strenuous work, check with your doctor before operating the device.
DISCLAIMER
Eteros Technologies recognizes that the Hybrid™ Trimmer is a purpose-built machine for processing
cannabis by licensed producers. Please check all municipal, provincial/state, and federal laws and
regulations before using the Hybrid™ Trimmer. Eteros Technologies does not promote or condone the
use of processing equipment in any way that may be deemed illegal
Eteros Technologies recognizes that our equipment can be used for processing herbs, hops, flowers,
and many other products. It is not the responsibility of Eteros Technologies to confirm alternative
applications for our equipment.
4

WARNING LABELS
Your safety and the safety of others are very important. We have provided important safety
messages in this manual and on the Triminator Hybrid™. This information alerts you to potential
hazards that could hurt you or others. Please read these messages carefully. Of course, it is not
practical or possible to warn you about all the hazards associated with operating or maintaining a
trimmer. You must use your own good judgment.
You will find important safety information in a variety of forms:
●Safety Labels - located on the trimmer.
●Instructions - how to use this trimmer correctly and safely.
●Safety Messages - preceded by a safety alert; a symbol and one of three signal words:
DANGER, WARNING, or CAUTION.
DANGER:
Indicates a hazardous situation that, if not avoided, will result
in serious injury and/or death. This signal word is to be
limited to the most extreme situations; typically for machine
components that, for functional purposes, cannot be guarded.
WARNING:
Indicates a potentially hazardous situation that, if not
avoided, could result in serious injury and/or death. It includes
hazards that are exposed when guards are removed. It may
also be used to alert against unsafe practices.
CAUTION:
Indicates a potentially hazardous situation that, if not
avoided, may result in minor or moderate injury. It may also
be used to alert against unsafe practices.
Damage Prevention Messages - You will also see other important messages that are preceded by
the word NOTICE. This word means:
NOTICE Your trimmer or other property can be damaged if you don’t follow instructions.
5

SERVICE AND REPAIRS
Repairs may only be carried out by Eteros Technologies or a designated authorized agent (service
technician).
Should the need arise, please notify us:
Eteros Technologies
6175 South Sandhill Road, Unit 600,
Las Vegas, NV 89120
www.eteros.com
www.thetriminator.com
[e-mail]
[phone]
Improper interfacing, improper repair, or an unauthorized modification could result in void warranty
claims.
6

SAFETY PRECAUTIONS
SAFETY INFORMATION
Read and become familiar with the entire User Guide. Learn the equipment applications, limitations,
and possible hazards.
TRAINED WORKERS ONLY
KEEP CHILDREN and BYSTANDERS AWAY from the device. Visitors should be kept at a safe distance
from the work area.
KEEP GUARDS AND SHIELDS IN PLACE
Guards and shields are designed to protect you from touching moving components. For your safety
and the safety of others, keep all shields in place when the trimmer is running, including the hopper,
chute, and tumbler guard.
CHECK FOR DAMAGED PARTS PRIOR TO OPERATION
The equipment should be inspected prior to use to ensure proper operation in performing its intended
function. Check for alignment of moving parts, binding of moving parts, breakage of parts, mounting,
and any other conditions that may affect its operation. Any damaged part including guards should be
properly repaired or replaced.
POWER DOWN AND DISCONNECT
Power down and disconnect equipment before servicing and when changing accessories, such as trim
bags, blades, etc.
DON’T FORCE THE EQUIPMENT
It will operate optimally and safely at the rate for which it was designed.
USE THE RIGHT TOOL
Don’t force the device to do a job for which it was not designed.
7

WORK IN A SAFE ENVIRONMENT
DO NOT USE THE DEVICE IN A DANGEROUS ENVIRONMENT or damp or wet locations. Never expose
the control panel directly to rain or water. Keep the work area well-illuminated. DO NOT use the
device in the presence of flammable liquids or gasses.
KEEP THE WORK AREA CLEAN
Cluttered areas and workspaces invite accidents.
ALWAYS OPERATE THE DEVICE IN A WELL-VENTILATED AREA
Dust generated from certain materials can be a health hazard. Use a dust collection system whenever
possible.
WEAR PROPER APPAREL
Do not wear loose clothing, gloves, neckties, rings, bracelets, or other jewelry which may get caught in
moving parts. Non-slip footwear is recommended. Wear protective hair covering to contain long hair.
WEAR EYE PROTECTION
Safety goggles can protect your eyes from fast-moving debris.
WEAR A FACE MASK OR DUST MASK
Trimming operations may produce dust. If dust extraction is not considered, a dust mask should be
worn.
8

COMPONENTS
9

POWER PACK
POWER PACK CABLES
There are 2 connectors on the Power Pack; the AC supply cable and the vacuum motor output cable.
The two connectors are different so it is not possible to plug in the wrong cable.
The AC supply cable requires a NEMA 5-20R outlet. Do not use the Hybrid™ Trimmer with an
extension cord as the voltage drop across the extension cord will result in excessive current drawn by
the Hybrid™, potentially tripping breakers and overheating the motors.
POWER PACK HOUR METER
The Power Pack is equipped with an hour meter, located underneath the
small tumbler drive gear. The hour meter records time when either the
tumbler or helical motors are operating.
CONTROL OVERVIEW
10

EMERGENCY STOP
Pressing the emergency stop button will immediately shut down the machine, stopping the tumbler,
blades, and vacuum system. When the emergency stop button is depressed, the tumbler chamber
will be illuminated red.
NOTICE It is NOT recommended to use the emergency stop button to stop the machine in everyday
operation.
LID
The lid is an integral part of the safety system. Magnets are incorporated into the lid so the trimmer
can detect when the lid is installed. When the lid is installed and the emergency stop button is not
depressed, the tumbler chamber will be illuminated white and the trimmer ready for operation.
When the lid is removed, the trimmer will shut down, turning off all motors and control panel LEDs,
and illuminating the tumbler chamber red. The lid is symmetrical and may be installed in either
orientation.
START/STOP
The START/STOP button acts as a master switch, toggling the Hybrid™ between the stop/standby
and start/operational modes. Both modes allow for changes to the tumbler, blade, and vacuum
settings. In operational mode, the machine will run with all current settings. In standby mode, the
machine will turn off all motors. Toggling between standby and operational modes will not change
individual motor on/off or speed settings.
The led above the START/STOP button will be illuminated during operational mode and off during
standby mode. The tumbler chamber will be illuminated in white for both modes.
For normal day-to-day operations, the trimmer should be turned on and off using the START/STOP
button instead of the emergency stop.
TUMBLER
The tumbler center button toggles the tumbler rotation on and off. The tumbler will rotate when the
integrated LED is illuminated red and the Hybrid™ is in operational mode. The left arrow decreases
and the right arrow increases the tumbler speed. The six LEDs above the buttons indicate the current
speed setting.
11

BLADES
The blade center button toggles the blade rotation on and off. The blade will rotate when the
integrated LED is illuminated red and the Hybrid™ is in operational mode. The left arrow decreases
and the right arrow increases the blade speed. The six LEDs above the buttons indicate the current
speed setting.
VACUUM
The vacuum button toggles the vacuum motor on and off. The vacuum motor will turn on when the
integrated LED is illuminated red and the Hybrid™ is in operational mode. While there is no speed
control for the vacuum motor, it is possible to adjust the vacuum level by manipulating the vacuum
adjustment lever.
VACUUM STRENGTH
The vacuum adjustment lever, integrated into the bypass, is used to control the vacuum strength. To
adjust the vacuum strength, push the handle away from the bypass and select one of the six notched
positions. The side of the bypass is marked with “MIN” and “MAX” to indicate minimum vacuum and
maximum vacuum positions.
MAX (6) MIN (1)
12

TRIMMER TILT
The product dwell time in the tumbler is controlled by the angle of the trimmer.
To prevent over-trimming and to ensure a constant flow of material through the tumbler, the trimmer
should be raised on the infeed side. The closer the trimmer is to horizontal, the longer the dwell time
in the tumbler. Conversely, a steeper tilt angle will move product through the tumbler quicker.
Locate the jacking mechanism knob on the front side of the base near the caster wheel. A ¾in hex
head socket and cordless drill (not included) can be used to drive the jacking mechanism.
NOTICE Always lower the jack to the horizontal position when transporting the trimmer to avoid
damaging the jacking mechanism.
●INCREASE INCLINE
Rotate the knob clockwise to increase the level of
incline.
●DECREASE INCLINE
Rotate the knob counterclockwise to decrease the
level of incline.
13

SETUP
FEED RATES
SINGLE MACHINE FEED RATE
TANDEM MACHINES FEED RATE
WET (18%+)
40 lbs/hr
88 lbs/hr
SEMI-DRY (11-18%)
20 lbs/hr
45 lbs/hr
DRY (9-11%)
15 lbs/hr
35 lbs/hr
OPERATING CONDITIONS
Location
Indoor or covered outdoor
Altitude
0-2000 m (0-6500 ft) above sea level
Temperature (Ambient)
5°C - 40°C (40°F - 105°F)
Maximum Relative Humidity
80% at 31°C (88°F), decreasing linearly to 50% at 40°C (105°F)
Voltage and Current Rating
120 V (60 Hz), 16 A
Overvoltage Category
II
Environment: While the Hybrid™ can be used in a variety of conditions, the best results are achieved
in spaces with low humidity and cool temperatures.
14

NOTICE This machine should not be operated in conditions or orientations where accessing the
emergency stop would be difficult or impossible. Always ensure that any operators have clear access
to the power off and e-stop buttons.
NOTICE If this equipment is used in conditions outside the specified operating conditions, Eteros
Technologies cannot guarantee that the built-in safety functions of the Triminator Hybrid™ will
function as intended.
UNCRATING THE HYBRID™
Your Triminator Hybrid™ Trimmer will arrive with the primary assemblies ready for operation.
1. Remove the crate clips to release the top and side walls of the crate.
2. Release the ratchet straps.
3. Remove all packaging materials. Note that there is foam between the tumbler and the trim
module; this foam must be removed prior to operation.
4. With the help of another person, lift the machine off of the supports and onto the floor. You
can use the handles on the trimming module to lift it off of the base frame.
5. Unpack the box that is nested into the frame module. Inside, you will find the hopper, chute,
and filter bags.
15

ASSEMBLY / DISASSEMBLY
HOPPER AND CHUTE INSTALLATION
AND REMOVAL
The hopper and chute hang on the trimming module end plates.
The hopper/chute have tabs and the end plates have
corresponding slots. To install the hopper or chute, align the tabs
with the slots, push the hopper/chute in towards the tumbler, and
then push the hopper/chute down to latch them in place. To
remove the hopper/chute, lift them up and then pull them away
from the tumbler.
TUMBLER COVER INSTALLATION AND REMOVAL
To remove the cover from the machine for cleaning, grasp the cutouts above the tumbler on either
end of the machine and lift it up.
TO INSTALL THE COVER:
1. Tilt one end down and engage the cover tabs into the cutouts in the end plate.
2. Rotate the other end and engage the second set of tabs.
3. The cover will be flush with the Power Pack and frame when installed correctly and the
magnet will be aligned with the decal.
NOTICE The cover protects operators from dangerous rotating components. Never operate the
trimmer with the cover removed.
16

TUMBLER INSTALLATION AND REMOVAL
To facilitate regular cleaning, the tumbler is designed to allow for quick tool-free removal.
REMOVAL
1. Make sure the machine is powered off and all
motors have stopped turning.
2. Unplug the power cords.
3. Remove the hopper, chute, and cover.
4. Disengage the spring pin on the infeed side of
the machine, pivot the brush up, and then
remove it from the trimming module. Set the
brush assembly aside for cleaning.
5. Lift the tumbler out of the machine.
INSTALLATION
The tumbler can be re-installed by following the above steps in reverse order. The tumbler is properly
seated when it protrudes evenly from both ends of the trimming module.
Ensure that when the brush assembly is re-installed that the spring pin clicks into place to lock the
brush in the machine. Reinstall all guarding before resuming trimming.
POWER PACK REMOVAL / INSTALLATION
The Power Pack is easily removable for cleaning and maintenance.
POWER PACK REMOVAL
1. Unplug all cables.
2. Remove the cover as per the TUMBLER COVER INSTALLATION instructions.
17

3. Grasp the Power Pack by the handles on either end of the machine. Use two people if
necessary.
4. Lift the Power Pack up and towards the tumbler to clear the hangers.
5. Set the Power Pack down on a stable surface.
6. Take care to set the Power Pack down on the feet and not the plastic gears.
POWER PACK INSTALLATION
1. Ensure the cover is not on the machine.
2. Lift up the Power Pack so that the emergency stop will be on the infeed end of the machine
(the jacking mechanism end).
3. Center the Power Pack in the stainless steel unibody and slowly lower it into place.
NOTICE Be sure the helical blade access panel is in the up position against the blades. If it is
in the down position, the power pack will not sit flush.
4. When the Power Pack is 1.5-2.0” above the extrusion rail, move the Power Pack away from
the tumbler and towards the rear extrusion rail so the rear hangers can engage with the
Power Pack.
NOTICE Be careful not to damage the gears during this process.
5. The Power Pack should be flush with the trimming module frame when it is fully seated.
FRONT & REAR PANEL REMOVAL & INSTALLATION
The front and rear panels can be removed to provide access for cleaning.
PANEL REMOVAL
1. Remove the tumbler cover, brush assembly, tumbler, and Power Pack.
18

2. Press the two tabs on one end of
the machine until the tab
disengages with the slot.
3. Rotate the panel away from the
middle of the machine.
4. Remove the panel.
PANEL INSTALLATION
1. The panel with the cutout belongs
on the rear of the machine (Power Pack side) and the perforated panel belongs on the front of
the machine (tumbler side).
2. Orient the panel so the logo is right-side up.
3. Align the two tabs and slots on one end of the panel.
4. Push the other side of the panel in towards the center of the machine until the second set of
tabs and slots click together.
VACUUM SYSTEM INSTALLATION
AND REMOVAL
The elbow and fan housing can be easily removed for
cleaning with no tools required. To access these assemblies
for cleaning:
1. Make sure the machine is powered off and all motors
have stopped turning.
2. Unplug the power cords.
3. Remove the hopper and chute from the trimming
module.
4. With the help of a colleague, use the built-in handles
on the infeed and outfeed sides of the machine to lift
19
