ATN LTAD-SN User manual

stealth needle
stealth needle
IR laser aiming device
American Technologies Network Corp.
1341 San Mateo Avenue, South San Francisco, CA 94080
800-910-2862 650-875-0130 FAX [phone]
www.atncorp.com
E-mail: [e-mail], [e-mail]
• Weapon mounted IR laser aiming device for use in
combination with Night Vision
• 2 position power adjustment
• Precision Azimuth and Elevation adjustments
with secure covers
• Durable and compact design
• Waterproof of 20 meters for 2 hours
• Operates on a standard 3V CR123A long-life
lithium battery
• Mounts to standard Weaver and Picatinny rails
• Returns to zero after remounting
• Equipped with a variable intensity adjustment
switch allowing CQB and long-range operations
• Equipped with waterproof remote switch with
push-button that allows continuous or momentary
operation
AIMING LIGHT WAVELENGTH, nm 850
ILLUMINATOR WAVELENGTH, nm -
STROBE MODES CONTINUOUS
OPERATING MODES OFF, ON, STAND-BY
POWER ADJUSTMENT 2 POSITION
AIMING OUTPUT POWER, mW min 0.05 ; max 0.7
ILLUMINATOR OUTPUT POWER, mW -
LASER DEVICE CLASS 1
AIMING LIGHT DIVERGENCE, mrad 0.3
ILLUMINATOR DIVERGENCE, deg. -
OUTPUT BEAM DIAMETER, mm 5
BATTERY TYPE 3V Lithium CR123A
REVERSE POLARITY PROTECTION Yes
SUPPLY CURRENT, mA max 50
BATTERY LIFE, h min 20
REVERSE RECOGNITION ANGLE, deg. ±10
WINDAGE/ELEVATION ADJUSTMENT, mrad ±20
ADJUSTMENT STEP, mrad 0,5
WATERPROOF 20 m SUBMERSION FOR 2h
OPERATING TEMPERATURE, °C -40°C…+60°C
WEIGHT, kg 0.19
DIMENSIONS, mm 94x65x42
MOUNTING SYSTEM Picatinny rail, Weaver rail
The ATN Stealth Needle (SN) is a Class-1 infra-red
Laser Target Acquisition Device (LTAD) designed for
Commercial and Law Enforcement use.
The LTAD-SN is intended for illumination of a target
or for target acquisition during night time use with a
weapon or paintball gun in conjunction with Night Vi-
sion devices.
The Infra-red laser is invisible to a naked eye, but can
be visible to night vision devices.
It is designed to provide covert target acquisition and
illumination for night time Law Enforcement opera-
tions or scenario paintball games.
The ATN LTAD-SN has a mount for weapon compat-
ibility with standard Weaver or Picatinny rails.
The LTAD-SN is easy to mount and zero.
