True Induction TI-3B User manual

1
TRIPLE BURNER INDUCTION COOKTOP MANUAL
TRUE INDUCTION TRIPLE BURNER
INDUCTION COOKTOP MANUAL
TI-3B

2
I.
II.
III.
IV.
V.
VI.
VII.
VIII.
Control Panel Overview
Cooktop Installation
Important safety Information
Product Specications
How to Use
> Power Invariance Technology
> Using the Temperature Setting
> Using the Timer Function
> Built-In Safety Shut O
> Turning O Unit
Compatible Cookware
Cleaning & Maintenance
Troubleshooting Error Codes
TRIPLE BURNER INDUCTION COOKTOP MANUAL
TABLE OF CONTENTS
1
2-4
5-6
6
7
7-8
8
8
9
9
9
10
10-11
Thank you for purchasing the True Induction Triple Burner Induction
cooktop. Please read the entire instruction manual prior to using your
unit. If you have any questions regarding the True Induction cooktop
please visit http://www.Truelnduction.com or call: 1-877-862-7049.

3
TRIPLE BURNER INDUCTION COOKTOP MANUAL P.1
I. Control Panel Overview
1. Upper Left Cooking Zone
2. Lower Left Cooking Zone
3. Right Cooking Zone
4. Ceramic– Glass
5. Upper Left Touch Control Panel
6. Right Touch Control Panel
7. Lower Left Touch Control Panel
8. Power Option Display
9. Lower Power Key
10. Raise Power Key
11. Cooking Zone ON/OFF Key
12. Time Control Key
13. Power Button
1
2
3
4
5
6
7
8
910
11 12
13

4
II. Cooktop Installation
Dimensions and Placement for Cut-out in Countertop
This appliance is not user serviceable. Installation must be completed by a qualied
technician.
WARNING!
FOR YOUR SAFETY: Do not store or use gasoline or other ammable vapors and liquids in
the vicinity of the unit. To eliminate the risk of burns or re due to overheating, cabinets located
above the induction cooktop should be avoided or allowed a minimum of 30’’ clearance. If cabi-
net space is available, the risk can be reduced by installing a range hood at a minimum of 5
inches below the bottom of the cabinets.
IMPORTANT INSTALLATION INFORMATION:
All electric cooktops run o of a single phase, three-wire cable, 120V/60Hx AC only electrical
supply with ground. The installation should be made using wires, conduits, and ttings size in
accordance with the National Electrical Code– ANSI/NFPA 70.
Cut a rectangle hole in the countertop where the cook top is to be placed. The dimensions
for the cut-out are 21 3/4' x 19 3/8''
The cut-out must be placed at least 2 1/2" from any side of the countertop.
To achieve ush mounting installation, use a router tool to round the corners of the hole cut
into the countertop.
TRIPLE BURNER INDUCTION COOKTOP MANUAL P.2
20’’
13 3/4’’
21 3/4’’
19 3/8’’

5
TRIPLE BURNER INDUCTION COOKTOP MANUAL P.3
II. Cooktop Installation Continued...
First feed the power wire through the hole and to the location of the power receptacle un-
derneath the cabinet.
The 'h'' overhang on the induction cooker comes with pre-installed foam gasket. Peel o the
adhesive protector on the bottom of the gasket and set the induction cooker into the cut-
out. Gently press down on the induction cook top to secure the adhesive gasket to the coun-
tertop. The cook top should be sitting on the supports previously installed.
For RV use, apply butyl tape instead of the supplied foam tape. Butyl tape will provide ade-
quate adhesion and still allow for removal if the unit needs to be serviced.

6
II. Cooktop Installation Continued...
Clearance Needed for Air Circulation
Below you will see a diagram of the air ow. Be sure not to block either the intake or exhaust
For proper air circulation, allow at least 3" of clearance from the bottom of the induction
cooker to any shelving or storage. The underside of the countertop should not be closed o
from the cabinetry underneath for better air ow.
TRIPLE BURNER INDUCTION COOKTOP MANUAL P.4

7
III. Important Safety Information
When using electrical appliances, basic safety precautions should always be followed. For the True
Induction cooker, even with built-in safety features, it is essential to heed all precautions:
When the unit is on, do not touch outside the control panel as the surface may contain residual
heat.
To protect against electric shock, do not immerse cord plugs or cooker in water (or other liquid
substances).
When using any electric appliance used around children, close supervision is strongly suggested.
Do not operate any appliance with a damaged cord or plug, after a malfunction or if it has been
damaged in any manner. Read the seller's guidelines for warranty repairs and returns.
Do not cook on a broken or damaged cooktop as spillovers may penetrate the surface and cre-
ate a risk of electric shock.
To avoid potential injury, do not use accessory attachments which aren't recommended by the
manufacturer.
Do not let the cord dangle over the edge of the table or counter. Keep the cord away from hot
surfaces.
Do not place cooktop on or near: hot gas, electric burner or heated oven.
To prevent accidents and achieve optimal fan ventilation, allow for sucient space around the
cooking area.
Items with a magnetic eld such as: radios, televisions, credit cards, cassette tapes etc., can
aect the unit.
The power cord provided has been sized accordingly, however, with caution and care extension
cords may be used.
a.The marked electrical rating should be at least as great as the electrical rating of the
appliance.
b.The cord should be arranged so that it will not drape over the countertop or tabletop
where it can be pulled on by children or tripped over.
Do not use with empty pans/pots.
Do not place metallic objects such a knives, forks, spoons, lids, cans or aluminum foil on the
cooktop.
To prevent accidents and achieve optimal ventilation, allow for sucient space around the cook-
ing area.
TRIPLE BURNER INDUCTION COOKTOP MANUAL P.5

8
III. Important Safety Information Continued...
This appliance has a polarize plug (one blade is wider than the other). To reduce the risk of
electric shock, the plug will t on the outlet only one way. If the prongs do not t fully, re-
verse the plug. If it still does not t, contact the seller for warranty support; do not attempt
to modify the plug in anyway.
To properly turn o unit press the Power button.
It is important to be aware that the unit's surface will remain hot for a short period of time
after use.
Disconnect power and allow to cool before performing any maintenance or repairs.
Clean cooktop with caution - do not clean while unit is still hot, some cleaners produce
steam or fumes if applied to a heated surface.
Do not use cooktop for any other use then directed by the manufacturer.
IV. Product Specifications
TRIPLE BURNER INDUCTION COOKTOP MANUAL P.6
Power
Voltage
Temperature Range
Level Selection
Max Time
Material
Unit Measurement
3300 Watts
120v, 240v/ 60Hz
150°F - 450°F (in 10 degree variables)
Selecting settings 1—10
Set timer up to 150 minutes
Glass ceramic top
23 1/4’’ W x 20 1/2’’ L x 2 1/2“ H

9
V. How to Use
There are 2 plugs for this unit. The UPPER and LOWER LEFT ZONES are controlled by the left
plug (total power is 1800W). And the RIGHT ZONE is controlled by the right plug (power is
1500W).
WARNING!
The left and right plug must utilize two separate dedicated 15 amp breakers.
The Power button will light up and the unit will sound to indicate on.
The device will remain in standby mode, awaiting user direction.
Place ferromagnetic cookware (with water, oil or food already inside) on the center of the
glass-ceramic top center.
Now press the Power button on the control panel, this will turn the cooktop on. The power
display will blink and sound another indicator.
Press the Heat function key once. The pre-set power level "5" is the default selection as the
device turns on.
Using the +/ - keys you can change the settings at any time, ranging from 1- 10. This is con-
sidered to be the HEAT function.
Power Invariance Technology
The maximum power of an individual burner level is at setting 10. But, when operating
both burners on the same side their combined total is level 10, meaning that when operating
the two burners at the same time they'll self adjust levels accordingly:
•When you increase the power of one, the power output of the other will reduce au-
tomatically (i.e., one is at 6, the other burner automatically reduces power to level 4 creating
a total of max 10 setting).
•If one of the burners on the same side is using the HEAT function and the other uses the
TEMP settings, the maximum HEAT setting is "5."
TRIPLE BURNER INDUCTION COOKTOP MANUAL P.7

10
V. How to Use Continued...
Power Invariance Technology Continued...
NOTE: This function is equipped with safeguards against parching. The unit might shut o auto-
matically when this function is used for frying, stir-frying, grilling and other high temperature
cooking formats.
Using the Temperature Setting
Using the +/ - keys you can change the temperature settings at any time. Settings range from
150-450 degrees Fahrenheit. (Exact temperatures: 150, 180, 210, 240, 270, 300, 360, 390, 420
and 450 F).
Using the Timer Function
After selecting the HEAT or TEMP mode, press the TIMER button once. The display will show
the number "0." Using the +/ - keys you can select the operating time in 5-minute intervals
(up to max 150 min.) and reducing 1 minute.
The display will count down the duration in minutes. Once the time is up, the unit sounds
and automatically goes into standby mode. To continue cooking, press the Power button
and Heat button to restart.
During the timer operation, you can change the timer duration at any time with the arrow
keys. The device's built-in memory maintains the HEAT or TEMP setting previously entered.
You can also change the HEAT or TEMP settings without aecting the current timer setting.
TRIPLE BURNER COOKTOP MANUAL P.8
NOTICE FOR UPPER AND LOWER LEFT ZONES ONLY:
1. If only one zone is being used and the other zone is o, the zone being used can be utilized
to max level 10.
2. If the UPPER and LOWER LEFT ZONES are both being used in HEAT mode at the same time,
the max setting of one zone is level 7 and the max settings of two zones combined will reach
level 10. For example, if UPPER LEFT ZONE is set at level “4”, when you adjust the HEAT level of
the LOWER LEFT ZONE from 6 to 7, the UPPER LEFT ZONE will automatically reduce to level “3”.
3. If one zone is using TEMP mode and the other zone is using HEAT mode, the max level of the
HEAT mode is “5”.
