Triumph Bonneville Bobber 2016 User guide

Owner's Handbook
Bonneville Bobber
This handbook contains information on the Triumph Bonneville Bobber motorcycles.
Always store this Owner's Handbook with the motorcycle and refer to it for
information whenever necessary.
The information contained in this publication is based on the latest information
available at the time of printing. Triumph reserves the right to make changes at any
time without prior notice, or obligation.
Not to be reproduced wholly or in part without the written permission of Triumph
Motorcycles America Limited.
© Copyright 10.2016 Triumph Motorcycles America Limited.
Publication part number 3855567-US issue 1
1

2
TABLE OF CONTENTS
This handbook contains a number of different sections. The table of contents below
will help you find the beginning of each section where, in the case of the major
sections, a further table of contents will help you find the specific subject required.
Foreword 3
Safety First 6
Warning Labels 12
Parts Identification 14
Serial Numbers 17
General Information 18
How to Ride the Motorcycle 49
Accessories, Passengers and Loading 61
Maintenance 63
Cleaning and Storage 105
Specifications 114
Index 118

Foreword
3
FOREWORD
Warnings, Cautions and Notes
Throughout this Owner's Handbook
particularly important information is
presented in the following form:
Warning
This warning symbol identifies special
instructions or procedures, which if not
correctly followed could result in
personal injury, or loss of life.
Caution
This caution symbol identifies special
instructions or procedures, which, if not
strictly observed, could result in damage
to, or destruction of, equipment.
Note:
• This note symbol indicates points of
particular interest for more
efficient and convenient operation.
Warning Labels
At certain areas of the motorcycle, the
symbol (above) can be seen. The symbol
means 'CAUTION: REFER TO THE
HANDBOOK' and will be followed by a
pictorial representation of the subject
concerned.
Never attempt to ride the motorcycle or
make any adjustments without
reference to the relevant instructions
contained in this handbook.
See page 12 for the location of all labels
bearing this symbol. Where necessary,
this symbol will also appear on the pages
containing the relevant information.
Maintenance
To ensure a long, safe and trouble free
life for your motorcycle, maintenance
should only be carried out by an
authorized Triumph dealer.
Only an authorized Triumph dealer will
have the necessary knowledge,
equipment and skills to maintain your
Triumph motorcycle correctly.
To locate your nearest Triumph dealer,
visit the Triumph website at
www.triumph.co.uk or telephone Triumph
Motorcycles America Limited on
[phone].

Foreword
4
Noise Control System
Tampering with the noise control
system is prohibited.
Owners are warned that the law may
prohibit:
1. The removal or rendering
inoperative by any person other
than for purposes of maintenance,
repair or replacement, of any device
or element of design incorporated
into any new vehicle for the
purpose of noise control prior to its
sale or delivery to the ultimate
purchaser or while it is in use and,
2. the use of the vehicle after such
device or element of design has
been removed or rendered
inoperative by any person.
Immobilizer and Tire Pressure
Monitoring System
This device complies with part 15 of the
Federal Communications Commission
(FCC) Rules.
Operation is subject to the following two
conditions:
• This device may not cause harmful
interference.
• This device must accept any
interference received, including
interference that may cause
undesired operation.
Changes or modifications to the device
could void the user’s authority to
operate the equipment.
Tires
With reference to the Pneumatic Tires
and Tubes for Automotive Vehicles
(Quality Control) Order, 2009, Cl. No. 3 (c),
it is declared by M/s. Triumph
Motorcycles Ltd. that the tires mounted
on this motorcycle meet the
requirements of IS 15627: 2005 and
comply with the requirements under
Central Motor Vehicle Rules (CMVR), 1989.
Owner's Handbook
Warning
This Owner's Handbook, and all other
instructions that are supplied with
your motorcycle, should be considered
a permanent part of your motorcycle
and should remain with it even if your
motorcycle is subsequently sold.
All riders must read this Owner's
Handbook and all other instructions
which are supplied with your
motorcycle, before riding, in order to
become thoroughly familiar with the
correct operation of your motorcycle's
controls, its features, capabilities and
limitations. Do not lend your
motorcycle to others as riding when
not familiar with your motorcycle's
controls, features, capabilities and
limitations can lead to an accident.

Foreword
5
Thank you for choosing a Triumph
motorcycle. This motorcycle is the
product of Triumph's use of proven
engineering, exhaustive testing, and
continuous striving for superior
reliability, safety and performance.
Please read this Owner's Handbook
before riding in order to become
thoroughly familiar with the correct
operation of your motorcycle's controls,
its features, capabilities and limitations.
This handbook includes safe riding tips,
but does not contain all the techniques
and skills necessary to ride a motorcycle
safely.
Triumph strongly recommends that all
riders undertake a safety course
approved by the Motorcycle Safety
Foundation to ensure safe operation of
this motorcycle. Information about the
nearest Motorcycle Safety Foundation
course to you can be obtained by calling
the following nationwide toll free
number: 800-447-4700, or by writing to
the Motorcycle Safety Foundation at:
2, Jenner Street, Irvine, California 92718.
To ensure a long and trouble free life for
your motorcycle, maintenance should be
carried out as described in this manual
by an authorized Triumph dealer.
This handbook is available from your
local dealer in:
• English
• US English
• French
• German
• Italian
• Dutch
• Spanish
• Portuguese
• Swedish
• Japanese
• Thai.
Talk to Triumph
Our relationship with you does not end
with the purchase of your Triumph. Your
feedback on the buying and ownership
experience is very important in helping
us develop our products and services
for you.
Please help us by ensuring your
authorized Triumph dealership has your
email address and registers this with us.
You will then receive an online customer
satisfaction survey invitation to your
email address where you can give us
this feedback.
Your Triumph Team.

Safety First
6
SAFETY FIRST
The Motorcycle
Warning
This motorcycle is designed for on-
road use only. It is not suitable for off-
road use.
Off-road operation could lead to loss of
control of the motorcycle resulting in
an accident causing injury or loss of
life.
Warning
This motorcycle is not designed to tow
a trailer or be mounted with a sidecar.
Installing a sidecar and/or a trailer may
result in loss of control and an
accident.
Warning
This motorcycle is designed for use as
a two-wheeled vehicle capable of
carrying a rider on his/her own.
Operation of this motorcycle with a
passenger is dangerous and could lead
to loss of control and an accident.
Warning
The total weight of the rider,
accessories and luggage must not
exceed the maximum load limit of
275 lb (125 kg).
Fuel and Exhaust Fumes
Warning
GASOLINE IS HIGHLY FLAMMABLE:
Always turn off the engine when
refueling.
Do not refuel or open the fuel filler cap
while smoking or in the vicinity of any
open (naked) flame.
Take care not to spill any gasoline on
the engine, exhaust pipes or mufflers
when refueling.
If gasoline is swallowed, inhaled or
allowed to get into the eyes, seek
immediate medical attention.
Spillage on the skin should be
immediately washed off with soap and
water and clothing contaminated with
gasoline should immediately be removed.
Burns and other serious skin
conditions may result from contact
with gasoline.
Warning
Never start your engine or let it run for
any length of time in a closed area. The
exhaust fumes are poisonous and may
cause loss of consciousness and death
within a short time. Always operate
your motorcycle in the open-air or in
an area with adequate ventilation.

Safety First
7
Helmet and Clothing
Warning
When riding the motorcycle, both rider
and passenger must always wear a
motorcycle helmet, eye protection,
gloves, boots, trousers (close fitting
around the knee and ankle) and a
brightly colored jacket. Brightly colored
clothing will considerably increase a
rider’s (or passenger’s) visibility to
other operators of road vehicles.
Although full protection is not possible,
wearing correct protective clothing can
reduce the risk of injury when riding.
Warning
A helmet is one of the most important
pieces of riding gear as it offers
protection against head injuries. You
and your passenger’s helmet should be
carefully chosen and should fit you or
your passenger’s head comfortably
and securely. A brightly colored helmet
will increase a rider’s (or passenger’s)
visibility to other operators of road
vehicles.
An open face helmet offers some
protection in an accident though a full
face helmet will offer more.
Always wear a visor or approved
goggles to help vision and to protect
your eyes.
cbma
When choosing a helmet, always look for
a DOT (Department of Transport) sticker
indicating that the helmet has DOT
approval. Do not buy a helmet without
DOT approval.
Parking
Warning
Always turn off the engine and remove
the ignition key before leaving the
motorcycle unattended. By removing
the key, the risk of use of the
motorcycle by unauthorized or
untrained persons is reduced.
When parking the motorcycle, always
remember the following:
Engage first gear to help prevent the
motorcycle from rolling off the stand.
The engine and exhaust system will be
hot after riding. DO NOT park where
pedestrians, animals and/or children
are likely to touch the motorcycle.
Do not park on soft ground or on a
steeply inclined surface. Parking under
these conditions may cause the
motorcycle to fall over.
For further details, please refer to the
'How to Ride the Motorcycle' section of
this owner's handbook.

Safety First
8
Parts and Accessories
Warning
Owners should be aware that the only
approved parts, accessories and
conversions for any Triumph motorcycle
are those which carry official Triumph
approval and are mounted on the
motorcycle by an authorized dealer.
In particular, it is extremely hazardous
to fit or replace parts or accessories
whose installation requires the
dismantling of, or addition to, either
the electrical or fuel systems and any
such modification could cause a safety
hazard.
The installation of any non-approved
parts, accessories or conversions may
adversely affect the handling, stability
or other aspect of the motorcycle
operation that may result in an
accident causing injury or death.
Triumph does not accept any liability
whatsoever for defects caused by the
installation of non-approved parts,
accessories or conversions or the fitting
of any approved parts, accessories or
conversions by non-approved personnel.
Maintenance/Equipment
Warning
Consult your authorized Triumph dealer
whenever there is doubt as to the
correct or safe operation of this
Triumph motorcycle.
Remember that continued operation of
an incorrectly performing motorcycle
may aggravate a fault and may also
compromise safety.
Warning
Ensure all equipment that is required
by law is installed and functioning
correctly. The removal or alteration of
the motorcycle’s lights, mufflers,
emission or noise control systems can
violate the law. Incorrect or improper
modification may adversely affect the
handling, stability or other aspect of
the motorcycle operation, which may
result in an accident causing injury or
death.
Warning
If the motorcycle is involved in an
accident, collision or fall, it must be
taken to an authorized Triumph dealer
for inspection and repair. Any accident
can cause damage to the motorcycle
that, if not correctly repaired, may
cause a second accident that may
result in injury or death.

Safety First
9
Riding
Warning
Never ride the motorcycle when
fatigued or under the influence of
alcohol or other drugs.
Riding when under the influence of
alcohol or other drugs is illegal.
Riding when fatigued or under the
influence of alcohol or other drugs
reduces the rider's ability to maintain
control of the motorcycle and may lead
to loss of control and an accident.
Warning
All riders must be licensed to operate
the motorcycle. Operation of the
motorcycle without a license is illegal
and could lead to prosecution.
Operation of the motorcycle without
formal training in the correct riding
techniques that are necessary to
become licensed is dangerous and may
lead to loss of motorcycle control and
an accident.
Warning
Always ride defensively and wear the
protective equipment mentioned else-
where in this foreword. Remember, in
an accident, a motorcycle does not give
the same impact protection as a car.
Warning
This Triumph motorcycle should be
operated within the legal speed limits
for the particular road traveled.
Operating a motorcycle at high speeds
can be potentially dangerous since the
time available to react to given traffic
situations is greatly reduced as road
speed increases. Always reduce speed
in potentially hazardous driving
conditions such as bad weather or
heavy traffic.
Warning
Continually observe and react to
changes in road surface, traffic and
wind conditions. All two-wheeled
vehicles are subject to external forces
which may cause an accident. These
forces include but are not limited to:
Wind draft from passing vehicles
Potholes, uneven or damaged road
surfaces
Bad weather
Rider error.
Always operate the motorcycle at
moderate speed and away from heavy
traffic until you have become
thoroughly familiar with its handling
and operating characteristics. Never
exceed the legal speed limit.

Safety First
10
Warning
Ensure that you know and respect the
rules of the road. Read and observe
publications such as ‘MOTORCYCLE
SAFETY’, ‘YOU AND YOUR MOTORCYCLE,
RIDING TIPS’ and also read and become
familiar with the contents of the
MOTORCYCLE HANDBOOK for your
state.
Caution
This Triumph motorcycle is not
equipped with spark arresters.
Operation in forests, brush or grass
areas may violate state and local laws
and regulations.
Wobble/Weave
A weave is a relatively slow oscillation of
the rear of the motorcycle, while a
wobble is a rapid, possibly strong
shaking of the handlebar. These are
related but distinct stability problems
usually caused by excessive weight in
the wrong place, or by a mechanical
problem such as worn or loose bearings
or under-inflated or unevenly worn tires.
Your solution to both situations is the
same. Keep a firm hold on the
handlebars without locking arms or
fighting the steering. Smoothly ease off
the throttle to slow gradually. Do not
apply the brakes, and do not accelerate
to try to stop the wobble or weave. In
some cases, it helps to shift your body
weight forward by leaning over the tank.
Copyright © 2005 Motorcycle Safety
Foundation. All rights reserved. Used
with permission.
Handlebars and Footrests
Warning
The rider must maintain control of the
vehicle by keeping hands on the
handlebars at all times.
The handling and stability of a
motorcycle will be adversely affected if
the rider removes their hands from the
handlebars, resulting in loss of
motorcycle control and an accident.
Warning
The rider must always use the
footrests provided, during operation of
the vehicle.
By using the footrests, the rider will
reduce the risk of inadvertent contact
with any motorcycle components and
will also reduce the risk of injury from
entrapment of clothing.
Warning
Use of a motorcycle with bank angle
indicators worn beyond the maximum
limit will allow the motorcycle to be
banked to an unsafe angle. Therefore,
always replace the bank angle
indicator pegs before they are worn to
their maximum limit. Banking to an
unsafe angle may cause instability, loss
of motorcycle control and an accident.
Details of the bank angle wear limits
can be found in the Maintenance and
Adjustment section on page 91.

Safety First
11
Warning
The bank angle indicators must not be
used as a guide to how far the
motorcycle may be safely banked. This
depends on many various conditions
including, but not limited to, road
surface, tire condition and weather.
Banking to an unsafe angle may cause
instability, loss of motorcycle control
and an accident.
Warning
When banking and the bank angle
indicator, attached to the rider's
footrest, makes contact with the ground,
the motorcycle is nearing its bank angle
limit. A further increase of the banking
angle is unsafe. Banking to an unsafe
angle may cause instability, loss of
motorcycle control and an accident.
cjva
1
1. Bank angle indicator

Warning Labels
12
WARNING LABELS
Warning Label Locations
The labels detailed on this and the following pages draw your attention to important
safety information in this handbook. Before riding, make sure that all riders have
understood and complied with all the information to which these labels relate.
R.P.M.
123
4
DAILY SAFETY CHECKS
TÄGLICHE SICHERHEITSKONTROLLEN
CONTROLES DE SECURITE QUOTIDIENS
CHEQUEOS DE SEGURIDAD DIARIOS
VERIFICAÇÕES DIÁRIAS DE SEGURANÇA
VERIFICHE GIORNALIERE DI SICUREZZA
DAGELIJSKE VEILIGHEIDSINSPECTIES
DAGLIG SÄKERHETSKONTROLL
運
行
前点検
1. Headlight (page 101)
2. Running-In (page 46)
3. Unleaded Fuel (page 40)
4. Daily Safety Checks (page 47)

Warning Labels
13
Warning Label Locations (continued)
Caution
All warning labels and decals, with the exception of the Running-in label, are
mounted on the motorcycle using a strong adhesive. In some cases, labels are
installed prior to an application of paint lacquer. Therefore, any attempt to remove
the warning labels will cause damage to the paintwork or bodywork.
12
3
45
1. Helmet (page 7)
2. Mirrors (page 86)
3. Drive Chain (page 78) and Tires (page 91)
4. Engine Oil (page 69)
5. Coolant (page 73)

Parts Identification
14
PARTS IDENTIFICATION
1
2
3 5
6
7
8
91011
1213
14
15
16
17
4
18
1. Front turn signal
2. Headlight
3. Clutch lever
4. Fuel tank filler cap
5. Fuel tank
6. Brake/tail light
7. Rear turn signal
8. Rear brake disc
9. Rear brake caliper
10. Fuse box (behind side panel)
11. Adjustment tool and inspection cap
tool (behind side panel)
12. Battery (behind cover panel)
13. Side stand
14. Gear shift pedal
15. Horn
16. Radiator
17. Front brake caliper
18. Front brake disc

Parts Identification
15
Parts Identification - Continued
6
7
85
12
910
3
11
4
12
13
1. Ignition switch
2. Front brake fluid reservoir
3. Front brake lever
4. Steering lock
5. Oil filler plug
6. Rear brake pedal
7. Oil level sight glass
8. Rear brake fluid reservoir (behind cap)
9. Coolant expansion tank cap (behind
sprocket cover)
10. Final drive chain tensioner
11. Rear suspension unit
12. Muffler
13. Final drive chain

Parts Identification
16
Parts Identification
13
456
78
91 012
2
13 11
1. Clutch lever
2. Headlight dimmer switch
3. SCROLL button
4. Speedometer
5. Warning lights
6. Odometer/Information display screen
7. Front brake fluid reservoir
8. Front brake lever
9. Engine start/stop switch
10. MODE button
11. Hazard switch
12. Turn signal switch
13. Horn button

Serial Numbers
17
SERIAL NUMBERS
Vehicle Identification Number (VIN)
The vehicle identification number is
stamped into the steering head area of
the frame. In addition, it is displayed on
a label which is mounted on the steering
head.
cjwa_b
1
1. VIN number
Record the vehicle identification number
in the space provided below.
Engine Serial Number
The engine serial number is stamped on
the upper engine crankcase, towards
the rear, and is visible from the right
hand side.
cjvw_a
1
1. Engine serial number
Record the engine serial number in the
space provided below.

General Information
18
GENERAL INFORMATION
Table of Contents
Instrument Panel Layout 20
Instrument Panel Adjustment 21
Warning Lights 22
Engine Management System Malfunction Indicator Light (MIL) 22
Low Oil Pressure Warning Light 22
High Coolant Temperature Warning Light 23
Immobilizer Indicator Light 23
ABS (Anti-Lock Brake System) Warning Light 23
Traction Control (TC) Indicator Light 23
Traction Control (TC) Disabled Warning Light 24
Low Fuel Indicator Light 24
Neutral 24
Turn Signals 24
Daytime Running Lights (DRL) (if equipped) 25
Cruise Control Indicator Light (if equipped) 25
Instruments 25
Speedometer and Odometer 25
Tachometer 25
Gear Position Display 26
Average Fuel Consumption 26
Fuel Gauge 26
Range to Empty 27
Trip Meter 27
Clock 28
Service Interval 29
Riding Modes 29
Selecting a Riding Mode – with the Motorcycle Stationary 30
Selecting a Riding Mode – when Riding the Motorcycle 30
Traction Control (TC) 32
Traction Control Settings 32
To Disable the Traction Control 33
Ignition Switch 33
Ignition Key 34
Steering Lock 35
Right Handlebar Switches 36
STOP Position 36

General Information
19
RUN Position 36
START Position 36
MODE Button 37
Hazard Warning Lights 37
Left Handlebar Switches 37
SCROLL Button 37
Horn Button 38
Turn Signal Switch 38
High Beam Button 38
Throttle Control 38
Brake and Clutch Lever Adjusters 39
Fuel Requirement/Refueling 40
Fuel Tank Cap 42
Filling the Fuel Tank 42
Side Stand 43
Side Panels 44
Tool Kit 45
Seat Adjustment 45
Running-In 46
Daily Safety Checks 47

General Information
20
Instrument Panel Layout
cjux
19 18 17 16 15
11
10
9
8
7
5
4
3
1
12
14 13
6
2
20
21
22
1. Speedometer
2. Cruise control indicator light (if equipped)
3. Traction Control (TC) disabled warning
light
4. Daytime Running Lights (DRL) indicator
light (if equipped)
5. Traction Control (TC) indicator light
6. Low fuel level indicator light
7. High coolant temperature warning light
8. Low oil pressure warning light
9. Engine management Malfunction
Indicator Light (MIL)
10. ABS (Anti-Lock Brake System) warning
light
11. Immobilizer status indicator light
12. Right hand direction indicator light
13. Neutral indicator light
14. Information display screen
15. Service interval indicator
16. Rider modes
17. Odometer/Trip meter/Clock
18. Gear position indicator
19. Fuel gauge
20. Cruise control indicator (if equipped)
21. High beam indicator light
22. Left hand turn signal light
