Trivum TouchPad 4.3 User manual

trivum technologies GmbH
Eierstraße 48
70199 Stuttgart
[email protected]
www.trivum.com
www.facebook.com/trivumtechnologies
Further documentation and troubleshooting
To nd helpful log les in support cases:
– Open the Music Center WebCong.
– Click Logs & Warnings.
Please visit also our website for the latest documentation,
videos and information:
http://www.trivum.com
http://service.trivum.com
If support is needed
Please contact your local trivum dealer or write to:
[email protected]
Download links:
trivum ServerAdmin Tool (Windows):
http://service.trivum.com/win-admintool
How to update your trivum v8 to v9?
http://service.trivum.com/v9-update
v2_201603 - Errors and specications subject to change
without notice.
Quick Installation Guide for
TouchPad 4.3“
1. Unpacking
2. Mounting
3. MusicCenter binding
– Wait a few seconds until the TouchPad has booted
– On the starting screen press Pair TouchPad with
Audio System
– Press Select... and select your preferred trivum
MusicCenter from the pop-up menu
iNote: The TouchPad 4.3”necessarily require the
current multiroom software v9!
Please make sure your trivum multiroom system is
running v9.
How to update: http://service.trivum.com/v9-update
Connector TouchPad side
CAT5
POE
1
2
2
wall box 4.3“
TouchPad
magnet
v9
Requires:
1
23 45 67 8

Quick Installation Guide for TouchPad 4.3“
Required components for installation:
– Cat5 cable
– wall box 4.3“ (dimensions 104x82x62mm)
– PoE Switch
To use the TouchPad in connection with trivum
Multiroom Audio System:
– trivum device(s) (e.g. RP, FLEX, AudioBox, ...)
– network DHCP capable router
– music archive (network share, NAS)
Optional components:
– internet connection (required for software updates and
remote support)
– KNX/IP-Router (required for using the TouchPad as
a KNX room controller)
1. Mounting the TouchPad 4.3“
1.1 Mount the wall box 4.3“.
1.2 Adjust the screws in the wall box to set a proper
distance between the TouchPad and the wall.
1.3 Check that the magnets are attached to the TouchPad.
1.4 Connect the Cat5 cable (see illustration
„Connector TouchPad side“ on the backside) and plug in.
1.5 Insert the TouchPad in the wall box.
2. Linking the TouchPad to a trivum device
To link the TouchPad to your trivum device :
2.1 Wait a few seconds until the TouchPad has booted.
2.2 On the starting screen press
Pair TouchPad with Audio System.
2.3 Press Select... and select your preferred trivum
MusicCenter from the pop-up menu.
3. Conguring the TouchPad
The trivum TouchPad has to be congured via web browser.
To identify the TouchPads IP please go on the TouchPad:
3.1 Press on the right upper corner trivum.
3.2 Press settings -> Touchpad settings -> Info.
3.3 Open your web browser and type in the IP to open the
trivum TouchPad Setup
4. Use your TouchPad as music and
KNX room controller
As default the TouchPad is congured as trivum audio
controller without any need for KNX.
If you want to integrate the TouchPad in your KNX
installation, you can add simply embedded web objects
(e.g. weather forecast, webcams, ...) or KNX object like
dimmer, switches, shutters etc via the trivum TouchPad
Setup Tool. The KNX programming of the TouchPad is done
via the web browser. No need for extra KNX software.
4.1 Open the trivum TouchPad WebCong.
4.2 Click KNX Settings.
4.3 Enable Use KNX/IP.
4.4 Go back to the TouchPad WebCong main page.
4.5 Click Page Editor.
4.6 Move the mouse over the square where you want to
place your button and click the“plus-button”
4.7 Choose your preferred APPS or KNX BUTTONS
Enter the specic settings for this app or the KNX
group addresses for this KNX button
You nd further informations for KNX on:
http://service.trivum.com/knx
lTip: Tap on the date to quickly switch between the
music view and the KNX view.
lTip: You can set the default mode of the TouchPad
(audio controller / KNX room controller)
– Open the trivum TouchPad Setup Tool.
– Click Basic Setup.
– Enable the checkbox TouchPad mode.
Backup your conguration
Once you have completed the setup, we recommend you
to make a backup of your conguration:
– Open the TouchPad WebCong.
– Click Backup/Restore -> Export/import conguration.
– Follow the instructions.
