ATN Ultra Sight Digital Compact User manual

user`s guide
Ultra Sight
Digital Compact
Important Export Restrictions! Commodities,
products, technologies and services contained in this
manualaresubjecttooneormoreoftheexportcontrollawsand
regulations of the U.S. Government and they fall
under the control jurisdiction of the US BIS-Department of
Commerce. It is unlawful and strictly prohibited to
export, or attempt to export or otherwise transfer or sell any
hardware or technical data or furnish any service to any
foreign person, whether abroad or in the United States, for
which a license or written approval of the U.S. Government
is required, without first obtaining the required license or
writtenapprovalfromtheDepartmentoftheU.S.Government
havingjurisdiction.DiversioncontrarytoU.S.lawisprohibited.
USER’S GUIDE (ULTRA SIGHT DIGITAL COMPACT) REVISION 3 - MAY 2011
REFLEX SIGHT

The information in this manual furnished for information use only, is subject to change without notice, is not
to be construed as a commitment by ATN Corp.
ATN Corp. assumes no responsibility or liability for any errors or inaccuracies that may appear in this book.
©2011 ATN Corp. All right reserved.
SPECIFICATIONS
• Magnification: 1
• Exit Pupil: 22 mm
• Windage & Elevation adjustment
• Multi-Reticle System
• Parallax Free
• 3V Lithium Battery (CR2032)
• Dimensions: 69x30x52 mm
• Weight: 60 g
Large 22 mm
Heads-Up
Display
Reticle Pattern
Selector Power/Mode
Button
Windage
Automatic
Brightness
Sensor
Standard Weaver
Mount
Battery Housing
Screws
THREE RETICLE PATTERNS
4 MOA
Dot
4 MOA
64 MOA
4 MOA
Post with Dot
APPLICATION
The Ultra Sight Digital Compact was
designed to be for both eyes open operation,
heads-up, rapid acquisition reflex sight.
At half of the size and with all the features of
the regular Digital Ultra Sight the Ultra Sight
DC is the latest in reflex sights.
Digital controls allow you to choose between
three reticle patterns with a simple push of
a button. Unlike all other systems with inter-
changeable retitcles the Ultra Sight DC will
not have any reticle shift when the pattern
is changed.
Digital controls are also used for automatic
brightness adjusting. The unit has a built in
memory. So, when you turn the unit off and
then back on it will remember the last reticle
patterns you were on.
Combine all above features with an accurate
windage and elevation system making the
Ultra Sight DC the best compact reflex sight
on the market.
FEATURES
• 3 reticle patterns to choose from. Pattern
can be changed with a push of a button.
• Automatic adjusting of reticle pattern
brightness.
• Parallax Free.
• Instant Target acquisition.
• Fits standard Weaver style base.
• Ideal for handguns, rifles and shotguns.
• Heads-up display for extra wide field of
view.
• Installs quickly using 2 thumbnut tightened
clamps for extra stability.
• High intensity diode for super bright reticle
pattern.
• Two-color Mode Indicator.
• Efficient electrical design for extra battery
life.
Elevation
Locking Screws
4 MOA
16 MOA
Post
64 MOA
8 MOA
Mode Indicator
* ATN reserves the right to change the above specifica-
tions at any time without notice

OPERATING INSTRUCTIONS
Battery Installation
The battery (included) is a coin style 3V
Lithium (CR2032).
Unscrew two set screws on the top side of
the unit and open the body of unit.
Install the battery into housing with the polarity
order shown at the base of unit.
Turning the Ultra Sight On
After you install a battery press Power/
mode button to turn unit on in AUTO
BRIGHTNESS MODE. The mode indicator
light will glow with green. By pressing the
MODE button again you will select MAXI-
MUM BRIGHTNESS MODE. The mode indi-
cator light will glow with red. By pressing
this button a third time the unit will turn off.
Power/Mode Button
• Press once for: To turn unit on in AUTO
BRIGHTNESS MODE, indicator light will
glow with green.
• Press twice for: MAXIMUM BRIGHT-
NESS MODE, indicator light will glow with
red.
• Press third time: To turn Ultra sight off.
Hold the Ultra Sight away from you and
look through it with both eyes open to see
reticle pattern.
Reticle Patterns
Every Ultra Sight Digital Compact comes
with three reticle patterns.
• Dot
• Post
• Post with Dot
You can choose your preferred pattern
by pushing the Reticle Pattern Selector
button.
MOUNTING
The Ultra Sight Digital Compact is
designed to be mounted onto a standard
7/8 weaver rail.
CAUTION: Be sure gun is not loaded. Use
safe gun handling procedures all the time.
Slightly loosen horizontal fixation screws.
Place the scope on the dovetail mount,
making sure that the mount aligns with the
receptor attachment screw. Re-tighten hor-
izontal fixation screws.
AUTOMATIC BRIGHTNESS SENSOR
Your Ultra Sight DC has a built in Automatic
Brightness Control. This control automati-
cally adjusts the brightness of the reticle to
the optimal level.
IMPORTANT: It is very important that you
do not cover or block this sensor (it is
located in the front of the scope).
This sensor also will require to be cleaned
cleaning from time to time. To do this
please wipe clean gently with an optical or
soft cloth.
NOTE: If you need more reticle brightness
use the MAXIMUM BRIGHTNESS MODE.
WINDAGE AND ELEVATION ADJUSTMENTS
The vertical (elevation) and horizontal
(windage) adjustments for the Ultra Sight
Digital Compact can be achieved by turn-
ing the windage and elevation adjustment
mechanisms. Slightly loosen the locking
screw before windage/elevation adjust-
ment. Rotate windage and elevation screws
as needed to correct aiming point. When
reaching the maximum of the rotation do
not use force. After adjustment was done
turn the locking screw clockwise to block the
adjustment mechanism.
MAINTAINING YOUR ULTRA SIGHT
DIGITAL COMPACT
The Ultra Sight Digital Compact is water-
proof and shock-proof. However, you
should never try to take apart or clean it
internally (it will void your warranty). If your
scope ever does need repairs or adjust-
ments, it should be returned to ATN's
service department. Optical surfaces will
perform their best if they are occasionally
wiped clean with a lens cloth or with optical
quality lens paper like those for eyeglasses
or camera lenses. Maintain the metal sur-
faces of you Ultra Sight by removing any
dirt or sand with a soft brush so as to avoid
scratching the finish. Wipe down the unit
with a damp cloth and follow with a dry
cloth. Finally, going over the body with a
silicon treated cloth will restore luster and
protect the scope against corrosion, be
careful not to touch any of the lenses with
the silicon cloth.
17052011

2 YEAR PRODUCT WARRANTY
This product is guaranteed to be free from manufacturing
defects in material and workmanship under normal use for
a period of 2 (two) years from the date of purchase. In the
event a defect that is covered by the foregoing warranty
occurs during the applicable period stated above, ATN, at
its option, will either repair or replace the product, and such
action on the part of ATN shall be the full extent of ATN’s lia-
bility, and the Customer’s sole and exclusive remedy. This
warranty does not cover a product (a) used in other than
its normal and customary manner; (b) subjected to misuse;
(c) subjected to alterations, modifications or repairs by the
Customer of by any party other than ATN without prior writ-
ten consent of ATN; (d) special order or “close-out” mer-
chandise or merchandise sold “as-is” by either ATN or the
ATN dealer; or (e) merchandise that has been discontinued
by the manufacturer and either parts or replacement units
are not available due to reasons beyond the control of ATN.
ATN shall not be responsible for any defects or damage that
in ATN’s opinion is a result from the mishandling, abuse,
misuse, improper storage or improper operation, including
use in conjunction with equipment which is electrically or
mechanically incompatible with or of inferior quality to the
product, as well as failure to maintain the environmental
conditions specified by the manufacturer. This warranty is
extended only to the original purchaser. Any breach of this
warranty shall be waived unless the customer notifies ATN
at the address noted below within the applicable warranty
period.
The customer understands and agrees that except for the
foregoing warranty, no other warranties written or oral,
statutory, expressed or implied, including any implied war-
ranty of merchantability or fitness for a particular purpose,
shall apply to the product. All such implied warranties are
hereby and expressly disclaimed.
LIMITATION OF LIABILITY
ATN will not be liable for any claims, actions, suits, pro-
ceedings, costs, expenses, damages or liabilities arising
out of the use of this product. Operation and use of the
product are the sole responsibility of the Customer. ATN’s
sole undertaking is limited to providing the products and
services outlined herein in accordance with the terms and
conditions of this Agreement. The provision of products
sold and services performed by ATN to the Customer
shall not be interpreted, construed, or regarded, either
expressly or implied, as being for the benefit of or creating
any obligation toward any third party of legal entity out-
side ATN and the Customer; ATN’s obligations under this
Agreement extend solely to the Customer. ATN’s liabil-
ity hereunder for damages, regardless of the form or
action, shall not exceed the fees or other charges paid
to ATN by the customer or customer’s dealer. ATN
shall not, in any event, be liable for special, indirect,
incidental, or consequential damages, including, but
not limited to, lost income, lost revenue, or lost profit,
whether such damages were foreseeable or not at the
time of purchase, and whether or not such damages
arise out of a breach of warranty, a breach of agree-
ment, negligence, strict liability or any other theory of
liability.
PRODUCT WARRANTY REGISTRATION
In order to validate the warranty on your product, ATN must
receive a completed Product Warranty Registration Card for
each unit or complete warranty registration on our website at
www.atncorp.com. Please complete the included form and
immediately mail it to our Service Center: ATN Corporation,
1341 San Mateo Avenue, South San Francisco, CA 94080.
OBTAINING WARRANTY SERVICE
To obtain warranty service on your unit, End-user must
notify ATN service department by calling 800-910-2862
or 650-989-5100 or via e-mail [e-mail]
to receive a Return Merchandise Authorization number
(RMA).
When returning please take or send the product, post-
age paid, with a copy of your sales receipt to our service
center, ATN Corporation at the address noted above. All
merchandise must be fully insured with the correct post-
age; ATN will not be responsible for improper postage
or, missing or damaged merchandise during shipment.
When sending product back, please clearly mark the
RMA# on the outside of the shipping box. Please in-
clude a letter that indicates your RMA#, Name, Return
Address, reason for service return, Contact information
such as valid telephone numbers and/or e-mail address
and proof of purchases that will help us to establish the
valid start date of the warranty. Product merchandise re-
turns that do not have an RMA listed may be refused or a
significant delay in processing may occur.
Estimated Warranty service time is 10-20 business
days. End-user/customer is responsible for postage to
ATN for warranty service. ATN will cover return postage/
shipping to continental USA end-users/customers after
warranty repair only if product is covered by aforemen-
tioned warranty. ATN will return product after warranty
service by domestic UPS ground and/or domestic mail.
Any other requested, required or international shipping
method the postage/shipping fee will be the responsibil-
ity of the end-user/customer.
For customer service and technical support,
please contact
American Technologies Network Corp.
North American Office
1341 San Mateo Avenue,
South San Francisco, CA 94080
phone: [phone];
fax: [phone]
European Office
phone: [phone],
fax: [phone]
The following countries can use our
toll free number 00 800 9102-8620
Austria, France, Germany, Holland, Italy,
Spain, Sweden, Switzerland
www.atncorp.com
RegisteR youR pRoduct waRRanty online at
www.atncoRp.com/waRRanty
