TurboTronic TurboGrill TT-CG900 User manual

INSTRUCTION MANUAL
DIGITAL CONTACT GRILL
TT-CG900

Thank you for buying TurboGrill - Contact grill by TurboTronic®.
Panini press/sandwich maker, full grill, full griddle, or half grill/half griddle for
different cooking needs in one machine. The double damping hinge structure
allows 180° rotation of the lid, better for different thicknesses of food.
IMPORTANT SAFEGUARDS
HOUSEHOLD USE ONLY. READ ALL INSTRUCTIONS.
When using electrical appliance, basic safety precautions should always
be followed, including the following:
Read this user manual carefully, before you use the appliance, and keep it
safely for future reference.
WARNINGS
1. Take the machine out of the package and remove all the packaging
material. Check the machine for completeness.
2. Remove the grill plate by pressing the unlocking button and take them
out.
3. Before using it for the first time, clean the grill plate with warm water and a
mild cleaning agent. Then thoroughly dry the components.
4. Insert the grill plate, make sure that grill plate inserts into the place
correctly. Select the desired cooking surface when insert plate.
5. Ensure that drip tray is inserted correctly at the back of machine.
6. Connect the plug to a properly installed socket, ensure that the voltage
matches your domestic power supply.
7. The supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
8. To protect against electric shock, do not immerse the cord, plug or
machine into water or any liquids.
9. Do not touch the hot surface of the appliance during or after working.
10. Use a matching handle or handle to take out the food.
11. When the appliance is not in use, the plug should be pulled out of the
socket to avoid electric shock and leakage fire due to aging insulation.

12. The machine should be placed in a dry environment and the machine
should not be used outdoors.
13. Please keep the machine in a stable place when using. Do not approach
flammable articles.
14. When the machine is working, please carefully move the food or other
accessories to avoid scalding with hot oil or high temperature liquid.
15. The machine can be used by persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved.
16. The machine shall not be used by children. Keep the machine and its cord
out of reach of children. Children being supervised not to play with the
machine.
17. Cleaning and user maintenance shall not be made by children.
18. The machine is intended to be used for indoor and household use only.
Indicates to read and review instructions to understand operation and use of product.
Indicates the presence of a hazard that can cause personal injury, death or substantial
property damage if the warning included with this symbol is ignored.
Take care to avoid contact with hot surface. Always use hand protection to avoid burns.
For indoor and household use only.

PRODUCT DETAIL
220V -240V~ 50-60Hz, 2000W（1000W+1000W）
Lid
Handle
Control panel
Hot plate unlocking button
Grill plate

CONTROL PANEL
1.Beef
2. Fish
3.Chicken
4. Defrost
5.Increase the temperature
6. Reduce the temperature
7.Temperature display
8. Time display
9. Increase the time
10. Reduce the time
11. Both grill plate heating together
12. Only lower plate heating
13. Start/Pause
14. Cancel cooking and back to
standby mode
1
2
3
4
6
10
5
7
8
9
11
12
13
14

OPERATION:
1. Plug in, the machine beeps, all indication lights turn on then off. “OFF”
shows on display.
2. Select the desired cooking function (Beef \ Fish \ Chicken\ Defrost\ Both
plate\ lower plate), the indication light of corresponding function flashes
with sound when pressing. The light keeps flashing before pressing the
“Start” button.
Default time and temperature will show on display when using by first
time. Last setting will be memorized and indicated on display when
using by next time.
3. Press “˄” or “˅” to adjust temperature and time with BI sound. Long press
for quick adjustment.
4. When time/temperature setting is completed, press the "Start/Pause"
button to start, the corresponding function indicator will light up, setting
temperature and “PRE” will show on screen. When preheat finish, BI
sound five times, “Add” flash on display to remind user to put the food
inside machine.
If without pressing the "Start/Pause" button after setting time/temperature,
The current setting is always displayed.
5. Put the food inside machine then press "Start/Pause" button, cooking
starts and time counts down.
If without pressing "Start/Pause" button within 30 minutes, machine will go
into standby mode, “OFF” indicates on display.
6. When countdown is over, the unit beeps five times and “done” show on
display, function indicator lights off. All functional key will not work except
“Cancel” button. Press button “Cancel”, “OFF” shows on display.
Machine will be automatically enter standby mode after 30 minutes
without further operation, OFF indicates on display.

REMARK：
1. During cooking, press "Cancel" button at any time to exit the current
operation and return to the standby mode.
2. During cooking, reset the time or temperature by pressing “˄” or “˅” button
at any time, when setting finish, time/temperature will flash 3 times then
enter working mode automatically without further operation. Long press
for quick adjustment without BI sound.
3. During cooking, press the "Start/Pause" button to switch start or pause;
Preheat cannot be paused but only cancel.
4. Time indication: first two digitals for minute, last two digitals for second.
Temperature indication: first three digitals for degree, last digital for℃.
5. Press “˄” or “˅” button to adjust time and temperature circularly.
6. Press "Cancel" button for 3 seconds to delete all operation memories, BI
sounds one second.

TIME AND TEMPERATURE RANGE
Function
Default
display
Temperature range
Time range
Beef
230℃ 05:00
200-230℃
(5℃/step)
3 MIN -8MIN
(30s/ step)
Fish
210℃ 05:00
200-230℃
(5℃/step)
3 MIN -8MIN
(30s/ step)
Chicken
180℃ 05:00
160-200℃
(5℃/ step)
3MIN-12MIN
(30s/ step)
Defrost
80℃ 15:00
80-120℃
(5℃/ step)
1MIN-60MIN
(30s/ step)
Both grill plate
heating together
230℃ 05:00
80-230℃
(5℃/ step)
30S-60MIN
(30s/ step)
Only lower plate
heating
200℃ 10:00
80-230℃
(5℃/ step)
30S-60MIN
(30s/ step)

HELPFUL TIPS:
1. For satisfactory result, add a little cooking oil or cooking spray to the
plates.
2. Close the grill plates during preheating.
3. Open the lid by lifting the handle only. Remove the food with a heat-
resistant plastic spatula. Never use tongs or a knife as these can cause
damage to the non-stick coating of cooking plates.
CLEANING AND CARE
1. Be sure to unplug the machine and allows it to cool down completely
before cleaning.
2. It is important that cleaning the entire machine after each use to prevent
accumulation of grease and avoid unpleasant odors.
3. Do not immerse the machine in water or wash it under water-spout.
4. Clean external surface of the machine with a damp cloth.
5. Removable grill plate can be washed, as normal kitchenware. Press the
unlock buttons to removes the plates from the grill. After removing the grill
plates, clean them in warm soapy water or in the Dishwasher.
6. Remove the drip tray at the back of the machine with gloves on, pour the
drip tray into a heat-resistant pan, rinse with warm soapy water and dry
thoroughly.
7. Allow all components and surfaces to dry thoroughly before operating the
machine.
8. Note: Before removing the drip tray, make sure that the temperature of oil
or oil residues is less than 40℃, otherwise the excessive temperature may
cause burns.

ERROR CODE:
1. E1: open circuit of lower NTC
2. E2: short circuit of lower NTC
3. E3: open circuit of upper NTC
4. E4: short circuit of upper NTC
DISPOSAL OF OLD ELECTRICAL APPLIANCES
The European directive 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE), requires that old household
electrical appliances must not be disposed of in the normal
unsorted municipal waste stream. Old appliances must be
collected separately in order to optimize the recovery and recycling of the
materials they contain, and reduce the impact on human health and the
environment.
The crossed out “wheeled bin” symbol on the product reminds you of your
obligation, that when you dispose of the appliance, it must be separately
collected.
Consumers should contact their local authority or retailer for information
concerning the correct disposal of their old appliance.
LIMITED WARRANTY
ONLY THE SUPPLIER / WEBSHOP FROM WHICH YOU PURCHASED THE
ITEM CAN PROVIDE YOU WITH WARRANTY AND CUSTOMER SERVICE.
Limited Warranty applies to purchases made from authorized retailers of
TurboTronic®.
TurboTronic® Warranty coverage applies to the original owner and to the
original product only and is not transferable.
TurboTronic® warrants that the unit shall be free from defects in material and
workmanship. Limited Warranty apply only when it is used under normal
household conditions and maintained according to the requirements outlined in
the Owner’s Guide, subject to the following
conditions and exclusions:

ANY WARRANTY OR AFTER PURCHASE SERVICE, SHOULD BE WITH A THIRD-
PARTY COMPANY, FROM WHICH YOU PURCHASED THE PRODUCT.
TURBOTRONIC® PROVIDES THE WARRANTY ONLY TO OUR THIRD-PARTY
SUPPLIERS. SINCE THIS PRODUCT IS NOT PURCHASED DIRECTLY FROM
TURBOTRONIC® BUT THROUGH ONE OF OUR THIRD-PARTY SUPPLIERS, ANY
ISSUE AFTER THE PURCHASE, CUSTOMER SERVICE OR RECEIVING THE
WARRANTY SHOULD BE ONLY / DIRECTLY THROUGH THE THIRD-PARTY
SUPPLIERS FROM WHICH YOU PURCHASED THE PRODUCT.
What is covered by this warranty?
1. The original unit and/or non-wearable parts deemed defective, in
TurboTronic® sole discretion, will be repaired or replaced
2. TurboTronic® reserves the right to replace the unit with one of equal or
greater value.
What is not covered by this warranty?
1. Normal wear and tear of wearable parts (such as blending vessels, lids, cups,
blades, blender bases, removable pots, racks, pans, etc.), which require regular
maintenance and/or replacement to ensure the proper functioning of your unit,
are not covered by this warranty.
2. Any unit that has been tampered with or used for commercial purposes.
3. Damage caused by misuse, abuse, negligent handling, failure to perform
required maintenance (e.g., failure to keep the well of the motor base clear of
food spills and other debris), or damage due to mishandling in transit.
4. Consequential and incidental damages.
5. Defects caused by repair persons not authorized by TurboTronic®. These
defects include damages caused in the process of shipping, altering, or
repairing the TurboTronic® product (or any of its parts) when the repair is
performed by a repair person not authorized by TurboTronic®.
6. Products purchased, used, or operated outside Europe.
Illustrations may differ from actual product.
We are constantly striving to improve our products, therefore the specifications
contained herein are subject to change without notice.
TurboTronic® and Z-Line® are registered trademarks of Z-GLOBAL B.V.B.A®
PRINTED IN PRC
