TurboAnt V8 User manual

Email: [email protected]
Website: www.turboant.com
Made in China

Folding Electric Scooter
User Manual
V8

01
WARNING! RISK OF BATTERY EXPLOSION!
Do not use the battery if it is damaged or has been modified.
Do not expose to heat exceeding 95 °F (35 °C).
Only use the original charging adapter.
Wear protective gear such as a helmet.
Do not ride the scooter in wet conditions.
Thank you for purchasing this product. To avoid injury to the user and others, be sure to observe
the following safety instructions and guidelines. Keep this information for future reference.
Introduction
Featuring 9.3" tubed pneumatic tires, this scooter gives you a smooth riding experience. Its
powerful 450 W motor and 36 V batteries enable a speed of up to 20 mph with a range of up to
50 miles. The reinforced frame reliably supports a body weight of up to 275 lb.
Important Safety Instructions and Guidelines
Safety Checks
• Ensure the wiring and cables around the handlebar are not twisted, and that the throttle is on
the right side while riding the electric scooter.
• Make sure that no parts are damaged or have been modified.
• Make sure that the stem has been secured properly.
• Make sure that Hall cable (black) and brake cable (red) under the brake lever are connected
correctly and the brakes operate properly.
• Make sure that the tires are fully inflated.
• Make sure the battery is fully charged (the indicator light turns green).
• Test whether the scooter can be turned on/off.
• Make sure that the front and rear lights function properly in the dark.
• Children under 14 years old should be supervised by an adult.
Safety Guidelines

Package Contents
1 × Folding Electric Scooter
2 × Charging Adapters
3 × M5*8 Screws (including 1 spare screw)
5 × M4*10 Screws (including 1 spare screw)
1 × M3 Allen Wrench
1 × Valve Adapter
1 × User Manual
1 × Warranty Card
1 × Charging Dock
02
The maximum load is 275 lb (125 kg).
Do not ride under the influence of drugs or alcohol.
Do not use a cell phone or listen to music when riding
the e-scooter.
Check your local traffic regulations whether riding an
e-scooter in traffic is legal or not in your area.
Turn on the lights in the dark.
The scooter is only suitable for riding by a single person.

Technical Specifications
03
Product
Information
Unfolded Size
Folded Size
45.7 X 19.9 X 45.5 in
(1160 x 505 x 1155 mm)
45.7 X 19.9 X 18.1 in
(1160 x 505 x 460 mm)
LED headlight + taillight (1 W)
4 ambient lights under the deck
Ground Clearance
Product Weight
Adapter Input Voltage
Motor
Tire (Front & Rear)
Max Speed
Range
Max Climbing Capability
Load
Foldable Stem
Battery Pack
Brake System
Speed
Illumination
Warning Function
IP Rating
Operating Temperature
Storage Temperature
Input
Output
32 to 113 °F (0 to 45 °C)
-4 to 104 °F (-20 to 40 °C)
100-240 V AC, 50/60 Hz
42 V DC, 2 A
Yes
Detachable
Electronic brake and rear disc brake
3 settings (linear adjustment)
Bell
IP54
4.1 in (105 mm)
47.62 Ib (21.6 kg)
100-240 V AC, 50/60 Hz
36 V, 450 W
9.3-inch, tubed pneumatic tires
20 mph (32 km/h)
25-50 miles (40-80 km)
15°
44-275 lb (20-125 kg)
Drive System
Functions
Operating
Conditions
Charger

Notes
1. Max speed values stated in the user manual depend on the road conditions and the load. Values
stated on the rating label are related to average conditions.
2. Mileage is tested under the following conditions: the scooter is driven with the second speed
level, 41.8 V full power battery, a load of 165 lb (75 kg), temperature of 77 °F (25 °C), humidity of
70%, gentle breeze, tire pressure of 34.8 psi (240 kPa), and flat, dry road conditions. Actual results
may vary. If the load exceeds 275 lb (125 kg), the mileage and speed may be decreased, which can
affect the riding experience.
3. Please ride safely within the maximum speed limit set by local traffic officials. Everyone should
strictly abide by all traffic rules and regulations.
Battery Specifications
04
Type
Charging Time
Voltage
Capacity
Operating Temperature
Charging Temperature
Max Charging Voltage/Current
Storage Temperature
Storage Time
Li-ion
Approx. 4-8 hours
36 V
7.5 Ah x 2, 270 Wh x 2
32 to 113 °F (0 to 45 °C)
32 to 113 °F (0 to 45 °C)
42 V, 2.5 A
-4 to 104 °F (-20 to 40 °C)
3 months (after a full charge)

Product Overview
Controls Overview
05
Handlebar
Brake Lever
LED Headlight
Stem
Stem Lock
Motor
Kickstand
Disc Brake
Throttle
LED Display
Battery Release Button
Battery Pack
Charging Port
Stem Latch
Anti-skid Deck
Mudguard
Taillight
Brake Lever
Bell
LED Display
Brake Cable (Red)
Power Button
Throttle
Hall Cable (Black)

Note: If there is no operation within 10 minutes, the scooter will automatically turn off with a "beep" sound.
Controls Description
Control
Throttle
Power On/Off
Speed Level
Headlight
Cruise Mode
Operation
Level 1: shows the number “1”
Level 2: shows the number “2”
Level 3: shows the number “3”
Press down the throttle to accelerate.
Brake Lever
Squeeze the brake lever to stop the scooter. When the brake
lever is fully depressed, the scooter will come to a complete stop.
After that, it will have to be manually started (see the General
Troubleshooting and Solution Guide section).
Press and hold on the power button for 1 second or longer to turn
on/off the scooter.
Short press the power button while the scooter is on to turn
on/off the headlight and taillight.
Maintain a constant speed that you desire (must be at least 3.7 mph
or 6 km/h to activate cruise mode). Then, hold the throttle in the
same position for six seconds to enable cruise control. Exit cruise
mode by using either the throttle or brake lever.
Double press the
power button to
adjust the speed
level.
06
LED Display
Light Icon
Battery Status
Speed Level
Current Speed
Cruise Control Icon
Speed Unit Mph Km/h

1. Pull up the lock in the middle to release the latch.
2. Press down the latch to completely unfold the stem.
3. Push the latch inwards until a “click” sound is heard.
4. Align the scooter’s head with the stem.
5. Tighten the screws to secure the scooter’s head with the
provided tool.
07
Operating Instructions
Assembly

1. Fold the kickstand.
2. Pull up the lock in the middle to release the latch.
3. Press down the latch to completely fold up the stem.
4. Pull up the latch to secure it with the lock until a “click”
sound is heard.
08
Stem Folding

1. Pull up the battery release button on the stem.
2. Hold and pull the upper part of the battery pack
outwards while holding up the battery release button.
3. Pull out the entire battery pack.
09
Stem Battery Removal

1. Align the bottom of the battery with the stem.
2. Pull up the battery release button while pushing the upper
part of the battery pack into the stem.
10
Stem Battery Installation
3. Push down the battery release button to secure the battery
pack into the stem.

11
Battery Maintenance
1. Only use the original battery pack. Misuse of other models or brands can cause safety issues.
2. Only use the original power adapter to avoid potential damage, electric shock, or fire.
3. Mishandling of used batteries can cause tremendous harm to the environment. To protect the
natural environment, please follow local regulations to properly dispose of used batteries.
4. Do not place the battery in an environment where the ambient temperature is higher than 104
°F (40 °C) or lower than -4 °F (-20 °C) (e.g., do not leave the scooter or the battery pack in a car
under direct sunlight for an extended time).
5. Do not leave the battery pack near a heat source, such as a stove, and do not throw the
battery pack into fire. Doing so may result in overheating, explosion, or fire.
6. After every use, fully charge the battery to prolong its lifespan.
7. If the scooter is expected to be left unused for more than 30 days, please fully charge the
battery and place it in a dry and cool place. Keep in mind to recharge the battery every 30 days
to protect it from potential damage, which is beyond the coverage of our limited warranty.
Always charge before exhausting the battery to prolong the battery's lifespan.
8. The battery pack performs better within the normal temperature range of 32 to 113 °F (0 to
45 °C), and performs worse when below 32 °F (0 °C). For instance, when the temperature is
below -4 °F (-20 °C), the actual mileage will only be half or less than listed. When the tempera-
ture rises, the mileage will restore. Note: A fully charged TurboAnt Electric Scooter will last for
120-180 days.
9. The built-in intelligent chip will keep a log of its charging and discharging records. The
damage caused by prolonged periods without charging is irreversible and is beyond the
coverage of our limited warranty. Once the damage is done, the battery cannot be recharged.
Riding the Scooter
1. Wear protective gear such as a helmet.
2. Press and hold on the power button for 1 second or longer to turn on the scooter.
3. Place one foot on the middle of the deck and use the other foot to build up some momentum.
4. Gently press down the throttle to accelerate.
5. Squeeze the brake lever to brake.

Battery Charging
Charging the Installed Battery
Charging the Removed Stem Battery
1. Remove the stem battery (-> Stem Battery Removal).
2. Align the battery pack with the charging dock.
3. Connect the charging adapter with the charging dock, and then connect the charging adapter
to a power outlet.
4. The battery is fully charged when the indicator light of the charging adapter turns from red to
green.
5. Install the battery back to the scooter or securely store the battery in a cool, dry, and ventilated
place.
The scooter can be charged in two ways:
1. Charging only by the charging cable: It takes about 8 hours to fully charge the scooter.
2. Charging by the charging cable and the charging dock: It takes about 4 hours to fully charge
the scooter.
Only use the original charging adapter and charging dock to charge the scooter.
12
1. Remove the charging port cover on the left
side of the stem. Make sure the charging port
is dry and free of dust.
2. Connect the charging adapter.
3. The battery is fully charged when the
indicator light of the charging adapter turns
from red to green.
4. Close the charging port cover after charging
the battery.
*The scooter cannot be turned on if it is
connected to the charging cable, even if the
cable is unpowered. When turning on the
scooter, please completely remove the cable.

Maintenance
1. Make sure the scooter is turned off and the power adapter is disconnected.
2. Wipe clean the scooter with a damp cloth. Never use lubricating oil on the body and
do not immerse it in water.
Storage
1. Fully charge the scooter before storing, and charge it at least once a month to prevent
premature decay of the battery capacity.
2. Do not charge the battery if the temperature is below 32 ℉ (0 ℃).
3. Keep the scooter in a dry, ventilated, and cool area away from direct sunlight, rain, and high
humidity, and cover the scooter to protect it from dust.
4. The kickstand is designed to provide structural support, so avoid standing on the scooter
while the kickstand is down, as this can cause the kickstand to crack or break.
General Troubleshooting and Solution Guide
Problem Cause Solution
The scooter
will not
turn on.
The battery has run out. Recharge the battery.
The battery
will not
charge.
The charging adapter is
not connected to an AC
power source, or the
charging adapter is
damaged.
1. Connect the adapter to an AC power
source. If the indicator light turns on, the adapter is
in good working condition. Then, connect the
adapter to the charging port on the stem or the
battery (the battery can be detached for flexible
charging).
2. If the indicator light does not turn on, the
adapter has broken down. Replace the adapter.
The charging adapter is
not properly connected
to the charging port on
the stem or the battery.
Check whether the connector of the charging
cable is fully inserted into the charging port on the
stem or battery,
If it is not fully connected, please unplug the cable
and re-connect the cable to the charging port.
13

Cruise
control
cannot be
activated.
The stem
is loose.
The scooter
cannot
accelerate.
The tire has
an air leak.
Normal tire pressure is between 31.9-34.8 psi (220-240 kPa). It is necessary to periodically
check the scooter to make sure all parts are in good condition, including the throttle,
remaining power, tire pressure, and more.
The current speed is
below the minimum
speed required for cruise
control.
A constant speed is not
maintained.
The screws on the stem
folding spanner are
loose.
Tighten the screws on the stem folding spanner.
The scooter is set at
“non-zero” start and has
not been manually
started.
The tubed pneumatic tires
may have an air leak if
they have been stored for
a long period. This is
normal, as most air tires
require pumping
periodically.
The throttle is not
released.
Use your foot to give the scooter an initial
momentum. When the scooter’s speed reaches
1.9 mph (3 km/h), the scooter can be accelerated.
The throttle is equipped with an electric lock, so it
needs to be completely pressed down in order to
accelerate the scooter.
Pump up the tires by taking the scooter to an
automobile or motorbike repair center, or any
location with a proper air compressor. Standard
bicycle pumps can also be used to pump up the
scooter tires.
Cruise control can only be activated when
travelling at speeds greater than 3.7 mph
(6 km/h). Increase speed to enable cruise
control.
Keep a constant speed. Then, hold the throttle in
the same position for 6 seconds to enable cruise
control.
The battery power is full
or the battery has failed.
After confirming that the charging adapter is
functioning, connect the charging adapter to the
AC power source and the charging port on the
stem.
1. If the indicator light turns red, then charging is
normal and the battery is in good working
condition.
2. If the indicator light turns green, then the
battery is full or has reached its end of life. In case
of failure, replace the battery.
14

15
Frequently Asked Questions (FAQs)
1. What is the optimum tire pressure when riding this scooter?
The recommended tire pressure is between 31.9-34.8 psi (220-240 kPa). Please pump up the
tires to this pressure.
2. The headlight cannot be turned on. How can I solve this problem?
If the headlight won’t turn on, please verify that the scooter is turned on. When the scooter is
turned on, short press the power button to see whether the headlight functions. Also, check to
ensure that the lamp holder is not clogged with dust. If the lamp holder is not clogged with
dust, and the headlight still will not turn on, it may need to be replaced. Please contact our
customer support center for help.
3. What should I do if the scooter’s stem is swaying while riding the scooter?
Immediately stop riding the scooter. Verify that the screws that connect to the folding spanner
and other screws on the stem are well tightened. If not, tighten the screws using the hexagonal
wrench. Periodically tightening the screws on the scooter may be necessary.
4. What should I do if the brakes are not functioning properly?
a. Turn on the scooter. Don’t stand on the deck. Tilt the scooter to lift the front wheel and
manually rotate the wheel. Then, press down the throttle to accelerate, and the front wheel
should start to rotate. Next, hold the brake lever. If the front wheel stops rotating, the EBS
(Electronic Braking System) is functioning properly. If the front wheel does not stop rotating, the
Electronic Braking System may be faulty. Please contact our customer support center for help.
b. Turn off the scooter, tilt the scooter, and manually rotate the rear wheel. Then, hold the brake
lever. If the rear wheel stops rotating and there is no grinding noise, the disc brake is functioning
properly. If there is a grinding noise on the brake, the disc brake may be faulty. Please contact
our customer support center for help.
5. Can I replace the tires on my own if I have a flat tire?
If you have a flat tire, please contact our customer support center for help and repair. It is not
easy to replace on your own, and faulty installation may damage other parts of the scooter,
which can nullify our limited warranty. Seek help via our customer support center or take the
scooter to an automobile or motorbike repair center and ask the professionals for assistance.
6. Why does the battery life decrease over time?
The lithium-ion battery capacity will naturally degrade after 500 charge/discharge cycles. The
battery performs better when within the normal temperature range of 32 to 95 ℉ (0 to 35 ℃)
and performs worse when below 32 ℉ (0 ℃). For instance, when the temperature is below -4 ℉
(-20 ℃), the actual mileage will only be half or less than listed.
7. Why has my motor suddenly stopped working?
The reason may be that the controller has malfunctioned, and needs to be replaced. Please
contact our customer support center for help and repair.
8. When I press down the throttle, why doesn’t the motor function properly?
It could be that there is a Hall wire malfunction with the Electronic Braking System. Please check
to see if the wire terminals of the brake lever and the panel are loose, and whether the brake
lever has been damaged.

16
9. Why can’t my mileage reach 50 miles?
The max listed mileage is 50 miles, which is measured under the following conditions: the
scooter is ridden with the second speed level, 41.8 V full power battery, a load of 165 lb (75 kg),
temperature of 77 °F (25 °C), humidity of 70%, gentle wind, tire pressure of 34.8 psi (240 kPa),
and flat, dry road conditions. Actual mileage may depend on a variety of factors including
battery status, tire pressure, load, temperature, wind speed, road conditions, riding habits, and
more. Please note that the tire is a type of tubed pneumatic tire, so fully inflating the tires can
help extend your mileage.
Environmental Protection
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your local authority or retailer for recycling advice.
