Triumph XRX User guide

Owner’s Handbook
Tiger XRXand Tiger XCX
1
This handbook contains information on the Triumph Tiger XRXand Tiger XCX
motorcycles. Always store this Owner's Handbook with the motorcycle and refer to it
for information whenever necessary.
The information contained in this publication is based on the latest information
available at the time of printing. Triumph reserves the right to make changes at any
time without prior notice, or obligation.
Not to be reproduced wholly or in part without the written permission of
Triumph Motorcycle s L i m i t e d.
© Copyright 09.2014 Triumph Motorcycles Limited, Hinckley, Leicestershire, England.
Publication part number 3855459-EN issue 1.
cinl

2
Table of Contents
This handbook contains a number of different sections. The table of contents below
will help you find the beginning of each section where, in the case of the major
sections, a further table of contents will help you find the specific subject required.
Foreword . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Foreword – Safety First. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Warning Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Parts Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Serial Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
How to Ride the Motorcycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Accessories, Loading and Passengers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Maintenance and Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .157
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

Foreword
3
FOREWORD
Owner's Handbook
Thank you for choosing a Triumph
motorcycle. This motorcycle is the
product of Triumph's use of proven
engineering, exhaustive testing, and
continuous striving for superior
reliability, safety and performance.
Please read this Owner's Handbook
before riding in order to become
thoroughly familiar with the correct
operation of your motorcycle's controls,
its features, capabilities and limitations.
This handbook includes safe riding tips,
but does not contain all the techniques
and skills necessary to ride a motorcycle
safely.
Triumph strongly recommends that all
riders undertake the necessary training
to ensure safe operation of this
motorcycle.
An electronic version of this Owner's
Handbook is available to download on
the internet at www.triumph.co.uk.
This handbook is also available from your
local dealer in:
•Brazilian
•Dutch
•French
•German
• Italian
• Japanese
•Spanish
•Swedish.
Talk to Triumph
Our relationship with you does not end
with the purchase of your Triumph. Your
feedback on the buying and ownership
experience is very important in helping
us develop our products and services for
you. Please help us by ensuring your
dealership has your email address and
registers this with us. You will then
receive an online customer satisfaction
survey invitation to your email address
where you can give us this feedback.
You r Tr i u m p h Te a m .
Warning
This Owner's Handbook, and all other
instructions that are supplied with
your motorcycle, should be considered
a permanent part of your motorcycle
and should remain with it even if your
motorcycle is subsequently sold.
All riders must read this Owner's
Handbook and all other instructions
which are supplied with your
motorcycle, before riding, in order to
become thoroughly familiar with the
correct operation of your motorcycle's
controls, its features, capabilities and
limitations. Do not lend your
motorcycle to others as riding when
not familiar with your motorcycle's
controls, features, capabilities and
limitations can lead to an accident.

Foreword
4
Warnings, Cautions and
Notes
Throughout this Owner's Handbook
particularly important information is
presented in the following form:
Note:
•Thisnotesymbolindicates points of
particular interest for more efficient
and convenient operation.
Warning Labels
At certain areas of the
motorcycle, the symbol
(left) can be seen. The
symbol means 'CAUTION:
REFER TO THE HANDBOOK'
and will be followed by a
pictorial representation of
the subject concerned.
Never attempt to ride the motorcycle or
make any adjustments without
reference to the relevant instructions
contained in this handbook.
See page 12 for the location of all labels
bearing this symbol. Where necessary,
this symbol will also appear on the pages
containing the relevant information.
Maintenance
To ensure a long, safe and trouble-free
life for your motorcycle, maintenance
should only be carried out by an
authorised Triumph dealer. Only an
authorised Triumph dealer will have the
necessary knowledge, equipment and
skills to maintain your Triumph
motorcycle correctly.
To locate your nearest Triumph dealer,
visit the Triumph web site at
www.triumph.co.uk or telephone the
authorised distributor in your country.
Their address is given in the service
record book that accompanies this
handbook.
Warning
This warning symbol identifies special
instructions or procedures, which if
not correctly followed could result in
personal injury, or loss of life.
Caution
This caution symbol identifies special
instructions or procedures, which, if
not strictly observed, could result in
damage to, or destruction of,
equipment.

Foreword
5
Off-road Use
The Tiger XRXand Tiger XCXare
designed for on-road and light off-road
use. Light off-road use includes use on
unpaved, dirt or gravel roads, but does
not include riding on any motocross
course, any off-road competition (such
as motocross or enduro riding), or riding
off-road with a passenger.
Light off-road use does not include
jumping the motorcycle or riding over
obstacles. Do not attempt to jump over
any bumps or obstacles. Do not attempt
to ride over any obstacles.
Noise Control System
Tampering with the Noise Control
System is prohibited.
Owners are warned that the law may
prohibit:
• The removal or rendering
inoperative by any person other
than for purposes of maintenance,
repair or replacement, of any device
or element of design incorporated
into any new vehicle for the purpose
of noise control prior to its sale or
delivery to the ultimate purchaser or
while it is in use and,
• the use of the vehicle after such
device or element of design has been
removed or rendered inoperative by
any person.
Immobiliser and Tyre
Pressure Monitoring System
This device complies with part 15 of the
FCC Rules.
Operation is subject to the following two
conditions:
• This device may not cause harmful
interference
• This device must accept any
interference received, including
interference that may cause
undesired operation.
Changes or modifications to the device
could void the user's authority to
operate the equipment.
Tyres
With reference to the Pneumatic Tyres
and Tubes for Automotive Vehicles
(Quality Control) Order, 2009, Cl. No. 3 (c),
it is declared by M/s. Triumph
Motorcycles Ltd. that the tyres fitted on
this motorcycle meet the requirements
of IS 15627: 2005 and comply with the
requirements under Central Motor
Vehicle Rules (CMVR), 1989.

Foreword – Safety First
6
FOREWORD – SAFETY FIRST
The Motorcycle
Warning
The Tiger XRXand Tiger XCXare
designed for on-road and light off-
road use. Light off-road use includes
use on unpaved, dirt or gravel roads,
but does not include riding on any
motocross course, any off-road
competition (such as motocross or
enduro riding), or riding off-road with
a passenger.
Light off-road use does not include
jumping the motorcycle or riding over
obstacles. Do not attempt to jump
over any bumps or obstacles. Do not
attempt to ride over any obstacles.
Extreme off-road use could lead to
loss of motorcycle control and an
accident.
Warning
This motorcycle is not designed to tow
a trailer or be fitted with a sidecar.
Fitting a sidecar and/or a trailer may
result in loss of control and an
accident.
Warning
This motorcycle is designed for use as
a two-wheeled vehicle capable of
carrying a rider on his/her own, or a
rider and one passenger.
The total weight of the rider, and any
passenger, accessories and luggage
must not exceed the maximum load
limit of:
Tiger XRX– 219 kg (483 lb)
Tiger XCX– 217 kg (478 lb).
Warning
This motorcycle is fitted with a
catalytic converter below the engine,
which along with the exhaust system
reaches very high temperature during
engine operation. Flammable materials
such as grass, hay/straw, leaves,
clothing and luggage etc. could ignite
if allowed to come into contact with
any part of the exhaust system and
catalytic converter; always ensure
flammable materials are not allowed to
contact the exhaust system or
catalytic converter.

Foreword – Safety First
7
Fuel and Exhaust Fumes Helmet and Clothing
Warning
PETROL IS HIGHLY FLAMMABLE:
Always turn off the engine when
refuelling.
Do not refuel or open the fuel filler cap
while smoking or in the vicinity of any
open (naked) flame.
Take care not to spill any petrol on the
engine, exhaust pipes or silencers
when refuelling.
If petrol is swallowed, inhaled or
allowed to get into the eyes, seek
immediate medical attention.
Spillage on the skin should be
immediately washed off with soap and
water and clothing contaminated with
petrol should immediately be removed.
Burns and other serious skin
conditions may result from contact
with petrol.
Warning
Never start your engine or let it run
for any length of time in a closed area.
The exhaust fumes are poisonous and
may cause loss of consciousness and
death within a short time. Always
operate your motorcycle in the open-
air or in an area with adequate
ventilation.
Warning
When riding the motorcycle, both rider
and passenger must always wear a
motorcycle helmet, boots, eye
protection, gloves, trousers (close
fitting around the knee and ankle) and
a brightly coloured jacket. Brightly
coloured clothing will considerably
increase a rider's (or passenger's)
visibility to other operators of road
vehicles. Although full protection is
not possible, wearing correct
protective clothing can reduce the risk
of injury when riding.
Warning
A helmet is one of the most important
pieces of riding gear as it offers
protection against head injuries. You
and your passenger's helmet should
be carefully chosen and should fit you
or your passenger's head comfortably
and securely. A brightly coloured
helmet will increase a rider's (or
passenger's) visibility to other
operators of road vehicles.
An open face helmet offers some
protection in an accident though a full
face helmet will offer more.
Always wear a visor or approved
goggles to help vision and to protect
your eyes.
cbma

Foreword – Safety First
8
Riding
Warning
Never ride the motorcycle when
fatigued or under the influence of
alcohol or other drugs.
Riding when under the influence of
alcohol or other drugs is illegal.
Riding when fatigued or under the
influence of alcohol or other drugs
reduces the rider's ability to maintain
control of motorcycle and may lead to
loss of control and an accident.
Warning
All riders must be licenced to operate
the motorcycle. Operation of the
motorcycle without a licence is illegal
and could lead to prosecution.
Operation of the motorcycle without
formal training in the correct riding
techniques that are necessary to
become licenced is dangerous and
may lead to loss of motorcycle control
and an accident.
Warning
Always ride defensively and wear the
protective equipment mentioned
elsewhere in this foreword. Remember,
in an accident, a motorcycle does not
give the same impact protection as a
car.
Warning
This Triumph motorcycle should be
operated within the legal speed limits
for the particular road travelled.
Operating a motorcycle at high speeds
can be potentially dangerous since the
time available to react to given traffic
situations is greatly reduced as road
speed increases. Always reduce speed
in potentially hazardous driving
conditions such as bad weather or
heavy traffic.
Warning
Continually observe and react to
changes in road surface, traffic and
wind conditions. All two-wheeled
vehicles are subject to external forces
which may cause an accident. These
forces include but are not limited to:
• Wind draft from passing vehicles
• Potholes, uneven or damaged road
surfaces
•Badweather
• Rider error.
Always operate the motorcycle at
moderate speed and away from heavy
traffic until you have become
thoroughly familiar with its handling
and operating characteristics. Never
exceed the legal speed limit.

Foreword – Safety First
9
Handlebars and Footrests
Warning
The rider must maintain control of the
vehicle by keeping hands on the
handlebars at all times.
The handling and stability of a
motorcycle will be adversely affected if
the rider removes his hands from the
handlebars, resulting in loss of
motorcycle control and an accident.
Warning
The rider and passenger must always
use the footrests provided, during
operation of the vehicle.
By using the footrests, both rider and
passenger will reduce the risk of
inadvertent contact with any
motorcycle components and will also
reduce the risk of injury from
entrapment of clothing.
Warning
The bank angle indicators must not be
used as a guide to how far the
motorcycle may be safely banked. This
depends on many various conditions
including, but not limited to, road
surface, tyre condition and weather.
Banking to an unsafe angle may cause
instability, loss of motorcycle control
and an accident.
Warning
Use of a motorcycle with the bank
angle indicators worn beyond the
maximum limit will allow the
motorcycle to be banked to an unsafe
angle.
The bank angle indicators have
reached the maximum wear limit and
should be replaced when they have
worn down to a length of 20 mm.
Banking to an unsafe angle may cause
instability, loss of motorcycle control
and an accident.

Foreword – Safety First
10
Parking
Warning
When banking and the bank angle
indicator, attached to the rider's
footrest, makes contact with the
ground, the motorcycle is nearing its
bank angle limit. A further increase of
the banking angle is unsafe.
Banking to an unsafe angle may cause
instability, loss of motorcycle control
and an accident.
1. Bank angle indicator
1
Warning
Always turn off the engine and
remove the ignition key before leaving
the motorcycle unattended. By
removing the key, the risk of use of
the motorcycle by unauthorised or
untrained persons is reduced.
When parking the motorcycle, always
remember the following:
Engage first gear to help prevent the
motorcycle from rolling off the stand.
The engine and exhaust system will be
hot after riding. DO NOT park where
pedestrians, animals and/or children
are likely to touch the motorcycle.
Do not park on soft ground or on a
steeply inclined surface. Parking
under these conditions may cause the
motorcycle to fall over.
For further details, please refer to the
How to Ride the Motorcycle section of
this Owner's Handbook.

Foreword – Safety First
11
Parts and Accessories
Triumph does not accept any liability
whatsoever for defects caused by the
fitting of non-approved parts,
accessories or conversions or the fitting
of any approved parts, accessories or
conversions by non-approved personnel.
Maintenance/Equipment
Warning
Owners should be aware that the only
approved parts, accessories and
conversions for any Triumph
motorcycle are those which carry
official Triumph approval and are fitted
to the motorcycle by an authorised
dealer.
In particular, it is extremely hazardous
to fit or replace parts or accessories
whose fitting requires the dismantling
of, or addition to, either the electrical
or fuel systems and any such
modification could cause a safety
hazard.
The fitting of non-approved parts,
accessories or conversions may
adversely affect the handling, stability
or other aspects of the motorcycle
operation which may result in loss of
motorcycle control and an accident.
Warning
Consult your authorised Triumph
dealer whenever there is doubt as to
the correct or safe operation of this
Triumph motorcycle.
Remember that continued operation
of an incorrectly performing
motorcycle may aggravate a fault and
may also compromise safety.
Warning
Ensure all equipment that is required
by law is installed and functioning
correctly. The removal or alteration of
the motorcycle's lights, silencers,
emission or noise control systems can
violate the law. Incorrect or improper
modification may adversely affect the
handling, stability or other aspect of
the motorcycle operation, which may
result in loss of motorcycle control
and an accident.
Warning
If the motorcycle is involved in an
accident, collision or fall, it must be
taken to an authorised Triumph dealer
for inspection and repair. Any accident
can cause damage to the motorcycle
that, if not correctly repaired, may
cause a second accident.

12
Warning Labels
WARNING LABELS
The labels detailed on this and the following pages draw your attention to important
safety information in this handbook. Before riding, ensure that all riders have
understood and complied with all the information to which these labels relate.
Warning Label Locations
cinf_4
6
5
4
3
2
N
1
R.P.M.
Headlights
(page 147)
Windscreen
(page 153)
Running-In
(page 88)
Tyres
(page 136)
Drive Chain
(page 121)
Gear
Position
(page 94)

13
Warning Labels
Warning Label Locations (continued)
Caution
All warning labels and decals, with the exception of the Running-in label, are fitted
to the motorcycle using a strong adhesive. In some cases, labels are installed prior
to an application of paint lacquer. Therefore, any attempt to remove the warning
labels will cause damage to the paintwork or bodywork.
cine_5
Daily Safety Checks
(page 89)
Helmet
(page 7)
Unleaded Fuel
(page 70)
Engine Oil
(page 114)Coolant
(page 117)
TPMS
(if fitted)
(page 67)

Parts Identification
14
PARTS IDENTIFICATION
Tiger XRX
1. Headlight
2. Front direction indicator
3. Electrical accessory socket
4. Fuel tank and fuel filler cap
5. Battery and fuse boxes
6. Tool kit/Accessory U-lock storage
location
7. S e a t l o c k
8. Rear wheel adjuster
9. Electrical auxiliary socket
10. Drive chain
11. Centre stand
12. Side stand
13. Gear change pedal
14. Front brake caliper
15. Front brake disc
cinf_5
2 3 4 5 6 7
14 13 12 10 8
15
1
9
11

Parts Identification
15
PARTS IDENTIFICATION
Tiger XRX(continued)
16. Rear light
17. Rear brake fluid reservoir
18. Oil filler cap
19. Mirror
20. Headlight adjuster
21. Windscreen
22. Coolant expansion tank
23. Front fork
24. Radiator/Coolant pressure cap
25. Clutch cable
26. Engine oil level sight glass
27. Rear brake pedal
28. Rear suspension spring preload
adjuster
29. Rear brake caliper
30. Rear brake disc
31. Rear direction indicator
17 18 19 20 21 22
28 27 26 25 2430 29
16
23
31

Parts Identification
16
Tiger XCX
1. Headlight
2. Front direction indicator
3. Electrical accessory socket
4. Fuel tank and fuel filler cap
5. Battery and fuse boxes
6. Tool kit/Accessory U-lock storage
location
7. S e a t l o c k
8. Rear wheel adjuster
9. Electrical auxiliary socket
10. Drive chain
11. Centre stand
12. Side stand
13. Gear change pedal
14. Front brake caliper
15. Front brake disc
2 3 4 5 6 7
14 13 12 9 815
1
10
11

Parts Identification
17
Tiger XCX(continued)
16. Rear light
17. Rear brake fluid reservoir
18. Oil filler cap
19. Handguards
20. Mirror
21. Headlight adjuster
22. Windscreen
23. Coolant expansion tank
24. Front fork
25. Radiator/Coolant pressure cap
26. Clutch cable
27. Engine oil level sight glass
28. Rear brake pedal
29. Rear suspension rebound damping
adjuster
30. Rear suspension preload adjuster
31. Rear brake caliper
32. Rear brake disc
33. Rear direction indicator
17 18 20 21 22 23
29 28 27 26 2531 30
16
24
19
32
33

Parts Identification
18
All Models (Tiger XCXshown)
1. Clutch lever
2. Headlight dip switch
3. Passing button
4. Instrument SCROLL button
5. Heated grip switch (if fitted)
6. Hazard warning light button
7. MODE button
8. Trip computer display
9. Speedometer
10. Tachometer
11. Front brake fluid reservoir
12. Engine stop switch
13. Cruise control adjust button
14. Front brake lever
15. Starter button
16. Cruise control ON/OFF button
17. Ignition switch
18. Electrical accessory socket
19. Instrument SET button
20. Horn button
21. Direction indicator switch
TC
TC
cink
12 3 4 5
678
9
10
11 12 13 14
15
16
1718
19
20
21

Serial Numbers
19
SERIAL NUMBERS
Vehicle Identification Number
(VIN)
1. VIN number
The Vehicle Identification Number (VIN) is
stamped into the steering head area of
the frame. It is also displayed on a plate,
riveted to the frame, below the pillion
seat.
Record the vehicle identification number
in the space provided below.
Engine Serial Number
1. Engine serial number
The engine serial number is stamped on
the engine crankcase, immediately above
the clutch cover.
Record the engine serial number in the
space provided below.
1
cgiv
1
cgjf

Serial Numbers
20
This page intentionally left blank
