True GDM-72 User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • FAX [phone] • [phone] • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# [phone]
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
TM
AVAILABLE AT:
GDM-72
GDM-72
Model Doors
Capacity
(Cu. Ft.)
(liters) Shelves
Cabinet Dimensions
(inches)
(mm)
LD
†HHP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
GDM-72 3 72
2039
12 781/8
1985
297/8
759
793/8
2017
1/2
1/2
115/60/1
230-240/50/1
12.0
6.9
5-15P
▲
9
2.74
680
309
†Depth does not include 11/8" (29 mm) for door handles. ▲ Plug type varies by country.
1/06
Glass Door Merchandiser:
Swing Door Refrigerator
The world’s #1 manufaturer of
glass door merchandisers.
Oversized, factory balanced,
refrigeration system holds 33°F
to 38°F (.5°C to 3.3°C).
Exterior - non-peel or chip white
laminated vinyl; durable and
permanent.
Interior - attractive, NSF
approved, white aluminum
interior liner with 300 series
stainless steel floor.
Self closing doors. Positive seal,
torsion type closure system.
“Low-E”, double pane thermal
glass door assemblies with
extruded aluminum frames.
The latest in energy efficient
technology.
Patented integrated door light
(IDL) system for brighter, shadow
free illumination.
Entire cabinet structure is
foamed-in-place using high
density, CFC free, polyurethane
insulation.
Bottom mounted units feature
”No stoop” lower shelf to
maximize product visibility.
Storage on top of cabinet.
Easily accessible condenser coil
for cleaning.
R
Shown with optional TrueTrac4 gravity feed organizers.

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • FAX [phone] • [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
GDM-72 TFAY01E TFAY01S TFAY01P TFAY013
GDM-72
DESIGN
• True’s commitment to using the
highest quality materials and oversized
refrigeration systems provides the user
with colder product temperatures,
and lower utility costs in an attractive
merchandiser that brilliantly displays
packaged food and beverages.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free) 134A
refrigerant.
• Extra large evaporator coil balanced with
higher horsepower compressor and large
condenser; maintains cabinet temperatures
of 33°F to 38°F (.5°C to 3.3°C).
• Sealed, cast iron, self-lubricating
evaporator fan motors and larger fan
blades give True merchandisers a more
efficient low velocity, high volume airflow
design. This unique design insures faster
temperature pull down of warm product,
colder holding temperatures and faster
recovery in high use situations.
• Bottom mounted condensing unit positioned
for easy maintenance. “No stoop”
lower shelf maximizes visibility by raising
merchandised product to higher level.
CABINET CONSTRUCTION
• Exterior - non-peel or chip white
laminated vinyl; durable and permanent.
• Interior - attractive, NSF approved, white
aluminum liner with 300 series stainless
steel floor.
• Insulation - entire cabinet structure is
foamed-in-place using high density, CFC
free, polyurethane insulation.
• Welded, heavy duty galvanized frame rail
dipped in rust inhibiting enamel paint for
corrosion protection inside and out.
• Frame rail fitted with leg levelers.
• Illuminated exterior sign panel. Variety of
sign options available.
DOORS
• “Low-E”, double pane thermal glass
door assemblies with extruded aluminum
frames. The latest in energy efficient
technology.
• Self closing doors.
• Each door fitted with 12" (305 mm)
extruded handle.
• Magnetic door gaskets of one piece
construction, removable without tools for
ease of cleaning.
SHELVING
• Twelve (12) adjustable, heavy duty PVC
coated wire shelves 241/4"L x 221/8"D
(616 mm x 562 mm). Four (4) chrome
plated shelf clips included per shelf.
• Shelf support pilasters made of same
material as cabinet interior; shelves are
adjustable on 1/2" (13 mm) increments.
LIGHTING
• Safety shielded fluorescent interior
lighting. Doors utilize full-length,
patented, integrated doors light (IDL)
system.
• Cabinet lighting utilizes electronic ballast
and T-8 bulbs for brighter illumination,
longer bulb life and increased energy
efficiency.
MODEL FEATURES
• Evaporator is epoxy coated to eliminate
the potential of corrosion.
• See our website www.truemfg.com for
latest color and sign offerings.
• Convenient clean-out drain built in
cabinet floor.
• Listed under NSF-7 for the storage and/or
display of packaged or bottled product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1
phase - 15 amp dedicated outlet. Cord
and plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒230-240V / 50 Hz.
❒Black exterior.
❒Rosewood exterior.
❒Stainless steel exterior.
❒Black aluminum interior liner with
black shelving.
❒Stainless interior liner.
❒ 6" (153 mm) standard legs.
❒6" (153 mm) seismic/flanged legs.
❒ 4" (102 mm) diameter castors.
❒21/2" (64 mm) diameter castors.
❒Red wine thermostat.
❒Chocolate thermostat.
❒White wine thermostat.
❒Novelty baskets.
❒Wine racks.
❒ Additional shelves.
❒TrueTrac4 gravity feed organizers.
❒11/4" (32 mm) pricing strips.
❒Remote cabinet and/or condensing
unit. System comes standard with 404A
expansion valve and requires R404A
refrigerant.
115/60/1
NEMA-5-15R
Glass Door Merchandiser:
Swing Door Refrigerator
ELEVATION PLAN VIEW
781/8"
(1985 mm)
2913/16"
(758 mm)
3029/32"
(786 mm)
21/8"
(54 mm)
793/8"
(2017 mm)
5/16"
(8 mm)
13/32"
(28 mm)
535/8"
(1363 mm)
2313/16"
(605 mm)
7615/16"
(1956 mm)
