AXIOMTEK GOT715S-RA-M User manual

GOT715S-RA-M
Railway 15”XGA TFT LCD
PANEL PC
User’s Manual

ii
Disclaimers
This manual has been carefully checked and is believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any
form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without
the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery, and dispose of used ones.
©Copyright 2022 Axiomtek Co., Ltd.
All Rights Reserved
April 2022, Version A1
Printed in Taiwan

iii
Safety Precautions
Before getting started, read the following important cautions.
1. Be sure to ground yourself to prevent static charge when installing the internal
components. Use a grounding wrist strap and place all electronic components in any
static-shielded devices. Most electronic components are sensitive to static electrical
charge.
2. Disconnect the power cords from the GOT715S Series before making any installation. Be
sure both the system and the external devices are turned OFF. Sudden surge of power
could ruin sensitive components. Make sure the GOT715S Series is properly grounded.
3. Do not open the system’s top cover. If opening the cover for maintenance is a must, only
a trained technician is allowed to do so. Integrated circuits on computer boards are
sensitive to static electricity. To avoid damaging chips from electrostatic discharge,
observe the following precautions:
◼Before handling a board or integrated circuit, touch an unpainted portion of the
system unit chassis for a few seconds. This will help to discharge any static electricity
on your body.
◼When handling boards and components, wear a wrist-grounding strap, available
from most electronic component stores.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Windows®is a trademark of Microsoft Corporation.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Intel®and Pentium®are trademarks of Intel Corporation.
AMI is trademark of American Megatrend Inc.
Other brand names and trademarks are the properties and registered brands of their respective
owners.

iv
Table of Contents
Disclaimers.....................................................................................................ii
Safety Precautions........................................................................................iii
Section 1 Introduction............................................. 1
1.1 General Description ............................................................................1
1.2 Specifications......................................................................................2
1.3 Dimensions and Outlines ...................................................................4
1.4 I/O Outlets ............................................................................................5
1.5 Packing List .........................................................................................6
Section 2 Hardware and Installation ...................... 7
2.1 Open back cover .................................................................................8
2.2 Serial Ports Interface ..........................................................................8
2.3 USB Ports ............................................................................................9
2.4 Ethernet................................................................................................9
2.5 DIO......................................................................................................10
2.5.1 Digital I/O Specification ............................................................................. 10
2.5.2 Digital I/O Software Programming..............................................................11
2.5.3 Digital Input Wiring .................................................................................... 12
2.5.4 Digital Output Wiring ................................................................................. 13
2.6 Audio..................................................................................................13
2.7 CANBUS connector...........................................................................14
2.8 DC Power connector .........................................................................14
2.9 Mini card Installation.........................................................................15
2.9.1 Wireless LAN Card Installation ................................................................. 15
2.9.2 mSATA Card Installation............................................................................ 16
2.10 LED indicators...................................................................................17
2.11 Auto-dimming....................................................................................17
Section 3 AMI BIOS Setup Utility.......................... 19
3.1 Starting...............................................................................................19
3.2 Menu Bar............................................................................................20
3.3 Navigation Keys ................................................................................20
3.4 Main Menu..........................................................................................21
3.5 Advanced Menu.................................................................................22

v
3.6 Chipset Menu.....................................................................................30
3.7 Security Menu....................................................................................33
3.8 Boot Menu..........................................................................................34
3.9 Exit Menu ...........................................................................................35

vi
This page is intentionally left blank.

GOT715S-RA-M User’s Manual
Introduction 1
Section 1
Introduction
This chapter contains general information and detailed specifications of the GOT715S-RA-M.
Chapter 1 includes the following sections:
⚫General Description
⚫Specification
⚫Dimensions
⚫I/O Outlets
⚫Package List
1.1 General Description
GOT715S-RA-M is utilized to keep the train driver informed about the status of the train’s
status. Its design allows it to be deployed in environment with an extended temperature
(-25°C~70°C) and it also complies with the EMC, shock and vibration test requirements of
European standard EN 50155 for railway applications. GOT715S-RA-M is equipped with 15"
TFT ruggedized touch panel computer and all lockable connectors are perfect choice for
Human Machine Interface (HMI) in railway environments. The 15" railway touch panel PC
includes a comprehensive feature set with one CAN Bus, DIO, audio, two Ethernet ports,
USB ports and RS-232/422/485.
Railway application-EN 50155 certificated
The Railway power module design supports 20ms interruption, EMI EN 55022 CLASS A filter,
and over/short current protection.
Sunlight readable design
Its sunlight readable technology with LED tech high brightness 800 nits color display
allows the screen legible even under strong sunlight.
Powerful computing: Intel® Atom Bay Trail processor
GOT715S-RA-M features an Intel® Atom processor that offers reliable and stable performance
in harsh environment.

GOT715S-RA-M User’s Manual
2Introduction
1.2 Specifications
Main CPU Board
⚫CPU
◼Intel® AtomTM E3845 1.91GHz processor onboard
⚫System Memory
◼DDR3L 4 GB onboard
⚫BIOS
◼America Megatrends Inc BIOS
I/O System
⚫Standard I/O
◼2 x RS-232/422/485 with isolated 1.5KV (M12, A-coded)
◼2 x Gigabit LAN with isolated 1.5KV (M12, X-coded)
◼2 x USB 2.0 (M12, A-coded)
◼1 x DIO (6 input/2 output) with isolated 1.5KV (Phoenix type)
◼1 x CAN Bus with isolated 1.5KV (D-sub)
⚫Audio
◼1 x Audio: Line-in, & Mic-in, Speaker-out or Line-out (D-sub)
⚫Expansion
◼2 x PCIe Mini Card slots (slot 2 for mSATA use only)
⚫Storage
◼16 GB flash onboard
⚫Power connector
◼1 x DC for power input with isolated 1.5KV (M12, A-coded)

GOT715S-RA-M User’s Manual
Introduction 3
System Specification
⚫15”XGA (1024 X 768) LCD
⚫5-wire resistive Touch
⚫IP65 aluminum front bezel
⚫Net Weight
◼4.03 Kg
⚫Dimension (Main Body Size)
◼400(W)*300(H)*61.5(D)
⚫Operation Temperature
◼-25℃to 70℃
⚫Relative Humidity
◼10% to 95% @ 40℃, Non-Condensing
⚫Power Input
◼24V to 110VDC, 20ms interruption hold up (EN 50155 Class S3)
NOTE All specifications and images are subject to change without notice.

GOT715S-RA-M User’s Manual
4Introduction
1.3 Dimensions and Outlines
The following diagrams show the dimensions and outlines of GOT715S-RA-M.

GOT715S-RA-M User’s Manual
Introduction 5
1.4 I/O Outlets
Please refer to the following illustration for I/O locations of the GOT715S-RA-M.
No
Function
1
DC for power input with isolated 1.5KV
2
CAN Bus with isolated 1.5KV
3
Audio (Line out, Line in, speaker out)
4
DIO (6 input/2 output with isolated 1.5KV)
5
USB 2.0 x 2(M12, A-coded)
6
COM 2 (RS-232/422/485 with isolated 1.5KV)
7
COM 1 (RS-232/422/485 with isolated 1.5KV)
8
LAN 2 (Gigabit LAN with isolated 1.5KV)
9
LAN 1 (Gigabit LAN with isolated 1.5KV)
1 2 3 4 5 6 7 8 9

GOT715S-RA-M User’s Manual
6Introduction
1.5 Packing List
When you receive the GOT715S-RA-M, the bundled package should contain the following
items:
⚫GOT715S-RA-M unit x 1
⚫Phoenix Connector x 1
⚫Screw M2*3L x 2
If you cannot find the package or any items are missing, please contact Axiomtek distributors
immediately.

GOT715S-RA-M User’s Manual
Hardware and Installation 7
Section 2
Hardware and Installation
The GOT715S-RA-M provides rich I/O ports and flexible expansions for you to meet different
demand. The chapter will show you how to install the hardware. It includes:
⚫Open back cover
⚫Serial Ports
⚫USB Ports
⚫Ethernet
⚫DIO
⚫Audio
⚫CAN Bus
⚫DC Power
⚫Mini card
⚫LED Indicators
⚫Auto-dimming

GOT715S-RA-M User’s Manual
8Hardware and Installation
2.1 Open back cover
This section shows users how to open back cover. Please follow the steps below.
Step 1 Unscrew 14 screws on the back cover. Please refer the photo below.
2.2 Serial Ports Interface
This system supports RS-232/422/485 isolated 1.5KV on COM1~COM2 ports. The pin
assignments are listed in table below. If you need to adjust these COM ports to work as RS-
232/422/485, please refer to BIOS setting in section 3.5.
Pin
RS-232
RS-422
RS-485
1
NDCD
TX-
Data-
2
NRX
TX+
Data+
3
NTX
RX+
No use
4
NDTR
RX-
No use
5
NDSR
No use
No use
6
NRTS
No use
No use
7
NCTS
No use
No use
8
ISO1_GND
ISO1_GND
ISO1_GND

GOT715S-RA-M User’s Manual
Hardware and Installation 9
2.3 USB Ports
This system supports two USB ports. The pin assignments are listed in the table below.
2.4 Ethernet
The GOT715S-RA-M is equipped with two high performance plug and play Ethernet interfaces
with X-coded which are fully compliant with the IEEE 802.3 standard. Connection can be
established by plugging one end of the Ethernet cable into this RJ-45 connector and the other
end to a 1000/100/10-Base-T hub with isolated 1.5KV.
Pin
Definition
1
USB1_PWR
2
USB_DN1_C
3
USB_DP1_C
4
GND
5
USB2_PWR
6
USB_DN2_C
7
USB_DP2_C
8
GND
CN4_LAN1
CN4_LAN2
Pin
Definition
Pin
Definition
1
LAN1_MDOP0
1
LAN2_MDOP0
2
LAN1_MDON0
2
LAN2_MDON0
3
LAN1_MDOP1
3
LAN2_MDOP1
4
LAN1_MDON1
4
LAN2_MDON1
5
LAN1_MDOP3
5
LAN2_MDOP3
6
LAN1_MDON3
6
LAN2_MDON3
7
LAN1_MDON2
7
LAN2_MDON2
8
LAN1_MDOP2
8
LAN2_MDOP2
9
GND_LAN
9
GND_LAN

GOT715S-RA-M User’s Manual
10 Hardware and Installation
2.5 DIO
2.5.1 Digital I/O Specification
This system supports one DIO (6 input and 2 output) with isolated 1.5KV. The pin assignments
are listed in table below.
Digital Input:
Input channels: 6, sink/source type
Input voltage: 0 to 30VDC at 25Hz
Input level for dry contacts:
Logic level 0: close to ground
Logic level 1: open
Input level for wet contacts:
Logic level 1: +/-3VDC max.
Logic level 0: +/- 10VDC min. to +/-30VDC max. (source to digital input)
Digital output:
output channels: 2, sink type
output current: 200mA max. per channel
on-state voltage:12~ 24VDC nominal
max. voltage on COM+: 30VDC
Pin
Definition
1
Common PWR+
2
DI4
3
DI5
4
DO0
5
DO1
6
Common PWR-
7
EXT_POWER
8
DI0
9
DI1
10
DI2
11
DI3
12
Isolation GND

GOT715S-RA-M User’s Manual
Hardware and Installation 11
2.5.2 Digital I/O Software Programming
⚫I2C to GPIO PCA9554PW GPIO Group0[5:0] is Input, Group0[7:6] is Output.
⚫I2C address: 0b0100100x.
⚫Registers:
Register 0: Input Group0 register.
Register 2: Output Group0 register.

GOT715S-RA-M User’s Manual
12 Hardware and Installation
2.5.3 Digital Input Wiring
DRY contact
Logic level 0: close to ground Logic level 1: open
WET contact
Logic level 1: +/-3VDC max.
Logic level 0: +/- 10VDC min. to +/-30VDC max

GOT715S-RA-M User’s Manual
Hardware and Installation 13
2.5.4 Digital Output Wiring
2.6 Audio
This system supports one Audio (Line out, Line in, speaker out) with isolated 1.5KV. The pin
assignments are listed in table below.
Pin
Definition
1
SPEK_OUTA+
2
SPEK_OUTA-
3
AUDIO_GND
4
AUDIO_OUT_L
5
AUDIO_OUT_R
6
NA
7
FRONT-JD
8
AUDIO_GND
9
AUDIO_LIN_IN_L
10
AUDIO_LIN_IN_R
11
BUZZER+
12
BUZZER-
13
MIC-JD
14
MIC_IN
15
AUDIO_GND

GOT715S-RA-M User’s Manual
14 Hardware and Installation
2.7 CANBUS connector
This system supports one CAN Bus with isolated 1.5KV. The pin assignments are listed in table
below.
2.8 DC Power connector
The system supports one DC for power input with isolated 1.5KV. The pin assignments are
listed in table below.
Note 1：If the testing environment is not able to provide ACC, please shorten the V+ & ACC
signal pin of the cable.
Pin
Definition
1
NA
2
CAN_LO
3
ISO3_GND
4
NA
5
NA
6
ISO3_GND
7
CAN_HO
8
NA
9
NA
Pin
Definition
1
PWR_V+
2
PWR_V+
3
PWR_V-
4
PWR_V-
5
ACC
