TRU Audio UltraScape Series User manual

888.858.1555
www.TruAudio.com
Escape to paradise in your own backyard. Listen to beautifully toned music
that directs sound towards the listening area. Optimized performance and
size to deliver booming sound from a convenient source discreetly hidden in
any landscape.
UltraScape Series

Installing with the T100
888.858.1555
www.TruAudio.com
The UltraScape system MUST be wired as seen above when using a T100 as the
amplifier. You cannot put more than two satellite speakers on each side; doing so
can damage your system. Additional direct burial speaker wire can be used to run
from the amplifier to the subwoofer, and subwoofer to the satellite speakers as
desired. Space speakers no more than 10 feet apart.
Wiring Instructions
1. Connect Bluetooth adapter to the T100 with the included 3.5 mm to RCA cable.
2. Terminate “Yellow L+”, “Blue L-”, “Red R+” and “Black L-” wires into the T100 as
seen above.
3. Terminate right and left satellite speakers as pictured above.
4. With the Bluetooth adapter, use the T100 remote control to max out the volume.
Once maxed out, press the volume “-” button twice.
5. Test. Enjoy!
3.5mm to RCA Cable
+ -
+
R+
ORANGE
WHITE
R-
- + -
GREEN
GRAY
L+
L-
+ -
SOURCE
