TRU-SCAPES TS-OA2RS-GRY User manual

TS-OA2RS-GRY/SND BLUETOOTH
ROCK SPEAKER
Basic Setup of the TS-OA2RS-XXX Rock Speaker:
1) Turn switch to designate one speaker as the Main Speaker. The Main Speaker should be
placed in a centrally located area when connecting to the optional Deputy Speakers for
optimal Bluetooth connectivity.
Pairing your Bluetooth device and the
(TS-OA2RS-GRY/SND) Rock Speaker.
The process of connecting a Bluetooth speaker to your device
only needs to happen one time. Once a Bluetooth speaker is
successfully paired to your device, it should automatically
connect each time it's powered on.
• Make sure you have turned on the Power Source to your
Bluetooth Speaker(s)
• On your Device, open Settings.
• Select Bluetooth
• Ensure your Bluetooth functionality is switched on at the top of
your screen. If the switch is green, your Bluetooth is already
enabled and nothing needs to be changed. If not, tap the toggle.
• Scroll down to Other Devices and look for your new Bluetooth
speaker’s name “Tru-Scapes Audio” in the given list. Be patient, as
it may take a moment to show up.
• Once it appears, tap it to connect.
• It will take a few seconds for the two devices to pair. When
they're done, the status will update to Connected on your screen.
• Settings such as Volume, Mute, etc., will be controlled
directly from your Bluetooth phone, tablet or other device.
NOTE: Distances, both unobstructed and
obstructed, may dier depending on device you
are syncing up to the TS-OA2RS-XXX. The
Speakers sync with only one device at a time.
You must disconnect the current device
before Syncing to another device.
Deputy Speaker
Main Speaker
Main, Deputy, and OFF
Switch
Rock Speaker Specications:
• Product Dimensions: 14” x 11” x 13”
• Bluetooth Type: BT 5.0
• Bluetooth Range: 50ft Max
• Tweeter Quantity: One
• Tweeter Size: 1”
• Woofer Quantity: One
• Woofer Size: 6.5”
• Wattage Draw: 20w Max
• Speaker Output: 25w
• Speaker impendence: 4Ω
• Speaker Frequency: 50Hz-20KHz
• Speaker Sensitivity: 87dB
Tru-Scapes Bluetooth
Transformer (Power Source)
(TS-TAAB-150/300)
System Diagram
3) The optional Deputy Speakers should be placed up to a max of 50 feet in any direction
from the designated Main Speaker for optimum sound and connectivity. Distance may vary
based on environment. See additional notes under Pairing Bluetooth Device.
2) All Tru-Scapes Outdoor Audio Speakers can act as a Main or Deputy Speaker by turning
the switch (see diagram below). Only one speaker can operate as the Main Speaker when
connecting to a bluetooth device. No more than 6 Deputy Speakers can connect to the Main
Speaker in series.
50 Foot Max
RFI Disclaimer:
* Tru-Scapes Outdoor Audio does not
guaranty the performance of Bluetooth
devices due to RF (radio frequency)
interference.
Bluetooth is a wireless technology standard
for exchanging data between xed and
mobile devices over short distances using
short-wavelength UHF radio waves in the
industrial, scientic and medical radio bands.
To communicate between your devices,
Bluetooth sends signals over a 2.4GHz radio
frequency. There are many other devices and
processes that generate Electromagnetic
Radiation that can interfere with RF
Frequency.
4) Wire Instructions: TURN OFF POWER to transformer. Determine all of the speaker locations
prior to installation. Run low voltage direct burial wire from the low voltage transformer to each
speaker and terminate at the last speaker. Daisy chain each speaker to main wire.
NOTE: Speakers are 9v - 15v low voltage AC and do not require polarity when connection
to wire. Tru-Scapes Speakers and Low Voltage AC Lighting can be connected on the same
wire permitting enough power from the Transformer.
All Tru-Scapes
Outdoor Audio
Speakers can act
as a Main or
Deputy Speaker
by turning the
switch. Only one
speaker can
operate as the
Main Speaker
when connecting
to a bluetooth
device.
Main Speaker
Deputy Speakers
Bluetooth Device

!
!
!
!"#$%&'()*+,#-.//"+0#.1/+233+4)5#1")6)7-*+
!
•!!"#$%&'(#)'%)*+,-#'$%.#/"%,01/%23%*4%/"'%566%78-'$9%:,'10/#*;%#$%$8<=')/%/*%/"'%
4*--*.#;>%/.*%)*;&#/#*;$?%@2A%!"#$%&'(#)'%+0B%;*/%)08$'%"01+48-%#;/'14'1';)'C%
0;&%@DA%/"#$%&'(#)'%+8$/%0))',/%0;B%#;/'14'1';)'%1')'#('&C%#;)-8&#;>%#;/'14'1';)'%
/"0/%+0B%)08$'%8;&'$#1'&%*,'10/#*;9%!
!
•!E;B%6"0;>'$%*1%+*&#4#)0/#*;$%;*/%'F,1'$$-B%0,,1*('&%<B%/"'%,01/B%1'$,*;$#<-'%
4*1%)*+,-#0;)'%)*8-&%(*#&%/"'%8$'1G$%08/"*1#/B%/*%*,'10/'%/"'%'H8#,+';/9%
!
•!I*/'?%!"#$%'H8#,+';/%"0$%<'';%/'$/'&%0;&%4*8;&%/*%)*+,-B%.#/"%/"'%-#+#/$%4*1%0%
6-0$$%J%&#>#/0-%&'(#)'C%,81$80;/%/*%,01/%23%*4%/"'%566%78-'$9%!"'$'%-#+#/$%01'%
&'$#>;'&%/*%,1*(#&'%1'0$*;0<-'%,1*/')/#*;%0>0#;$/%"01+48-%#;/'14'1';)'%#;%0%
1'$#&';/#0-%#;$/0--0/#*;9%!"#$%'H8#,+';/%>';'10/'$%8$'$%0;&%)0;%10&#0/'%10&#*%
41'H8';)B%';'1>B%0;&C%#4%;*/%#;$/0--'&%0;&%8$'&%#;%0))*1&0;)'%.#/"%/"'%
#;$/18)/#*;$C%+0B%)08$'%"01+48-%#;/'14'1';)'%/*%10&#*%)*++8;#)0/#*;$9
K*.'('1C%/"'1'%#$%;*%>8010;/''%/"0/%#;/'14'1';)'%.#--%;*/%*))81%#;%0%,01/#)8-01%
#;$/0--0/#*;9%L4%/"#$%'H8#,+';/%&*'$%)08$'%"01+48-%#;/'14'1';)'%/*%10&#*%*1%
/'-'(#$#*;%1')',/#*;C%."#)"%)0;%<'%&'/'1+#;'&%<B%/81;#;>%/"'%'H8#,+';/%*44%0;&%
*;C%/"'%8$'1%#$%';)*810>'&%/*%/1B%/*%)*11')/%/"'%#;/'14'1';)'%<B%*;'%*1%+*1'%*4%
/"'%4*--*.#;>%+'0$81'$?%
M%7'*1#';/%*1%1'-*)0/'%/"'%1')'#(#;>%0;/';;09%
M%L;)1'0$'%/"'%$',010/#*;%<'/.'';%/"'%'H8#,+';/%0;&%1')'#('19%
M%6*;;')/%/"'%'H8#,+';/%#;/*%0;%*8/-'/%*;%0%)#1)8#/%&#44'1';/%41*+%/"0/%/*%."#)"%
/"'%1')'#('1%#$%)*;;')/'&9%!
M%6*;$8-/%/"'%&'0-'1%*1%0;%'F,'1#';)'&%10&#*N!O%/')";#)#0;%4*1%"'-,9%!
!
