True TUC-24 User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the next whole millimeter (inches rounded up to the next 1/8").
ROUGH-IN DATA
Field’s End Road, Goldthorpe, Nr. Rotherham, South Yorkshire S63 9EU,
England • www.truemfg.com • Tel [phone] • FAX [phone]
• Free Phone [phone] • Free Phone to U.S. 0 800 894 928
Model:
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
APPROVALS:
Printed in U.S.A.
TRUE EUROPE
AVAILABLE AT:
TUC-24
TUC-24
†Depth does not include 26 mm (1") for bumpers. ▲Plug type varies by country.
Undercounter:
Solid Door Refrigerator
8/07
True’s undercounters are
designed with enduring quality
that protects your long term
investment.
Designed using the highest
quality materials and
components to provide the
user with colder product
temperatures, lower utility
costs, exceptional food safety
and the best value in today’s
food service marketplace.
Oversized, environmentally
friendly (134A) forced-air
refrigeration system holds .5°C
to 3.3°C (33°F to 38°F).
300 series stainless steel front
and countertop. Matching
aluminum sides and finished
back.
Attractive, white aluminum
liner. 300 series stainless steel
floor with coved corners.
LED temperature display.
Front breathing.
Heavy duty PVC coated wire
shelves.
Foamed-in-place, high density
polyurethane insulation (CFC
free).
Model Doors
Capacity
(liters)
(Cu. Ft.)
Shelves
Cabinet Dimensions
(mm)
(inches)
LD
†HHP Voltage Amps
NEMA
Config.
Cord
Length
(total m)
(total ft.)
Crated
Weight
(kg)
(lbs.)
TUC-24 1 147
5.2
2 610
24
629
243/4
832
323/4
1/6230-240/50/1 1.34 ▲2.74
9
66
145

STANDARD FEATURES
Model:
TRUE EUROPE
Field’s End Road, Goldthorpe, Nr. Rotherham, South Yorkshire S63 9EU, England • 01709 888 080 • FAX [phone] • Free Phone [phone] • Free Phone to U.S. 0 800 894 928 • www.truemfg.com
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
TUC-24
TUC-24
DESIGN
• True’s commitment to using the
highest quality materials and
oversized refrigeration systems
provides the user with colder product
temperatures, lower utility costs,
exceptional food safety and the
best value in today’s food service
marketplace.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free)
R134A refrigerant.
• Oversized, factory balanced
refrigeration system with guided
airflow to provide uniform product
temperature.
• Extra large evaporator coil balanced
with higher horsepower compressor
and large condenser; maintains
cabinet temperature of .5°C to 3.3°C
(33°F to 38°F) for the best in food
preservation.
• Sealed, cast iron, self-lubricating
evaporator fan motor(s) and larger
fan blades give True undercounter
units a more efficient low velocity,
high volume airflow design. This
unique design ensures faster
temperature recovery and shorter
run times in the busiest of food
service environments.
• Condensing unit access in back
of cabinet, slides out for easy
maintenance.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel
front and countertop. Matching
aluminum sides and finished back.
• Interior - attractive, white aluminum
liner. 300 series stainless steel floor
with coved corners.
• Insulation - entire cabinet structure
and solid door is foamed-in-place
using high density, CFC free,
polyurethane insulation.
• Two (2) front leg levelers and Two (2)
rear recessed castors.
832 mm (323/4") work surface height.
DOOR
• Stainless steel exterior with white
aluminum liner to match cabinet
interior.
• Door fitted with 305 mm (12") long
recessed handle that is foamed-in-
place with a sheet metal interlock to
ensure permanent attachment.
• Positive seal self-closing door with
90° stay open feature. Door swings
within cabinet dimensions.
• Magnetic door gasket of one piece
construction, removable without
tools for ease of cleaning.
SHELVING
• Two (2) adjustable, heavy duty
PVC coated wire shelves 508 mm x
353 mm (20"L x 137/8"D). Four (4)
chrome plated shelf clips included
per shelf.
• Shelf support pilasters made of same
material as cabinet interior, shelves
are adjustable on 13 mm (1/2")
increments.
MODEL FEATURES
• Evaporator is epoxy coated to
eliminate the potential of corrosion.
• Door lock.
• Exterior rectangular digital
temperature display.
• Self-contained condensate pan. No
need for external drain.
ELECTRICAL
• Unit completely pre-wired at factory
and ready for final connection to a
230-240/50/1 phase dedicated outlet.
Cord and plug set included.
• Plug type varies by country.
Gastronorm Undercounter:
Solid Door Refrigerator
ELEVATION RIGHT VIEW
1229 mm
(483/8")
628 mm
(2411/16")
26 mm
(1")
577 mm
(2211/16")
815 mm
(321/16")
831 mm
(3211/16")
610 mm
(24")
16 mm
(5/8")
