ROTATRIM Digitech Medium Duty Trimmer
For fast, easy trimming of extra-wide digital media,
posters, and laminations. Based on the design and
construction of the Technical Series.
• Self-sharpening tungsten steel cutting wheel
• Cast metal cutting head and end supports
• Chromed steel guide bar, 1½" square
• Aluminum baseboard, 11" wide,
• Measuring scales at both ends
• Aluminum clamping bar with automatic release
• Baseboard extension rods for supporting large materials
are included. These removable rods slide into the
baseboard to extend the total depth to 28"
• Shipped in wooden crate
ROTATRIM has earned an international reputation for the highest standards of quality, design and
manufacturing. These award-winning, British-made trimmers are durable, versatile, precise, and safe.
Using only the finest materials, including Sheffield tungsten steel in its blades, ensures that every
RotaTrim trimmer will provide a lifetime of service – backed up by an outstanding five-year warranty. Alvin & Company has been a proud distributor of
RotaTrim trimmers for over 15 years and we are firmly committed to the service and technical support of every RotaTrim we sell. We stock an extensive
range of spare parts and our factory-trained technicians are available to assist you with product selection, trouble-shooting and repairs.
Model
Cut
Length Dimensions
Nunber of
Ext. Rods
Shipping
Weight
Net
Weight SRP
▲ DT1550 61" 76"l x 14"w 4 88 lbs. 35 lbs. $1,295.00 ea
▲ DT1850 73" 88"l x 14"w 4 106 lbs. 40 lbs. 1,495.00 ea
▲ DT2500 99" 113"l x 14"w 6 136 lbs. 51 lbs. 1,995.00 ea
▲ Oversize item shipped by truck.
TRIMMERS
®
ROTATRIM® Monorail Series
Rotatrim’s intelligent features and reputable quality condensed into an
economical version. Suited for light-duty classroom and office work.
• Designed for light-duty volume
• ¾" square chromed steel rail with unbreakable head and end frames
• Self-sharpening cutting wheel. Cuts in one direction only
• Gray MDF gridded baseboard is 7 /
8" thick x 12" wide
• Transparent clamp strip holds material firmly in place
• Aluminum side rule calibrated in inch and metric
• Adjustable cursor for precision repeat cutting
• Overload plate ensures that trimmer cannot be overloaded
Model
Cut
Length Dimensions
Shipping
Weight
Net
Weight SRP
MRT13 13" 21"l x 13"w 12 lbs. 10 lbs. $249.00 ea
MRT18 18" 26"l x 13"w 14 lbs. 12 lbs. 329.00 ea
MRT26 26" 34"l x 13"w 18 lbs. 15 lbs. 429.00 ea
MRT36 36" 44"l x 13"w 22 lbs. 18 lbs. 575.00 ea
MRT48 48" 57"l x 13"w 31 lbs. 26 lbs. 695.00 ea
ROTATRIM Professional M Series
Engineered for performance, trouble-free maintenance and long-
lasting service. Ideal for art studios, drafting rooms, darkrooms,
and workshops.
• Self-sharpening tungsten steel cutting wheel
• Cast metal cutting head and end supports
• Twin ¾" diameter chromed steel guide bars
• Gray Melamine® baseboard, 7 /
8" thick x 12" wide
• Printed grid, inch and metric, with ¼" grid lines
• Transparent clamp strip holds material firmly
• Aluminum side rule calibrated in inch and metric with adjustable
cursor for repeat cuts
• Cuts in both directions (an overload plate on models M24T-
M54T can be removed for bi-directional cutting of thin materials
• Floor stand and other accessories available
Model
Cut
Length Dimensions
Shipping
Weight
Net
Weight SRP
M12T 12" 18½"l x 15"w 13 lbs. 11 lbs. $415.00 ea
M15T 15" 21½"l x 15"w 14 lbs. 12 lbs. 485.00 ea
M18T 18" 24½"l x 15" w 15 lbs. 13 lbs. 525.00 ea
M24T 24" 30½"l x 15"w 18 lbs. 16 lbs. 620.00 ea
M30T 30" 36½"l x 15"w 21 lbs. 18 lbs. 765.00 ea
M36T 36" 42½"l x 15"w 23 lbs. 20 lbs. 895.00 ea
M42T 42" 48½"l x 15"w 26 lbs. 23 lbs. 1,045.00 ea
M54T 54" 60½"l x 15"w 32 lbs. 27 lbs. 1,185.00 ea

Heavy-duty cutting
head with three
pressure rollers
ROTATRIM Technical Series
For cutting extra-thick, extra-dense materials, these
industrial strength trimmers are equally at home cutting
thin films and tissue paper.
• Self-sharpening tungsten steel cutting wheel
• Cast metal cutting head and end supports
• Chromed steel guide bar, 1½" square
• Aluminum clamping bar with automatic release
• Three pressure rollers and rugged gripper
for secure clamping
• Aluminum baseboard, 11" wide
• Cuts in both directions (an overload plate can be
removed for bi-directional cutting of thin materials)
• Factory set side rule
• Pull handle mounts to top of cutting head
• Baseboard extension rods for supporting large
materials are supplied with models 1550 and above.
These removable rods slide into the baseboard to
extend the total depth to 28"
• Floor stand and other accessories available
• Shipped in wooden crate, except T650 and T950
Model
Cut
Length Dimensions
Nunber of
Ext. Rods
Shipping
Weight
Net
Weight SRP
T650 26" 40"l x 14"w 26 lbs. 21 lbs.
$995.00 ea
T950 38" 52"l x 14"w 33 lbs. 26 lbs.
1,245.00 ea
▲ T1250
49" 64"l x 14"w 73 lbs. 30 lbs.
1,495.00 ea
▲ T1550
61" 76"l x 14"w 4 88 lbs. 35 lbs.
1,795.00 ea
▲ T1850
73" 88"l x 14"w 4 106 lbs. 40 lbs.
2,095.00 ea
▲ T2500
99" 114"l x 14"w 6 136 lbs. 51 lbs.
2,995.00 ea
▲ Oversize item shipped by truck.
ROTATRIM Power Technical Series
Electrically-powered, heavy-duty machines that
combine the best features of the Technical Series
with a belt-driven cutting head for heavy and
continuous workloads.
• Same features and specs as Technical Series
• Cutting head is driven by a heavy-duty
electric motor controlled by a foot-operated
pneumatic switch. Leaves both hands free for
positioning material
• Cutting speed 20 in./sec. (28 lbs./inch torque).
High-speed version also available that cuts at
39 in./sec. (16 lbs./inch torque)
• Modular circuit design is user friendly
• Baseboard extension rods for supporting large
materials are supplied with models 1550 and above.
These removable rods slide into the baseboard to
extend the total depth to 28"
• Floor stand and other accessories available
• All sizes shipped in wooden crate
Model
Cut
Length Dimensions
Nunber of
Ext. Rods
Shipping
Weight
Net
Weight SRP
▲ PT650
26" 55"l x 16"w 114 lbs. 54 lbs. $3,800.00 ea
▲ PT950
38" 67"l x 16"w 128 lbs. 59 lbs. 4,100.00 ea
▲ PT1250
49" 79"l x 16"w 143 lbs. 64 lbs. 4,200.00 ea
▲ PT1550
61" 91"l x 16"w 4 158 lbs. 73 lbs. 4,500.00 ea
▲ PT1850
73" 102"l x 16"w 4 176 lbs. 79 lbs. 4,600.00 ea
▲ PT2150
85" 1114"l x 16"w 5 194 lbs. 84 lbs. 4,800.00 ea
▲ PT2500
99 128"l x 16"w 6 202 lbs. 90 lbs. 6,900.00 ea
▲ Oversize item shipped by truck.
ROTATRIM APPLICATION & CUTTING GUIDE
MATERIAL
HEAVY DUTY
TECH. &
POWER
TECH.
MEDIUM
DUTY
PROF.
M SERIES
MEDIUM
DUTY
FLYER
DIGITECH
LIGHT DUTY
MONORAIL
Aluminum ● ●
Cardboard ● ●
Drafting Film ● ● ● ●
Illustration Board ● ●
Laminating Film ● ● ●
Leather ● ●
Mat Board ● ●
Newsprint ● ● ● ●
Paper ● ● ● ●
Photo Film ● ● ● ●
Polyester Film ● ● ● ●
Shim Steel ●
Tissue ● ● ● ●
Tracing Paper ● ● ● ●
Vellum ● ● ● ●
Vinyl ● ●
Vyco ●
!
RotaTrim Trimmers do not cut foam board products.
“Scratch and Dent” trimmers are often available. Please inquire.
THICKNESS REFERENCE FOR LAMINATED OUTPUT
Light Duty Combined thickness up to .014"
Medium Duty .015" up to .030"
Heavy Duty .030" and above
Actual results may vary depending on material density and hardness. Please
use these figures for reference only.
ROTATRIM PRODUCT WARRANTY
All RotaTrim trimmers are warranted against faulty workmanship and materials for a
period of five years, depending on the model. This warranty does not cover cutting
blades, clamp strips, or other plastic and rubber parts that are subject to normal wear
and tear. Damages due to improper use, handling, or storage will void this guarantee.
Please save the original shipping carton.
NOTE: Please allow eight weeks for delivery for PT series only.
©2006 ALVIN & COMPANY, INC. • P.O. Box 188, Windsor, CT 06095-0722
Phone: [phone] • Toll-Free: 800-444-2584 • Fax: [phone] • Toll-Free Fax: [phone] Visit us at www.alvinco.com
LIT-A6322 9/06
