Troy-Bilt 12AG836E011 Guide

Read and understand all instruction, warning, and danger labels.
IMPORTANT: READ OPERATOR'S MANUAL AND ENGINE MANUAL THOROUGHLY AND
FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING .
Need Help? Call 1-888-TO-HELP-U (1-888-864-3578)
Lea el manual de operación anexo sobre ensamblaje e inicio.
Secure cable to lower handle with
cable tie provided.
1
2
3
4
Refer to Operator’s Manual for instructions on attaching the grass catcher.
Insert carriage bolts and tighten with star knobs.
Repeat on opposite side.
12AG836E011
12AG836G211 778-11133A
© 2006
Starter
Rope
Blade Control Handle
Star Knobs
A
C
D
B
Hold blade control handle against upper handle.
Slowly slip starter rope into rope guide.
Tighten rope guide wing knob.
A
B
Lift handle to extended position.
Tighten star knobs.

Read and understand all instruction, warning, and danger labels.
IMPORTANT: READ OPERATOR'S MANUAL AND ENGINE MANUAL THOROUGHLY AND
FOLLOW THE SAFE OPERATION PRACTICES BEFORE OPERATING .
Need Help?
Call 1-888-TO-HELP-U
Lea el manual de operación anexo sobre ensamblaje e inicio.
Fill tank with gas to within 1/2 inch of
top of tank.
Fill engine with entire contents of oil bottle
supplied with your mower.
5
6
Gas Cap
Oil Fill
Need Help?
Call 1-888-TO-HELP-U
Depress blade control handle and hold.
8
7
Pull starter rope with quick, full arm stroke.
If engine does not start after ten seconds of
repeated pulls, wait a few minutes and repeat.
Electric start battery must be charged for 8-10 hours
before initial use. See Maintenance Section in Operator’s
Manual.
