Turbo air Speeds Up the Pace of Innovation
Refrigerator
Freezer
Installation and Operation Manual
Please read this manual completely before attempting to install or operate this equipment!
<Solid Door>
Refrigerator
MSR-23NM
MSR-49NM
Freezer
MSF-23NM
MSF-49NM
<Glass Door>
Refrigerator
MSR-23G-1
MSR-49G-2
MSR-72G-3
CAUTION!
PLEASE KEEP POWER SWITCH ON
BEFORE OPERATING THIS EQUIPMENT

1. SPECIFICATION.......................................................................................... 2
2. SERIAL NUMBER........................................................................................ 2
3. INSTALLATION............................................................................................ 3
4. CLEANING................................................................................................... 4
5. BASIC OPERATION
5-1. REFRIGERATORS........................................................................... 5~8
5-2. FREEZERS..................................................................................... 9~12
6. BEFORE REQUESTING SERVICE........................................................... 13
7. WARRANTY......................................................................................... 14~15
2
Turbo air
CONTENTS
PAGE
Refrigerators
SPECIFICATION
MODEL COMP H.P. V/Hz REFRIGERANT AMPS WEIGHT
MSR-23NM
1/3 115V/60Hz R-134a 5.5A 259lbs
MSR-49NM 1/3 115V/60Hz R-134a 9.2A 412lbs
MSR-23G-1 1/3 115V/60Hz R-134a 5.5A 274lbs
MSR-49G-2 1/3 115V/60Hz R-134a 9.2A 427lbs
MSR-72G-3
2/3 115V/60Hz R-134a 9.6A 610bls
The serial number is located on the data label inside.
Please retain the unit’s serial number for service purpose.
SERIAL NUMBER
Freezers
MODEL COMP H.P. V/Hz REFRIGERANT AMPS WEIGHT
MSF-23NM 1/2 115V/60Hz R-404A 8.7A 285lbs
MSF-49NM 3/4 115V/60Hz R-404A 10.5A 462lbs

3
Turbo air
1. GOOD AIR CIRCULATION
- Be sure to avoid any partition and object which may stop the air flow.
- Be sure that air space is allowed to flow the rear of the unit.
Turbo air recommends that the rear of the unit would be no less than 5 inches from the
wall.
2. PLACE ON STRONG GROUND
- Be sure that the location be chosen has a strong enough floor to support the total
weight of the cabinet and any other contents.
3. DO NOT PLACE NEAR HEAT
- Be sure to avoid hot corners and locations near stoves.
- High ambient temperature will make much lower cooling efficiency.
4. INDOOR USAGE ONLY
- Be sure to install this unit indoor.
- So, It should prohibit getting wet from the rain.
5. STABILIZING
- Make sure the unit is installed in a stable condition with the front wheels locked
while in use.
6. LEVELING
- Be sure that the unit levels from the front to the back and side to side.
7. Unit should be on dedicated outlet.
8. Place black plastic condensate pan through back or front.
Make sure pads are installed upwards, a drain hose is in pan.
INSTALLATION

4
Turbo air
CLEANING
1. CLEANING STAINLESS STEEL INTERIOR AND EXTERIOR (select models)
: Damage to stainless steel finish due to improper use of cleaning products or non-
recommended products is NOT covered under this product's warranty.
• DO NOT USE
- Abrasive or harsh cleaners
- Ammonia
- Chlorine bleach
- Concentrated detergents or solvents
- Metal or plastic-textured scouring pads
- Vinegar-based products
- Citrus-based cleaners
• Do
- Use warm, soapy water and a soft, clean cloth or sponge.
- Rinse surfaces with clean, warm water and dry immediately to avoid water spots.
2. CLEANING THE CONDENSER FINS
- To maintain proper refrigeration performance, the Condenser coil must be free of
dust, dirt, and grease.
This will require periodic cleaning. Condenser fins should be cleaned at least every
three months (90 days) or as needed.
3. CLEAN THE GASKET
- The door gasket should be cleaned frequently to maintain proper sealing.
4. CHECK AFTER CLEANING
- Check the unit again for safety.
- Check that the unit is operating properly.
1. POWER CORD
- Be sure that the power cord is connected to the proper voltage.
- A protected circuit of the correct voltage and amperage must be run for connection of
the line cord.
- Turn ‘off’ the power switch before disconnecting the power cord, whenever
performing maintenance functions or cleaning the refrigerated cabinet.
- Compressor warranties are void if compressor burns out due to low voltage.
2. RE-STARTING
- If disconnected, wait for 5 minutes before re-starting.
CAUTION

5
Turbo air
BASIC OPERATION
MSR-23NM MSR-23G-1
MSR-49NM MSR-49G-2
MSR-72G-3
1. Plug in and turn on the power switch located on the bottom of the top grille right side.
The Display panel will be lighted and make a beep sound. The compressor will begin
to run.
2. The default temperature setting is No. “5”.
3. The compressor is automatically cycled by the electronic controller (PCB, D-Sensor).
4. The Defrost cycle is automatically controlled by the R-sensor, and the PCB.
5. Set level toward “1” for higher temperature and toward “9” for lower temperature.
6. The interior light is activated by the rocker switch at the bottom of the grille when the
door is opened. (MSR-23NM,MSR-49NM)
7. Evaporator fan motor(s) will run after all doors are completely closed.
REFRIGERATORS

6
Turbo air
DISPLAY PANEL OF REFRIGERATOR
9
TEMPERATURE Q.C.
8
7654321
FAN DOOR
QUICK COOLING
TEMPERATURE
˚F
TEMP. SETTING
QUICK COOLING
FAN RUNNING
DOOR OPENING
QUICK COOLING
BUTTON
TEMP. CONTROL BUTTON
(SEE TO PAGE 7)
INNER TEMP.
(SEE TO PAGE 8)
(SEE TO PAGE 7)

7
Turbo air
1. If you push the Q.C. (QUICK Cooling) button, the compressor will run continuously
until D-Senser detect 14˚F (-10˚C) to bring down the temperature more quickly.
(max.comp.run time = 120 min.)
2. If you push the Q.C. button again during QUICK Cooling mode, the compressor will
return to the normal operation.
3. During the QUICK Cooling mode works, the temperature Up/Down button will not
affect the compressor’s operation.
1. By pushing the up/down button, you can set the inside temperature level from ‘1’ to
‘9’.
2. If you want lower temperature, push the Down button to be lighted higher level
numbers.
QUICK COOLING
UP/DOWN BUTTON (Temperature control button)

8
Turbo air
1. It displays the inside temperature.
2. Display range is 14˚F to 69˚F (-10˚C ~ +20˚C).
3. When the inside temperature is lower than 14˚F, the panel will display ‘ ’.
and, higher than 69˚F, the panel will display ‘ ’.
1. If the fan motor is running, fan running indicator will be turned on.
2.
Evaporator fan motor is activated when the door is closed.
1. If any door is opened, door opening indicator will be turned on.
2. In case that any door was opened around 30 seconds, warning beep sound will ring
three (3) times.
3. In case of passing around 1 minute, warning beep sound will ring again five (5) times.
4. In case of passing around 5 minutes, the beep sound will ring continuously.
5. The beep sound will stop immediately if door is closed properly.
INNER TEMPERATURE DISPLAY
FAN RUNNING INDICATOR
DOOR OPENING INDICATOR

9
Turbo air
BASIC OPERATION
1. Plug in and turn on the power switch located on the bottom of the top grille right side.
The Display panel will be lighted and make a beep sound. The compressor will begin
to run.
2. The default temperature setting is No. “5”.
3. The compressor is automatically cycled by the electronic controller (PCB, F-Sensor).
4. The Defrost cycle is automatically controlled by the D-sensor, and the PCB.
5. Set level toward “1” for higher temperatures and toward “9” for lower temperatures.
6. The interior light is activated by the rocker switch at the bottom of the grille when the
door is opened.
7. Evaporator fan motor(s) will run after all doors are completely closed.
8. Good Air Flow in freezer unit is critical.
Be careful to load product so that it neither presses against the back wall, nor reaches
within four inches from the evaporator compartment.
MSF-23NM
MSF-49NM
FREEZERS

10
Turbo air
DISPLAY PANEL OF FREEZER
9
TEMPERATURE D.F.
8
7654321
FAN DOOR
MANUAL DEFROST
TEMPERATURE
˚F
TEMP. SETTING
MANUAL DEFROST
FAN RUNNING
DOOR OPENING
MANUAL DEFROST
BUTTON
TEMP. CONTROL BUTTON
(SEE TO PAGE 11)
INNER TEMP.
(SEE TO PAGE 12)
(SEE TO PAGE 11)
