Troy-Bilt 18AEB9C7766 Guide

Wing Knobs
778-13524© 2016 18XEB9C7
Note: Refer to your Operator’s Manual
for instructions on attaching the grass collector.
A. Pull out the handle adjustment levers to
release the handle adjustment pins from the
handle bracket.
Handle Bracket
Blade Control
Handle
Adjustment
Lever
C
B. Rotate the levers up
perpendicular to the handle.
A
A
B
B
C. Carefully lift the handle up.
Setting-Up Handle
A. Place the handle into one of the three handle height
positions, high (a), medium (b) or low (c), located on
the handle brackets
B. Turn the handle adjustment levers until they are
parallel with the handle to release the pins and lock
them into one of the handle height holes in the
handle brackets.
B
(c)
(b)
(a)
A
C
A
B
A. Turning counterclockwise, loosen wing
knob securing the left side upper and lower
handles together. Remove packaging with
wing knob and bolt securing the right side
upper and lower handles together.
B. Gently lift and
pivot the upper
handle forward.
C. Remove the wing knob and bolt from
packaging removed in STEP A. Insert bolt
through the right side upper and lower
handles. Turning clockwise, tighten the
wing knobs to secure the upper and lower
handles together.
12
3
READ AND UNDERSTAND ALL INSTRUCTION, WARNING, AND DANGER LABELS.
PARA INSTRUCCIONES EN ESPAÑOL, REFIÉRASE AL MANUAL DEL OPERADOR.
IMPORTANT: READ OPERATOR'S, BATTERY AND CHARGER MANUALS THOROUGHLY
AND FOLLOW THE IMPORTANT SAFE OPERATION PRACTICES BEFORE OPERATING . Need Help? Call 1-888-TO-HELP-U

778-13524© 2016 18XEB9C7
A. Lift up the battery
housing lid.
Charging Battery Starting Motor
Installing Battery
A. Plug the battery charger into an
appropriate power outlet.
B. With the battery indicator light facing away from the
battery latch, slide the battery into the active battery
port. Push the battery firmly until the battery locks
into place. There should be an audible “click” and the
battery latch should be in the upright position.
C. Close battery housing lid.
B. Insert the battery into the charging dock.
The LED should illuminate.
C. Once the battery is fully charged, remove
it from the battery charger.
A
B
C
B
C
A
Blade Control
Battery
Battery
Charger
Starter Push Key
LED
A. Insert the push start safety key into the
starter housing located in the center of
handle panel until it snaps in place.
B. Standing behind the mower, pull the blade
control back against the upper handle.
C. Push the push start safety key to start the
motor.
46
5
READ AND UNDERSTAND ALL INSTRUCTION, WARNING, AND DANGER LABELS.
PARA INSTRUCCIONES EN ESPAÑOL, REFIÉRASE AL MANUAL DEL OPERADOR.
IMPORTANT: READ OPERATOR'S, BATTERY AND CHARGER MANUALS THOROUGHLY
AND FOLLOW THE IMPORTANT SAFE OPERATION PRACTICES BEFORE OPERATING . Need Help? Call 1-888-TO-HELP-U
