TriPollar STOP V User manual

USER MANUAL
ENGLISH
FACIAL
RENEWAL AND REJUVENATION

ENGLISH
Congratulations on purchasing your TriPollar STOP V device!
You have taken the first step toward flawless beautiful skin!
This user manual describes the TriPollar STOP V product and how to use it.
1

TABLE OF CONTENTS
INTRODUCING TRIPOLLAR STOP V 8
• OVERVIEW
• THE TRIPOLLAR STOP V KIT
USING TRIPOLLAR STOP V 11
• THE TRIPOLLAR STOP V DEVICE
• BEFORE YOU BEGIN
• TREATING YOUR SKIN
• RECOMMENDED TREATMENT GUIDELINES
TROUBLESHOOTING 22
CUSTOMER SUPPORT 22
TECHNICAL SPECIFICATIONS 23
APPENDIX 24
2

3
© Pollogen Ltd. All rights reserved.
Design and technical specifications are subject to change without prior notice.
Manufactured by Pollogen Ltd.
Patented technology.
The names Pollogen, TriPollar and STOP are registered trademarks of
Pollogen Ltd.
All intellectual property rights in this publication are owned by Pollogen
Ltd. and protected by applicable copyright laws and international treaty
provisions. Pollogen Ltd. retains all rights not expressly granted. No part
of this publication may be reproduced in any form whatsoever or used to
make any derivative work without prior written approval by Pollogen Ltd.
All other trademarks are the property of their respective owners. Other
company and brand products and service names are trademarks or registered
trademarks of their respective holders.
IMPORTANT NOTICE

4
SAFETY
Important: Be sure to read the entire user manual prior to using the product.
Always adhere to all warnings and cautions. Be sure to follow all safety
precautions below when using the TriPollar STOP V product.
To learn more about TriPollar technology, visit our website at www.stop-age.com.
WARNINGS AND CAUTIONS
TriPollar STOP V is an electrical device that must be used properly.
To reduce the risk of injury, adhere to all warnings and cautions below:
• Do not touch the device should it fall into water. Unplug the device
immediately with dry hands.
• Do not place or store the device near any source of water, such as a sink
or bathtub.
• Do not submerge the device under water.
• When plugged in, do not leave the device unattended.
• Before use, ensure that the system and its power supply do not show
any visible damage. Do not operate if the electric cord is damaged or
if the system is disassembled.
• Only use the device with the electric cord and power supply provided.
• Keep the device out of the reach of children.
• Be sure that your hands are completely dry when operating the device.
• Turn the device OFF and then unplug the power supply from the electrical
outlet after use or before cleaning and maintenance.

5
• Use STOP Preparation Gel during treatment according to its instructions
for use.
SAFETY INSTRUCTIONS
• Only use this device for its intended purpose, as described in this manual.
• Do not use the device over eyelids, closed eyes, thyroid area, lips, ears,
breasts or genital areas.
• The sensation while using the device should be warm and pleasant. If
you experience discomfort, discontinue use immediately.
Failure to follow the instructions in this manual may cause damage or
burns to your skin.
DO NOT USE THE DEVICE IF ANY OF THE FOLLOWING APPLY TO YOU:
• Are under 18 years of age.
• Have a pacemaker or internal defibrillator.
• Have metal implants in the treatment area, such as gold threads. This
does not apply to dental fillings or implants, which present no problem.
• Currently have cancer or a history of cancer, especially skin cancer or
premalignant moles.
• Have severe concurrent conditions, such as cardiac disorders.
• Are pregnant or nursing.
• Have an impaired immune system due to immunosuppressive diseases
such as AIDS, or are using immunosuppressive medications.
• Have any disease that is stimulated by heat, such as recurrent Herpes
Simplex (within the treatment area).

6
• Have any active skin condition within the treatment area, such as sores,
psoriasis, eczema or a rash.
• Have a history of keloid scarring, abnormal wound healing or fragile skin.
• Have had any surgical procedure, laser resurfacing or deep chemical
peeling in the treatment area within the past three months or are still
undergoing a healing process.
• Have permanent fillers within the treatment area.
If you have temporary dermal fillers within the treatment area, consult your
physician before using the device.
• Have had Botox administered in the treatment area within the past three
months.
• Have suspicious lesions within the treatment area.
• Currently use medications, herbal preparations, vitamins or food supplements
that may cause fragile or dry skin.

7
The following side effects are rare. However, should they occur, they are
usually temporary. If any of the following conditions appear and last more
than 24 hours, consult your physician:
• Pain
• Damage to natural skin texture (crusting, blistering, burns, fragile skin, bruising)
• Mild headache
For other aesthetic procedures or should you have any uncertainty regarding
potential side effects, consult your physician before using the device.
POSSIBLE SIDE EFFECTS

8
INTRODUCING TRIPOLLAR STOP V
This chapter introduces the TriPollar STOP V product and describes its
components.
OVERVIEW
TriPollar STOP V is a safe, effective and easy-to-use skin renewal device
that delivers professional level aesthetic results in the comfort of your
own home. The TriPollar STOP V device produces genuine, noticeable,
immediate and long-lasting results. The revolutionary TriPollar STOP V
combines two effective technologies – TriPollar Radio Frequency (RF) and
Dynamic Muscle Activation (DMA) that work simultaneously to deliver
non-invasive collagen remodeling and muscle activity, as well as skin
tightening and treatment of wrinkles.
Powered by Pollogen’s revolutionary, patented TriPollar technology,
TriPollar STOP V delivers RF energy into the dermis skin layer. TriPollar
energy stimulates dermal activity to increase and accelerate the natural
production of collagen, the protein responsible for the skin’s supple texture.
Increased collagen levels in the skin result in tighter, more-supple skin.
DMA targets the SMAS (muscle) layer, toning and lifting it by stimulating
gentle muscle contractions inducing a face lift effect. The combination
of RF and DMA has a synergistic effect on the skin, improving the
appearance of the skin.
The TriPollar STOP V system is intended for non-invasive skin renewal at
home, specifically indicated for skin tightening and treatment of wrinkles.
When the TriPollar STOP V device is used properly in accordance with the
recommended treatment protocol, it effectively postpones the signs of aging.

9
THE TRIPOLLAR STOP V KIT
The TriPollar STOP V kit contains the following components:
1. TRIPOLLAR STOP V KIT (FIG.1)
FIG.1

10
FIG.3 FIG.6
FIG.5
FIG.4
2. TRIPOLLAR STOP V DEVICE (FIG.2)
3. TRIPOLLAR STOP V POWER SUPPLY AND ELECTRIC CORD (FIG.3)
4. TRIPOLLAR STOP V ELECTRICAL OUTLET ADAPTERS (FIG.4)
5. STOP PREPARATION GEL (FIG.5)
After the container has been opened, the gel can be used for up to 12 months.
Important: It is recommended to perform a patch test 24 hours prior to initial
use. See page 15 for details.
6. TRIPOLLAR STOP V USER MANUAL AND WARRANTY POLICY (FIG.6)
FIG.2
Preparation
Gel
User Manual/
International
Warranty

11
USING TRIPOLLAR STOP V
This chapter describes the TriPollar STOP V device and how to use it.
THE TRIPOLLAR STOP V DEVICE
The TriPollar STOP V device is used to increase and accelerate collagen
production for skin renewal.
TriPollar STOP V focuses heat deep within the dermis. The TriPollar
STOP V’s DMA technology targets the SMAS layer, as shown below.
1. TRIPOLLAR STOP V TREATMENT HEAD
2. EPIDERMIS
3. DERMIS
4. TRIPOLLAR STOP V POWER IS FOCUSED
DEEP WITHIN THE DERMIS
5. HYPODERMIS
6. SMAS (MUSCLE)
FIG.7

12
The components comprising the TriPollar STOP V device:
1. DEVICE BODY
2. TREATMENT HEAD
3. ELECTRODE
4. TEMPERATURE SENSOR
5. POWER SUPPLY CONNECTION
6. GREEN/BLUE INDICATOR LIGHT
7. ORANGE INDICATOR LIGHT
8. ON/OFF BUTTON
9. LOW RF
10. HIGH RF
11. LOW RF AND LOW DMA
12. HIGH RF AND HIGH DMA
13. PROTECTIVE COVER
FIG.8
9. 10.
5.
8.
7.
6.
4.
3.
2.
1.
12.11. 13.

13
The indicator lights on the TriPollar STOP V device works as follows:
GREEN LIGHTS INDICATE RF MODE
• A single green light means that the device is ON and is operating in low-
level RF mode.
• Two green lights mean that the device is operating in high-level RF mode.
BLUE LIGHTS INDICATE RF + DMA MODE
• A single blue light means that the device is operating in low-level RF mode
and low-level DMA mode.
• Two blue lights mean that the device is operating in high-level RF mode
and high-level DMA mode.

14
Each press of the Power button changes the mode and power level.
1. ON/OFF BUTTON
2. GREEN/BLUE INDICATOR LIGHT
3. LOW RF
4. HIGH RF
5. LOW RF AND LOW DMA
6. HIGH RF AND HIGH DMA
FIG. 9
3. 4.
5. 6.
1.2.

15
FIG.11FIG.10
BEFORE YOU BEGIN
Before using the TriPollar STOP V device, do the following:
1. Open the box containing the device, and remove the device and its power supply.
2. Insert the adapter onto the electrical posts (Fig.10).
3. Twist the adapter clockwise to secure it (Fig.11).
4. Connect the power supply to the device (Fig.12).
5. Plug the power supply into an electrical outlet (Fig.13).
6. Remove the STOP Preparation Gel from its box.
Important: Before using the device for the first time, it is recommended
to perform a patch test 24 hours prior to initial use. To do so, apply a
small amount of STOP Preparation Gel to the inner arm and treat the
area with the TriPollar STOP V device. Ensure that the skin does not have
a negative reaction to the gel or treatment.
7. Remove the protective cover from the device.

16
TREATING YOUR SKIN
To treat your skin using the TriPollar STOP V device:
1. Cleanse and dry the treatment area.
2.
Apply a very thin, even layer of STOP Preparation Gel over the entire
treatment area (face and/or neck). This gel must be used during the
entire treatment session. Your skin may feel a warm sensation when
the gel is applied.
3. Turn the device ON by pressing the Power button (Fig.14).
Make sure that the green indicator light turns ON.
Tip: A long press of the Power button turns the device OFF.
4.
Select the RF power setting (Low/High) that is most comfortable for you.
Important: During your first treatment session, we recommend that you
use the Low power setting and then adjust the power level according
to your skin’s tolerance for subsequent treatments.
FIG.12 FIG.13 FIG.14

17
5. Divide the entire treatment area into two main sections - one for each
side of your face and/or neck (right side and left side). Typically, you treat
one side of your face/neck entirely before treating the other side. Divide
each side into several working sections that are approximately twice the
size of the device head. In general, you first treat one working section
and then move to an adjacent section. You repeat this general technique
and movement until you have treated one entire side of your face/neck.
Then, you use the same technique to treat the other side of your face
and neck (Fig.15).
6.
Place the device on your skin, ensuring that all four electrodes are touching
the skin. For best results, all four electrodes must be in full contact with
the skin at all times during treatment.
7. Start moving the device in very slow circular motions or small figure
eights, slowly heating your skin (Fig.16). The orange indicator light will
turn ON when the skin is heated to the optimal temperature. In addition,
a beep will sound to indicate that the optimal treatment temperature
has been reached.
Important: Be sure to keep the device constantly moving on your skin.
Do not leave the device on one place for long without movement, as
skin overheating may occur. Be sure to constantly move the device slowly
over the skin to ensure proper heating of the treated area. Moving the
device too fast will not achieve the intended effect.

18
8. Once the orange light turns ON and a beep sounds, continue moving the
device within one working section using the same slow circular motions for
a few moments and then move to an adjacent working section. The new
working section now includes the heated section and the new section,
thus enlarging the area. You may want to start your treatment by treating
the section at the jaw line, and then moving to the nasal area and so on,
moving from the bottom to the top of your face (Fig.17).
The device’s automatic temperature-optimization mechanism protects the
skin from overheating. After the skin has reached the maximal treatment
temperature, the green indicator light goes OFF and the orange indicator
light goes ON to indicate that the energy source has been automatically
shut down. The device automatically turns itself back ON when the skin
temperature drops below the optimal temperature or when you move the
device to an adjacent treatment area where the skin temperature is lower.
As you move from one section to another, the orange indicator light
turns OFF if the temperature of the skin in an area is not warm enough.
This is normal. Therefore, as you work within one working section and
move back to the previous section, you maintain the heat in that area
too. In this way, as you move back and forth between working sections,
you are able maintain the heat in both sections for as long as possible.
WORKING
SECTIONS
TREATMENT
AREA
FIG.16 FIG.17FIG.15

19
For effective treatment, the goal is to maintain the optimal temperature
for several seconds before moving to the next treatment section. This
means that the orange indicator light should be illuminated as much as
possible when treating an area.
Important: The orange indicator light turns ON and OFF, depending on
the temperature of the skin in the current area of treatment. The orange
light is ON when the temperature of the skin in that area is sufficiently
heated and is OFF when it is not. In addition, a beep sounds whenever
the orange indicator light turns ON.
For optimal treatment, it is recommended to begin the treatment using
the Low power setting in RF mode and to follow the guidelines below:
• If the orange indicator light and sound indicators do not appear within
5 minutes, or if you do not feel any heating, try moving the device as
slowly as possible without stopping the motion. Slow, circular, constant
movements are more effective than rapid movements. The slower the
movement, the faster the treatment area heats internally.
•
If the orange indicator light and sound indicators still do not appear after
3-5 minutes, select a higher power level. If the indicators still do not
appear after increasing to the High power setting, try moving the device
more slowly, without stopping the motion.
• If the orange indicator light and sound indicators turn ON immediately
or if you feel excessive heat, select a lower power level.
9. Repeat this technique one working section at a time until the entire
treatment area has been heated.
10. For best results, after treating all working sections on one side of your
